Stanley Argon Built 3 Sided User manual
Argon Built 3 Sided
NMARBI1003SXD
NMARBI1253SXD
2
TABLE OF CONTENTS
Please read and carefully follow all of the instruction found in this manual. The instructions
included here will assure that you have many years of dependable and enjoyable service
from your Stanley product.
IMPORTANT INSTRUCTIONS ......................................................................................................................................... 3
UNPACKING AND TESTING THE APPLIANCE .......................................................................................................... 4
LOCATING THE FIREPLACE ........................................................................................................................................... 4
SAFETY DRILL SCREW AREA ....................................................................................................................................... 4
MANTEL CLEARANCE ..................................................................................................................................................... 4
NMARBI1003SXD ............................................................................................................................................................... 5
NMARBI1253SXD ............................................................................................................................................................... 6
INSTALLATION ................................................................................................................................................................ ..
MEDIA OPTIONS .............................................................................................................................................................. 13
DECORATIVE MEDIA INSTALLATION ...................................................................................................................... 13
OPERATION ....................................................................................................................................................................... 14
MANUAL OPERATION ................................................................................................................................................... 14
REMOTE CONTROL OPERATION ................................................................................................................................ 15
WIFI OPERATION ............................................................................................................................................................. 18
CARE AND MAINTENANCE ......................................................................................................................................... 21
REPLACEMENT PARTS .................................................................................................................................................. 22
EXPLODED VIEW ............................................................................................................................................................ 23
TROUBLE SHOOTING ..................................................................................................................................................... 24
SERVICE HISTORY .......................................................................................................................................................... 25
WARRANTY ...................................................................................................................................................................... 26
3
IMPORTANT INSTRUCTIONS
PLEASE RETA N TH S USER GU DE FOR FUTURE REFERENCE
When using electrical appliances, basic precautions should always be followed to reduce the
risk of fire, electric shock, and injury to persons, including the following:
1) Read all instructions before using this fireplace
2) The fireplace is hot when in use. To avoid burns, do not let bare skin touch hot surfaces.
Keep combustible material such as furniture, cushions, bedding, paper, clothes, curtains
at least 3 feet/ 915mm from the front of the unit
3) Extreme caution is necessary when any heater is used near children and whenever the
unit is left operating and unattended.
4) Do not operate a fireplace with a damaged cord or plug, or if the heater has
malfunctioned, the fireplace has drooped or damaged in any manner
5) This fireplace is not suitable for use in wet areas such as bathrooms or utility rooms.
6) Do not run the cord under carpeting. Do not cover cord with throw rugs, runners or the
like. Arrange the cord away from traffic area and where it will not be tripped over
7) Do not modify this fireplace. Use it as described in the manual. Any other use not
recommended by the manufacture may cause fire, shock or injury to persons
8) Do not use this heater with programmer, timer, separate remote-control system or any
other device that switches the heater on automatically, since a fire risk exists if the heater
is covered or positioned incorrectly
9) Disconnect all power supply before cleaning, maintenance or relocation of the fireplace
10) Keep the heater clean. Do not allow any objects to enter any ventilation or exhaust
opening as this may cause electric shock, fire or damage to the heater
11) Do not immerse the cord, plug or any part of the appliance in water or any other liquid
12) n order to avoid a hazard due to inadvertent resetting of the thermal cut-out, this
appliance must not be supplied through an external switching device
CAUTION: Procedures and techniques, which, if not carefully followed, will result in damage to
the equipment.
WARNIN : Procedures and techniques, which, if not carefully followed, will expose the user to
the risk of fire, serious injury, illness or death.
SAVE THESE INSTRUCTIONS
Always use a certified electrician should new circuits or outlets be required, the socket or
switched fused spur should be accessible at all times to isolate the product.
Carefullyremove the appliance from the box. Prior to installing the appliance, test to make sure the
appliance operates properly by plugging the power supply cord into a conveniently located 240 Volt
grounded outlet.
Plan where to locate and frame the fireplace. This will save time and money later when you install
thefireplace. Before installation consider the following:
1. Where the fireplace is located must allow for wall and ceiling clearances (see INSTALLATION)
2. Consider a location where the fireplace screen will not be exposed to direct sunlight from
windows ordoors.
