Stanley NMARBI100 User manual

SAFETY INFORMATION
WARNING
If theinformationintheseinstructionsare
not followed exactly,afireorexplosion
mayresult causingpropertydamage,
personalinjuryorlossoflife.
Do not storeoruse gasolineorotherflammablevapors
and liquidsinthevicinity ofthisorany otherappliance.
INSTALLER:LEAVETHIS MANUALWITH THE APPLIANCE.
CONSUMER:RETAINTHISMANUALFOR FUTURE REFERENCE.
Version:202111
NMARBI100
NMARBI130
Argon Built In

2
TABLE OF CONTENTS
Please read and carefully follow all of the instruction found in this manual. The instructions
included here will assure that you have many years of dependable and enjoyable service
from your Stanley product.
IMPORTANT INSTRUCTIONS ......................................................................................................................................... 3
UNPACKING AND TESTING THE APPLIANCE .......................................................................................................... 4
LOCATING THE FIREPLACE ........................................................................................................................................... 4
NMARBI100 ......................................................................................................................................................................... 5
NMARBI130 ......................................................................................................................................................................... 6
SAFETY DRILL SCREW AREA ..................................................................................................................................... ..7
MANTEL CLEARANCE ................................................................................................................................................... ..7
INSTALLATION ................................................................................................................................................................ ..
MEDIA OPTIONS .............................................................................................................................................................. 13
MEDIA INSTALLATION ................................................................................................................................................. 13
OPERATION ....................................................................................................................................................................... 14
MANUAL OPERATION ................................................................................................................................................... 14
REMOTE CONTROL OPERATION ................................................................................................................................ 15
WIFI OPERATION ............................................................................................................................................................. 17
CARE AND MAINTENANCE ......................................................................................................................................... 20
REPLACEMENT PARTS .................................................................................................................................................. 21
EXPLODED VIEW ............................................................................................................................................................ 22
TROUBLE SHOOTING ..................................................................................................................................................... 23
SERVICE HISTORY .......................................................................................................................................................... 24
WARRANTY ...................................................................................................................................................................... 25

IMPORTANT INSTRUCTIONS
PLEASE RETA N TH S USER GU DE FOR FUTURE REFERENCE
When using electrical appliances, basic precautions should always be followed to reduce the
risk of fire, electric shock, and injury to persons, including the following:
1) Read all instructions before using this fireplace
2) The fireplace is hot when in use. To avoid burns, do not let bare skin touch hot surfaces.
Keep combustible material such as furniture, cushions, bedding, paper, clothes, curtains
at least 3 feet/ 915mm from the front of the unit
3) Extreme caution is necessary when any heater is used near children and whenever the
unit is left operating and unattended.
4) Do not operate a fireplace with a damaged cord or plug, or if the heater has
malfunctioned, the fireplace has drooped or damaged in any manner
5) This fireplace is not suitable for use in wet areas such as bathrooms or utility rooms.
6) Do not run the cord under carpeting. Do not cover cord with throw rugs, runners or the
like. Arrange the cord away from traffic area and where it will not be tripped over
7) Do not modify this fireplace. Use it as described in the manual. Any other use not
recommended by the manufacture may cause fire, shock or injury to persons
8) Do not use this heater with programmer, timer, separate remote-control system or any
other device that switches the heater on automatically, since a fire risk exists if the heater
is covered or positioned incorrectly
9) Disconnect all power supply before cleaning, maintenance or relocation of the fireplace
10) Keep the heater clean. Do not allow any objects to enter any ventilation or exhaust
opening as this may cause electric shock, fire or damage to the heater
11) Do not immerse the cord, plug or any part of the appliance in water or any other liquid
12) n order to avoid a hazard due to inadvertent resetting of the thermal cut-out, this
appliance must not be supplied through an external switching device
CAUTION: Procedures and techniques, which, if not carefully followed, will result in damage to
the equipment.
WARNIN : Procedures and techniques, which, if not carefully followed, will expose the user to
the risk of fire, serious injury, illness or death.
Consult with professional electrician and adhere to all code requirements for
installations in bathrooms
SAVE THESE INSTRUCTIONS
3

