Sprout Harmonic 3.0 User manual

Harmonic 3.0
Bluetooth Headphones
INSTRUCTION MANUAL

01. PRODUCT OVERVIEW 04
02. WHAT’S IN THE BOX? 05
03. QUICK START GUIDE 06
04. ADDITIONAL CONTROLS 10
05. SPECIFICATIONS 12
06. IMPORTANT SAFETY INFO 13
07. DISPOSAL INSTRUCTIONS 14
08. CONSUMER GUARANTEE 15
CONTENT
Sprout is an Australian brand
that develops technology
accessories to enhance your
world, now and into the
future. From maximising your
productivity at work and while
you study to enriching your
downtime and recreational
activities, we develop accessories
that add value to your way of life.
Scan the QR code
to access an online
version of this manual
03

Product Overview
01.
1. Active Noise Cancellation switch
2. USB-C charging input
3. LED indicator
4. Volume control
5. Duolink button
6. Power/play/pause button
7. Microphone for calls
8. AUX input
1
What’s in the box?
Thank you for choosing Harmonic 3.0 Bluetooth
Headphones by Sprout.
For optimum performance and safety, please read
instructions carefully before usage.
Please keep this manual for future reference.
1x Harmonic 3.0 Bluetooth Headphones
1x USB A to USB C cable (Black)
1x Plane adaptor
1x Carry case
1x 3.5mm audio wire (AUX)
1x Product manual
02.
2 4 5 6 7 83
0504

Quick Start Guide Quick Start Guide
03. 03.
LED Indicator Quick-Start Guide:
Funtion LED Indicator Status
Power on Blue/Red LED indicator
lights up for 3 seconds
Power off Blue/Red LED indicator
lights up for 3 seconds
Pairing Red LED & Blue LED
flashes alternately
Standby Blue LED flashes 3 times
in 1 second
Incoming call Blue LED flashes
continuously
Low battery Red LED flashes with
a warning tone
Charging
Red LED indicates
charging in progress
Blue LED indicates
charging finished
Charging your Harmonic 3.0 Bluetooth Headphones:
1. Insert the USB-C end of the charging cable into
the charging input as shown.
2. Insert the USB-A end of the cable into a power
source* to charge. The LED indicator will be red
while charging is in progress. The LED indicator
will be blue when charging is complete. A full
charge will take approximately 1.5 hours.
iOS enabled devices will display the Harmonic 3.0
battery power status on the top right hand side of
their screen.
*Power options include USB connection to a power
source such as a Sprout AC power adapter, a Sprout
car charger or computer/notebook USB connection.
To turn on:
• Press and hold the power/play/pause button
for 3 seconds
• The LED indicator will alternate blue/red
for 3 seconds
To turn off:
• Press and hold the power/play/pause button
for 3 seconds
• The LED indicator will alternate blue/red
for 3 seconds
0706

Connecting to Harmonic 3.0 via Bluetooth:
• Your mobile device needs to be within 10 meters
of the Harmonic 3.0
• Make sure your Harmonic 3.0 battery has a
sufficient charge
To pair your device:
1. Enter into pairing mode:
• From power off status, press and hold the
multifunction button for 5 seconds to enter
pairing mode
• From power on status, press and hold the
multifunction button for 2 seconds to enter
pairing mode
Once in pairing mode, Harmonic 3.0’s LED indicator
will flash blue/red until a device is connected.
2. Turn on Bluetooth on your mobile phone/music
device*
3. ‘Harmonic 3.0’ will appear on your mobile phone/
music device. Select ‘Harmonic 3.0’ to pair
4. The LED indicating light will flash blue every
5 seconds when you are
5. Enjoy your music
*If you are not familiar with Bluetooth pairing for your
mobile phone or music device, refer to the user guide
for your mobile phone/music device for instructions to
pair a new device using Bluetooth.
Using AUX to connect:
Connect your Harmonic 3.0 to a smartphone, tablet
or other audio device using your 3.5mm audio wire
(AUX). Once connected, all additional controls
(volume, skip track etc) will be disabled on your
headphones. Your audio device must be used to
perform these functions.
Quick Start Guide Quick Start Guide
03. 03.
0908