3. A15 ampere, 240 Volt, 50 Hz branch circuit with proper ground must be available at the location.
Preferably a dedicated branch circuit should be provided to avoid circuit breakers to trip of fuses
to blow.
Safety drill screw area
(Dark area)
6"
Fireplace Mantel
Wall (Combustible facing allowed)
Floor
Fireplace
NMARBI1003SXD
5
Description Built-inAppliance
Voltage 230V ac 50Hz
Watts 1900WMax
NOHEATER 26W
MOTOR HEATER 19W
ApplianceWidth 43 1/4”or1098 mm
ApplianceHeight 26 5/8”or676 mm
ApplianceDepth 14 1/4”or362 mm
Gross Weight
PlugLocation Left side
Cord Length 707/8”or1800 mm
RoughWall OpeningSize 43 3/4”27 5/8“or
1365 mm 702 mm
BTU 6500
119.05lbs or 54kg
4314" [1098]
5" [126] 1558" [398]
2658" [676]
3958" [1007] 1358" [347]
1414" [362]
614" [160]
Description Built-in Appliance
Voltage 230V ac 50Hz
Watts 1900WMax
NO HEATER 29.3W
MOTOR HEATER 19W
Appliance Width 53 1/4!or1351 mm
Appliance Height 26 5/8!or676 mm
Appliance Depth 14 1/4!or362 mm
Gross Weight
Plug Location Left side
Cord Length 70 7/8 !or 1800 mm
Rough Wall Opening Size 53 3/4! 27 5/8"or
1365 mm 702 mm
BTU 6500
128.31lbs or 58.2kg
5314" [1351]
5" [126] 1558" [398]
2658" [676]
4958" [1261] 1358" [347]
1414" [362]
614" [160]
1. Product is fixed with fending bars and panels
on the left and right side.
2. Take off the fending bars and panels if you
want to view the fire from three angles.
3. Fix back the fending bar after the panel is
removed.
4. Remove the framing plates from the fireplace
and fix them as the picture shows.
Note: After removing framing plates on the left
and right sides, screw back the screws.
The rough wall opening size of the fireplace:
fending bar
fending panel
W
D
H
5.Makeanopeningforthefireplaceaccording
torequestedmeasurement.
framing plate
framing plate
7.Aftercheckingthatthefireplaceoperates
properly,covertheglasspanelswithprotective
plasticbag and install plywood or drywall.
6.Insertthefireplaceintothewall opening.
Drivethemountingscrewsintotheframeplates
ontheunitandthewall studs. To fixthebottom
ofthefireplace and thewall studs withthe
framingplatesthatyou’veremovedfromleft
and rightsideofthefireplace atSTEP4. Plugin
and check ifthefireplace works.
8.Decoratetheplywood or drywall with glazed
tile,wallpaper,etc.
3.Afterthefendingpanelisremoved,screw
backthebar.
4.Removetheframingplatesfromthefireplace
and fixthemasthepictureshows.
Note:Afterremovingframingplatesontheleft
and right sides, screwbackthescrews.
InstallationforFrontand RightSide
Viewing
1.Toinstall thefireplacewheretheleft sideis
closetoawall, andyouwanttoviewthefire
fromfrontand right side,takeoffthefending
panelontheright.
fendingbarand panel.
2.Unscrew7screwsontheright sidethatfix
thefendingbar andpanelandthentakeoffthe
9
8.Decoratetheplywood or drywall with glazed
tile,wallpaper,etc.
5.Makeanopeningforthefireplaceaccording
torequestedmeasurement. 7.Aftercheckingthatthefireplaceoperates
properly,covertheglasspanelswithprotective
plasticbag and install plywood or drywall.
6.Insertthefireplaceintothewall opening.
Drivethemountingscrewsintotheframeplates
ontheunitandthewall studs. To fixthebottom
ofthefireplace and thewall studs withthe
framingplatesthatyou’veremovedfromleft
and rightsideofthefireplace atSTEP4. Plugin
and check ifthefireplace works.
10
3.Afterthefendingpanelisremoved,screw
backthebar.