UNPACKINGANDTESTINGAPPLIANCE
Carefullyremovetheappliancefromthebox. Priortoinstallingtheappliance,testtomakesurethe
applianceoperatesproperlybypluggingthepowersupplycordintoaconvenientlylocated240Volt
groundedoutlet.
LOCATINGTHEFIREPLACE
Planwhere tolocateandframethefireplace.This will savetimeandmoneylaterwhenyouinstall
thefireplace.Beforeinstallationconsiderthefollowing:
1. Where thefireplaceis locatedmust allowforwallandceilingclearances(see INSTALLATION)
2. Consideralocationwhere thefireplacescreenwill notbeexposedtodirectsunlight from
windowsordoors.
3. A15 ampere,240 Volt,50 Hz branchcircuit with properground mustbeavailableatthelocation.
Preferablyadedicatedbranchcircuitshouldbeprovidedtoavoidcircuitbreakerstotripoffuses
toblow.
4

Description Built-inAppliance
Voltage 230V ac 50 Hz
Watts 1900WMax
NOHEATER 25W
MOTOR HEATER 19W
ApplianceWidth 38 5/8”or98.1 cm
ApplianceHeight 23 5/8”or60 cm
ApplianceDepth 6 3/4”or17.2 cm
Gross Weight 88 lbsor40kg
PlugLocation Left side
Cord Length 707/8”or180 cm
RoughWall OpeningSize 40”25“or
101.6 cm 63.5 cm
BTU 6500
NMARBI100
5

ModelNumber BI-50-SLIM
Voltage 230V ac 50Hz
Watts 1900WMax
NOHEATER 25W
MOTOR HEATER 19W
ApplianceWidth 48 5/8”or123.5cm
ApplianceHeight 23 5/8”or60 cm
ApplianceDepth 6 3/4”or17.2 cm
Gross Weight 105.6 lbsor48kg
PlugLocation Left side
Cord Length 707/8”or180 cm
RoughWall OpeningSize 50”25“or
127 cm 63.5 cm
BTU 6500
NMARBI130
6

Thereis asafetydrillscrewareaasshow below.
Pleasemakesurethat thefixscrewsare inthis area.
Safetydrill screwarea
(Darkarea)
MANTEL CLEARANCE
4"
Fireplace Mantel
Wall (Combustible facing allowed)
Floor
Fireplace
SAFETY DRILL SCREW AREA
7
The clearance to the mantel should be 4”/ 105mm minimum when a mantel is applied
(Measurement is taken from the trim).

Theroughwall openingsizeof thefireplace:
1. Takeouttheunit fromthebox.Pleasedo thepre-testbeforeyouinstall the fireplace. Pull
outtheoptionaltrim fromtheunit as shows below.
optional trim
Note:Theoptional trim can bepulledoutdirectlyfromtheunit.Itwill need twopeopletodoit.
INSTALLATION
This series of models are designed to be built-in and allow for finishing material (drywall, stone, tile,
etc) to be built right down to the glass edge. However, that application is not always desirable or
available so the surround could be used as an alternate finish option.
w D H
NMARBI100 40”/ 101.6cm 7”/ 17.78cm 25”/ 63.5cm
NMARBI130 50”/ 127cm 7”/ 17.78cm 25”/ 63.5cm

2. Removetheframingplates fromtheunit
framing plate
3. Re-fixtheframingplates to theunit as thepicture shows
framing plate
9

4. Bend up theframingplates.
5. Puttheunit into theopening.
10

6. Drivethemountingscrews into theframingplates on theunit and thewall studs.
Fireplace
framing plate
7. After checkingthatthefireplace operatesproperly,cover theglass panelwith
protectiveplasticbagand install plywood or drywall.
NOTE: In order to use the supplied trim kit, the thickness of the desired wall finish
can not exceed 1 inch.
11

Fireplace
9. Put back the optional trim, that you've removed from the unit at step 1 if required.
trim
8. Decoratetheplywood or drywall with glazed tile, wallpaper, etc.
12

