Relief Valve
DELTA UF3 (A) / UFR3 (A)
Instruction Manual: UK-7
APV
Content Page
1. General Terms 2
2. Safety Instructions 3 - 4
3. Intended Use 6
4. Mode of Operation
4.1. General terms
5. Auxiliary Equipment
6. Cleaning 8
7. Installation 10 - 11
7.1. Welding instructions
8. Dimensions / Weights 12
9. Technical Data 13
9.1. General terms
9.2. Compressed air quality
10. Maintenance
10.2 Assembly tool 4 - 15
11. Service Instructions 16 - 19
11.1. Dismantling from line system
11.2. Dismantling of wear parts (product-wetted parts)
11.3. Assembly of spring cylinder
11.4. Installation of seals and assembly of valve
11.5. Installation of valve
12. Installation of seat seal 20
12.1. Installation of seat seal in valve shaft
13. Trouble Shooting 21
14. Spare parts lists 22
UF3, UFE3, UFR3, UFRE3
I. spring cylinder, II. spring cylinder with seat lift actuator DN & Inch RN 01.054.53
UF3, UFE3, UFR3, UFRE3 - 3A design
I. spring cylinder, II. spring cylinder with seat lift actuator DN & Inch RN 01.054.574

2
APV_UF3-UFR3_UK-7_082017.indd
UK
Relief Valve
DELTA UF3 (A) / UFR3 (A)
Instruction Manual: UK-7
APV
1. General Terms
This instruction manual must be read and observed by the
responsible operating and maintenance personnel.
We point out that we will not accept any liability for damage or
malfunctions resulting from the non-compliance with this instruction
manual.
Descriptions and data given herein are subject to technical changes.
2. Safety Instructions
Danger!
The technical safety symbol draws your attention to important
directions for operating safety. You will find it wherever the activities
described are bearing health hazards or risks for persons or
material assets.
- Separate electric and pneumatic connections.
- Before any maintenance work the line system must be
depressurized and drained if possible.
- Observe the following Service Instructions to ensure safe
maintenance of the valve.
Danger!
- Do not touch the open valve or yoke!
Risk of injury due to sudden valve operation.
Risk of injury in dismantled valve state due to sudden valve
operation.
- Regular maintenance including the replacement of all seals and
bearing bushes must be scheduled in order to prevent leakages and
discharge of liquids.
- The valve must only be assembbled, operated, disassembled and
maintained by persons who have been trained accordingly.
If necessary, contact your local SPX FLOW representative.

3
APV_UF3-UFR3_UK-7_082017.indd
UK
Relief Valve
DELTA UF3 (A) / UFR3 (A)
Instruction Manual: UK-7
APV
2. Safety Instructions
Danger!
Welded actuators are preloaded by spring force.
Opening of the actuators is strictly forbidden.
Danger to life!
Actuators which are no longer used or defective must be diposed in
professional manner.
Defective actuators must be returned to your SPX FLOW
representative for their professional disposal and free of charge for
you.
Please address to your local SPX FLOW representative.
3. Intended Use
The intended use as field of application of the DELTA DELTA UF3
relief valve is to prevent the max. product pressure from being
exceeded or to discharge a certain product quantity.
Attention:
In the sense of the Pressure Equipment Directive 2014/68/EU, the
DELTA UF3/UFR3 relief valve is a "pressure-retaining component"
and is not a "component with safety function", i.e. the valve must
not be used as safety valve.
Its use is permissible only within the admissible pressure and
temperature margins and under consideration of chemical and
corrosive influences.
Any use exceeding the margins and specifications set forth,
is considered to be not intended.
Any damage resulting therefrom is not within the responsibility
of the manufacturer.
The user will bear the full risk.
Attention!
Improper use of the valve leads to:
- damage
- leakage
- destruction.
Failures in the production process are possible.
Arbitrary, constructive changes at the valve will influence safety
as well as the intended functionality of the valve and are not
permissible.
Authorizations and External Evaluations
ATEX (Directive 2014/34/EU)
3-A Sanitary Standards, Inc.

