Squareled PQ1036 User manual

User Manual: PQ1036

PQ1036 - LED PAR 36*10w RGBW Quad-color 4 in 1 LED
Summarize
Thank you for purchasing our LED PAR lighting. Please read these instructions
carefully before begin and operate the xtures according to these instructions
to avoid any possible damages and accidents causes by misusage.
Products introduce
This led par color-changing projecting light is covered by high strength die-
casting aluminum which is able to endure high temperature, designed in a
fashion of hydrodynamic form. It takes uses high power 10w,RGBW 4-IN-1
LED, the color mixing eect is very good, high brightness. Each color can
be independently dimmer, fading changes and so on. It uses power switch,
performs low weight and consumption, stable capability and long life.The
built-in program includes dimmer, strobe, eotic, gradual change, fading and
so on. International standard DMX 512 signal is requested.
Packing List
»PQ1036 light 1PC (waterproof power in/out extension cable,waterproof
DMX in/out extension cable)
»waterproof power in cable 1PC (with plugs)
»waterproof DMX in cable 1PC(connect to the controller)
»The use manual
»Warranty Card
Manual | PQ1036 | 1. Summarize

Safety Information
Safety Notes
! Enquire the skilled people before any repair;
! Always make sure disconnect from the power source before setting up,
serving and moving;.
! Avoid direct eye exposure to the xture when it is on;
Safety instruction
»Make sure the power supply voltage are consistent with this lights
»Ensure the use of voltage is in the range of the request technical
parameter.
»before the installation, please check the light’s fasteners and mechanical
structure have been received in good condition and appear no damage.
»This light is designed for indoor use, working temperature is lower
than 40 degree.
»The xtures maybe mounted in any position provided there is adequate
room for ventilation. Make sure there are no inammable and explosive
items(ornaments) in 0.5 meters away.
»Yellow / green cabling earthling safety; no icker when the xture
is working on.

Outside Size Picture

2. DMX512 Channel Description
Order number Item Quantity Remarks Order number Item Quantity Remarks
1Front cover 1 11 Power main board
bracket
1
2Glass 1 12 Main board 1
3Glass waterproof
silicone
1 13 Display platen 1
4Lens plate 1 14 display 1
5Lamp panel 1 15 Silica gel tabletting 1
6bulb holder 1 16 waterproof silicone
7bracket 1 set 2PCS 17 Bottom base 1
8Bottom case cover 1 18 wire clip 1
9Bottom case waterproof
silicone
1 19 bumper bracket 1
10 Power supply 1

»Protection rating:IP65,in-door or out-door use
»unique cooling mode: natural convection
»DMX512 Controller, 4 button set DMX ID address with led display
»master slave/interconnected multi-machine control
»lens degree: 25º, 45º optional
»using switching power supply to protect the LED to work well
»R,G,B,W LED, dimmable separately
»Strobe, gradual change, jumping change
Main Function
»3CH
Channel DMX Value Control Function Remark
1CH 0-255 RGB mixing Hue
2CH 0-255 White diming 0-100% Color Saturation
3CH 0-255 General dimming 0-100% Purity
Note: In this mode, the color represents visible light, such as red, green, yellow, blue and so on. Color saturation
refers to proportion of the main color ,100% saturation means it has reached the solid.Value refers to the purity
of the color brightness, 100% is the brightest.
»4CH
Channel DMX Value Control Function Remark
1CH 0-255 R 0-100%
2CH 0-255 G 0-100%
3CH 0-255 B 0-100%
4CH 0-255 W 0-100%
»5CH
Channel DMX Value Control Function Remark
1CH 0-255 General dimming
2CH 0-255 R 0-100%
3CH 0-255 G 0-100%
4CH 0-255 B 0-100%
5CH 0-255 W 0-100%
DMX Control Function

»8CH
Channel DMX Value Control Function Remark
1CH 0-255 General dimming
2CH 0-255 Red Dimming 0——100%
3CH 0-255 Green Diming0——100%
4CH 0-255 Blue Dimming 0——100%
5CH 0-255 White 0——100%
6CH 0-14 Dimming When the 7CH above31, this function is invalid
15-255 Strobe Speed
7CH
0-31 Invalid
32-63 From dark to bright MustuseCH1,2,3,4,5otherwisenolight.Fromthe 8CH,startspeedadjustment
64-95 From bright to dark
96-127 From dark—bright—dark
128-159 RGB Gradient From the 8CH, start the speed adjustment
160-191 dark-bright-dark Automatic
192-223 4 colors jumping change
224-255 Manycolormixingjumpingchange
8CH 0-255 Speed adjust (7CH)
DMX Control Function
Display Operation
»MENU : access the menu or return to a previous menu option
»ENTER:select the current menu option
»UP:menu selection or parameter increments
»DOWN:menu selection or parameters decrease

