SQ Professional BLITZ User manual

instruction manual
BEFORE OPERATING THIS UNIT, PLEASE CAREFULLY READ THE FOLLOWING INSTRUCTIONS.
SQIM 9171-9172 22-05-2020 V4
instruction manual
HAND MIXER

SQIM 9171-9172 22-05-2020 V4 | SQ Professional Ltd © 2020 All rights reserved
Hand Mixer Instruction Manual
TABLE OF CONTENTS
CONTENTS
FEATURES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 4
SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 4
IMPORTANT SAFEGUARDS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 5
BEFORE FIRST USE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 5
ASSEMBLY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 5
CHOPPING TIPS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 6
CLEANING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 6
PROCESSING GUIDE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 6
WIRING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 7
ENVIRONMENTAL PROTECTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 7
SERVICE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 7
GUARANTEE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 7
2

All images are for illustration purposes only. Actual products may vary.
SAFETY
Hand Mixer Instruction Manual
IMPORTANT!
Due to sharp and fast moving parts and potential
hazards the appliance is not suitable for the use of
children under 8 years old.
When off please keep the appliance and mains cable out
of the reach of children.
Children over 8 must be supervised by an adult at all
times when using or cleaning the appliance.
This is not a toy!
The appliance can be used by persons with reduced
physical, sensory or mental capabilities if they have
been given supervision and instruction and understand
the use and hazards involved.
Always disconnect the appliance from the mains supply
socket if it is left unattended and before assembling,
disassembling or cleaning.
If the mains cable is damaged, it must be replaced by
qualified persons in order to avoid any hazards.
3

SQIM 9171-9172 22-05-2020 V4 | SQ Professional Ltd © 2020 All rights reserved
Hand Mixer Instruction Manual
FEATURES
FEATURES
1 Release Button
2 Speed Selector
3 Turbo Speed Button
4 Main Unit
5 Beaters
6 Dough Hooks:
6a Right Dough Hook (with metal collar)
6b Left Dough Hook
7 Attachment insertion openings:
7a O-opening (right)
7b D-opening (left)
8 Heel rest
SPECIFICATIONS
Rated Voltage: . . . . . . . . . . . . . .220-240V~
Frequency:. . . . . . . . . . . . . . . . . . .50Hz
Rated Power:. . . . . . . . . . . . . . . .300W
READ THE INSTRUCTIONS AND KEEP THEM SAFE. REMOVE ALL PACKAGING BEFORE USE.
2
3
4
5
8
6a
7a
6b
7b
1
4

All images are for illustration purposes only. Actual products may vary.
IMPORTANT SAFEGUARDS
Hand Mixer Instruction Manual
IMPORTANT SAFEGUARDS
WHEN USING ANY ELECTRICAL APPLIANCE, BASIC SAFETY PRECAUTIONS SHOULD ALWAYS BE FOLLOWED, INCLUDING THE FOLLOWING:
1 Read all instructions carefully before using the appliance.
2 This appliance is intended for household use only.
It is not suitable for commercial use such as staff
kitchen areas and other working environments.
3 Ensure that the appliance is always placed on a firm and flat
surface, away from the edge of the work top. Do not place the
appliance onto a metal tray or metal surface whilst in use.
Do not place the appliance on, or near, a hot gas or electric
burner or in a heated oven. Do not operate the appliance with
wet hands or barefoot.
4 Keep the appliance and cord away from the edges of work
tops and out of reach of children. Route the cable so it does
not overhang, and cannot be tripped over or caught.
5 Do not let the cable run across an open space, such as
between a low electrical outlet and a table, or across any hot
area, such as a cooker. Heat may damage the cord.
6 The connections on both sides of the cord (the appliance
and electrical outlet) should never be strained. If the cord is
damaged it must be replaced by a qualified person or service
to avoid any hazards.
7 Do not use the appliance in a bathroom, near
water, or outdoors. Do not immerse any of the
parts (Main Unit 4, cord, plug) in water or other
liquids to protect against fire, electric shock and
personal injury.
8 Do not use the appliance if it is damaged or
malfunctions. Do not leave the appliance unattended
whilst in use. Use and store it out of reach of children.
9 This appliance must not be operated by an external timer or
a remote control system.
10 SQ Professional Ltd may not be held liable for eventual
damages to persons, animals or objects caused by incorrect
installation or deriving from improper, erroneous or
unreasonable use.
11 This appliance is not suitable for processing very
hard ingredients, such as ice cubes, coffee beans,
hard spices and similar.
12 Keep hands, hair, clothing, and handheld
spatulas and other utensils away from Beaters
5or Dough Hooks 6during operation to
reduce the risk of injury to persons, and/or
damage to the appliance.
13 Ensure the Beaters 5or Dough Hooks 6are securely locked
in place before operating the appliance.
14 Switch off the appliance and unplug from the electrical
outlet before changing attachments or approaching parts
that move while in use. Unplug the appliance when not in
use.
15 Ensure that the appliance has come to a complete stop
before cleaning and storing away. Keep the attachments,
Main Unit
4
, cable, and plug away from sources of heat.
Store in a dry place.
16 Do not use this appliance for any other purpose
than its intended use.
17 Do not operate this appliance where oxygen is
being administered or in presence of explosive
and/or flammable fumes.
18 Only use the attachments supplied with this appliance to
prevent injury or damage.
SAVE THESE INSTRUCTIONS
FOR FUTURE REFERENCE!
BEFORE FIRST USE
19 Make sure your electricity supply is the same as the one
shown on the underside of the power unit.
20 Remove all the packaging and place the appliance on a dry,
flat, heat-resistant, non-flammable surface.
21 Wash and dry all the attachments thoroughly (see ‘Cleaning’).
ASSEMBLY
1 Turn the Speed Selector 2to “0” then insert the Beaters 5
into openings 7on the Main Unit 4and gently push until
they click in place.
2 To insert the Dough Hooks 6ensure that they are inserted
in their respective openings - the right dough hook 6a (with a
metal collar) must be inserted into the right opening 7a and
the left dough hook 6b into the left opening 7b .
3 Ensure that the Speed Selector 2is in the “0” position
before plugging the cord into the electrical outlet.
5