4
APV_UF3-UFR3_UK-7_082017.indd
UK
Relief Valve
DELTA UF3 (A) / UFR3 (A)
Instruction Manual: UK-7
APV
4. Mode of Operation
4.1. General terms
The valve has been developed for use in the brewing and beverage,
dairy and food industries as well as for chemical and pharmaceutical
applications.
The valves are designed for universal applications and stand out
for their increased mechanical reliability and absolute ease of
service.
The APV UF3/UFR3 relief valve is used to prevent a desired
product pressure from being exceeded due to process requirements
or to discharge a certain product quantity.
If the preset opening pressure is exceeded, the valve is opened
automatically by the imminent line pressure in the supply line (A)
under the valve seat. The liquid is drained via the discharge line (B).
If the adjusted set value falls short, the valve is closed by spring
force.
The flow direction is always from A B.
Attention:
In the sense of the Pressure Equipment Directive 2014/68/EU, the
DELTA UF3/UFR3 relief valve is a "pressure-retaining component"
and is not a "component with safety function", i.e. the valve must
not be used as safety valve.
Proximity switches to signal the valve position can be installed in the
yoke area (C).
APV DELTA UF3/ UFR3
relief valve
A
B
C

5
APV_UF3-UFR3_UK-7_082017.indd
UK
Relief Valve
DELTA UF3 (A) / UFR3 (A)
Instruction Manual: UK-7
APV
5. Auxiliary Equipment
5.1. Seat lift actuator (fig. 5.1)
The UF3 valve can be equipped with a seat lift cylinder if required
for cleaning technical reasons. (see chapter 6.)
5.2. Valve position indication
For the valve position indication, proximity switches can be installed
in the yoke area.
We recommend to use our APV standard types:
Operating distance: 5mm / Diameter: 11mm.
If the customer decides to use a valve position indication other
than APV type, we cannot take over any guarantee for a faultless
function.
5.3. Valve seat variants (fig. 5.3.)
Valve seat in at and conical design, for special requirements, are
available. Through the use of a valve seat with regulating cone,
the ow behaviour at low ow quantities is improved and a "softer"
valve closing is achieved.
The valve variant is called "UFR3".
5.4. Housing configurations (fig. 5.4.)
Different housing shapes can be applied to reduce dead spaces to a
minimum.
* The spring cylinder is available with scale and hand wheel to allow
for a simple adjustment of the response pressure (g. 5.5.).
* As a special version, the pressure relief valves are available in
aseptic design (with at diaphragm or metal bellow).
- Deviations from the standard spare parts lists result. These special
drawings and spare parts lists will be supplied separately.
-
seat lift actuator
hand wheel
scale
0-100%
regulating cone
fig. 5.3.
fig. 5.1.
fig. 5.4.
fig. 5.5.
UF31
UF32
UFE31
UFE33
UFE32
UFE34

6
APV_UF3-UFR3_UK-7_082017.indd
UK
Relief Valve
DELTA UF3 (A) / UFR3 (A)
Instruction Manual: UK-7
APV
6. Cleaning
Optimum cleaning is given if the seat lift actuator (E) drives
the valve seat into the position “on” during the cleaning process
(fig. 6.1).
During this process, the cleaning liquid can flush the seal
surfaces.
After termination of the cleaning step, the seat lift actuator is vented
and the valve seat moves into "closed" position by spring force.
6.1. The flow chambers
The passages of the valve are cleaned by the cleaning liquid during
cleaning of the connected pipelines.
Depending on the degree and substances of soiling, cleaning
liquids, times and processes must be scheduled for the individual
application.
The compatibility of the individually selected cleaning processes
and liquids with the respective seal material must be veried.
fig. 6.1.
seat lift cylinder
(E)
valve seat
regulating cone

7
APV_UF3-UFR3_UK-7_082017.indd
UK
Relief Valve
DELTA UF3 (A) / UFR3 (A)
Instruction Manual: UK-7
APV
7. Installation
7.1. General terms
Installation has to be done in such a way that liquids can drain off
the valve housing. Vertical position is preferred.
Valves can be welded direct into the pipeline (valve insert
completely dismantable).
- After the installation, the set value must be adjusted by a pressure
gauge.
Adjustment: turn right = pressure increase
turn left = pressure reduction
If required, the value can be corrected during production
by turning the adjusting screw at the spring cylinder.
Attention! Observe Welding Instructions 7.2.
7.2. Welding Instructions
- Before welding of the valve, the valve insert must be dismantled
from the housing. Careful handling to avoid damage to the parts
is necessary.
- Welding should only be carried out by certified welders (DIN EN ISO
9606-1). (Seam quality DIN EN ISO 5817).
- The welding of the valve housings must be undertaken in such a
way that the valve body is not deformed.
- The preparation of the weld seam up to 3 mm thickness must be
carried out as a square butt joint without air.
(Consider shrinkage!)
- TIG orbital welding is best!
- After welding of the valve housings or of the mating flanges
and after work at the pipelines, the corresponding parts of the
installation or pipelines must be cleaned from welding residues
and soiling.
If these cleaning instructions are not observed, welding residues
and dirt particles can settle in the valve and cause damage.
- Any damage resulting from the non-observance of these welding
instructions is not subject to our guarantee.