• Volume adjustment: Short press on Vol+ or
Vol- buttons
• Play/Pause: Short press the power/play/pause
button button to pause audio. Press again to
resume audio
• Answer call: Short press the power/play/pause
button to answer an incoming call
• End call: Short press the power/play/pause
button to end a phone call
• Reject call: Press the power/play/pause button
for 2 seconds to reject a call
• Transfer call: After accepting a phone call, press
the power/play/pause button for 2 seconds, and
your call will tranfer to your smartphone. Press
the power/play/pause button for 2 seconds again,
and your call will be transferred to your Harmonic
3.0 Headphones
• Restore factory settings: Connect your Harmonic
3.0 to a computer via the USB A to USB C
cable, press Vol + button and Vol - together for
5 seconds. Once complete, your LED indicating
light will flash blue 6 times
• Active Noise Cancellation function (ANC):
ANC function can be enabled to reduce outside
noise and provide enhanced sound quality. To
activate ANC, switch the ANC button to “ON”.
Your LED indicating light will turn green once
ANC is engaged
Connecting Multiple Harmonic 3.0 via Duolink®
Using the Duolink®feature you can connect
multiple Harmonic 3.0 Headphones. One set
will be your ‘primary’ headphones and another
will be your ‘replica’.
To connect:
• Short press the Duolink®button on your
primary device once. The primary will announce
“Duolink®enabled”
• Short press the Duolink®button on your
replica device once. The replica will announce
“Duolink®enabled”
• Press the Duolink®button once more on the
replica to connect both devices
• Once connected, the replica will announce that it
is using “Duolink®Audio”. The primary device will
show a solid blue light while the replica will show
a flashing red and blue light
To disconnect or reset:
• Press Duolink®button again to disable Duolink®.*
• Press and hold the Duolink®button for five
seconds to reset the Duolink®function.**
*If Duolink®is disabled, Harmonic 3.0 will disconnect
from the replicas, but will still remember them.
**Resetting DUOLINK®will make your Harmonic 3.0
‘forget’ all replica devices.
Additional Contols
04.
Additional Controls
04.
1110

Important Safety Information
06.
Read all instructions and warnings prior to using
this product. Improper use of this product may
result in product damage, excess heat, toxic fumes,
fire or explosion.
• Do not use your Harmonic 3.0 near an open fire,
heat source or excessive heat
• Do not use your Harmonic 3.0 near water
• Using your Harmonic 3.0 is not recommended
while charging
• Protect your charging cable from being pinched
particularly at the connectors
• Unplug your charging cable during lightning storms
or when unused for long periods of time
• Avoid listening at excessive volume levels or for
prolonged periods
• Do not disassemble this device or attempt to modify
it in any manner
• All Sprout products have gone through a thorough
quality assurance inspections. If you find that
your device is excessively hot, is emitting odor,
is deformed, abraded, cut or is experiencing
or demonstrating an abnormal phenomenon,
immediately stop all product use and contact Sprout
• 4x ANC Microphone, 1x Call Microphone
• Bluetooth V5.1
• Operation range - 10m
• Qualcomm QCC3021 chipset
• Rechargeable battery
• Up to 35 hours playing time
• 800 mAh battery
• Type C USB charging input
• 3.5mm AUX-in
• Noise reduction coefficient: 35dB +/-3 dB
• Protein leather (Pleather) ear pads with
memory foam
• Operating Temperature: 0-40°C
Specifications
05.
1312

Consumer Guarantee
08.
Our goods come with guarantees that cannot be
excluded under the Australian Consumer Law.
You are entitled to a replacement or refund for a
major failure and compensation for any other
reasonably foreseeable loss or damage. You are also
entitled to have the goods repaired or replaced if the
goods fail to be of acceptable quality and the failure
does not amount to a major failure. If you have any
questions about your rights in relation to this product,
please return it to point of sale or contact us at
www.sproutinc.com.au. This warranty does not
affect your legal statutory rights under the Australian
Consumer Law. For more information about your rights
under Australia Consumer Law go to www.accc.gov.au.
Your Harmonic 3.0 Bluetooth Headphones are
warranted to the original owner for 24 months
from the date of purchase against defects in material
and workmanship under normal use and service.
The warranty does not cover misuse of this product
and liability will not exceed the purchase price
of the product.
If you have any problems while using the product,
please do not hesitate to contact our customer
support team.
For warranty and technical support please visit
www.sproutinc.com.au or contact us at
275 George Street, Brisbane, QLD, 4000
E [email protected]
Thank you for choosing a Sprout product.
Disposal Instructions
07.
At the end of the useful life of your Harmonic 3.0,
please recycle through your local e-waste collection
point. If you are unsure of your local waste collection
point, please consult your local council for details.
1514

Sprout Accessories Pty Ltd
W: www.sproutinc.com.au
E: [email protected]
