SPL SUPREME AIRFORCE Installation and operating instructions

Installation
& maintenance
instructions.

2
splwashrooms.co.nz

3
splwashrooms.co.nz
General Safety Information
WARNING - TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK
OR INJURY TO PERSONS, OBSERVE THE FOLLOWING:
• Failure to disconnect the power source before installation can result in
serious injury or death from electric shock. Always disconnect the power
source before servicing or installing the hand dryer.
• Fixed wiring is recommended for all installations. Wiring should emerge from
the wall in the position marked on the mounting diagram. All  xed wiring
should incorporate a switch or breaker with a contract separation of at least
3mm in all poles.
• SPL (2021) Ltd accepts no responsibility for any damage or injury to property
or persons caused by improper, incorrect or unreasonable use or installation.
• Failure to properly ground this unit could result in severe electrical shock
and/or death. This hand dryer must be properly grounded (Earthed) for safe
operation. An identi ed ground connection point is supplied on the chassis of
the hand dryer. We recommend GFCI protection in wet or damp locations or
as required by local code.
• Risk of  re, personal injury or property damage are possible if local codes, or
safety recommendations are not followed. Installation must be carried out by
a quali ed person in accordance with all local wiring regulations.
• If the supply cord is damaged, it must be replaced by the manufacturer, its
service agent or similarly quali ed persons in order to avoid a hazard.
• The instructions contained within the Mounting Template must be followed
carefully when installing this unit. Failure to accurately follow the instructions
may result in the incorrect operation of this unit, damage to property and/or
personal injury.
• This appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience
and knowledge, unless they have been given supervision or instruction
concerning use of the appliance by a person responsible for their safety.
• Do not insert objects into the air outlet, doing so can be hazardous and could
result in electric shock.
• Do not obstruct the air inlets or outlets in any way.
• Do service your hand dryer at regular intervals.

4
splwashrooms.co.nz
Operating Instructions and Parts Manual
Please read carefully before attempting to assemble, install, operate or maintain
the product described. Protect yourself and others by observing all safety
information. Failure to comply with instructions could result in personal injury
and/or property damage. Retain instructions for future reference.
Supreme AIRFORCE Hand Dryer
Description:
The Supreme AIRFORCE hand dryer, powered by universal brushed motor,
delivers 1100W of drying power and runs on 230V AC electrical supply.
An infrared sensor is used to automatically activate the dryer. This model is
intended for use in commercial, industrial, education sector, o󰀩ce and public
facility environments.
Specications
Cover
Motor
Power
Element
Rating
Switching
Sound Level
Max Airow
Dimensions
Weight
Warranty
Standards
Die cast aluminium or Brushed Stainless Steel with
SteriTouch nish
Universal Brushed 34,000 rpm
1100W
Nil - ambient temperature. Air warms as it passes over motor
220-240V AC, 50/60Hz, IP24
Infrared sensor
75 dBA @ 1.5m
178 m3 / hour @ 330km/h
271H x 266W x 165D mm
3.3kg
The Supreme Comprehensive Hand Dryer Warranty
36 Month Limited Warranty
Complies with New Zealand and Australian Standards
Recommended Mounting Heights
From Floor to Dryer Bottom Edge:
Men’s washroom 1100mm
Ladies’ washroom 1050mm
Children’s washroom 13-17yr 1000mm
Children’s washroom 10-13yrs 950mm
Children’s washroom 7-10yrs 900mm
Children’s washroom 4-7yrs 800mm
Disabled Person’s 950mm

5
splwashrooms.co.nz
Planning
We suggest that one hand dryer be installed for every two hand basins.
Ensure that no reective object (such as hand basin) is located directly under
infrared sensor eye; the minimum distance is 460mm.
Installation Instructions
1. Disconnect power source.
2. Use the security hex key supplied and turn the cover mounting screws
clockwise to remove the cover from the dryer.
3. Place the hand dryer base on the wall at the required location using
recommended mounting heights. With the base located, use it as a
template to mark locations of the four mounting bolt holes on the wall.
4. Fasten the base to the wall, using suitable xings for the type of wall.
5. All automatic dryers must have their own dedicated 10 amp circuit.
6. Connect the dryer to the nearest suitable distribution panel.
7. Replace cover, turn screws counter-clockwise making certain not to over
tighten.
In some installation environments,
sensing distance may need to be
adjusted lower due to environmental
conditions to eliminate unattended
activation or ghosting. Installation
close to a reective surface, exposure
to natural sunlight or other nearby IR
activated devices can be conditions
causing unattended activation. Lowering
the IR sensor’s sensing range /
sensitivity can resolve this. To adjust the
IR sensing range, remove the cover and
locate the blue trimmer pot on the control
board as shown.
CAUTION: These instructions involve
adjusting the IR sensor trimmer POT
with the power connected (live) to the
hand dryer. The trimmer POT is located
in a low voltage area of the electronic
controls, but there is hazardous live
voltage in other areas of the dryer when
the cover is removed. Be careful making
adjustments, if you are not experienced
making this kind of “live” adjustment, do
not attempt to make the adjustment.
Adjusting IR Sensor Distance
Please see page 6 for instructions.

