Sprout Nomad Mi+ User manual

Nomad 3 Mi+
Bluetooth Speaker
Sprout Accessories Pty Ltd
W: www.sproutinc.com.au
E: [email protected]

Nomad 3 Mi+
Bluetooth Speaker
INSTRUCTION MANUAL
Sprout Accessories Pty Ltd
W: www.sproutinc.com.au
E: [email protected]

Sprout is an Australian brand that
develops technology accessories
to enhance your world, now and
into the future. From maximising
your productivity at work and
while you study to enriching
your downtime and recreational
activities, we develop accessories
that add value to your way of life.

01. PRODUCT OVERVIEW 04
02. WHAT’S IN THE BOX? 06
03. QUICK START GUIDE 07
04. OPERATING CONTROLS 11
05. SPECIFICATIONS 13
06. PRODUCT USE AND CARE 14
07. IMPORTANT SAFETY INFO 16
08. CONSUMER GUARANTEE 18
CONTENT
03
Scan the QR code
to access an online
version of this manual

Product Overview
01.
1. Protective screw cap
2. Aux in
3. Main power on/off switch
4. USB 2.0 output
5. USB-C input
6. Microphone
7. Power/Bluetooth button (plus play, pause and
answer functions)
8. Power/Bluetooth indicator
9. Battery level indicator
10. Volume control (plus skip forward/back function)
11. UNISYNC®button
04

Product Overview
01.
05
1
2
4
3
5
6
7
8
10
11
9

What’s in the Box?
02.
06
1x Nomad 3 Mi+ Bluetooth Speaker
1x USB Type-A to USB Type-C charging cable
1x Aux cable
1x Product manual
Thank you for choosing our Nomad 3 Mi+ Bluetooth
Speaker.
For optimum performance and safety, please read
instructions carefully before usage.
Please keep this manual for future reference.

Quick Start Guide
03.
Charging Your Nomad 3 Mi+:
1. Connect the USB Type-C cable into the ‘USB-C
input’ and connect the USB-A end of cable into
a power source*.
2. The battery LED indicator will flash from one to
four LEDs to indicate Nomad 3 Mi+ is charging.
The lights will stop flashing once Nomad 3 Mi+ is
fully charged**.
07
Important note: Charging the Nomad 3 Mi+
requires the use of a power source*. The speaker
is supplied with a USB-A to USB-C charging
cable, but does not include a power source.
4 white lights on: Battery 100%
3 white lights on: Battery 75%
2 white lights on: Battery 50%
1 white light on: Battery requires recharge
The speaker will announce “Low Battery” when the
battery level reaches 10%.
*Power source options include USB connection to
an AC power adapter, a car charger or computer/
notebook USB connection.
**Full charge will take approximately 2 - 3 hours.

Turning Nomad 3 Mi+ on/off:
• Unscrew the protective screw cap anticlockwise
and change the main power on/off switch to
the ‘on’ position. The Nomad 3 Mi+ is now on
standby.
• To power on, press the Power/Bluetooth button.
A blue LED light on the Power/Bluetooth indicator
will show when the Nomad 3 Mi+ is on.
• To turn off, switch the main power on/off switch to
the ‘off’ position.
• Always ensure that the protective screw cap is
replaced and screwed clockwise until tightly
sealed. The Nomad 3 Mi+ is only waterproof when
this cap is tightly closed.
USB charging output:
• Nomad 3 Mi+ can recharge a variety of devices
using its 5,200mAh internal battery.
• Simply connect your device using a USB Type-A
cable into the USB output port.
Quick Start Guide
03.
08

Quick Start Guide
03.
Connecting to your Nomad 3 Mi+ Speaker:
You can play music through your Nomad 3 Mi+
Speaker using Bluetooth or an Auxiliary Cable.
Method 1: Connecting via Bluetooth
1. Press the power button for approximately three
seconds. The power/Bluetooth indicator will flash
blue and red to indicate the Nomad 3 Mi+ is ready
for pairing*.
2. Turn on Bluetooth on your mobile phone/music
device**.
3. ‘Nomad 3 Mi+’ will appear on your mobile phone/
music device. Select ‘Nomad 3 Mi+’ to pair.
4. Once your mobile phone/music device is connected
to the Nomad 3 Mi+, you will hear ‘Bluetooth
connected’***.
5. Enjoy your music
*If the single LED is not flashing red and blue,
hold the UNISYNC button for 5 seconds to initiate
Bluetooth pairing.
**If you are not familiar with Bluetooth pairing for
your mobile phone or music device, refer to the
user guide for your mobile phone/music device for
instructions to pair a new device using Bluetooth.
***Nomad 3 Mi+ will always store the last device
paired and if the device is within Bluetooth range,
Nomad 3 Mi+ will automatically connect to the
device. 09

Method 2: Connecting via Auxiliary Cable
To play music using the auxiliary cable, connect
the cable with your device or mobile phone.
Nomad 3 Mi+ will play the music when you press
‘play’ on your device.
Quick Start Guide
03.
10

The following controls will assist in the operation of
the Nomad 3 Mi+ Speaker:
Play/Pause/Answer Phone Calls
Once your device is connected to the Nomad 3 Mi+,
you can press the Power/Bluetooth button once to:
• Pause and play music
• Answer phone calls
Volume Control
Short press the +/- volume control buttons to increase
and decrease music and phone call volume.
Skip music tracks
Long press the volume control buttons to skip music
tracks:
• Long press ‘+’ button to skip to next song
• Long Press ‘-‘ button to skip to previous song
Operating Controls
04.
11

