Stagnoli ULIXES 230V User manual

Istruzioni Instructions Anleitungen Instructions Instrucciones Instruções
I - Motoriduttore elettromeccanico per cancelli battenti
GB - The electromechanical gear motor for swing gates
ULIXES
Rev. 0 - 03/05
1

Istruzioni Instructions Anleitungen Instructions Instrucciones Instruções
Attention!
• This manual is for qualified installers only and not for the end user. It is the installer’s job to
explain to the user how the automatism works, about possible hazards related to it and the
need for periodical maintenance.
• Installation must be carried out by qualified personnel only, in compliance with current
standards concerning automatic closing mechanisms.
• ULIXES is made specifically to control the automation of swing gates and therefore it is
forbidden to use it for any other purposes or improperly.
• Use original components only. Stagnoli is not liable for damages if any other components
are used.
• Make sure that the gate structure is solid and suitable to be motorised.
• Make certain that when the gate is moving there are no points of friction and there is no
chance of it derailing.
• Make absolutely certain the power is disconnected before carrying out any work on the
device.
• Connect the power lead only to supply lines with adequate electrical protection.
• Be particularly careful when evaluating the safety devices to install and their location.
Always install an emergency stop device that will cut power off in the case of necessity.
• The irreversible gearmotor avoids installing an electric lock and in case of black-out the
release with personal single key allows the gate to be easily opened and closed.
Nevertheless the electronic lock should be installed to assure a better closing above all by
wings longer than 2.5 meters.
13

Istruzioni Instructions Anleitungen Instructions Instrucciones Instruções
ARGOwallmounted
optic-eye
ASM1keyselector
PEGASUSflashinglight
POLIFEMOpostmountedoptic-eye
ZEUSTransmitter
3x1.5
230V
Controlpanel
2x1- TX
2x1.5
TRG58
4x1RX
4x1.5
4x1.5
2x1TX
2x1
4x1RX
ULIXES 230V: residential application
ULIXES230Vswinggategear
motor
14

Istruzioni Instructions Anleitungen Instructions Instrucciones Instruções
Ulixes technical features
Technical data ULIXES 230V ULIXES 24V
Supply power 230V~ (50Hz) 230V~ (50Hz)
Max. Input current (A) 1.3 1
Motor power supply 230V~ 24V –––––
Max. Motor power (W) 160 W 120 W
Capacitor 10 µF -
Working travel (mm)* 350 – 500 350 – 500
Travel time* (sec) 20 - 35 20 - 35
Rpm 1000 1100
Reduction ratio 1/24 1/24
Thrust force Adjustable (max. 2500 N) Adjustable (max. 2500 N)
Working temperature (°C) -20 ↔+60 -20 ↔+60
Thermal overload protection (°C) 150 -
Work cycle (%) 30 70
IP protection level 44 44
Weight* (Kg) 9 9
Note: working travel, the length of the automation and weight depend on the ULIXES model
used.
Overall dimensions
118
139
139
118
Ulixes 350
Ulixes 500
810
958
Travel 350
Travel 500
15

Istruzioni Instructions Anleitungen Instructions Instrucciones Instruções
Limits of use
LEAF 2 m
2.5 m
3 m
3.5 m 4 m 4.5 m 5 m
300 kg
ULIXES
350
ULIXES
350
ULIXES
350
ULIXES
350
ULIXES
500
ULIXES
500
ULIXES
500
400 kg
ULIXES
350
ULIXES
350
ULIXES
350
ULIXES
500
ULIXES
500
500 kg ULIXES
350
ULIXES
350
ULIXES
500
ULIXES
500
600 kg ULIXES
350
ULIXES
350
ULIXES
500
700 kg ULIXES
350
ULIXES
500
800 kg ULIXES
350
ULIXES
500
900 kg ULIXES
500
1000 kg ULIXES
500
Releasing manually
1. Slide the lock cover forwards
2. Turn the key
3. Pull the handle until it is perpendicular to the motor
90°
0°
3
2
1
16

Istruzioni Instructions Anleitungen Instructions Instrucciones Instruções
Preliminary checks
Check the following points before commencing to install Ulixes:
• Check that the gate structure is sufficiently robust and there are no points of friction.
• Check the condition of the gate hinges; make sure they are adequately lubricated.
• Check there is a mechanical stop in closing.
• Check value “C” before installing, observing the specifications in the assembly table (tab.1).
By increasing value “B” the opening angle is reduced, peripheral speed and the thrust of the motor on the
gate is increased; to the contrary, by increasing “A”the opening angle is increased, peripheral speed and
the thrust of the motor on the gate is reduced.
DA
B
Opening
A
B
C
OPENING A B C D
Travel 350 90°140 140 60 570
Travel 350 115°160 150 40 550
Travel 500 90°140 140 60 720
Travel 500 115°160 150 40 700
Tab.1
17

Istruzioni Instructions Anleitungen Instructions Instrucciones Instruções
Fixing the brackets to the post and gate
After having verified the optimum conditions for placing the plates and their alignment, fix them to the
post and gate permanently, either welding them or utilising expansion bolts (if the post is made of brick),
observing the value specified in Fig. 2.
28
Bottom edge of the
bracket fixed to the gate
Bottom edge of the
bracket fixed to the post
Fig.2
Fixing the gear motor
Lock the gear motor at the back with the M8 hex head screw with nut and washer (Fig.3).
Fig.3
Fit the nut screw on the front bracket pin and tighten the traverse screw to lock it in the working position
(Fig. 4).
Fig. 4
18