6
splwashrooms.co.nz
Instructions for IR Sensor adjustment:
To establish the initial sensing distance setting, place palm at and horizontal
well below the hand dryer; starting at a point where the dryer will not activate.
Slowly move upward towards the dryer until the dryer activates and will sustain
operation. Note the approximate distance between your palm and the bottom of
the hand dryer. Adjusting the screw clockwise will increase the sensing distance
/ sensitivity; adjusting the screw counter-clockwise will reduce sensing distance /
sensitivity. The trimmer POT has a high resolution adjustment. 20 to 40 degrees
adjustment of the screw (from 3 o’clock position to 1 o’clock position) may be
all that is needed for adequate adjustment. To eliminate unattended activation
/ghosting, adjust the trimmer POT screw counter-clockwise 20 - 40 degrees
and recheck sensing distance and repeat, as necessary, to reduce the sensing
distance to a comfortable activation point that resolves the issue.
Maintenance Instructions
The following maintenance should be carried out six monthly in high tra󰀩c areas
and twelve monthly in normal tra󰀩c areas. Your warranty could become void if
the above is not performed at the specic intervals.
1. Isolate the dryer either by turning o󰀨 the switch, normally located above the
dryer or by unplugging the unit if tted with a power cord.
2. Use the security hex key supplied and turn the cover screw clockwise until
the bottom of the cover can be lifted out from the base plate and then push to
unlatch from the top of base plate.
3. The motor inlet lter should be replaced if it appears clogged. You can reorder
from our website www.splwashrooms.co.nz - search for consumables.
4. Brush any lint away with a soft brush.
5. To replace cover, replace cover squarely over base and push at to wall.
Screw cover mounting screws counter-clockwise and tighten until snug. Do
not overtighten.
6. Liven dryer and test operation.

7
splwashrooms.co.nz
Symptom Possible cause Corrective action
Dryer fails to
start.
No power to unit. Check power to unit and connections.
Sensor
obstruction.
1. Check sensor lens for foreign material
or dirt. Clean lens with soft damp cloth
and mild cleaning agent.
2. If lens is damaged or scratched,
replace it. Part number WD207K.
Faulty motor. If relay “click” is heard, but unit does not
start, replace the motor / fan assembly.
Part number WD707.
Defective PCB
or Sensor.
Listen for PCB relay “click”, if no “click” is
heard, an Electronic Upgrade kit is
required. Part number WD600K.
Dryer will not
shut o󰀨 or is
running for 20
seconds or until
it times out.
Sensor
obstruction.
1. Check sensor lens for foreign material
or dirt. Clean lens with soft damp cloth
and mild cleaning agent.
2. If lens damaged or scratched, replace
it. Part number WD207K.
Sensor receiving
false signal or
reection.
1.Ensure that no reective object (such
as hand basin) is located directly under
infrared sensor eye; the minimum
distance is 460mm.
2. Check if other infrared operated
appliances in the vicinity may be
triggering the dryer.
3. Replace the PCB and sensor.
Electronic Upgrade kit - Part number
WD600K.
Burning Smell
/ Crackling
Noise.
Defective Motor. Replace motor. Part number WD707.
Motor will start
and slow down,
then speed up.
Defective PCB. Replace PCB. Part number WD500K.
Troubleshooting

splwashrooms.co.nz
Supreme Comprehensive Warranty
Your Supreme Hand Dryer is fully guaranteed against defective materials and
faulty workmanship commencing from the date of sale (according to SPL’s
records), subject to it being installed and maintained in accordance with the
manufacturer’s instructions.
SPL (2021) Limited warrants that should any part of the dryer fail within the given
warranty period (2- 5 years product dependant), it will be remedied by SPL. The
dryer should be returned to SPL (2021) Limited for all warranty claims. The cost
of cartage will be payable by the customer.
This warranty excludes:
• Incorrect installation, or installation that does not specically follow the
installation guidelines supplied
• Failure to follow manufacturer’s maintenance instructions
• Damage/Failure resulting from:
- the use of non-authorised parts
- authorised parts not installed in accordance with the manufacturer’s
instructions
- accidental damage, negligent use, misuse, vandalism, neglect
- damage caused either directly or indirectly by external sources (power
outages, power surges, incorrect power supply, natural disaster, or insect
infestation)
• Water ingress caused by property maintenance or ooding
• Negligent cleaning practices (water ingress, harmful chemical etc)
The above includes consequential damage to any other goods,
furnishings, or property.
• Normal wear and tear and consumable parts (HEPA lters, UV C Lamps,
fuses, motor brushes etc)
• This warranty does not displace any statutory warranty in relation to the dryer
but any liability of SPL (2021) Limited under any statutory warranty will be
limited to a replacement or repair of the dryer or payment of the cost of such
replacement or repair at the sole discretion of SPL (2021) Limited
Note: Our Warranty only extends to products purchased and installed in
New Zealand.