SQIM 9171-9172 22-05-2020 V4 | SQ Professional Ltd © 2020 All rights reserved
Hand Mixer Instruction Manual
USE & CARE
USING THE HAND MIXER
1 Assemble the hand mixer appropriate to the ingredients you
intend to use (see the table). Ensure the Speed Selector 2is
in the “0” position and plug the cord into the electrical outlet.
2 Lower the Beaters or Dough Hooks into the ingredients and
switch the appliance on by turning the Speed Selector 2
to position “1” and gradually increase speed by turning the
Speed Selector 2.
3 For extra power, press and hold the Turbo Speed button 3
and release it to return to previously selected speed
4 To temporarily stop mixing, switch the appliance off by
turning the Speed Selector 2to “0” position and place its
heel rest.
5 When mixing is finished, turn the Speed Selector 2to “0”
to switch the appliance off and unplug the cord from the
electrical outlet.
6 To remove or change attachments, position the Main Unit 4
over a bowl or sink, turn the Speed Selector 2to “0” then
firmly press the Release Button 1.
CLEANING
THE ATTACHMENTS SHOULD BE THOROUGHLY CLEANED AND DRIED
AFTER EVERY USE. ALWAYS MAKE SURE THAT THE APPLIANCE IS
UNPLUGGED BEFORE YOU ATTEMPT CLEANING. NEVER IMMERSE ANY
PART OF THE MAIN UNIT IN WATER OR RINSE IT UNDER THE TAP.
1 Turn the Speed Selector 2to “0” to switch the appliance off
and unplug the the cord from the electric outlet.
2 Press the Release Button 1to release the attachments from
the Main Unit 4.
3 Wash the Beaters 5or Dough Hooks 6with warm soapy
water or in dishwasher. Dry thoroughly before storing.
4 Wipe the Main Unit 4with a damp cloth and immediately
dry with a soft dry cloth. To clean stubborn spots, wipe the
surface with a cloth dampened in warm soapy water or a
mild, non-abrasive detergent. Wipe with a clean damp cloth,
then dry thoroughly.
5 Do not use any abrasive cleaners or harsh brushes or sponges
on any part of the Hand Mixer to prevent scratching of the
surface.
BEATERS
USE FOR: SPEED
Blending dry ingredients into liquid ingredients.
1
Folding flour into batters or cookie dough.
Mixing thin batters for waffles, pancakes and similar. 2
Mixing cake batters that require adding eggs or mixing cream or butter
and sugar 3
Beating eggs (yolks and whites), frostings, light batters or thin sauces 4
Whipping cooked potatoes, squash, turnips, thick soups
5
Whipping egg whites, cream, mayonnaise
DOUGH HOOKS To mix or blend yeast dough (breads, cakes), not longer than 5 minutes
at the time. 5
Turbo Speed Button is used when bursts of maximum power are needed for heavy mixing jobs. TURBO
6

13 AMP
All images are for illustration purposes only. Actual products may vary.
SERVICE & GUARANTEE
Hand Mixer Instruction Manual
WIRING
Should the power cable or the power plug become
damaged, arrange for these to be replaced by
Customer Service or qualified person before continuing
to use the appliance. This appliance is fitted with a 3A
BS1362 fuse in a BS 1363/A plug.
Do not use a non-wireable plug unless the fuse cover
is in place.
ENVIRONMENTAL PROTECTION
To avoid environmental and health problems due
to hazardous substances in electrical and electronic
goods, appliances marked with this symbol must
not be disposed of with unsorted municipal waste,
but recovered, reused or recycled.
SERVICE
The product is not user-serviceable. If it is not working, read the
instructions, check the plug fuse and main fuse/circuit breaker. If it
is still not working, consult your retailer.
If that does not solve the problem ring Customer Service – they may
be able to offer technical advice. Please have the Model Number
to hand, as they will not be able to help you without it.
If you are advised to return the product to us, pack it carefully,
include a note with your name, address, day phone number, and
description of the problem.
If under a guarantee, say where and when it was purchased and
include a valid VAT receipt. Send it to SQ Professional Ltd.
GUARANTEE
THE GUARANTEE FOR THIS PRODUCT IS COVERED BY
SQ PROFESSIONAL LIMITED. ANY FAULTS WITH THIS PRODUCT
ARISING THROUGH A MANUFACTURER DEFECT WILL BE COVERED
FOR 1 YEAR FROM THE DATE OF PURCHASE, SUBJECT TO A VALID
VAT RECEIPT BEING PRESENTED.
THIS DOES NOT INCLUDE FAULTS OR DAMAGE CAUSED BY MISUSE
OF GENERAL WEAR AND TEAR.
PLEASE CONTACT CUSTOMER SERVICES ON 01992 716 070
OR SEND AN E-MAIL TO [email protected],
MONDAY TO FRIDAY FROM 09:30 - 17:30.
THIS DOES NOT AFFECT YOUR STATUTORY RIGHTS.
7

SCAN THE QR CODE TO EXPLORE
OUR FULL PRODUCT RANGE.
Voltage Business Centre, Units 1 - 3
6 Mollison Avenue, Enfield, EN3 7XQ
T: 01992 716 070 | F: 01992 700 538
E: [email protected]
WWW.SQPROFESSIONAL.COM