4.Removetheframingplatesfromthefireplace
and fixthemasthepictureshows.
Note:Afterremovingframingplatesontheleft
and right sides, screwbackthescrews.
InstallationforFrontandLeftSide
Viewing
1.Install thefireplacewheretherightsideis
closetoawall, andyouwanttoviewthefire
fromfront andleftside,takeoffthefending
panelontheleft.
5.Makeanopeningforthefireplaceaccording
torequestedmeasurement.
2.Unscrew7screwsontheright sidethatfix
thefendingbar andpanelandthentakeoffthe
fendingbarand panel.
11
8.Decoratetheplywood or drywall with glazed
tile,wallpaper,etc.
7.Aftercheckingthatthefireplaceoperates
properly,covertheglasspanelswithprotective
plasticbag and install plywood or drywall.
6.Insertthefireplaceintothewall opening.
Drivethemountingscrewsintotheframeplates
ontheunitandthewall studs. To fixthebottom
ofthefireplace and thewall studs withthe
framingplatesthatyou’veremovedfromleft
and rightsideofthefireplace atSTEP4. Plugin
and check ifthefireplace works.
12
4. Installing the fire glass media. Pour the fire
glass media into the tray as shown below.
Feelfree to use any combination of fire glass
media that you find most appealing.
5.Put back the front glass and screw back the
bracket.
3. Take off the front glass panel and put it in safe place.
1. Unscrew 2 screws and take off two brackets which
are fending the front glass panel.
Screws and brackets
2. After the brackets are removed, the front glass panel
will fall down automatically.
Oak log set
Suntea Clear glass Vermiculite
14
OPERATION
Plug the fireplace into a 15 Amp wall socket.
MANUAL OPERATION
Plug the fireplace into a 15 Amp wall socket.
The Fireplace operates by using either the touch panel located on the upper left hand corner
or by remote control.
1.
2.
Press to turn on and off the fireplace.
Press to adjust the flame brightness. There are 6 brightness levels（L6-L1） and
an off(OF) position. Each time the flame button is pressed, the brightness of the flame
decrease.
press the flame button for 10 seconds, the timing indicator light on and will rapidly
blinks, at this time, You can use the TuyaSmart APP to connect to the fireplace.
3. Press to adjust the ember Bed /Moodlight brightness. There are 11 brightness.
levels (d11-d2), dynamic condition(d1) ,and the OFF(OF) setting you can cycle through.
4. Press to set the turn-off time, 30min-1h-2h-3h-4h-5h-6h-7h-8h-t0. The indicator light
the current timing. If the timing in off position, the second press will show 30. Multiple times
to set operating duration to OF, 30 min, 1h, 2h, 3h, 4h, 5h, 6h, 7h, 8h.
5. Press or the first time to display the current setting temperature，press the button
again to clear the current temperature. If the heater in off position, the second press will
show 22℃(72℉).Multiple times to set ambient temperatures at 22℃( 72℉) , 23℃
(74℉) ,24℃( 76℉) , 25℃( 78℉) , 26℃( 80℉) , 27℃( 82℉) , 28℃( 84℉) ,15℃( 52℉) ,
16℃( 54℉) , 17℃( 56℉) ,18℃( 58℉) , 19℃( 60℉) , 20℃( 62℉) , 21℃( 64℉) .
Temperature unit convert functionZ When the heater is on, press and hold the“ ”
Button for 5 seconds, current temperature unit display will convert to another temperature
unit.
B
U（℃）（）
H1 means the firepalce on Low Heat/ 50W.
H2 means the fireplace on High Heat/1 00W.
16
Press this button to adjust the speed of the flame. There are 3 options: High-
Medium- Low.
The Ember bed /moodlight Button turn the ember bed or moodlight on and off.When
in on position,the display screen of the remote control shows AD1.,when the
number“1”flash,you can set the color with or keys. There are 10 different
colors (AD1-10) and dynamic condition(AD11) to choose from.
Press the Flame button to turn on and off the Flame. When in ON position, the LCD
screen of the remote control shows 6 6 6. Press or or to change
the brightness of each color flame.