8
APV_UF3-UFR3_UK-7_082017.indd
UK
Relief Valve
DELTA UF3 (A) / UFR3 (A)
Instruction Manual: UK-7
APV
8. Dimensions / Weights
* *** *** **
Pressure range
(bar) A1 A2 Ø Di F L1 L2 Ø K Weight in kg
DN Inch flat cone with-
out with DN Inch with- out with with- out with
25 1" 0-6,8 0-5,4 310 395 26 22,2 50 360 445 53 2,4 4,9
25 1" 0-10,0 0-10,0 353 438 26 22,2 50 403 488 53 2,6 5,1
40 1,5" 0-3,5 0-2,9 316 401 38 34,9 67 383 468 53 3,3 5,8
40 1,5" 0-7,5 0-6,3 359 444 38 34,9 67 426 511 53 3,5 6,0
40 1,5" 0-10,0 0-10,0 389 474 38 34,9 67 456 541 85 5,6 8,1
50 2" 0-2,1 0-1,8 322 407 50 47,6 72 394 479 53 3,8 6,3
50 2" 0-4,5 0-4,0 365 450 50 47,6 72 437 522 53 4,0 6,5
50 2" 0-10,0 0-10,0 395 480 50 47,6 72 467 552 85 6,1 8,6
65 2,5" 0-1,2 0-1,1 330 415 66 60,3 85 415 500 53 5,2 7,7
65 2,5" 0-2,7 0-2,4 373 458 66 60,3 85 458 543 53 5,4 7,9
65 2,5" 0-7,6 0-7,0 403 488 66 60,3 85 488 573 85 7,5 10,0
65 2,5" 0-10,0 0-10,0 451 536 66 60,3 85 536 621 85 8,0 10,5
3" 0-1,1 0-1,0 333 418 72,9 90 423 508 53 6,6 9,1
3" 0-2,3 0-2,1 376 461 72,9 90 466 551 53 6,8 9,3
3" 0-6,5 0-6,0 406 491 72,9 90 496 581 85 8,8 11,3
3" 0-10,0 0-10,0 454 539 72,9 90 544 629 85 9,3 11,8
80 0-0,9 0-08 338 423 81 98 436 521 53 6,7 9,2
80 0-1,8 0-1,7 381 466 81 98 479 564 53 6,9 9,4
80 0-5,2 0-4,8 411 496 81 98 509 594 85 9,0 11,5
80 0-10,0 0-10,0 459 544 81 98 557 642 85 9,5 12,6
100 4" 0-0,6 0-0,5 347 432 100 97,6 111 458 543 53 8,5 11,0
100 4" 0-1,2 0-1,1 390 475 100 97,6 111 501 586 53 8,7 11,2
100 4" 0-3,5 0-3,2 420 505 100 97,6 111 531 616 85 10,8 13,3
100 4" 0-8,3 0-7,7 468 553 100 97,6 111 579 664 85 11,3 13,8
Di
ØK
L1
L2
A1
A2
F
F
spring cylinder with
seat lift actuator
* without/with regulating cone
** weight without/with seat lift actuator
*** dimensions without/with s.l. actuator
spring cylinder

9
APV_UF3-UFR3_UK-7_082017.indd
UK
Relief Valve
DELTA UF3 (A) / UFR3 (A)
Instruction Manual: UK-7
APV
9. Technical Data
9.1. General data
- Product-wetted parts: 1.4404 (DIN EN 10088)
- Other parts: 1.4301 (DIN EN 10088)
- Seals: standard design EPDM
- option: HNBR, VMQ, FPM
- max. line pressure 10 bar or acc. to
drawing data
- max. operating temperature: 135°C EPDM, HNBR
*FPM, *VMQ
- short-term load: 140°C EPDM,
HNBR *FPM, *VMQ
*(no steam)
- air connection (for hose): 6 x 1mm
- control pressure for seat lift actuator: 10 bar max. / 6 bar min.
Depending on the size of the spring cylinder, the response
pressure can be adjusted variably or up to max. 10 bar. (or
according to drawing data)
- The minimum response pressure can be > 0 bar depending on the
valve mounting position and the friction of the shaft seal.
Use dry and clean control air only!
9.2. Compressed air quality
- Compressed air quality: quality class according to ISO 8573-1
- Content of solid particles: quality class 3,
max. number of particles per m³
10000 of 0,5 μm < d ≤ 1,0 μm
500 of 1,0 μm < d ≤ 5,0 μm
- Content of water: quality class 3,
max. dew point temperature - 20 °C
For installations at lower temperatures
or at higher altitudes, additional
measures must be considered to reduce
the pressure dew point accordingly.
- Content of oil: quality class 1,
max. 0,01 mg/m³
The oil applied must be compatible with Polyurethane elastomer
materials.

