Xenon OSSC03700 User manual

WARNING:To reduce
the risk of serious injury, read these
warnings before using the scooter.
1. Read and follow all instructions.
2. It is the owner’s responsibility to
ensure that all users of the scooter
are adequately informed of all
warnings and instructions.
3. Inspect the scooter and tighten or
replace any loose or missing parts
before each use. In addition, make
sure that the handles and the stem
are securely locked in position, the
wheels rotate freely, the brake is in
working order and free of all debris,
and the wheel bolts are secure.
4. The scooter should not be used by
children under the age of eight. A
responsible adult must always
supervise young riders.
5. Always wear protective equipment,
including a helmet, knee pads, wrist
guards, elbow pads, and closed-toed
shoes, when using the scooter.
6. Never ride on streets, roadways, or
driveways that enter vehicle traffic
routes. Never ride on wet or uneven
surfaces, at night, or when visibility
is poor.
7. Never tow a rider with a bicycle,
motorcycle, or vehicle.
8. Locate the warning decals on the
scooter, and read the warnings
before using the scooter.
9. Save this User’s Manual for future
reference.
10. This scooter should not be used by
persons weighing more than 200
pounds.
11. Braking from high speeds or pro-
longed braking on inclines can cause
excessive wear of the rear wheel and
brake. Exercise caution when select-
ing your area of use.
12. To prevent burns, avoid touching the
brake after prolonged use.
User’s Manual
Model No. OSSC03700

Setup
1. Depress the lock pin on the left side of the deck (see the
drawing below). Pivot the upright up until it locks into a
nearly vertical position. Turn the release knob clockwise
until it is tight.
2. Insert the handles into the stem until the lock pins are visi-
ble in the holes in the stem.
3. Open the quick-release lever. Depress the lock pin on the
stem, and slide the stem up until the lock pin is visible in
the top hole. Close the quick-release lever so that it is snug
against the upright. If the quick release is not snug, see
ADJUSTING THE QUICK RELEASE on the back of this
user’s manual.
Before using the scooter, make sure that the scooter is set up
as described and that all parts are securely tightened.
The decals shown at the right have been placed on the
scooter. If a decal is missing, or if a decal is not legible,
please call our Customer Service Department toll-free at
1-800-999-3756, Monday through Friday, 6 a.m. until 6 p.m.
Mountain Time, to order a free replacement decal. Apply
the replacement decal in the location shown.
Storage
1. Open the quick-release lever. Depress the lock pin on the
stem and slide the stem into the upright. Close the quick-
release lever.
2. Depress the lock pins and remove the handles from the
stem. Press the handles into the storage clip on the upright.
3. Turn the release knob counterclockwise until you can pull it
out, and pivot the upright down past the lock pin into the
horizontal position.
Release Knob
Release Knob
Storage Clip
Rear Brake
Stem
Groove
Front
Left Side
Right Side
Quick Release
Handle
Handles
Upright
Lock Pin
Lock Pins
Lock Pin
Upright

No. Qty. Description
1 1 Deck
2 1 Head Tube
3 1 Fork
4 1 Upright
5 1 Stem
6 2 Handle
7 2 Foam Pad
8 2 Handle Cap
9 3 Lock Pin
10 1 Handle Cord
11 1 Release Knob
12 1 Upright Clamp
13 1 Bearing Nut
14 1 Bearing Cap
15 2 Bearing
16 2 Bearing Race
17 4 Bushing
18 1 Pivot Union Bolt Set
19 1 Front Union Bolt Set
20 2 Rear Union Bolt Set
21 2 Wheel
22 1 Endcap
23 1 Brake Spring
24 1 Brake
25 1 Quick Release
26 1 Storage Clip
27 1 Deck Lock Pin
28 1 Upright Bushing
29 4 Wheel Bearing
* 1 User’s Manual
*The user’s manual is not shown
Specifications are subject to change without notice.
Part List/Exploded Drawing—Model No. OSSC03700 R0101A
1
21
17
17 24
23
21
3
15
16
1817
17
11
2
16
15
4
14
13
12 25
9
10
8
7
7
6
9
8
6
526
27
28
22
18
19
20 20
29
29
29
29
Ordering Replacement Parts
To order replacement parts, call toll-free 1-800-999-3756, Monday through Friday, 6 a.m. until 6 p.m. Mountain Time (excluding
holidays). When ordering parts, please mention the model number (OSSC03700) and the number and description of the parts needed.

Part No. 168665 R0101A Printed in China © 2001 ICON Health & Fitness, Inc.
Adjusting The Quick Release
Brake Maintenance
If the quick release doesn’t hold the stem snug in place, you
will need to adjust it.
Open the quick-release lever. Turn the adjustment nut clockwise
one half turn while keeping the lever from turning. Close the
lever. Repeat this procedure until the stem is held snug in place.
If the quick release is too snug to close, it will need to be
adjusted.
While the quick-release lever is open, turn the adjustment nut
counterclockwise one quarter turn while keeping the lever from
turning. Close the lever. Repeat this procedure until the stem is
held snug in place and the quick release is closed.
Road debris and abraded material from the rear wheel may
accumulate under the brake. Clean the underside of the brake
periodically to ensure maximum braking capability.
The rear brake is capable of reaching high temperatures.
Exercise caution when handling the scooter after extended
periods of braking or after braking on steep inclines.
Adjustment
Nut
Open
Close
Lever
Quick Release
Brake
