SPL SUPREME DIAMOND V Installation and operating instructions

1
splwashrooms.co.nz
Installation
& maintenance
instructions.

2
splwashrooms.co.nz

3
splwashrooms.co.nz
General Safety Information
WARNING - TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK
OR INJURY TO PERSONS, OBSERVE THE FOLLOWING:
• Failure to disconnect the power source before installation can result in
serious injury or death from electric shock. Always disconnect the power
source before servicing or installing the hand dryer.
• Fixed wiring is recommended for all installations. Wiring should emerge from
the wall in the position marked on the mounting diagram. All  xed wiring
should incorporate a switch or breaker with a contract separation of at least
3mm in all poles.
• SPL (2021) Ltd accepts no responsibility for any damage or injury to property
or persons caused by improper, incorrect or unreasonable use or installation.
• Failure to properly ground this unit could result in severe electrical shock
and/or death. This hand dryer must be properly grounded (Earthed) for safe
operation. An identi ed ground connection point is supplied on the chassis of
the hand dryer. We recommend GFCI protection in wet or damp locations or
as required by local code.
• Risk of  re, personal injury or property damage are possible if local codes, or
safety recommendations are not followed. Installation must be carried out by
a quali ed person in accordance with all local wiring regulations.
• If the supply cord is damaged, it must be replaced by the manufacturer, its
service agent or similarly quali ed persons in order to avoid a hazard.
• The instructions contained within the Mounting Template must be followed
carefully when installing this unit. Failure to accurately follow the instructions
may result in the incorrect operation of this unit, damage to property and/or
personal injury.
• This appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience
and knowledge, unless they have been given supervision or instruction
concerning use of the appliance by a person responsible for their safety.
• Do not insert objects into the air outlet, doing so can be hazardous and could
result in electric shock.
• Do not obstruct the air inlets or outlets in any way.
• Do service your hand dryer at regular intervals.

4
splwashrooms.co.nz
Operating Instruction and Parts Manual
Please read carefully before attempting to assemble, install, operate or maintain
the product described. Protect yourself and others by observing all safety
information. Failure to comply with instructions could result in personal injury
and/or property damage. Retain instructions for future reference.
Supreme DIAMOND-V Hand Dryer
Description:
The Supreme DIAMOND-V hand dryer is a surfaced-mounted dryer, powered
by a brushless DC motor, which delivers up to 760 watts of drying power.
Incorporated with a switchable 500W integrated heating element and infrared
sensor with blue light assist for automatic activation. These models are intended
for use in commercial, o󰀩ce and public facility environments.
Specications
Cover
Motor
Power
Element
Rating
Switching
Sound Levels
Max Airow
Dimensions
Weight
Warranty
Standards
Recommended Mounting Heights
From Floor to Dryer Bottom Edge:
Men’s washroom 1100mm
Ladies’ washroom 1050mm
Children’s washroom 13-17yr 1000mm
Children’s washroom 10-13yrs 950mm
Children’s washroom 7-10yrs 900mm
Children’s washroom 4-7yrs 800mm
Disabled Person’s 950mm
Aviation aluminium cover, anodised nish
Brushless DC Motor 24,500 rpm
260W motor, 760w total with heater
500w switchable on/o󰀨
220 -240V AC, 50/60Hz, IPX2
Infrared sensor with blue light assist
72dBA @ 1m
84 m3/hour @ 266km/h
275H x 130W x 128D mm
3.5kg
The Supreme Comprehensive Hand Dryer Warranty -
36 month limited warranty
Complies with New Zealand and Australian Standards

