Sprout Nomad Alpha User manual

NOMAD ALPHA
BLUETOOTH
SPEAKER
PRODUCT MANUAL

01. What’s in the box? 2
02. Product overview 3
03. Quick star guide 4
04. Operating controls 6
05. Specifications 9
06. Care and maintenance 10
07. Imporant safety info 11
08. Consumer guarantee 12
CONTENTS
Scan the QR code
to access an online
version of this manual
WE PUT MORE INTO
OUR TECH, SO YOU CAN
GET MORE OUT OF LIFE.
At Sprout, our purpose is to help
you unlock the potential of your
technology. We’re an Australian
brand, and we design all of our
products locally to ensure they
are uniquely suited to your lifestyle.
1

01. What’s in the box? 2
02. Product overview 3
03. Quick star guide 4
04. Operating controls 6
05. Specifications 9
06. Care and maintenance 10
07. Imporant safety info 11
08. Consumer guarantee 12
CONTENTS
Scan the QR code
to access an online
version of this manual
WE PUT MORE INTO
OUR TECH, SO YOU CAN
GET MORE OUT OF LIFE.
At Sprout, our purpose is to help
you unlock the potential of your
technology. We’re an Australian
brand, and we design all of our
products locally to ensure they
are uniquely suited to your lifestyle.
1

1. WHAT’S IN THE BOX?
Thank you for choosing the Nomad Alpha
Bluetooth Speaker by Sprout.
For optimum perormance and safety, please
read instructions carefully before usage.
Please keep this manual for future reference.
1x Nomad Alpha Bluetooth Speaker
1x USB-A to USB-C charging cable
1x Aux-in audio cable
1x Product manual
1. Power buton
2. UNISYNCTM
3. LED flashlight buton
4. LED indicator
5. Batery LED indicator
6. Wireless charging pad
7. Volume down buton
8. Play/pause/answer
buton
9. Volume up buton
10. Locking side panel cap
11. 3.5mm aux input por
12. USB-A output
13. Main power switch
14. USB-C input
15. LED flashlight
2. PRODUCT OVERVIEW
1 2 3 6
7
8
9
54
10 15
11
12
13
14
32

1. WHAT’S IN THE BOX?
Thank you for choosing the Nomad Alpha
Bluetooth Speaker by Sprout.
For optimum perormance and safety, please
read instructions carefully before usage.
Please keep this manual for future reference.
1x Nomad Alpha Bluetooth Speaker
1x USB-A to USB-C charging cable
1x Aux-in audio cable
1x Product manual
1. Power buton
2. UNISYNCTM
3. LED flashlight buton
4. LED indicator
5. Batery LED indicator
6. Wireless charging pad
7. Volume down buton
8. Play/pause/answer
buton
9. Volume up buton
10. Locking side panel cap
11. 3.5mm aux input por
12. USB-A output
13. Main power switch
14. USB-C input
15. LED flashlight
2. PRODUCT OVERVIEW
1 2 3 6
7
8
9
54
10 15
11
12
13
14
32

UNLOCKING THE SIDE PANEL CAP
1. To unlock, turn the cap anti-clockwise
2. Lif the cap to detach
LOCKING THE SIDE PANEL CAP
1. Place the cap over the input panel
2. Turn the cap clockwise until tight*
*Nomad Alpha is only dust and waterproof when this cap is
properly closed.
CHARGING YOUR NOMAD ALPHA
1. Switch of the main power switch
2. Connect the speaker via the USB-C input to
a power source* using the included USB-A to
USB-C cable
3. Blue LEDs indicate the power level of charge**
*Power source options include USB connection to
a Sprout AC power adapter, a Sprout car charger or
computer/notebook USB connection.
**Full charge will take about 8-10 hours.
Please refer to LED indicator section in this product manual.
CONNECTING VIA 3.5MM AUX CABLE
To play audio using the aux cable, connect the cable
from the Nomad Alpha to your device.
Please note: Using 3.5mm aux input will override a
Bluetooth source input.
CONNECTING VIA BLUETOOTH
1. Switch on the main power switch
2. Press the power buton for approximately three
seconds. The LED indicator will flash blue/red to
indicate Nomad Alpha is ready for pairing*
3. Turn on Bluetooth on your mobile phone/music
device**
4. ‘Nomad Alpha’ will appear on your mobile phone/
music device. Select ‘Nomad Alpha’ to pair
5. Once your mobile phone/music device is
connected to Nomad Alpha, you will hear
‘Bluetooth connected’***
6. Enjoy your music
*If the LED indicator is not flashing red and blue, hold the
UNISYNC buton for 5 seconds to initiate Bluetooth pairing.
**If you are not familiar with Bluetooth pairing for your mobile
phone/music device, refer to the user guide for your mobile
phone/music device for instructions to pair a new device
using Bluetooth.
***Nomad Alpha will always store the last device paired and
if the device is within Bluetooth range, Nomad Alpha will
automatically connect to the device.
3. QUICK START GUIDE 3. QUICK START GUIDE
54