Istruzioni Instructions Anleitungen Instructions Instrucciones Instruções
ULIXES 230V electrical connections : after having made the last checks with the motor already
fixed to the gate, wire as shown in Fig. 5. For more specifications please see the diagrams for connecting
to the control unit.
(light blue)
Common
Capacitor
Wire connecting to the control unit
Phase (brown)
+ capacitor cable
Phase (black)
+ capacitor cable
Ground
(yellow-green)
Fig.5
ULIXES 24V electrical connections :
after having made the last checks with the motor already fixed
to the gate, wire as shown in Fig. 6. For more specifications please see the diagrams for connecting to the
control unit
ENCODER
+24V
-24V
Fig. 6
19

Istruzioni Instructions Anleitungen Instructions Instrucciones Instruções
Below is the exploded diagram of the Stagnoli Ulixes motor for swing gates.
10
18
5
7
8
9
24(x2)
14
28
48
24(x3)
47
46
45
44
43
39
38
40
41
42
37
36
35
34
33
32
31
30
29
28
27
26 25
24(x2)
23(x2)
22
21 20
19
17
16
13
12x3
11
6
4
3
2-2A
1-1A
Rev.1 del 25/08/04
24(x6/x7)
ULIXES 230V
15
49
50(x2)
20

Istruzioni Instructions Anleitungen Instructions Instrucciones Instruções
10
5
7
8
9
24 (x2)
28
48
24 (x6/x7)
47
46
45
44
43
39
38
40
41
42
37
36
35
34
33
28
27
26 25
12x3
11
6
2-2A
62-62A
Rev.1 del 25/08/04
61
58
57
56
59
55 51
3
22
23 (x2)
63 (x2)
53
52
15
17
54
19
20
60
32
31
30
29
ULIXES 24V
50 (x2)
49
21

Istruzioni Instructions Anleitungen Instructions Instrucciones Instruções
Posiz Componente Q.ta' Codice Posiz Componente Q.ta' Codice
1 Base portamotore corto C.A. 1 44 Snodo posteriore 1
1A Base portamotore lunga C.A. 1 45 Dado autobloccante 1
2 Guscio superiore corto 1 46 Vite per snodo 1
2A Guscio superiore lungo 1 47 Perno di oscillazione 1
3 Calotta motore 1 48 Tassello sblocco 1
4 Culatta portacuscinetto CA 1 49 Bloccacavo BLO-R 5N 1
5 Leva sblocco 1 50 Vite x fissaggio bloccacavo 2
6 Supporto sblocco 1 51 Culatta porta cuscinetto e spazzole C.C. 1
7 Blocca copri chiave 1 52 Albero motore C.C. 1
8 Copri chiave 1 53 Tubo motore Ø80 1
Serratura cilindro italiano 1 X13A03 54 Cuscinetto albero motoreC.C. 1
Rosetta elastica con dentatura 1 55 Vite fissaggio motore C.C. 2
Vite testa cilindrica con calotta 1 56 Encoder 1
10 Piastrina sagomata per cilindro italiano 1 57 Vite di fissaggio encoder 1
11 Spina cilindrica di tenuta leva sblocco 1 58 Lettore encoder 1
12 Viti sblocco 3 59 Viti di fissaggio scheda lettore encoder 2
Albero motore C.A. 1 60 Coperchio encoder 1
Rotore C.A. 0 61 Viti di fissaggio coperchio encoder e
messa a terra 3
14 Statore C.A. 1 X61A470 62 Base portamotore corto C.C. 1
15 Anello elastico di compensazione 1 62A Base portamotore lunga C.C. 1
16 Cuscinetto albero motore C.A. 1 63 Viti fissaggio culatta versione CC 2
17 Paraolio albero motore C.A. 1
18 Cuscinetto albero motore C.A 1
19 Vite messa a terra 1
20 Morsettiera a 4 poli 1
21 Condensatore 1
22 Guarnizione 1
23 Passacavi a membrana 2
24 Viti fissaggio gusci
Ingranaggio conico conduttore con inserto 1
Inserto ruota conica 1
26 Bussola anteriore ingranaggio conico 1
27 Chiavetta di sblocco 1
28 Molla di sblocco 2
29 Ruota dentata elicoidale 1
30 Seeger di tenuta ing. Elicoidale 1
31 Bussola posteriore ingranaggio conico 1
32 Perno sblocco 1
Ingranaggio conico condotto con inserto 1
Inserto per detto ing. Conico 1
34 Cuscinetto per ingranaggio con. in uscita 1
35 Boccola di fermo 1
36 Grani di bloccaggio boccola di fermo 2
37 Vite TE 440 a 5 PRINCIPI passo 4 D=20 1
37A Vite TE 590 a 5 PRINCIPI passo 4 D=20 1
38 Madre vite 1
39 Bussola madre vite 1
40 Bussola vite 1
41 Vite di aggancio staffa a madrevite 1
42 Staffa piana 1
42A Staffa ad angolo
43 Piastra piana 1
43A Piastra ad angolo
25
33
ULIXES corsa 350-500
9
13 X61A468
13-14x CA
8-9x CC
22

Istruzioni Instructions Anleitungen Instructions Instrucciones Instruções
23

Istruzioni Instructions Anleitungen Instructions Instrucciones Instruções
Stagnoli s.r.l.
Via Mantova, Traversa 1^, 105 A/B-25017 Lonato (Bs) - Italia
Tel. [phone] Fax. [phone]
www.stagnoli.com
