Sprout Immerse User manual

IMMERSE
BLUETOOTH
SPEAKER
PRODUCT MANUAL

01. What’s in the box? 2
02. Product overview 3
03. Quick star guide 4
04. Operating controls 6
05. Specifications 9
06. Imporant safety info 10
07. Consumer guarantee 11
CONTENTS
Scan the QR code
to access an online
version of this manual
WE PUT MORE INTO
OUR TECH, SO YOU CAN
GET MORE OUT OF LIFE.
At Sprout, our purpose is to help
you unlock the potential of your
technology. We’re an Australian
brand, and we design all of our
products locally to ensure they
are uniquely suited to your lifestyle.
1

01. What’s in the box? 2
02. Product overview 3
03. Quick star guide 4
04. Operating controls 6
05. Specifications 9
06. Imporant safety info 10
07. Consumer guarantee 11
CONTENTS
Scan the QR code
to access an online
version of this manual
WE PUT MORE INTO
OUR TECH, SO YOU CAN
GET MORE OUT OF LIFE.
At Sprout, our purpose is to help
you unlock the potential of your
technology. We’re an Australian
brand, and we design all of our
products locally to ensure they
are uniquely suited to your lifestyle.
1

1. WHAT’S IN THE BOX?
Thank you for choosing the Immerse Bluetooth
Speaker by Sprout.
For optimum perormance and safety, please read
instructions carefully before usage.
Please keep this manual for future reference.
1x Immerse Bluetooth Speaker
1x Australian standard charging adaptor power supply
1x Aux-in audio cable
1x Product manual
1. Wireless charging pads
2. Bluetooth buton
3. Power buton
4. UNISYNCTM buton
5. LED indicator
6. Batery LED indicator
7. Voice assistant buton
8. Volume down buton
9. Play/pause/answer
buton
10. Volume up buton
11. Ventilation
12. USB-C output
13. 3.5mm aux input por
14. Charging input
2. PRODUCT OVERVIEW
2 3 4 5 6 7 8 9
1 1 11
10
12 13 14
32

1. WHAT’S IN THE BOX?
Thank you for choosing the Immerse Bluetooth
Speaker by Sprout.
For optimum perormance and safety, please read
instructions carefully before usage.
Please keep this manual for future reference.
1x Immerse Bluetooth Speaker
1x Australian standard charging adaptor power supply
1x Aux-in audio cable
1x Product manual
1. Wireless charging pads
2. Bluetooth buton
3. Power buton
4. UNISYNCTM buton
5. LED indicator
6. Batery LED indicator
7. Voice assistant buton
8. Volume down buton
9. Play/pause/answer
buton
10. Volume up buton
11. Ventilation
12. USB-C output
13. 3.5mm aux input por
14. Charging input
2. PRODUCT OVERVIEW
2 3 4 5 6 7 8 9
1 1 11
10
12 13 14
32

CHARGING YOUR IMMERSE
1. Connect the speaker via the DC 15V/4.3A
charging input to a power source using the
included Australian standard power supply
2. The LED batery indicator will flash from one
to four LEDs to indicate Immerse is charging.
A full charge will take about 2-3 hours
CONNECTING VIA 3.5MM AUX CABLE
To play audio using the aux cable, connect the
cable from the Immerse to your device.
Please note: Using 3.5mm aux input will
override a Bluetooth source input.
CONNECTING VIA BLUETOOTH
1. Press the power buton for approximately three
seconds. The LED indicator will display as solid
blue to indicate power is on
2. Press the Bluetooth buton once. The LED Indicator
will flash red and blue to indicate Immerse is ready
for pairing*
3. Turn on Bluetooth on your mobile phone/music
device**
4. ‘Immerse’ will appear on your mobile phone/music
device. Select ‘Immerse’ to pair
5. Once your mobile phone/music device is
paired with Immerse, you will hear ‘Bluetooth
connected’***
3. QUICK START GUIDE 3. QUICK START GUIDE
6. Enjoy your music
*If the LED is not flashing red and blue, press the Bluetooth
buton one more time.
**If you are not familiar with Bluetooth pairing for your
mobile phone or music device, refer to the user guide for your
mobile phone/music device for instructions to pair a new
device using Bluetooth.
***Immerse will always store the last device paired and if the
device is within Bluetooth range, Immerse will automatically
connect to the device.
54