UNLOCKING THE SIDE PANEL CAP
1. To unlock, turn the cap anti-clockwise
2. Lif the cap to detach
LOCKING THE SIDE PANEL CAP
1. Place the cap over the input panel
2. Turn the cap clockwise until tight*
*Nomad Alpha is only dust and waterproof when this cap is
properly closed.
CHARGING YOUR NOMAD ALPHA
1. Switch of the main power switch
2. Connect the speaker via the USB-C input to
a power source* using the included USB-A to
USB-C cable
3. Blue LEDs indicate the power level of charge**
*Power source options include USB connection to
a Sprout AC power adapter, a Sprout car charger or
computer/notebook USB connection.
**Full charge will take about 8-10 hours.
Please refer to LED indicator section in this product manual.
CONNECTING VIA 3.5MM AUX CABLE
To play audio using the aux cable, connect the cable
from the Nomad Alpha to your device.
Please note: Using 3.5mm aux input will override a
Bluetooth source input.
CONNECTING VIA BLUETOOTH
1. Switch on the main power switch
2. Press the power buton for approximately three
seconds. The LED indicator will flash blue/red to
indicate Nomad Alpha is ready for pairing*
3. Turn on Bluetooth on your mobile phone/music
device**
4. ‘Nomad Alpha’ will appear on your mobile phone/
music device. Select ‘Nomad Alpha’ to pair
5. Once your mobile phone/music device is
connected to Nomad Alpha, you will hear
‘Bluetooth connected’***
6. Enjoy your music
*If the LED indicator is not flashing red and blue, hold the
UNISYNC buton for 5 seconds to initiate Bluetooth pairing.
**If you are not familiar with Bluetooth pairing for your mobile
phone/music device, refer to the user guide for your mobile
phone/music device for instructions to pair a new device
using Bluetooth.
***Nomad Alpha will always store the last device paired and
if the device is within Bluetooth range, Nomad Alpha will
automatically connect to the device.
3. QUICK START GUIDE 3. QUICK START GUIDE
54

CONNECTING MULTIPLE SPEAKERS
VIA UNISYNCTM
If you are using the UNISYNC feature you can
connect one Nomad Alpha as a primary, then
connect up to 50 UNISYNC compatible devices
as replicas.
To connect a replica, shor press the UNISYNC
buton on your primary device once to enter
UNISYNC mode. Once the primary announces it
is in UNISYNC mode, repeat on the replica. Afer
the replica announces it is in UNISYNC mode,
press the UNISYNC buton once more – the
replica should now announce it is using UNISYNC
audio. The primary speaker will show a solid blue
light while replicas will show a flashing red and
blue light.
Press the UNISYNC buton again to disable
UNISYNC.* Press and hold the UNISYNC buton for
five seconds to reset the UNISYNC function.**
*If UNISYNC is disabled, Nomad Alpha will disconnect from
but remember the replicas connected to it.
**Reseting UNISYNC will enable Nomad Alpha to ‘forget’ all
replica devices.
WIRELESS CHARGING
The wireless charging pad conveniently recharge
your Qi-compatible devices. The main power
switch must be turned on to use this feature.
4. OPERATING CONTROLS 4. OPERATING CONTROLS
MAIN POWER SWITCH
The main power switch must be set to the ‘ON’ position
for Nomad Alpha to be operational. The power standby
function will only work when the main power switch is in the
‘ON’ position.
POWER
Press the power buton to turn on or of. When turned of,
Nomad Alpha remains in standby power mode. Please note
that the main power switch at the side panel needs to be
switched to on for the power buton to operate.
PLAYPAUSEANSWER
Press the play/pause/answer buton to play or pause songs
and answer mobile phone calls.
VOLUME CONTROL
Shor press ‘-’ buton to decrease volume.
Shor press ‘+’ buton to increase volume.
TRACK CONTROL
Long press ‘-’ buton to select previous song.
Long press ‘+’ buton to select nex song.
LED FLASHLIGHT
Hold the LED flashlight buton for 5 seconds to
turn on or of. Continue pressing the buton to cycle
through the available flashlight modes. Normal
brightness, highlights, slow flash, quick flash.
WARNING: In about 5% of people with epilepsy, exposure to
flashing or flickering lights can trigger seizures (Source: Epilepsy
action Australia). The strobe light function in this device may
potentially trigger seizures for people with photosensitive
epilepsy. User discretion is advised.
76