7 Day Timer Function
Press once, 7 days from Monday to Sunday will display on the LCD screen of
the remote control, press within 5 seconds to enter 7 day timer function. When
“Sun” flashes, press or to select the day that you want to set, press to
confirm your setting. Then “ON” will be display on the LCD screen of the remote
control, at the same time, digital of time hour flashes, press or to set the
time to turn the fireplace on. After setting the startup time, “OFF” will be displayed on
the LCD screen and press or to set the shutdown time. When the
shutdown time’s set, “AUTO” will be displayed on the LCD screen of the remote
control and the digital of temperature flashes. At this time, you can set the
temperature by or . Now, you have finished setting of this function.
AUTO means fireplace can automatically adjust to the temperature you set. When in
AUTO, you can set the desired temperature with or keys. You can switch
temperature between Celsius and Fahrenheit with or keys.When it is on Auto
mode,fireplace operate at 1 00W.
9
17
When the 7 day timer’s set, the icon will be displayed on the LCD screen of the
remote control. Press again to cancel the 7 da
will disappears.
NOTE: If the 7 day timing and the general timing are set at the same time, the
system will respond to an earlier shutdown time.
Press Refer button to check the settings of 7 day timer. Press or to see the
settings of the day of the week and or the settings of the startup and
shutdown time.
y timer and the icon
1
WIFI OPERATION
IN TALL Tuya mart life
There are 2 ways to install TuyaSmart;
1. Search for “TuyaSmart life” in the APP store on your phone, download and install.
2. Scan the QR code below with your mobile phone.
WIFI ETTING AND FIREPLACE OPERATION
1. Create an account and log in.
2. When you log in, touch “+” (FIG.1) to enter in FIG.2. Touch “others” on the left corner first
and then choose “Connector (Wi-fi)” to enter in FIG.3 to set your Wi-fi account and
password.
FIG.1 FIG. 2 FIG.3
19
FIG.4
3. Press (flame button) on the touch panel of the fireplace for more than 5 seconds
when the fireplace in standby mode. There will be 2 beeps come out from the fireplace
and the (flame button) will flash as well indicating that Wi-fi is in EZ mode. Then
please confirm to go next. (FIG.5)
4. The APP will scan (FIG.6) and add the fireplace to APP (FIG.7) automatically. Please
make sure the Wi-fi account and password you set are correct and Wi-fi signal is good.
5. Touch “Done” to finish Wi-fi setting.(FIG.7)
FIG.5 FIG.6 FIG.7
NOTE: Turn off the flashing blue Wifi indicator light
Touch the (power button) once, the blue light will stop flashing.
This manual suits for next models
2
Table of contents
Other Stanley Indoor Fireplace manuals
Popular Indoor Fireplace manuals by other brands
Continental Fireplaces
Continental Fireplaces EFL42 Installation and operating instructions
Desa
Desa VK36N SERIES OWNER'S OPERATION AND INSTALLATION MANUAL
Empire
Empire VSM-18-1 Installation instructions and owner's manual
Lenoxx
Lenoxx LF100 Important instructions & operating manual
Empire
Empire DVCP32BP30N-4 installation instructions
Dimplex
Dimplex DWOP20R owner's manual
IN & OUT HOUSE
IN & OUT HOUSE EF160B instruction manual
kozy heat
kozy heat windom 56101 Installation and operation manual
Empire Comfort Systems
Empire Comfort Systems DVX36FP32CLN-2 Installation instructions and owner's manual
FMI
FMI 36EMW-RBC Owners & installation manual
Monessen Hearth
Monessen Hearth IDV490NV Installation and operating instructions
Travis Industries
Travis Industries 21 DV RV user manual
Superior Fireplaces
Superior Fireplaces VRT4032WS Installation and operation instruction
Hearth & Home
Hearth & Home DVLINEAR36 Series owner's manual
Temco
Temco DV1000N/P Installation and operating manual
CHAD-O-CHEF
CHAD-O-CHEF VFG 600 Installation & operating instruction manual
Amantii
Amantii BI-40-DEEP Installation and operation instructions
Global Fires
Global Fires Fantasy SC Installation and maintenance instructions