CHARGING YOUR IMMERSE
1. Connect the speaker via the DC 15V/4.3A
charging input to a power source using the
included Australian standard power supply
2. The LED batery indicator will flash from one
to four LEDs to indicate Immerse is charging.
A full charge will take about 2-3 hours
CONNECTING VIA 3.5MM AUX CABLE
To play audio using the aux cable, connect the
cable from the Immerse to your device.
Please note: Using 3.5mm aux input will
override a Bluetooth source input.
CONNECTING VIA BLUETOOTH
1. Press the power buton for approximately three
seconds. The LED indicator will display as solid
blue to indicate power is on
2. Press the Bluetooth buton once. The LED Indicator
will flash red and blue to indicate Immerse is ready
for pairing*
3. Turn on Bluetooth on your mobile phone/music
device**
4. ‘Immerse’ will appear on your mobile phone/music
device. Select ‘Immerse’ to pair
5. Once your mobile phone/music device is
paired with Immerse, you will hear ‘Bluetooth
connected’***
3. QUICK START GUIDE 3. QUICK START GUIDE
6. Enjoy your music
*If the LED is not flashing red and blue, press the Bluetooth
buton one more time.
**If you are not familiar with Bluetooth pairing for your
mobile phone or music device, refer to the user guide for your
mobile phone/music device for instructions to pair a new
device using Bluetooth.
***Immerse will always store the last device paired and if the
device is within Bluetooth range, Immerse will automatically
connect to the device.
54

POWER
Press the power buton for 3 seconds to turn the
Immerse on or of.
PLAY/PAUSE/ANSWER
Press the play/pause/answer buton to play or pause
songs and answer mobile phone calls.
VOLUME CONTROL
Shor press ‘-’ buton to decrease volume.
Shor press ‘+’ buton to increase volume.
TRACK CONTROL
Long press ‘-’ buton to select previous song.
Long press ‘+’ buton to select nex song.
BLUETOOTH
Press the Bluetooth buton to turn on/of the Immerse
Bluetooth function.
CONNECTING MULTIPLE SPEAKERS VIA
UNISYNCTM
If you are using the UNISYNC feature you can
connect one Immerse as a primary, then connect up
to 50 UNISYNC devices as replicas.
To connect a replica, shor press the UNISYNC
buton on your primary device once to enter
UNISYNC mode. Once the primary announces it is
in UNISYNC mode, repeat on the replica. Afer the
replica announces it is in UNISYNC mode, press the
UNISYNC buton once more – the replica should now
announce it is using UNISYNC audio. The primary
speaker will show a solid blue light while replicas will
show a flashing red and blue light.
Press UNISYNC buton again to disable UNISYNC.*
Press and hold the UNISYNC buton for five seconds
to reset the UNISYNC function.**
*If UNISYNC is disabled, Immerse will disconnect from but
remember the replicas connected to it.
**Reseting UNISYNC will enable Immerse to ‘forget’ all replica
devices.
WIRELESS CHARGING
The wireless charging pads conveniently recharge
your Qi-compatible devices.
4. OPERATING CONTROLS 4. OPERATING CONTROLS
76

