A926
OWNER'S MANUAL
ASSEMBLY INSTRUCTIONS
LAT PULL DOWN

A. SAFETY INSTRUCTIONS
Read all cautions/warnings and obtain proper instruction on use of the machines
prior to using. Use appropriate positioning and controlled movements.
Assemble and operate the strength on a solid, level surface. Do not use outdoors
or near water.
Never allow children on or near the strength.
Make sure all fasteners are properly tightened for safety. DO NOT use the
strength if the unit is disassembled in any way.
Keep head, limbs, and fingers clear of all moving parts.
If at any time during exercise you feel faint, dizzy or experience pain, stop and
consult you physician.
DO NOT wear loose or dangling clothing while using the equipment. Keep away
from all moving parts.
Use care when mounting and dismounting the unit.
DO NOT use any accessories that aren't specifically recommended by the
manufacturer. These might cause injuries or cause the unit to fall.
Close supervision is necessary when this strength is used by, on, or near
adolescent, invalids, and disabled persons.
Use this strength only for its intended use as described in this manual.
Never operate this strength if it has been damaged in any way. If it is not working
properly, been dropped or damaged, contact your dealer. DO NOT attempt to fix a
broken or jammed machine. Notify floor staff.
Never drop or insert any object into any opening.
1

2
Belt
Grip
Knee post support bar
Seat cushion
Seat cushion
adjustment handle
B. Introduction
Rear cover
Front cover
Usage sticker
Display board
Side frame
Selection pin (3.5 Lbs / 1.5 kgs)
Selection pin (6.5 Lbs / 3 kgs)
Cord
Stack fork
Weight stacks (11 Lbs / 5 kgs)
Foot pad

C. List of Parts
1. One grip
2. I seat cushion
3. Four hexagon socket raised head bolts, M8 x L20, for the seat pad
4. Four spring washers, M8, for the seat cushion
5. Four hexagon socket counter sunk flat-head bolt for the cushion
6. Four hexagon nylon nuts, M8, for the seat plate
7. One double-end open wrench, 17mm x 23mm
8. One double-end open wrench, 8mm x 17mm
9. One hex key wrench, M6
10. One hex key wrench, M5
11. User's manual
3

D. STEP BY STEP INSTRUCTION:
1. Fasten the seat plate with screws provided. (See Fig. 1)
2. Fasten the seat cushion in the plate with the screws provided. (See Fig. 1-1)
4
Fig.1
Fig.1-1

3. Assemble the grip with the hook as shown in Fig. 2.
5
Fig.2

Fig.3
6
E. BELT ADJUSTMENT:
1. If the belt is too tight or too loose, first loosen nut A as shown then adjust nut B. If
the belt length is too long, adjust downward; if the belt length is too short, adjust
upward. Adjust the belt to the proper position, then tighten nut A.
2. The gap between nut A and B must be within 35mm(1.4"). If the gap still
exceeds the 35mm limit after the first step, please loosen the screws on C
and adjust the belt to the proper length. Tighten the screws and follow the
1st step again. (See Fig. 3)

Fig.4
7
F. HOW TO USE THE MINOR WEIGHT STACK
1. To adjust the minor weight stack, insert the upper pin to add 3.5Lbs/1.5kgs
or the lower pin to add 6.5Lbs/3kgs.
2. Pull the pin to release the weight. (See Fig. 4)
3.5Lbs/1.5kgs
6.5Lbs/3kgs

8