10
APV_UF3-UFR3_UK-7_082017.indd
UK
Relief Valve
DELTA UF3 (A) / UFR3 (A)
Instruction Manual: UK-7
APV
10. Maintenance
The maintenance intervals depend on the corresponding
application and are to be determined by the operator himself
carrying out temporary checks.
The valve must not be cleaned with products containing abrasive
or polishing material. Especially the valve shaft must not, under
any circumstances, be cleaned with such agents. Damage of the
valve shaft can lead to leakages.
Exchange of seals is done according to Service Instructions.
Customer stock keeping of spare seals is recommended.
For valve service actions we supply complete seal kits
including seal grease (see spare parts lists).
Attention! Use food-grade grease and special greases being
suited for the respective seal material, only!
Recommendation:
APV assembly grease for EPDM, FPM, HNBR and NBR
(0,75 kg/tin - ref.-No. 000 70-01-019/93; H147382)
(60 g/tube - ref.-No. 000 70-01-018/93; H147381)
or
APV assembly grease for VMQ (Silicone)
(0,6 kg/tin - ref.-No. 000 70-01-017/93; H147380)
(60 g/tube - ref.-No. 000 70-01-016/93; H147379)
! Do not use grease containing mineral oil for EPDM seals.
! Do not use Silicone-based grease for VMQ seals.
Less suited grease types can influence function and service life.

11
APV_UF3-UFR3_UK-7_082017.indd
UK
Relief Valve
DELTA UF3 (A) / UFR3 (A)
Instruction Manual: UK-7
APV
.11. Service Instructions
Corresponding spare parts list:
DN design / Inch design:RN 01.053.53
DN design / Inch design:RN 01.054.574 (3A version)
11.1. Dismantling from the line system
1. Shut off line pressure in the product line and drain lines if possible.
2. Remove pneumatic air lines (seat lift actuator).
3. Release clamp screw at the feedback support and extract proximity
switches. (If valve is not equipped with feedback, omit 11.1.3).
4. Remove flange screws (10).
5. Screw two flange screws into the threaded bores of the valve yoke,
slightly lifting the complete valve insert.
6. Remove the flange screws and carefully lift the valve insert vertically
out of the valve housing.
10

12
APV_UF3-UFR3_UK-7_082017.indd
UK
Relief Valve
DELTA UF3 (A) / UFR3 (A)
Instruction Manual: UK-7
APV
11. Service Instructions
11.2. Dismantling of wear parts (product-wetted parts)
1. Remove housing screws (7) from housing cover (6).
2. Release screw of coupling (13) and dismantle.
3. Take the valve shaft (3) from the housing cover, simultaneously
removing the operating cam (12) and the intermediate piece (14) of
the UF valve without seat lift actuator.
4. Prick into the seat seal (2) with a peak object and carefully take it
out of the groove.
5. Release screw (11). This is to position the housing cover. Remove
the housing cover (6) and take out the two seal parts (4, 5).
6. Press the guide ring (8) out of the yoke flange.
7. Take the guide bush (9) out of the guide ring.
8. Remove the screws (16) and separate the complete spring
cylinder(21) from the yoke (15).
9. UF3 with seat lift actuator: remove the O-ring (19).
UF3 without seat lift actuator: remove the guide band (17).
11.3. Assembly of spring cylinder
1. UF3 with seat lift actuator: insert the O - ring (19).
UF3 without seat lift actuator: insert the guide band (17).
7
4, 5
8, 9
6
11
12
13
21
15
2
16
17
UF3 - without seat lift actuator

