Sprout SOUNDWAVE User manual

SOUNDWAVE
BLUETOOTH
SPEAKER
PRODUCT MANUAL

01. What’s in the box? 2
02. Product overview 3
03. Quick start guide 4
04. Operating controls 7
05. Specifications 10
06. Important safety info 11
07. Consumer guarantee 12
CONTENTS
Scan the QR code
to access an online
version of this manual
WE PUT MORE INTO
OUR TECH, SO YOU CAN
GET MORE OUT OF LIFE.
At Sprout, our purpose is to help
you unlock the potential of your
technology. We’re an Australian
brand, and we design all of our
products locally to ensure they
are uniquely suited to your lifestyle.
1

1. WHAT’S IN THE BOX?
Thank you for choosing the Soundwave Bluetooth
Speaker by Sprout.
For optimum performance and safety, please
readinstructions carefully before usage.
Please keep this manual for future reference.
1x Soundwave speaker
1x USB-A to USB-C charging cable
1x Strap
1x Product manual
1. LED indicator
2. Power buon
3. Play buon
4. Volume up buon
5. Volume down buon
6. UNISYNCTM buon
7. LED baery indicator
8. Lanyard/clip
9. USB-A output port
10. USB-C input port
11. 3.5mm aux input port
2. PRODUCT OVERVIEW
1
2
3
4
5
6
7
8
9 10 11
32

TURNING SOUNDWAVE ON/OFF
To power on, long press the power buon for 2
seconds. Soundwave will announce “power on”
whilst the LED indicator light at the top will light up.
It will flash blue/red until a Bluetooth connection
has been established.
To power o, long press the power buon for 2
seconds. The speaker will announce “power o”
with the LED indicator also turning o.
To preserve baery, Soundwave will automatically
turn o aer 5 minutes of no Bluetooth or 3.5mm
aux connection.
CONNECTING VIA 3.5MM AUX CABLE
To play audio using the aux cable, connect the cable
from the Soundwave to your device. The LED indicator
light will change to a solid red. Soundwave will play the
audio when you press ‘play’ on your device.
Please note: Using 3.5mm aux input will override a
Bluetooth source input.
CONNECTING VIA BLUETOOTH
1. Press the power buon for approximately two
seconds. The LED indicator light will flash blue and
red to indicate Soundwave is readyfor pairing.*
2. Turn on Bluetooth on your mobile phone/
musicdevice.**
3. ’Soundwave’ will appear on your mobile phone/
music device. Select ‘Soundwave’ to pair.
4. Once your mobile phone/music device is
connected to the soundwave speaker, the LED
indicator light will change to a solid blue, and the
speaker will announce “Bluetooth connected”.***
5. Enjoy your music.
*Soundwave will automatically enter Bluetooth pairing mode
when turned on for the first time. To reset Bluetooth pairing,
hold the UNISYNC buon for 6 seconds to initiate Bluetooth
pairing mode again.
**If you are not familiar with Bluetooth pairing foryour mobile
phone or music device, refer to theuser guide for your mobile
phone/music device forinstructions to pair a new device
using Bluetooth.
***Soundwave will always store the last device paired
and if the device is within Bluetooth range, Soundwave
will automatically connect to the device.
3. QUICK START GUIDE 3. QUICK START GUIDE
54

LED INDICATOR
• Flashing blue/red - Bluetooth pairing mode
• Solid blue - Bluetooth connected
• Solid red - 3.5mm aux connected
POWER BUTTON
• 2 second long press - power on/power o
• 4 second long press - power on + Bluetooth pairing
PLAY BUTTON
• 1 press - play/pause/answer call/end call
• 2 second long press - reject call
• 2 presses - Siri/Google
VOLUME UP BUTTON
• 1 press - volume up
• 2 second long press - next track
VOLUME DOWN BUTTON
• 1 press - volume down
• 2 second long press - restart track
• 2 second long press x2 - previous track
UNISYNCTM BUTTON
• 1 press - cycle through UNISYNC functions
(UNISYNC mode/UNISYNC audio/UNISYNC disabled)
• 2 second long press - disconnects Bluetooth (device
remains paired to soundwave)
• 6 second long press - resets UNISYNC and Bluetooth
connection (device will need to be re-paired)
3. QUICK START GUIDE 4. OPERATING CONTROLS
CHARGING YOUR SOUNDWAVE
1. Remove the port cover on the back of the
speaker, and connect the speaker via the USB-C
port to the USB-A power source, using the
included charging cable.
2. The LED baery indicator will flash from one to four
LEDs to indicate Soundwave is charging. The lights
will stop flashing once Soundwave is fully charged.
A full charge will take approximately 3-4 hours,
depending on the speed of the charger.
Once charged, remove the charge cable and
replace the port cover.
Please note: Soundwave will announce
“low baery” when the baery level reaches
approximately 10%.
LED BATTERY INDICATOR
4 white lights on: Batery 76-100%
3 white lights on: Batery 51-75%
2 white lights on: Batery 26-50%
1 white light on: Batery 0-25%
76

