Stanley IntelliLaser Pro User manual

IntelliLLaasseerrPPrroo
Stud Finder and Laser Line Level
with Continuous
AC Warning
INSTRUCTION
MANUAL
7
77 7- -5 50 00 0
™
114C IM 14Aug06 8/14/06 7:40 PM Page 1

SAFETY INSTRUCTIONS
Failure to follow warnings may result in bodily injury.
The following warnings must be followed to avoid
injury:
•DO NOT remove warning labels.
• DO NOT use optical tools such as a transit to
view laser beam. Serious eye injury could result.
• DO NOT project the laser beam directly into the
eyes of others.
• DO NOT stare directly at the laser beam.
• DO NOT project laser beam onto a reflective
surface.
• DO NOT operate around children, or allow
children to operate.
• DO NOT disassemble the laser.
• Always turn off laser when the tool is not in use.
WARNINGS:
IMPORTANT:Read all instructions prior to operating
the IntelliLLaasseerr™PPrrooand DO NOT remove any labels
from the tool.
The 77-500 produces a straight line on the same
surface on which the tool is placed. Any reflection of
the line on another surface should be considered
reference.
–1–
114C IM 14Aug06 8/14/06 7:40 PM Page 2

IntelliLLaasseerr™PPrroo(77-500)
Main Stud Sensing/Laser Unit
The Stanley®IntelliLLaasseerr™PPrroouses electronic signals
to locate the position of studs, joists or live AC wires
through drywall and other common wall materials.
Once the edge of the stud has been detected, the
IntelliLLaasseerr™PPrrooLCD display gives visual and audio
indications that allow you to easily pinpoint the stud’s
edge position. A pencil line allows you to quickly note
the location of the stud edges.
The Stanley®IntelliLLaasseerr™PPrroostud sensor generates
a vertical laser plane. The unit can also be tilted to
produce a laser plane at any angle.
The IntelliLLaasseerr™PPrrooallows the user to locate wood
and metal studs through common wall materials up
to 1 1/2inches thick.
The IntelliLLaasseerr™PPrrooprovides automatic calibration ,
a backlit LCD screen, auto shut off and heavy duty
ABS construction.
Depth detection selected by side button for 1/2inch,
1inch and 1 1/2inch.
–2–
114C IM 14Aug06 8/14/06 7:40 PM Page 3

IntelliLaser™ Pro (77-500)
Laser Pod
The addition of the laser pod opens up the functionality
of the stud finder. The unit is mountable using adhesive
pads (included). Retractable feet keep the adhesive
away from the surface during placement. The laser pod
can be tilted ±10°once it is attached to the surface
without removing the adhesive. This allows for easy
repositioning of the laser plane. The laser pod can be set
to level, plumb or any other angle required. With the
laser pod mounted to the wall horizontally, you are free
to use the main stud sensor laser pod and mark both the
height and stud locations at the same time.
The IntelliLLaasseerr™™PPrroolaser pod generates a horizontal
or vertical laser plane. It can also be mounted to the wall
to reproduce any angle required.
The IntelliLLaasseerr™™PPrroolaser pod provides heavy duty
ABS construction with large rubber pads to provide a
firm grip and superior impact
resistance.
Operating Instructions
Battery Replacement
Open the battery door on back of unit
and connect a 9-volt battery (not
included) to the clip. Place battery into
case and snap battery door in place. It
is recommended that you replace the
battery when the low battery indicator
is lit.
Open the battery door on back of
unit by sliding the door down. Slide
in (2) AAA batteries (not included).
Slide the battery door in place.
–3–
Battery
Door
ILLUSTRATION 1
Battery
Door ILLUSTRATION 2
114C IM 14Aug06 8/14/06 7:40 PM Page 4

–4–
Indicator Mark
Level & Plumb Vials
Live Wire LED
Backlit LCD
ON Button / Depth
Detection Mode
Selection
ILLUSTRATION 3
Depth Dectection
Mode Indicator
Battery
Door
ILLUSTRATION 1
Battery
Door ILLUSTRATION 2
Lit When
Live Wire
is
Detected
Laser Plane
ON
Low Battery
Indicator
Indicator Graphic
A B C
ILLUSTRATION 5
ILLUSTRATION 4
A = Wood or metal stud detection up to 1/2”
B = Wood or metal stud detection up to 1”
C = Wood or metal stud detection up to 1-1/2”
Unit is
Calibrating
Calibration
Complete
Ready to Scan
Live wire
Lit When
Live Wire
is
Detected
Laser Plane
ON
Low Battery
Indicator
Indicator Graphic
A B C
ILLUSTRATION 5
ILLUSTRATION 4
A = Wood or metal stud detection up to 1/2”
B = Wood or metal stud detection up to 1”
C = Wood or metal stud detection up to 1-1/2”
Unit is
Calibrating
Calibration
Complete
Ready to Scan
Live wire
114C IM 14Aug06 8/14/06 7:40 PM Page 5