13
1. Take off the front glass. There is a
bracket holding the front glass which
shows as below. Unscrew the screw and
take off the bracket. Turn around and
insert into the gap. Hook the front glass
and pull it out.
2. Installing the fire glass media. Pour the
decorative media into the tray. Feel free
to use any combination of fire glass
media that you find most appealing.
3. Put back the front glass and screw back
the bracket.
20
MEDIA OPTIONS
MEDIA INSTALLATION
The media that come with this appliance are
og Set, Clear glass, Suntea glass and White
Vermiculite. Consumers may purchase optional
decorative media if they choose. See dealer for
more details.
Log set
Suntea Clear glass Vermiculite

OPERATION
Plug the fireplace into a 15 Amp wall socket.
MANUAL OPERATION
Plug the fireplace into a 15 Amp wall socket.
The Fireplace operates by using either the touch panel located on the upper left hand corner
or by remote control.
14
1.
2.
Press to turn on and off the fireplace.
Press to adjust the flame brightness. There are 6 brightness levels（L6-L1） and
an off(OF) position. Each time the flame button is pressed, the brightness of the flame
decrease.
press the flame button for 10 seconds, the timing indicator light on and will rapidly
blinks, at this time, You can use the TuyaSmart APP to connect to the fireplace.
4. Press to set the turn-off time, 30min-1h-2h-3h-4h-5h-6h-7h-8h-t0. The indicator light
the current timing. If the timing in off position, the second press will show 30. Multiple times
to set operating duration to OF, 30 min, 1h, 2h, 3h, 4h, 5h, 6h, 7h, 8h.
5. Press or the first time to display the current setting temperature，press the button
again to clear the current temperature. If the heater in off position, the second press will
show 22℃(72℉).Multiple times to set ambient temperatures at 22℃( 72℉) , 23℃
(74℉) ,24℃( 76℉) , 25℃( 78℉) , 26℃( 80℉) , 27℃( 82℉) , 28℃( 84℉) ,15℃( 52℉) ,
16℃( 54℉) , 17℃( 56℉) ,18℃( 58℉) , 19℃( 60℉) , 20℃( 62℉) , 21℃( 64℉) .
Temperature unit convert functionZ When the heater is on, press and hold the“ ”
Button for 5 seconds, current temperature unit display will convert to another temperature
unit.
3. is void in this model.

15
REMOTE CONTROL OPERATION
For remote to function make sure the fireplace is plugged in and the remote has batteries.
Important: When operating the remote make sure you point the remote to the center of the
fireplace. Each time you press the button, the buzzer inside the unit will beep once. It takes
some time for the receiver to respond to the transmitter. Do not PRESS the buttons more
than once within two seconds for correct operation.
Set the current time of the remote control
Press the to activate the remote control and press to set the time and date.
When one of the “Sun” “Mon” “ Tue” “Wed” “Thu” “Fri” “Sat” is flashing, press or to
set the day of the week, press to confirm day of the week and then enter hour setting.
Press or to set the hour, press to confirm the hour and then enter minute
setting. Press or to set the minute and press to confirm the minute and
finish time setting.
Press this Power button to turn on and off the fireplace.
Press this Timer button to set the time to turn off the fireplace.
The available settings range from 3 minutes to 8 hours. As
shown in the following: :3 - 1: - 1:3 - 2: - 2:3 - 3: -
3:3 - 4: - 4:3 - 5: - 5:3 - 6: - 6:3 - 7: - 7:3 - 8: .
Once you have set the timer, the icon will be displayed
on the LCD screen of the remote control. Press this button
again to cancel the timer setting and the icon disappears.
Each time the Heater Button is pressed, the power of the
heater will change. As shown the following: H1- H2-
AUTO（22℃）- OFF（no display）
H1 means the fireplace on Low Heat/950W
H2 means the fireplace on High Heat/1900W