13
APV_UF3-UFR3_UK-7_082017.indd
UK
Relief Valve
DELTA UF3 (A) / UFR3 (A)
Instruction Manual: UK-7
APV
11. Service Instructions
11.4. Installation of seals and assembly of valve
1. Fasten the spring cylinder (21) at the yoke (15) by the screws (16).
2. Insert the guide bush (9) in the guide ring (8) and press the
complete unit into the yoke flange.
3. Insert the greased seal parts (4, 5) into the groove of the
housing cover.
4. Screw the housing cover (6) to the yoke (15) by the hexagon
screws (11).
5. Before installing the valve shaft, insert the seat seal (2).
* UF3 valve without regulating cone - use assembly tool for seat seal
(2).
* UF3 valve with regulating cone - install seal as follows:
Press the slightly greased seal at four spots, the wide side to the
front and the graduation to the top, into the groove. Introduce the
seal, at the four protuding loops, e.g. by a thin, dull screwdriver
into the groove and insert it by strong thumb pressure. Proceed
alternately at the four loops to get an even fit of the seal. Finally,
flatten the seal by strong pressure, e.g. by the handle of a
screwdriver and prick the blade of a small screwdriver between
the groove edge and the inner side of the seal down to the groove
ground to vent the groove.
Check the even fit of the seal after the installation.
6. UF3 valve without seat lift actuator - press the intermediate piece
(14) from the bottom into the spring cylinder (21).
7. Slide the shaft (3) carefully through the housing cover (6).
8. Attach the operating cam (12) on the valve shaft (3).
9. Push the valve shaft against the intermediate piece and connect
both shaft ends with the coupling clamp (13).
Attention: The distance tube must be between the two
coupling halves when tightening the screws.
The coupling screw must not slew into the
feedback area.
10. Check the firm fit of the adjusting screw (11).
11. Insert the slightly greased housing seal (7) into the groove of the
housing cover (6).
shaft with regulating
cone (3.1)
seat seal (2.1)
valve shaft (3)
seat seal (2)

14
APV_UF3-UFR3_UK-7_082017.indd
UK
Relief Valve
DELTA UF3 (A) / UFR3 (A)
Instruction Manual: UK-7
APV
11. Service Instructions
11.5. Installation of valve
1. Place the complete valve insert carefully into the valve housing
(1).
2. Enter the screws (10) and tighten them crosswise.
3. UF3 valve with seat lift actuator: mount the pneumatic air lines.
4. Installation of valve feedback.
basic adjustment: Push the proximity switch into the holder
with a 2 mm distance to the operating cam
(12)
fine adjustment: By slightly displacing the switch, the shift
point can be adjusted more precisely
if necessary. Observe the luminous
diode at the switch during this adjustment.
Fix the switch by the clamp screw.

15
APV_UF3-UFR3_UK-7_082017.indd
UK
Relief Valve
DELTA UF3 (A) / UFR3 (A)
Instruction Manual: UK-7
APV
12. Installation of Seat Seal
12.1. Installation of seat seal (2) in valve shaft
The assembly tool (fig. 12.1) consists of:
- nut
- thrust ring
- ring with venting nose
- housing
- threaded bolt
1. Insert the valve shaft into the housing in such a way that
the seal groove is in the housing.
2. Clamp the shaft into the housing by means of the threaded bolt.
3. Slightly grease the seat seal with APV assembly grease.
Then install the seal on the ring with the venting nose until it stops.
4. Introduce the ring with the installed seat seal into the housing and
press it down until it stops sensibly.
5. Insert the thrust ring into the housing. Screw on the nut and tighten
it with a hook spanner until it stops.
6. Release the nut. Take ring and thrust ring off the housing.
7. Take housing out of the vice, take off the threaded bolt.
Detach the valve shaft from the housing.
Check the even fit of the seat seal.
Attention:
The tool is not suited for the installation of seals in valve shafts
of UFR valves with regulating cone.
To simplify the installation of the seat seal, the
following assembly tools are available:
Assembly tool for seat seal
DN Inch Reference number ID number
25 1" 000 51-13-110/17 H179465
40 1,5" 0 0 0 51-13 -111/17 H179466
50 2" 000 51-13-112/17 H179467
2,5" 000 51-13-12017 H179468
65 000 51-13-113/17 H179469
3" 000 51-13-121/17 H179470
80 000 51-13-114/17 H179471
100 4" 000 51-13-115/17 H179472
nut
thrust ring
ring
seat seal
housing
shaft (flat)
threaded bolt
fig. 12.1.