Manual Instruction

Operations:
1. MENU is used to access the menu or return to a previous menu option. It can not be
used to select and store the current menu option. Press UP / DOWN to choose a desired
menu item. Here are the operation details:
»”addr”: DMX mode (A001-A512)
»“SLAV”:slave receive mode#
»“CHNd”:DMX channel (3,4,5,8CH)
»”SP”; built-in program speed change model (SP00-SP15, SP00 is the fastest)
»”Pr”; Built-in program (Pr00-Pr15 16 program in all)
»”ASC”; several colors jumping (AS00-AS15 speed adjustable)
»”FAdE”: gradual change model (FA00-FA15 speed adjustable)
»”FLAS”: white color strobe (FL00-FL15 speed adjustable)
»”rL”: red dimmer (r000-r255,, r255 is the brightest)
»”gL”: green dimmer (g000- g255, g255 is the brightest)
»”bL”: blue dimmer (b000- b255, b255 the brightest)
»”UL”: white dimmer (U000- U255, U255 the brightest)
»“nodE”: switchover DMX dimming mode (nod0 linear light, nod1/2 is built-in non-linear
light, change dimming output curve)
2. Press ENTER to access the further menu setting.This process can be saved automati-
cally; that means you will enter the process saved previously when you activate the light
next time. For example, if you want to choose DMX mode A001, operate as follows:
»Press MENU, go back to the initial setting
»Press UP / DOWN until Addr
»Press ENTER to choose, the display will glinting at this moment
»Press UP / DOWN to change the address code to select A001
»Press ENTER to select and store the current menu options. DMX mode will be stored
automatically and the screen will stop glinting
»DMX channel choosing Operation, CHNd mode
»Press Menu, go back to the initial setting

»Press UP/DOWN, until shows“CHNd”
»Press ENTER to access the menu items to select, the screen will now be glinting
»Press UP/DOWN to change the DMX Channel: 3CH, 4CH, 5CH, 8CH
»At last, press ENTER to conrm, if it delay for 3 seconds, DMX channel choosing will be
saved, and go back to DMX receive mode(A001); If your press ENTER for short time or not
press, delaying for 8 seconds, the DMX channel will select to be saved automatically, and
then go back to DMX receive mode(A001)
2. Details of program built inside(Pr- -)
NOTE:Pr14--- Pr30 Can change the content Of S, correct the speed of jumping change ,
SP00 is the fastest, SP15 is the slowest
»Pr00--- Pr13 :R,G,B,W single or multi-colors mixing.
»Pr14--- Pr27: corespond to Pr00--- Pr13,add strobe.
»Pr28:four colors jumping change.
Operating Control Instruction
Master/Slave
Master:The master should always work as a master and send out synchronizing si-
gnal as long as it is not set in a DMX mode (Addr), Slave mode(SLAV), DMX channel
mode(CHND), nodE mode. To avoid the host signal and DMX512 signals interfere with
each other, should cut o the DMX512 signals. The signal lines are longer than 60 me-
ters(20 lamps) ,should increase a signal amplier.
Slave: he Slave must be set in DMX mode and the address code should be A001, to assure
receive the master’s signals correctly. Only one light can be set as a Master and others are
slaves.
Note:This product uses input and output power cord 2.5 m2copper core wire, power
line in series, when 220V AC should less than 15lights, and 110V AC less than 8 lights!

XLR cable connecting
XLR cable
The standard connection way of the XRL is: one end connect to the male plug ,and the
other connect to the female.
Noted: In order to avoid failures and interference signal transmission, we connect a
resistance120Ω (1/4W) at the end of the DMX connecting as below:
The Conversion between 3pin and 5 pin XLR
If the output cable of DMX512 controller is the 5PIN, please use 1pc 5PIN to 3PIN cable.

Connecting picture: Light connecting picture
Connecting picture: Great waterproof PAR lamp wiring diagram

Problem Analyse
Problem Checking way
Can not turn on the light
Check the power source plug is in normal or not
Check the switch of the lights is o or on
Check the fuse if in normal
DMX can not control it
Check the DMX cable is connect to the lights or not
Check the DMX512 controller work in normal or not
Check the DMX cable is normal or not
Check if the lights is in DMX mode(A001)
Display not bright
When connect to the electricity, did the led ash one time? If so, the power source is
normal; If not, please check if the switch and the transformer has power out
Check if the power input of the IC board is normal
Check if the cable connect to the display loose
Change the main board to see if it is normal.
Chang the display
LED not light
When connect to the electricity, did the led ash one time? If so, the power source is
normal; If not, please check if the switch and the transformer has power out
Check if the power input of the IC board is normal
Check if the cable connect to the display loose
Change the main board to see if it is normal.
Chang the display
Some of the LED not light
LED is connect by leds in series rst, then connect parallel, so please check if the leds is
loose
Use the multimeter to check if the led is bright or not, of not, please change the led
check whether current limiting resistor is normal or not
Check constant current IC is normal or not (compared with the normal IC)
Single color leds always
bright/not bright
Check the switch of this color is normal or not
Change the IC control board
Noted: only professional persons can do as above！

Technical Specication
»Input voltage: AC 90-135V/47-63HZ AC 170V-264V/47-63HZ
»Output voltage: DC24V
»Consume: 350W
»Lamp Type: High Power LED(10w)
»Lamp Spec: RGBW 4-in-1 LED(36 pcs)
»Constant current drive: 500mA
»Refresh Rate: 400HZ
»Life Span: 50000~100000 hours
»Control Signal: DMX512, master and slaver
»Control mode: stand alone/ DMX/ master and slaver
»Channel: 3,4,5,8 CH
»Function Eect: dimmer, strobe, eotic, gradual change
»Beam Angle: 25° or 45°
»Cooling mode: Natural Convection
»Protection rate:IP65
»Anti-electricity intension: 1.5KV
»Insulation Resistance: MΩ
»Size: 325*272*351mm
»Net Weight: 13kg
