St Helens GH516 User manual

GH516
Mop Holder
User Manual
Please retain for future reference

IMPORTANT
Installer and users please note:
Please read the enre instrucon manual before using the product and then save it for future reference.
We reserve the right for any errors in text or images and any necessary changes made to technical data.
PRODUCT SAFETY
 Prior to the installaon of this product, the installaon instrucons should be read and completely
understood. The installaon instrucons must be read to prev ent personal injury and. Keep these
installaon instrucons in an easily accessible locaon for future reference.
 CAUTION: the maximum load capacity for the unit is 15kg (screw fied) and 7.5kg (adhesive pad); max
load per individual mop clamp is 2.5kg. Exceeding the maximum load capacity may cause injury.
 Do not install on a structure that is prone to vibraon, movement or chance of impact.
 CAUTION: Before installaon, a full survey of the mounng area must be conducted, to ensure that it
is suitable for the weight of the bracket and is free from pipes, electric cables or any other obstrucons.
FITTING INSTRUCTIONS
A - ADHESIVE PAD FITTING
1. Gently remove an end-cap hook from the aluminium rail
2. Slide the adhesive pads into the track on the rear of the rail and replace the end-cap hook
3. Space the pads evenly across the rail and remove the film from the pads
4. Posion the mop holder in the required locaon and affix using the adhesive pads, press the pads
firmly into the surface and take care to expel any air bubbles that have formed under the pad
B – SCREW FITITNG
1. Locate the 2x fixing holes in the recessed part of the aluminium track (note, it may be easier to
remove an end cap and slide all the components out the rail – they can then be replaced in any order
required)
2. Posion the mop holder in the required locaon and use these fixing holes to mark drilling locaons
on the wall (use a spirit level to achieve a level fing)
3. Pre-drill the wall and (if required) fit rawl plugs
4. Fix using appropriate screws
USAGE INSTRUCTIONS
 Simply push a mop handle (pole diameter 18-30mm), held vercally, into the holder and the
silicon grip will ‘lock’ the mop in place. To remove, simply pull the mop away from the wall.
CLEANING INSTRUCTIONS
The holder should be cleaned periodically with warm water and mild detergent.
SERVICE WARRANTY
Electrovision guarantees the product free from defects in materials and workmanship for a period of 1
year. Should this unit be used under condions other than those recommended, or any aempts made to
service or modify the unit, then the warranty will be rendered void. The product you buy may somemes
differ slightly from illustraons. This warranty is in addion to, and does not affect, your statutory rights.
If you have any problems with this product, please call our help desk on [phone].
Electrovision Ltd. Lancots Lane, Suon, St. Helens, Merseyside, WA9 3EX
www.Electrovision.co.uk
