Xtreme XR-302 User manual

Page
1
(Photos may vary)
PLEASE BE SAFE WHEN RIDIN
X-Treme TM Electric Scooters
Model: XR-302
Product Handbook

Page
2
PLEASE BE SAFE WHEN RIDING
!ALWAYS WEAR A HELMET AND OBEY ALL LAWS!
BATTERY MAINTENANCE and
CHARGING INSTRUCTIONS
1. You MUST charge completely prior to initial use. (Follow
charging instructions in your Product Handbook)
2. Charge immediately after each use.
3. Charge before storage. You must charge every 30 days if not
in use.
4. Charge the unit for 6-8 hours after the light on the charger turns
green.
5. DO NOT allow this unit to deep discharge the battery.
6. For safety purposes, DO NOT charge for over 12 hours.
7. Turn the unit OFF when not in use.
This PRODUCT IS NOT INTENDED FOR EXTREME or
OFF-ROAD Use! Please take care of your XR-302!
DO NOT JUMP or ABUSE THIS PRODUCT!
DO NOT RIDE IN WET/ICY CONDITIONS!
Failure to follow these instructions will
VOID YOUR WARRANTY!
IMPORTANT
Failure to follow these INSTRUCTIONS will
VOID YOUR WARRANTY!

Page
3
WARNING
This product does not conform to Federal Motor Vehicle Standards and is not
intended for operation on public streets, roads or highways. Serious injury can
result from the unsafe operations of this product. Operator can minimize these
risks by using certain safety equipment such as: safety helmet, goggles, gloves,
elbow and kneepads and appropriate footwear.
DO NOT operate this product in traffic, on wet, frozen, oily or unpaved surfaces.
Avoid uneven surfaces, potholes, surface cracks and obstacles.
DO NOT use a water hose to clean this product.
This product is recommended for riders 3-8 years of age and under 85lbs.
SAFETY GUIDE
An adult should preform charging of the scooter. TO AVOID ELECTRIC
SHOCK, NEVER ALLOW CHILDREN TO HANDLE THE CHARGER OR
ATTEMPT TO PLUG THE BATTERY CHARGER INTO AWALL OUTLET!
Keep children away from the scooter during the charging process.
Do not place the battery near fire or heat.
To avoid damage to the battery, do not use the charger if it has been damaged
in any way.
Keep hands, face, feet and hair away from all moving parts.
Do not touch the motor or wheels while they are rotating.
Adult supervision during operation is required at all times.
The scooter is designed for flat terrains only. For safety purposes, never
allow children to operate the scooter in hilly areas.
When not in use, ensure the scooter is turned off and stored in an enclosed dry
area away from moisture or rain.
This product is ELECTRIC! DO NOT ride this product in wet conditions,
puddles or rainy weather.
The user of this product assumes ALL risks associated with its use. To
minimize these RISKS, the user must wear safety helmet, goggles, gloves,
elbow and kneepads and appropriate footwear.
IMPORTANT
PLEASE READ THIS BEFORE USING THIS PRODUCT
READ THIS FIRST!

Page
4
SAFETY GUIDE
The recommended age for riding this scooter is 3-8 years old and under 85lbs.
To avoid damage to the motor and footplate, do not overload the scooter.
Never ride with more than one person.
Inspect your scooter thoroughly before each use for loose or missing parts.
Avoid unintentional starts by turning the scooter off while not in use.
To avoid the risk of a short circuit in the electrical parts, do not use your
X-Treme Electric scooter in the rain and never spray or wash off your scooter
with water.
Do not place the battery near fire or heat.
To avoid damage to the battery, do not use the charger if it has been damaged
in any way.
Keep hands, face, feet and hair away from all moving parts.
Do not touch the motor or wheels while they are rotating.
Brakes are designed to control speed as well as stop the scooter. Practice
braking for proper slowing down and smooth stops.
Maintain your X-Treme XR-302 as recommended in this Product Handbook.
Use only quality replacement parts as recommended by the manufacturer.
Inspect the entire scooter prior to each use. Replace any part that is cracked,
chipped or damaged before use.
*NEVER ALLOW CHILDREN TO OPERATE THE SCOOTER WITHOUT ADULT
SUPERVISION.
Contact your dealer or X-Treme (www.x-tremescooters.com/support/)
if you need further assistance
QUICK
REFERENCE
SAFETY GUIDE

Page
5
TABLE OF CONTENTS
IMPORTANT
INFORMATION…………………………………….………………………...……2-3
QUICK REFERENCE……………………………………………………………….4
TABLE OF CONTENTS……………………………….…………….………………5
GETTING TO KNOW YOUR X-TREME XR-302………………..………...……..6
PACKAGE CONTENTS…………………………………………………………….7
GETTING STARTED………………..……………………………..………………..7
ASSEMBLY………………………………………………………………….…..…7-9
CHARGING……………………………………………………………..………….10
OPERATING INSTRUCTIONS…………………………………………………….9
IMPORTANT SAFETY GUILDINES..…………………………….………………10
MAINTENANCE…………………………………………………………………….11
OTHER QUESTIONS….…………………………………………………………..11
GENERAL INFORMATION/TECH SUPPORT………………………………….12

Page
6
GETTING TO KNOW YOUR X-TREME XR-302
(Photo’s may vary)
Recommended Age 3-8yrs Speed 1.5mph – 3mph
Maximum Weight 85lbs Battery 6V 10AH x 2
Assembled Size Charge Time 6-8 hours
Acceleration Foot Push Button Charge AC110V
Fuse 18A Speed Dual speed switch