POWER
Press the power buton for 3 seconds to turn the
Immerse on or of.
PLAY/PAUSE/ANSWER
Press the play/pause/answer buton to play or pause
songs and answer mobile phone calls.
VOLUME CONTROL
Shor press ‘-’ buton to decrease volume.
Shor press ‘+’ buton to increase volume.
TRACK CONTROL
Long press ‘-’ buton to select previous song.
Long press ‘+’ buton to select nex song.
BLUETOOTH
Press the Bluetooth buton to turn on/of the Immerse
Bluetooth function.
CONNECTING MULTIPLE SPEAKERS VIA
UNISYNCTM
If you are using the UNISYNC feature you can
connect one Immerse as a primary, then connect up
to 50 UNISYNC devices as replicas.
To connect a replica, shor press the UNISYNC
buton on your primary device once to enter
UNISYNC mode. Once the primary announces it is
in UNISYNC mode, repeat on the replica. Afer the
replica announces it is in UNISYNC mode, press the
UNISYNC buton once more – the replica should now
announce it is using UNISYNC audio. The primary
speaker will show a solid blue light while replicas will
show a flashing red and blue light.
Press UNISYNC buton again to disable UNISYNC.*
Press and hold the UNISYNC buton for five seconds
to reset the UNISYNC function.**
*If UNISYNC is disabled, Immerse will disconnect from but
remember the replicas connected to it.
**Reseting UNISYNC will enable Immerse to ‘forget’ all replica
devices.
WIRELESS CHARGING
The wireless charging pads conveniently recharge
your Qi-compatible devices.
4. OPERATING CONTROLS 4. OPERATING CONTROLS
76

LED INDICATOR
Solid blue LED indicates Immerse is switched on.
FLASHING
• Solid blue – Power on
• Flash blue/red – Power of
• Flashing blue/red – Bluetooth pairing mode
• Solid blue – Bluetooth connected
LED BATTERY INDICATOR
The batery LED indicator will flash from one to four
LEDs to indicate Immerse is charging. The lights will
stop flashing once Immerse is fully charged.
4. OPERATING CONTROLS
4 white lights on: Batery 76-100%
3 white lights on: Batery 51-75%
2 white lights on: Batery 26-50%
1 white light on: Batery 0-25%
• Weight: 1.9kg
• Output power: RMS 40W
• S/N ratio: 85db +/- 3db
• Frequency range: 90Hz - 20kHz
• Power source: 11.1V, 7800mAh lithium batery
• Playime: 4-5 hours from full charge at 75%
volume level
• Charging time: Approximately 2-3 hours
• Function: Bluetooth/ UNISYNC/ Aux-in/Microphone/
USB Type-C power output/ DC input/
Dual 10W wireless charging output
• Bluetooth version: 5.1
• Operating temperature: -10°C to 55°C
5. SPECIFICATIONS
98

LED INDICATOR
Solid blue LED indicates Immerse is switched on.
FLASHING
• Solid blue – Power on
• Flash blue/red – Power of
• Flashing blue/red – Bluetooth pairing mode
• Solid blue – Bluetooth connected
LED BATTERY INDICATOR
The batery LED indicator will flash from one to four
LEDs to indicate Immerse is charging. The lights will
stop flashing once Immerse is fully charged.
4. OPERATING CONTROLS
4 white lights on: Batery 76-100%
3 white lights on: Batery 51-75%
2 white lights on: Batery 26-50%
1 white light on: Batery 0-25%
• Weight: 1.9kg
• Output power: RMS 40W
• S/N ratio: 85db +/- 3db
• Frequency range: 90Hz - 20kHz
• Power source: 11.1V, 7800mAh lithium batery
• Playime: 4-5 hours from full charge at 75%
volume level
• Charging time: Approximately 2-3 hours
• Function: Bluetooth/ UNISYNC/ Aux-in/Microphone/
USB Type-C power output/ DC input/
Dual 10W wireless charging output
• Bluetooth version: 5.1
• Operating temperature: -10°C to 55°C
5. SPECIFICATIONS
98