CONNECTING MULTIPLE SPEAKERS
VIA UNISYNCTM
If you are using the UNISYNC feature you can
connect one Nomad Alpha as a primary, then
connect up to 50 UNISYNC compatible devices
as replicas.
To connect a replica, shor press the UNISYNC
buton on your primary device once to enter
UNISYNC mode. Once the primary announces it
is in UNISYNC mode, repeat on the replica. Afer
the replica announces it is in UNISYNC mode,
press the UNISYNC buton once more – the
replica should now announce it is using UNISYNC
audio. The primary speaker will show a solid blue
light while replicas will show a flashing red and
blue light.
Press the UNISYNC buton again to disable
UNISYNC.* Press and hold the UNISYNC buton for
five seconds to reset the UNISYNC function.**
*If UNISYNC is disabled, Nomad Alpha will disconnect from
but remember the replicas connected to it.
**Reseting UNISYNC will enable Nomad Alpha to ‘forget’ all
replica devices.
WIRELESS CHARGING
The wireless charging pad conveniently recharge
your Qi-compatible devices. The main power
switch must be turned on to use this feature.
4. OPERATING CONTROLS 4. OPERATING CONTROLS
MAIN POWER SWITCH
The main power switch must be set to the ‘ON’ position
for Nomad Alpha to be operational. The power standby
function will only work when the main power switch is in the
‘ON’ position.
POWER
Press the power buton to turn on or of. When turned of,
Nomad Alpha remains in standby power mode. Please note
that the main power switch at the side panel needs to be
switched to on for the power buton to operate.
PLAYPAUSEANSWER
Press the play/pause/answer buton to play or pause songs
and answer mobile phone calls.
VOLUME CONTROL
Shor press ‘-’ buton to decrease volume.
Shor press ‘+’ buton to increase volume.
TRACK CONTROL
Long press ‘-’ buton to select previous song.
Long press ‘+’ buton to select nex song.
LED FLASHLIGHT
Hold the LED flashlight buton for 5 seconds to
turn on or of. Continue pressing the buton to cycle
through the available flashlight modes. Normal
brightness, highlights, slow flash, quick flash.
WARNING: In about 5% of people with epilepsy, exposure to
flashing or flickering lights can trigger seizures (Source: Epilepsy
action Australia). The strobe light function in this device may
potentially trigger seizures for people with photosensitive
epilepsy. User discretion is advised.
76

• Dimensions: 280x 141x 151mm
• Unit weight: 1.9kg
• Output power: RMS 40W
• S/N ratio: 85db +/- 3db
• Frequency range: 90Hz - 20 kHz
• USB-C input: 5V⎓3A (15W), 9V⎓3A (18W),
12V⎓2.5A (30W), 15V⎓2A (30W)
• USB-A output: 5V⎓2.4A (12W)
• Batery capacity: 15,600mAh
• Playime: Up to 10 hours at 75% volume
• Charging time: Approximately 8-10 hours
• Function: Bluetooth/ UNISYNC/ Aux-in/
Microphone/ USB-C input/ USB-A power output/
LED flashlight/ Wireless charging pad
• Bluetooth version: 5.1
• Drop proof to 2 metres
• Waterproof IP67
• Shock proof
• Operating temperature: -10C to 55C
4. OPERATING CONTROLS 5. SPECIFICATIONS
LED INDICATOR
The single blue LED indicator will flash when Nomad
Alpha is switched on
When it is flashing red and blue, Nomad Alpha is in
pairing mode.
LED BATTERY INDICATOR
The batery LED indicator will flash from one to four
LEDs to indicate Nomad Alpha is charging. The lights
will stop flashing once Nomad Alpha is fully charged.
POWERBANK
Nomad Alpha comes with a USB-A output por, which
is capable of supplying up to 5V⎓2.4A. The main
power switch must be turned on to use this feature.
Whilst charging another device, the LED batery
indicator lights will indicate how much charge is
remaining in the speaker’s powerbank.
4 blue lights on: Batery 100%
3 blue lights on: Batery 75%
2 blue lights on: Batery 50%
1 blue light on: Batery 25%
1 red light on: Batery requires
recharge
98