This button is void in this model.
Press this button to adjust the speed of the flame. There are 3 options: High-
Medium- Low.
Press the Flame button to turn on and off the Flame. When in ON position, the LCD
screen of the remote control shows 6 6 6. Press or or to change
the brightness of each color flame.
7 Day Timer Function
Press once, 7 days from Monday to Sunday will display on the LCD screen of
the remote control, press within 5 seconds to enter 7 day timer function. When
“Sun” flashes, press or to select the day that you want to set, press to
confirm your setting. Then “ON” will be display on the LCD screen of the remote
control, at the same time, digital of time hour flashes, press or to set the
time to turn the fireplace on. After setting the startup time, “OFF” will be displayed on
the LCD screen and press or to set the shutdown time. When the
shutdown time’s set, “AUTO” will be displayed on the LCD screen of the remote
control and the digital of temperature flashes. At this time, you can set the
temperature by or . Now, you have finished setting of this function.
AUTO means fireplace can automatically adjust to the temperature you set. When in
AUTO, you can set the desired temperature with or keys. You can switch
temperature between Celsius and Fahrenheit with or keys.When it is on Auto
When the 7 day timer’s set, the icon will be displayed on the LCD screen of the
remote control. Press again to cancel the 7 da
will disappears.
NOTE: If the 7 day timing and the general timing are set at the same time, the
system will respond to an earlier shutdown time.
Press Refer button to check the settings of 7 day timer. Press or to see the
settings of the day of the week and or the settings of the startup and
shutdown time.
y timer and the icon
16
mode, fireplace operate at 1900W.

17
WIFI OPERATION
IN TALL Tuya mart life
There are 2 ways to install TuyaSmart;
1. Search for “TuyaSmart life” in the APP store on your phone, download and install.
2. Scan the QR code below with your mobile phone.
WIFI ETTING AND FIREPLACE OPERATION
1. Create an account and log in.
2. When you log in, touch “+” (FIG.1) to enter in FIG.2. Touch “others” on the left corner first
and then choose “Connector (Wi-fi)” to enter in FIG.3 to set your Wi-fi account and
password.
FIG.1 FIG. 2 FIG.3

1
FIG.4
3. Press (flame button) on the touch panel of the fireplace for more than 5 seconds
when the fireplace in standby mode. There will be 2 beeps come out from the fireplace
and the (flame button) will flash as well indicating that Wi-fi is in EZ mode. Then
please confirm to go next. (FIG.5)
4. The APP will scan (FIG.6) and add the fireplace to APP (FIG.7) automatically. Please
make sure the Wi-fi account and password you set are correct and Wi-fi signal is good.
5. Touch “Done” to finish Wi-fi setting.(FIG.7)
FIG.5 FIG.6 FIG.7

19
6. Now you are in the interface like FIG.7. You can operate the fireplace via Wi-fi.
FIG.7
NOTE: Turn off the flashing blue Wifi indicator light
Touch the (power button) once, the blue light will stop flashing.

CARE AND MAINTENANCE
CAUTION: Do not use harsh detergents, chemical cleaners or solvents as they may damage the
surface finish of the plastic components.
CONFORMITY WITH DIRECTIVES
Conforms to all relevant European directives
ENVIRONMENTAL PROTECTION
Recycling
This symbol is known as the 'Crossed-out Wheelie Bin Symbol'. When
this symbol is marked on a product or battery, it means that it should not
be disposed of with your general household waste. Some chemicals
contained within electrical/electronic products or batteries can be harmful
to health and the environment.
Only dispose of electrical/electronic/battery items in separate collection
schemes, which cater for the recovery and recycling of materials contained
within. Your co-operation is vital to ensure the success of these schemes
and for the protection of the environment.
1. Switch off and unplug from the power supply before cleaning.
2. Using a soft, moist cloth, with or without a mild soap solution, carefully clean the exterior surface
of the products.
CAUTION: Allow the product to completely cool before handling or cleaning it.
3. Do not allow water or other liquids to run into the interior of the product, as this could create a
fire and/or electrical hazard.
4. We also recommend the periodic cleaning of this appliance by lightly running a vacuum cleaner
nozzle over the guards to remove any dust or dirt that may have accumulated inside or on the
unit.
20