6. IMPORTANT SAFETY INFO
1. Immerse Bluetooth Speaker is designed for
indoor use
2. Do not use Immerse in conditions that expose
it to liquid
3. Do not put metal objects or magnets between the
mobile device and the wireless charging surace
4. Ensure all ventilation openings remain clear and
dust free
5. Do not atempt to charge Immerse when
it is wet, or you suspect water has seeped
into Immerse
6. Do not use Immerse near any open fire, heat source
or excessive heat
7. Do not open to modify, repair or remove any original
component of Immerse. A qualified technician must
carry out repair work. Do not remove the buil-in
batery or the grill cover. Doing so could cause
damage to Immerse
8. Sound levels should be appropriate to your
environment and comply with all local regulations.
Ensure that you can hear and are aware of any
potential hazards around you when you are enjoying
your Immerse
All Sprout products go through thorough quality assurance
inspections. If you find that your device is excessively hot, is
emiting odour, is deformed, abraded, cut or is experiencing
or demonstrating an abnormal phenomenon, immediately
stop all product use and contact Sprout.
Our goods come with guarantees that cannot be
excluded under the Australian Consumer Law. You are
entitled to a replacement or refund for a major failure
and compensation for any other reasonably foreseeable
loss or damage. You are also entitled to have the
goods repaired or replaced if the goods fail to be of
acceptable quality and the failure does not amount to
a major failure. If you have any questions about your
rights in relation to this product, please return it to point
of sale or contact us at [e-mail].
This warranty does not afect your legal statutory
rights under the Australian Consumer Law. For more
information about your rights under Australia Consumer
Law go to .accc.gov.au.
Your Immerse Bluetooth Speaker is warranted
to the original owner for 24 months from the
date of purchase against defects in material and
workmanship under normal use and service.
The warranty does not cover misuse of this product
and liability will not exceed the purchase price of
the product.
If you have any problems while using the product,
please do not hesitate to contact our customer
suppor team.
For warranty and technical suppor please visit
sproutinc.com.au or email [e-mail].
Thank you for choosing a Sprout product.
7. CONSUMER GUARANTEE
1110

6. IMPORTANT SAFETY INFO
1. Immerse Bluetooth Speaker is designed for
indoor use
2. Do not use Immerse in conditions that expose
it to liquid
3. Do not put metal objects or magnets between the
mobile device and the wireless charging surace
4. Ensure all ventilation openings remain clear and
dust free
5. Do not atempt to charge Immerse when
it is wet, or you suspect water has seeped
into Immerse
6. Do not use Immerse near any open fire, heat source
or excessive heat
7. Do not open to modify, repair or remove any original
component of Immerse. A qualified technician must
carry out repair work. Do not remove the buil-in
batery or the grill cover. Doing so could cause
damage to Immerse
8. Sound levels should be appropriate to your
environment and comply with all local regulations.
Ensure that you can hear and are aware of any
potential hazards around you when you are enjoying
your Immerse
All Sprout products go through thorough quality assurance
inspections. If you find that your device is excessively hot, is
emiting odour, is deformed, abraded, cut or is experiencing
or demonstrating an abnormal phenomenon, immediately
stop all product use and contact Sprout.
Our goods come with guarantees that cannot be
excluded under the Australian Consumer Law. You are
entitled to a replacement or refund for a major failure
and compensation for any other reasonably foreseeable
loss or damage. You are also entitled to have the
goods repaired or replaced if the goods fail to be of
acceptable quality and the failure does not amount to
a major failure. If you have any questions about your
rights in relation to this product, please return it to point
of sale or contact us at [e-mail].
This warranty does not afect your legal statutory
rights under the Australian Consumer Law. For more
information about your rights under Australia Consumer
Law go to .accc.gov.au.
Your Immerse Bluetooth Speaker is warranted
to the original owner for 24 months from the
date of purchase against defects in material and
workmanship under normal use and service.
The warranty does not cover misuse of this product
and liability will not exceed the purchase price of
the product.
If you have any problems while using the product,
please do not hesitate to contact our customer
suppor team.
For warranty and technical suppor please visit
sproutinc.com.au or email [e-mail].
Thank you for choosing a Sprout product.
7. CONSUMER GUARANTEE
1110

Sprout Accessories Pty Ltd
W: Sproutinc.com.au | E: [e-mail]