Page
7
PACKAGE CONTENTS
Your X-Treme XR-302 comes with the following items in the box. Please locate
all of the following:
1. Body, 1pc
2. Handlebar Assembly, 1pc
3. Front Fender, 1pc
4. Gearbox, 2pc
5. Side Wheel Fenders, 2pcs
6. Tool Kit, Washers & Screws
7. Left & Right Front Fork, 2pc
8. Front & Rear Wheels, 2pcs
9. Side Power Wheels, 2 pc
10.Front & Rear Axles, 2pc
11.Middle Axle, 1pc
12.Charger, 1pc
13.User Manual
GETTING STARTED
Please read and understand these instructions and the OPERATING
PROCEDURES section, prior to starting or riding your XR-302
KEEP CHILDREN AWAY DURING ASSEMBLY. SOME SMALL
PARTS POSE A CHOKING HAZARD. DISCARD ALL PLASTIC
COVERINGS AND BAGS.
Assembly
Carefully remove the XR-302 from the box.
Installation of Side Power Wheels
1. Attach the left and right side wheel fenders
using the enclosed screws.
2. Position the left gearbox into the left side
fender gaining access thru the inside of the
body.
3. Position the power wheel under the fender
being sure it fits properly inside the
gearbox. Remove the two nut caps and
spacers/washers from the enclosed Middle
Axle, and insert the axle thru the fender,
then the large black spacer, the power
wheel & gearbox until it protrudes on the
right side.
4. Repeat this for the right side power wheel
and secure the middle axle in place with the
two nut caps. Tighten securely.

Page
8
Finish the power wheel installation by attaching
thecorresponding wire clips on the inside of the
body as shown.
Installation of Rear Wheel
1. Locate the rear axle, remove the two
nut caps and set aside.
2. Insert the axle thru the rear wheel being
sure to insert the black spacers in the
correct orientation.
3. Insert the axle thru the rear wheel
brackets and tighten the two nut caps
securely.
Installation of Front Wheel/Fender/Forks
1. Slide the front fender onto the
handlebars assembly as shown
securing it with one of the enclosed
screws.
2. Next attach the left and right fork by
snapping them around the handlebar
posts. Secure with enclosed screws.
3. Locate the front axle, remove the two
nut caps an set aside.
4. Insert the axle thru the front forks and
front wheel being sure to insert the
black spacers in the correct orientation.

Page
9
Your XR-302 is now complete and ready for use.
Operation Instructions
*Be sure all assembly is complete before riding.
*Disconnect charger from scooter and store properly.
Your scooter is operated using a foot push button. To ride the scooter, simply
set on the scooter, turn the speed switch to the desired speed and using your
right foot, push the foot button located on the right footplate. To stop the
scooter, simply release the foot button.
1. Locate the slot/fast switch located on the scooter, move the switch to
the desired position.
2. To accelerate forward, use your right foot to press the foot button on
the right footplate.
3. To stop, simply release the foot button.
4. To park the scooter, keep the slow/fast switch in the middle (neutral)
position.
Finally, attach the Handlebar Assembly/Front
Wheel to the body.
1. Locate and remove the handlebar lock
screw at the top of the handlebars on
the body.
2. Position the handlebar assembly/front
wheel in the correct orientation and
insert the lock screw from the top and
secure the bottom nut.
Attach the wires coming from the body to the
wires coming from the handlebar assembly.

Page
10
Charging Instructions
***WARNING*** An adult should perform charging of the scooter. TO AVOID
ELECTRIC SHOCK, NEVER ALLOW CHILDREN TO HANDLE THE
CHARGER OR ATTEMPT TO PLUG THE BATTERY CHARGER INTO A
WALL OUTLET!
1. Locate the enclosed battery charger. Plug the charger into a wall
outlet.
2. Locate the charger socket on the scooter.
3. Plug the battery charger into the socket on the scooter. Depending on
the charge remaining in the battery, charging time will vary. Normal
charging time will be 6-8 hours.
Do not allow the charger to charge the batteries for more than 20 hours as
this may damage the batteries.
IMPORTANT SAFETY GUIDELINES
Keep hands, face, feet and hair away from all moving parts.
Do not touch the motor or wheels while they are rotating.
Adult supervision during operation is required at all times.
The scooter is designed for flat terrains only. For safety purposes,
never allow children to operate the scooter in hilly areas.
When not in use, ensure the scooter is turned off and stored in an
enclosed dry area away from moisture or rain.
This product is ELECTRIC! DO NOT ride this product in wet
conditions, puddles or rainy weather.
You MUST charge completely prior to initial use.
Charge immediately after each use, before prolonged storage and at
least every 30 days if not used for at least 6-8 hours. DO NOT allow
this unit to deep discharge the battery
DO NOT charge the scooter for more than 20 hours as this may
damage the batteries.
Keep children away from the scooter during the charging process.
Do not place batteries near fire or heat.
The user of this product assumes ALL risks associated with its use. To
minimize these RISKS, the user must wear safety helmet, goggles,
gloves, elbow and kneepads and appropriate footwear.

Page
11
MAINTENANCE SCHEDULE
Proper care of your X-Treme XR-302 will insure optimal performance and
longer life span. The following are a few maintenance suggestions that will
keep your X-Treme XR-302 running in top condition:
Daily Maintenance
Perform each time you ride your XR-302
Clean the exterior of the unit with a soft, damp rag.
Check that all nuts and bolts are securely tightened.
Check battery charger for any frayed/cut wires.
OTHER QUESTIONS
For additional questions, service instructions, further information and important
phone numbers, please go to the X-Treme website at www.x-tremescooters.com
Thank you for purchasing an X-Treme XR-302 and please tell your friends how
much fun you’re having on the X-Treme XR-302

Page
12
For General Information or Parts Visit
www.x-tremescooters.com
For Technical Support or Assistance Visit
www.x-tremescooters.com/support/
