Ss Brewtech Brew Cube User manual

Page 1
ENGINEERING BETTER BEER
Brew Cube│Product Guide

Page 2
OVERVIEW
IN THE BOX
(2) Frame (1) Top Plate│Solid
Note: Additional plates sold
seperately
(4) Threaded Foot
(4) 12” Leg
(8) Silicone Hole Plug
(8) Silicone Strip
(4) 3/8” - 16 x 2” Stainless
Steel Frame Screws

Page 3
OVERVIEW
FRAME ASSEMBLY

Page 4
INSTRUCTIONS
FRAME ASSEMBLY
½” MAX
1. Apply a Silicone Strip to the top surface on each member of the square top Frame (4 strips per
frame). If an additional Plate will be used, also apply a Silicone Strip to each member of the square
bottom Frame.
Note: Top surface has the large corner holes
2. Insert the Threaded Feet through the corner holes on the bottom side of the bottom Frame (oppo-
site the side that has the Silicone Strips applied). The washer on the Threaded Feet should be in
direct contact with the bottom face of the bottom Frame.
Note: 1/2” max distance between the nuts on the base foot
3. If an additional plate will be used, position the countersinks of the Bottom Plate over the large
holes on the bottom Frame.
4. While holding the leg steady, thread the Threaded Feet into the Legs to fasten the Leg and bottom
Frame together. It is recommended to not twist the Legs during assembly to prevent detachment of
the silicone at each end of the Legs. Wait to fully tighten the Threaded Feet until step 9.
←
←

Page 5
5. Place top Frame onto the Legs with the Silicone Strips facing up.
6. Position the countersinks of the Top Plate over the large holes on the top Frame.
7. Use the four 3/8” - 16 x 2” Stainless Steel Frame Screws to secure the Top Plate and Frame to
the Legs.
8. Fully tighten the screws until just past snug. Do not overtighten.
9. Fully tighten the nuts on the Threaded Feet until just past snug. Do not overtighten.
10.Insert the Silicone Plugs into any of the external accessory mounting holes in the top and bottom
Frame.
INSTRUCTIONS
FRAME ASSEMBLY (CONTINUED)

Page 6
COMPLETED ASSEMBLY

Page 7
COMBINING BREW CUBES
COMPONENTS SHOWN
FRAME ASSEMBLY
(2) 12” Brew Cube Kit
(1) Connection Bolts Kit
(2) extra Top Plate (optional)

Page 8
INSTRUCTIONS
COMBINING BREW CUBES
1. Refer to the Brew Cube Product Guide for
assembly of the rst Brew Cube. The top and
bottom holes on one side of the Brew Cube will
be used for the attachment hardware. Silicone
Hole Plugs will not be needed on this side.
2. For the second Brew Cube, use (2) 3/8”-16x2-1/4” screw and washer assemblies in place of two
Threaded Feet as shown above. The top and bottom holes on one side of the Brew Cube will be used
for the connection hardware. Silicone Hole Plugs will not be needed on this side.
3. Lay both Brew Cubes on their side and assemble the (4) 3/8”-16x3-1/2” screw, washer, and nut
assemblies on the top and bottom holes as shown. Wait to fully tighten the hardware until all four
screws have been installed. Fully tighten the hardware until just past snug. Do not overtighten.

Page 9
COMPLETED ASSEMBLY

REV 07102020