CONNECTING MULTIPLE SPEAKERS VIA UNISYNCTM
Using the UNISYNC feature you can connect up to
50 UNISYNC compatible speakers. In this example,
your Soundwave is your primary device.
To connect a replica, short press the UNISYNC
buon on your primary speaker once to enter
UNISYNC mode. Once the primary announces it is
in UNISYNC mode, repeat on the replica. Aer the
replica announces it is in UNISYNC mode, press the
UNISYNC buon on the replica device once more –
the replica will announce it is using UNISYNC audio.
The primary speaker will show a solid blue light while
replicas will show a flashing red and blue light.
To exit UNISYNC mode, press the UNISYNC buon
until you hear UNISYNC disabled.*
Press and hold the UNISYNC buon for 6 seconds
to reset the UNISYNC function.**
*If UNISYNC is disabled, Soundwave will disconnectfrom but
remember the replicas connected to it.
**Reseing UNISYNC will enable Soundwave to ‘forget’ all
replica devices and Bluetooth connections.
POWERBANK
Soundwave comes with a USB-A output port, which
is capable of supplying up to 5V⎓2A (10W).
Whilst charging another device, the LED baery
indicator lights will flash. The number of lights
flashing will indicate how much charge is remaining
in the speaker’s powerbank.
MULTIPOINT CONNECTION
Multipoint is a feature that allows Soundwave to
connect to two Bluetooth devices at once. This
means that you can listen to music from one device,
whilst still hearing notifications and receiving calls
from another device.
To setup Multipoint:
1. Connect your first Bluetooth device.
2. Hold down the UNISYNC buon for 2 seconds
to disconnect Bluetooth.
3. Connect your second Bluetooth device.
4. Hold down the power buon for 2 seconds
and turn o Soundwave.
5. Hold down the power buon for 2 seconds
and turn on Soundwave.
Soundwave will announce “Bluetooth connected”
twice. Soundwave will play audio from the last device
it receives a command from, but it will treat the
device with calls and notifications as priority.
4. OPERATING CONTROLS 4. OPERATING CONTROLS
98

• Dimensions: 155x 110x 80mm
• Unit weight: 645g
• USB-C input: 5V⎓3A (15W)
• USB-A output: 5V⎓2A (10W)
• Baery capacity: 5200mAh
• Playtime: Up to 14 hours at 50% volume
• Driver size: 2x 47mm
• Frequency response: 20-22kHz
• Power output: 12W
• Total max power output: 24W
• IP rating: 56 Splashproof
(when port cover is closed)
• Bluetooth version: 5.3
• Aux input: 3.5mm
1. Do not aempt to charge Soundwave when it is
wet or you suspect water has seeped into the
device. Thoroughly dry Soundwave and make
sure all connections are dry before aempting to
remove the port cover. Failure to do so may result
in electrical shock, fire or electrical damage to
Soundwave and may void the warranty.
2. Do not use Soundwave near an open fire,
heatsource or excessive heat.
3. Do not disassemble this device or aempt to
modify in any manner.
4. Sound levels should be appropriate to your
environment and comply with all local regulations.
5. Ensure that you can hear and are aware of
anypotential hazards around you when you are
enjoyingyour Soundwave speaker.
All Sprout products go through thorough quality
assurance inspections. If you find that your device
is excessively hot, is emiing odour, is deformed,
abraded, cut or is experiencing or demonstrating an
abnormal phenomenon, immediately stop all product
use and contact Sprout.
5. SPECIFICATIONS 6. IMPORTANT SAFETY INFO
1110

Our goods come with guarantees that cannot be
excluded under the Australian Consumer Law. You are
entitled to a replacement or refund for a major failure
and compensation for any other reasonably foreseeable
loss or damage. You are also entitled to have the
goods repaired or replaced if the goods fail to be of
acceptable quality and the failure does not amount to
a major failure. If you have any questions about your
rights in relation to this product, please return it to point
of sale or contact us at [e-mail].
This warranty does not aect your legal statutory
rights under the Australian Consumer Law. For more
information about your rights under Australia Consumer
Law go to www.accc.gov.au.
Your Sprout Soundwave speaker is warranted
to the original owner for 24 months from the
date of purchase against defects in material and
workmanship under normal use and service.
The warranty does not cover misuse of this product
and liability will not exceed the purchase price of
the product.
If you have any problems while using the product,
please do not hesitate to contact our customer
support team.
For warranty and technical support please visit
sproutinc.com.au or email [e-mail].
Thank you for choosing a Sprout product.
7. CONSUMER GUARANTEE
12

Sprout Accessories Pty Ltd
W: Sproutinc.com.au | E: [e-mail]