5
splwashrooms.co.nz
Planning
We suggest that one hand dryer be installed for every two hand basins.
NOTE: Dryer should not be installed within 600mm of a bench top or reective surface.
Installation Instructions
1. Disconnect the power source.
2. Place the main cover on a cloth to avoid marking its surface.
3. Use the security hex key supplied to remove two security screws from the
dryer, then lift cover o󰀨 the main body. (Image 5)
4. To position, use template provided to mark locations of four xing points.
Do not use the backplate as a guide for drilling. Ensure there is a 600mm
clearance from surface below.
5. Pre-drill the wall in the marked locations using a 5/16 (8mm) drill, insert the
plastic anchors and tap ush to the wall. (Image 1)
6. Secure the backplate to the wall with appropriate ttings (Image 2)
7. To install power cable and connection to terminal block pull the cable through the
grommet. Ensure the cable is long enough to route correctly through the backplate to
the terminal block. All automatic dryers must have their own dedicated 10 amp circuit.
8. The cable must sit in the dedicated channel.
9. As shown, connect cable to terminal block (Image 3) and screw in to
terminal block.
10. Fix the cable clamp with screw in the backplate. CAUTION: Connect the
earthing wire to the terminal block marked
11. Set heater switch ON/OFF (Factory default setting “ON”) (Image 4)
12. Attach main body by positioning the cover over backplate.
13. Insert and tighten the security screws into the top and bottom of the main
body with the hex key (Image 5).
14. Turn unit on and test operation.
15. Handover security hex key to property manager.

6
splwashrooms.co.nz

7
splwashrooms.co.nz
Regularly clean the outer casing using a
soft, damp cloth to gently wipe away dirt.
DO NOT use abrasives or chemicals.
Periodically deep clean:
1. Disconnect power source.
2. Use hex key provided to remove two
security screws.
3. Clean all dust and lint from the interior.
4. Replace cover and tighten security
screws until snug. Do not overtighten.
5. Wipe with a damp cloth.
6. Liven dryer and test operation.
Troubleshooting
Symptom Possible Cause Corrective Action
Dryer not
blowing hot air.
Heater switch is set
to “OFF.”
1. Remove cover and locate switch, set
to ‘ON”.
Element needs
replacing.
Replacement element part number -
DDV200.
Dryer fails to
start.
Sensor obstruction. 1. Check sensor lens for foreign
material or dirt. Clean lens with soft
damp cloth and mild cleaning agent.
2. If lens is damaged or scratched,
replace it. Part number DDHV207.
Faulty motor. If relay “click” is heard, but unit does not
start, replace the motor / fan assembly.
Part number DDHV707.
Motor will start
and slow down,
then speed up.
Defective PCB. Replace PCB. Part number DDV500.
Maintenance and Cleaning Instructions

splwashrooms.co.nz
Supreme Comprehensive Warranty
Your Supreme hand dryer is fully guaranteed against defective materials and
faulty workmanship commencing from the date of sale (according to SPL’s
records), subject to it being installed and maintained in accordance with the
manufacturer’s instructions.
SPL (2021) Limited warrants that should any part of the dryer fail within the
given warranty period (2- 5 years product dependant), it will be remedied by
SPL.
The dryer should be returned to SPL (2021) Limited for all warranty claims.
The cost of cartage will be payable by the customer.
This warranty excludes:
• Incorrect installation, or installation that does not speci cally follow the
installation guidelines supplied
• Failure to follow manufacturer’s maintenance instructions
• Damage/Failure resulting from:
- the use of non-authorised parts
- authorised parts not installed in accordance with the manufacturer’s
instructions
- accidental damage, negligent use, misuse, vandalism, neglect
- damage caused either directly or indirectly by external sources (power
outages, power surges, incorrect power supply, natural disaster, or
insect infestation)
• Water ingress caused by property maintenance or  ooding
• Negligent cleaning practices (water ingress, harmful chemical etc)
The above includes consequential damage to any other goods, furnishings,
or property.
• Normal wear and tear and consumable parts (HEPA  lters, UV-C lamps,
fuses, motor brushes etc)
• This warranty does not displace any statutory warranty in relation to the
dryer but any liability of SPL (2021) Limited under any statutory warranty
will be limited to a replacement or repair of the dryer or payment of the
cost of such replacement or repair at the sole discretion of SPL (2021)
Limited
Note: Our Warranty only extends to products purchased and installed in
New Zealand.
SPL Limited
PO Box 437, Cambridge 3450
New Zealand
p. [phone]
e. o󰀩 [email protected]