12
Connecting Multiple Devices via UNISYNC®
Using the UNISYNC®feature you can connect up to
50 UNISYNC®-compatible devices. In this example,
your Nomad 3 Mi+ is your primary device.
To connect a replica, short press the UNISYNC®
button on your primary device once to enter
UNISYNC®Mode. Once the primary announces it is
in UNISYNC®Mode, repeat on the replica. After the
replica announces it is in UNISYNC®Mode, press the
UNISYNC®button on the primary device once more –
the replica will announce it is using UNISYNC®Audio.
The primary speaker will show a solid blue light while
replicas will show a flashing red and blue light.
Press UNISYNC®button again to disable UNISYNC®.*
Press and hold the UNISYNC®button for five seconds
to reset the UNISYNC®function.**
*If UNISYNC®is disabled, Nomad 3 Mi+ will
disconnect from but remember the replicas connected
to it.
**Resetting UNISYNC®will enable Nomad 3 Mi+ to
‘forget’ all replica devices.
Operating Controls
04.

Specifications
05.
• Unit Size/Weight: 170 x 81.50x 73.50 mm
(L x W x H)
• Output Power: RMS 12W
• S/N Ratio: 85db +/- 3db
• Frequency Range: 90Hz - 20 kHz
• Power Source: 3.7V, 3000mAh Lithium Battery
• Playtime: 6hours from full charge at 75%
volume level
• Charging Time: Approximately 2-3hours
• Function: Bluetooth/Aux-in/Microphone/Powerbank
• Bluetooth: BT 5.1 Version + EDR
• Operating Temperature: 0-40°C
• Dust/Waterproof IP Code: IP67
• Drop-proof to 2m
13

14
Product Use and Care
06.
Nomad 3 Mi+ Bluetooth speaker is intended to be
used both indoors and outdoors. The speaker has
been tested to IP67 waterproofing and dustproofing
standards. IP67 standard allows Nomad 3 Mi+ to be
submerged in water up to 1 metre for 30 minutes
without any damage. However, Nomad 3 Mi+ is not
intended for constant underwater use.
Please ensure that the protective screw cap is
properly closed before use. The speaker will only meet
IP67 ratings if all rubber seals and cap are properly
locked and sealed. If Nomad 3 Mi+ is placed in water
without the protective screw cap securely closed,
water may enter Nomad 3 Mi+ and void its warranty.
Always make sure the protective screw cap is clean,
free of any debris and correctly fitted.
Included cables are not waterproof.
Important: The speaker will
only meet IP67 ratings if
all rubber seals and cap are
properly locked and sealed.

Product Use and Care
06.
If you notice a muffling of audio after submersion,
gently shake Nomad 3 Mi+ to clear excess water.
If your speaker is exposed to salt water clean it
thoroughly after use with fresh water. Do not apply
excessive force to any surfaces of Nomad 3 Mi+ when
wet or in a wet environment.
Avoid prolonged exposure to ultraviolet radiation (UV)
sunlight or magnetic fields.
Check the rubber seal periodically for premature wear
and clean Nomad 3 Mi+ with a soft moist cloth and
ensure no objects such as dirt, hair or sand are on
the rubber seal ring. Do not use any oily solvent or
chemicals for cleaning.
15

16
Important Safety Info
07.
Do not attempt to charge Nomad 3 Mi+ when it is
wet or you suspect water has seeped into the device.
Thoroughly dry Nomad 3 Mi+ and make sure all
connections are dry before attempting to open the
protective screw cap or connect a USB cable or power
source. Failure to do so may result in electrical shock,
fire or electrical damage to the Nomad 3 Mi+ and
may void the warranty.
Do not use the Nomad 3 Mi+ when you are charging
the battery.
Do not use the Nomad 3 Mi+ near an open fire, heat
source or excessive heat.
Do not open to modify, repair or remove any original
component of Nomad 3 Mi+. A qualified technician
must carry out repair work. Do not remove the
built-in battery or the grill cover. Doing so could cause
damage to Nomad 3 Mi+ and allow water to enter.
Sound levels should be appropriate to your
environment and comply with all local regulations.
Ensure that you can hear and are aware of any
potential hazards around you when you are enjoying
your Nomad 3 Mi+.

17

18
Consumer Guarantee
08.
Our goods come with guarantees that cannot be
excluded under the Australian Consumer Law. You
are entitled to a replacement or refund for a major
failure and compensation for any other reasonably
foreseeable loss or damage. You are also entitled to
have the goods repaired or replaced if the goods fail
to be of acceptable quality and the failure does not
amount to a major failure. If you have any questions
about your rights in relation to this product, please
return it to point of sale or contact us at
www.sproutinc.com.au.
Your Nomad 3 Mi+ Speaker is warranted to the
original owner for 24 months from the date
of purchase against defects in material and
workmanship under normal use and service. The
warranty does not cover misuse of this product and
liability will not exceed the purchase price of the
product. To obtain warranty service, please contact
the Sprout dealer from which you purchased this
product or visit www.sproutinc.com.au for further

Consumer Guarantee
08.
information about customer support. You will need
to return this product to the dealer or to Sprout
Accessories Pty Ltd in either its original packaging
or packaging affording an equal degree of protection.
You will bear the cost of shipping the product
to a Sprout Accessories Pty Ltd dealer or Sprout
Accessories Pty Ltd. This warranty does not affect
your legal statutory rights under the Australian
Consumer Law. For more information about your
rights under Australia Consumer Law go to
www.accc.gov.au.
For warranty and technical support please visit
sproutinc.com.au or contact us:
275 George Street, Brisbane QLD 4000
E[email protected]
Thank you for choosing a Sprout product.
19
