SprintRay Pro User manual

Pro 3D Printer
Quick Start Guide
Resin Wiper
Print Platform
Pre-installed
Resin Tank
Pre-installed
Pro 3D Printer Power Cord
Print Removal Tool Support Snipper Cleaning Cloth Onboarding Card
The print platform and resin tank are pre-installed and have a protective film
that must be removed prior to first use.
In the Box
Congratulations!
In this brief guide, we’re going to show you how to set up
and make your first model on the new SprintRay Pro
Desktop 3D Printer.
Your purchase comes with a complimentary, live training
session with one of our technicians. For advanced users,
see our website for tips & tricks.
We’re so excited to see what you make!
Training and Support
Sign up for free training and contact our support team with
questions.
Visit
Call
Email
support.sprintray.com
800-914-8004
[email protected]
Hello...
1

Use the provided power cable to plug your printer into
a surge protector or uninterrupted power supply.
Pro automatically goes to sleep to save energy after
a period of inactivity. Interaction with the touchscreen
or sending a print job will reactivate it.
Use the power switch if you need to perform a hard
reset or disconnect your Pro from its power source.
To minimize cleanup,
always remove the
platform before removing
your resin tank.
Plug in Your Pro
UV Cover
USB Port
Touchscreen
Power
Switch
Ethernet Port
Print Platform
(Pre-installed)
Unlock and pull to remove.
Insert and lock.Turn to lock/unlock.
Resin Tank
(Pre-installed)
Gently pull toward you to
unlock and then lift up to
remove the resin tank.
Push away from you to lock it in
place. You will hear a “click” when
the resin tank is properly locked.
Align resin tank with tank cradle,
place it, and slide it into the tracks.
Situate your Pro 3D printer in a
well-ventilated area on a flat and level
surface. Keep it away from extreme
temperatures, windows, bright UV light
sources, and direct sunlight.
Where to Set Up
Level Surface
Using the touchscreen, follow these steps:
Settings > Wireless Network > Select a Network
Once connected to a wireless network, Pro will be discoverable by
SprintRay Desktop Software.
Connect to a Wireless Network
Settings
Uneven Surface Warm Environment
3
4
6
5
2

Prepare a Print Job
Ensure Your Pro is Ready
Install resin tank and build platform in their places.
It is extremely important to make sure both the build
platform and resin tank are fully secured and locked
before you start a print.
Refer to steps 5-7 to ensure your equipment is ready
before starting the print.
Get Software Download SprintRay Software from sprintray.com/software
Using Desktop Software to Prepare a Print
After launching SprintRay Software, begin by selecting your
printing material and the desired layer thickness. Next, import
your STL model, orient the model, and add supports if
necessary. If you are new to 3D printing, consult our website
and full user manual for more detailed information.
The model is now ready for printing. Now that everything is
set on the software side, follow the below instructions to
prepare your Pro printer.
Make sure your printer and your computer are both connected
to the same wireless network.
Once you've prepared both the software and hardware for your
print, click on the printer icon in SprintRay Software.
The software will process the job and send it to your printer.
The build platform should slowly descend into the resin tank.
Once this has happened, the print process has begun.
Your printer runs independently once it begins its print process.
Any changes to your network or computer will not effect print
progress as long as Pro maintains power.
Note: It's very important to ensure that the lid remains closed
during the entire print cycle.
Start a Print
Compatible with
Mac and Windows
A B
Fill the Resin Tank
Before you pour resin into your Pro’s tank, it is
important to shake the bottle until it is
thoroughly mixed.
When starting a print, the desktop software or
touchscreen of your Pro will display the resin
level necessary for the planned job.
Fill the tank to the suggested level, ensuring
even distribution of the resin across the tank.
Close the lid of the printer or cover the resin
tank at all times to minimize light exposure.
9
10
7
8
MAX 500mL
MED 400mL
MIN 300mL

Maintenance
Finishing a Print Job
Wash and Air Dry
Use IPA 91% to wash the parts. To ensure complete
cleanliness, the washing process can be repeated.
Post Curing
Depending on the material specifications
and FDA requirements, you may need to
post-cure the printed part after wash.
Please refer to the application guides to
complete the post-curing.
SprintRay ProCure
You can use presets on
SprintRay ProCure to complete
post-curing process.
SprintRay ProCure is sold
separately.
Resin Tank Inspection
Gently drag the resin wiper across the surface of the tank to
ensure there are no hard particles in the tank.
Cleaning the Printer
Use the cleaning cloth provided with the
printer to clean the glass on the printer.
Clean the printer with a soft damp cloth.
Resin Care
Cured resin can be discarded as regular trash. Never dispose of
liquid resin in your sink or other plumbing.
Resin should not be left out of the bottle for more than three days.
If it has been exposed to air for less than three days, it is safe to
pour it back into the bottle through a paper filter or loose mesh.
Mixing Resin Before Print
If you keep resin in the tank between jobs, use the resin wiper to
mix the tank before every print.
Inspect resin tank
with resin wiper.
Removing Prints from Print Platform
Note: We recommend wearing gloves in order to complete this step.
When the print job is complete and the build arm has fully raised,
remove the platform and place it on a flat surface.
Using the provided print removal tool, detach the part from print
platform. Using the clipping tool, remove the supports from your part.
A
B C
BA
Wear Gloves
Air Dry or Blow Dry
IPA 91%
ProCure