• Dimensions: 280x 141x 151mm
• Unit weight: 1.9kg
• Output power: RMS 40W
• S/N ratio: 85db +/- 3db
• Frequency range: 90Hz - 20 kHz
• USB-C input: 5V⎓3A (15W), 9V⎓3A (18W),
12V⎓2.5A (30W), 15V⎓2A (30W)
• USB-A output: 5V⎓2.4A (12W)
• Batery capacity: 15,600mAh
• Playime: Up to 10 hours at 75% volume
• Charging time: Approximately 8-10 hours
• Function: Bluetooth/ UNISYNC/ Aux-in/
Microphone/ USB-C input/ USB-A power output/
LED flashlight/ Wireless charging pad
• Bluetooth version: 5.1
• Drop proof to 2 metres
• Waterproof IP67
• Shock proof
• Operating temperature: -10C to 55C
4. OPERATING CONTROLS 5. SPECIFICATIONS
LED INDICATOR
The single blue LED indicator will flash when Nomad
Alpha is switched on
When it is flashing red and blue, Nomad Alpha is in
pairing mode.
LED BATTERY INDICATOR
The batery LED indicator will flash from one to four
LEDs to indicate Nomad Alpha is charging. The lights
will stop flashing once Nomad Alpha is fully charged.
POWERBANK
Nomad Alpha comes with a USB-A output por, which
is capable of supplying up to 5V⎓2.4A. The main
power switch must be turned on to use this feature.
Whilst charging another device, the LED batery
indicator lights will indicate how much charge is
remaining in the speaker’s powerbank.
4 blue lights on: Batery 100%
3 blue lights on: Batery 75%
2 blue lights on: Batery 50%
1 blue light on: Batery 25%
1 red light on: Batery requires
recharge
98

1. Do not atempt to charge Nomad Alpha when it is
wet, or you suspect water has seeped into Nomad
Alpha. Thoroughly dry Nomad Alpha and make sure
all connections are dry before atempting to open the
side panel cap and connect to a USB cable or power
source. Failure to do so may resul in electrical shock,
fire or electrical damage to Nomad Alpha and may void
the warranty.
2. Do not put metal objects or magnets between the
mobile device and the wireless charging surace.
3. Do not use Nomad Alpha near any open fire, heat
source or excessive heat.
4. Do not disassemble this device or atempt to modify in
any manner. Do not remove the buil-in batery or the
grill cover. Doing so could cause damage to Nomad
Alpha and allow water to enter.
5. Sound levels should be appropriate to your
environment and comply with all local regulations.
Ensure that you can hear and are aware of any
potential hazards around you when you are enjoying
your Nomad Alpha.
6. For approximately 5% of people with epilepsy,
exposure to flashing or flickering lights can trigger
seizures (Source: Epilepsy action Australia). The strobe
light function in this device may potentially trigger
seizures for people with photosensitive epilepsy. User
discretion is advised.
All Sprout products go through thorough quality assurance
inspections. If you find that your device is excessively
hot, is emiting odour, is deformed, abraded, cut or is
experiencing or demonstrating an abnormal phenomenon,
immediately stop all product use and contact Sprout.
6. CARE AND MAINTENANCE 7. IMPORTANT SAFETY INFORMATION
Nomad Alpha Bluetooth Speaker is intended to be
used both indoors and outdoors. The speaker has
been tested to IP67 waterproofing and dustproofing
standards. IP67 standard allows Nomad Alpha to be
submerged in water up to 1 metre for 30 minutes
without any damage. However, Nomad Alpha is not
intended for constant underwater use. Close the
side panel cap properly before use (see locking side
panel cap section). If Nomad Alpha is placed in water
without the cap securely closed, water will enter
Nomad Alpha and void the warranty.
Always make sure the side panel cap is clean, free
of any debris and correctly fited. The speaker will
only meet IP67 ratings when the side panel cap is
properly locked and sealed. Included USB cables
are NOT waterproof.
If you notice a mufling of audio afer submersion,
gently shake Nomad Alpha to clear excess water.
If your speaker is exposed to salwater clean it
thoroughly afer use with fresh water. Do not apply
excessive force to any suraces of Nomad Alpha
when it is wet or in a wet environment.
Check the rubber seal periodically for premature
wear and clean Nomad Alpha with a sof damp cloth
and ensure no objects such as dir, hair, sand are on
the rubber seal ring. Do not use any oily solvents or
chemicals for cleaning.
11
10

1. Do not atempt to charge Nomad Alpha when it is
wet, or you suspect water has seeped into Nomad
Alpha. Thoroughly dry Nomad Alpha and make sure
all connections are dry before atempting to open the
side panel cap and connect to a USB cable or power
source. Failure to do so may resul in electrical shock,
fire or electrical damage to Nomad Alpha and may void
the warranty.
2. Do not put metal objects or magnets between the
mobile device and the wireless charging surace.
3. Do not use Nomad Alpha near any open fire, heat
source or excessive heat.
4. Do not disassemble this device or atempt to modify in
any manner. Do not remove the buil-in batery or the
grill cover. Doing so could cause damage to Nomad
Alpha and allow water to enter.
5. Sound levels should be appropriate to your
environment and comply with all local regulations.
Ensure that you can hear and are aware of any
potential hazards around you when you are enjoying
your Nomad Alpha.
6. For approximately 5% of people with epilepsy,
exposure to flashing or flickering lights can trigger
seizures (Source: Epilepsy action Australia). The strobe
light function in this device may potentially trigger
seizures for people with photosensitive epilepsy. User
discretion is advised.
All Sprout products go through thorough quality assurance
inspections. If you find that your device is excessively
hot, is emiting odour, is deformed, abraded, cut or is
experiencing or demonstrating an abnormal phenomenon,
immediately stop all product use and contact Sprout.
6. CARE AND MAINTENANCE 7. IMPORTANT SAFETY INFORMATION
Nomad Alpha Bluetooth Speaker is intended to be
used both indoors and outdoors. The speaker has
been tested to IP67 waterproofing and dustproofing
standards. IP67 standard allows Nomad Alpha to be
submerged in water up to 1 metre for 30 minutes
without any damage. However, Nomad Alpha is not
intended for constant underwater use. Close the
side panel cap properly before use (see locking side
panel cap section). If Nomad Alpha is placed in water
without the cap securely closed, water will enter
Nomad Alpha and void the warranty.
Always make sure the side panel cap is clean, free
of any debris and correctly fited. The speaker will
only meet IP67 ratings when the side panel cap is
properly locked and sealed. Included USB cables
are NOT waterproof.
If you notice a mufling of audio afer submersion,
gently shake Nomad Alpha to clear excess water.
If your speaker is exposed to salwater clean it
thoroughly afer use with fresh water. Do not apply
excessive force to any suraces of Nomad Alpha
when it is wet or in a wet environment.
Check the rubber seal periodically for premature
wear and clean Nomad Alpha with a sof damp cloth
and ensure no objects such as dir, hair, sand are on
the rubber seal ring. Do not use any oily solvents or
chemicals for cleaning.
11
10

Our goods come with guarantees that cannot be
excluded under the Australian Consumer Law. You are
entitled to a replacement or refund for a major failure
and compensation for any other reasonably foreseeable
loss or damage. You are also entitled to have the
goods repaired or replaced if the goods fail to be of
acceptable quality and the failure does not amount to
a major failure. If you have any questions about your
rights in relation to this product, please return it to point
of sale or contact us at [e-mail].
This warranty does not afect your legal statutory
rights under the Australian Consumer Law. For more
information about your rights under Australia Consumer
Law go to .accc.gov.au.
Your Nomad Alpha Bluetooth Speaker is warranted
to the original owner for 24 months from the
date of purchase against defects in material and
workmanship under normal use and service.
The warranty does not cover misuse of this product
and liability will not exceed the purchase price of
the product.
If you have any problems while using the product,
please do not hesitate to contact our customer
suppor team.
For warranty and technical suppor please visit
sproutinc.com.au or email [e-mail].
Thank you for choosing a Sprout product.
8. CONSUMER GUARANTEE
12

Our goods come with guarantees that cannot be
excluded under the Australian Consumer Law. You are
entitled to a replacement or refund for a major failure
and compensation for any other reasonably foreseeable
loss or damage. You are also entitled to have the
goods repaired or replaced if the goods fail to be of
acceptable quality and the failure does not amount to
a major failure. If you have any questions about your
rights in relation to this product, please return it to point
of sale or contact us at [e-mail].
This warranty does not afect your legal statutory
rights under the Australian Consumer Law. For more
information about your rights under Australia Consumer
Law go to .accc.gov.au.
Your Nomad Alpha Bluetooth Speaker is warranted
to the original owner for 24 months from the
date of purchase against defects in material and
workmanship under normal use and service.
The warranty does not cover misuse of this product
and liability will not exceed the purchase price of
the product.
If you have any problems while using the product,
please do not hesitate to contact our customer
suppor team.
For warranty and technical suppor please visit
sproutinc.com.au or email [e-mail].
Thank you for choosing a Sprout product.
8. CONSUMER GUARANTEE
12

Sprout Accessories Pty Ltd
W: Sproutinc.com.au | E: [e-mail]