Power Button
Retractable
Legs
To hold adhesive
away from the wall
during placement
Sliding
Adhesive
Plate
Allows tilting of unit
±10˚ to level or
plumb the laser
Release Liner
For proper application
of adhesive to unit,
see illustration 8.
Illustration 7
Illustration 6
Release
Button
For Stand-off legs
Allows legs
to extend
+
_10˚
TILT
Level &
Plumb Vials
Aligned to the
laser plane
Adhesive
Pad w/
Pull Tab
–5–
114C IM 14Aug06 8/14/06 7:40 PM Page 6

–6–
Power Button
Retractable
Legs
To hold adhesive
away from the wall
during placement
Sliding
Adhesive
Plate
Allows tilting of unit
±10˚ to level or
plumb the laser
Release Liner
For proper application
of adhesive to unit,
see illustration 8.
Illustration 7
Illustration 6
Release
Button
For Stand-off legs
Allows legs
to extend
+
_10˚
TILT
Level &
Plumb Vials
Aligned to the
laser plane
Adhesive
Pad w/
Pull Tab
Application and Removal of Adhesive on Laser
Pod
1. To apply the adhesive to the unit, follow the steps
outlined in illustration 8.
2. Lower the standoff legs by pressing the release
button (see illustration 6).
3. Make sure that the adhesive plate is centered
so you have clearance to tilt the unit to either
side (see illustration 6).
4. Place the unit on the surface and position it
where required. Press the unit toward the wall
so the adhesive is applied and the legs lock in
the retracted position.
5. To remove the adhesive from the surface and
the laser unit, SSLLOOWWLLYYpull on the adhesive tab in
the direction shown.
Note: To assure a continued good bond of the adhesive
to the product, periodically wipe the sliding adhesive
plate (see illustration 6) with a swab dipped in
isopropyl or rubbing alcohol to keep the surface clean.
To remove the adhesive from
the surface and laser unit,
slowly pull the tab in the
direction shown.
Apply the 2nd adhesive pad
in the position shown.
Press the adhesive on to the
laser unit in the position shown.
Use the release liner to press the
adhesive to the unit. Then peel
away second release liner.
ILLUSTRATION 8
Remove the release
liner from 1 side.
Avoid touching adhesive.
114C IM 14Aug06 8/14/06 7:40 PM Page 7

Calibration
Calibrate the unit on wall before scanning for wood
or metal stud.
Note: While calibrating, the IntelliLLaasseerr™PPrroomust
nnoottbe placed directly over a stud, dense material
such as metal, wet or newly painted areas as this
will prevent the unit from calibrating properly. If this
is done over wood or metal stud the unit will give
no indication when moved away from the area.
Move to a different location and try again.
1. Hold the IntelliLLaasseerr™PPrrooflat against the surface,
making firm contact. Press and hold the “On”
button. All indicators on the LCD are displayed
while the unit goes through its’ 1 to 3 second
calibration cycle. The word “CALIBRATING“ will
appear on LCD (illustration 4) while the unit is
calibrating to surface.
Following the completion of calibration, the unit
will beep and the word “READY” will be shown
on the LCD (illustration 9). The LED light will
illuminate the keypad showing the depth mode
(1/2” depth default).
–7–
To remove the adhesive from
the surface and laser unit,
slowly pull the tab in the
direction shown.
Apply the 2nd adhesive pad
in the position shown.
Press the adhesive on to the
laser unit in the position shown.
Use the release liner to press the
adhesive to the unit. Then peel
away second release liner.
ILLUSTRATION 8
Remove the release
liner from 1 side.
Avoid touching adhesive.
WARNING: Do not pull the adhesive and/or laser pod
away from the surface. Damage to the surface may
result. If the tab separates from the adhesive, very slowly
pull the unit away from the surface to allow time for the
adhesive to gently separate from the surface/unit.
114C IM 14Aug06 8/14/06 7:40 PM Page 8

IMPORTANT:The unit can
not be moved before
calibration is complete.
“READY” will appear
on the LCD.
Notes:
1. Laser line is always on when
holding the “ON” button.
2. Continue to hold the “ON” button during stud
detection.
USAGE OF STUD SENSOR
Selecting depth detection
1. Depress and hold “ON” button once (1x) to select
to 1/2” read depth detection. The 1/2” mode LED
will illuminate (illustration 5). The unit will then
calibrate, followed by a beep and a “READY”
displayed on the LCD.
2. “Double-click”/Depress and hold “ON” button
twice (2x) to select 1” read depth selection. The
1” LED will illuminate (illustration 5). The unit will
then calibrate, followed by a beep and a “READY”
will appear on the LCD.
3. “Triple-click”/ Depress and hold “ON” button three
times (3x) to select 1-1/2” read depth selection.
The 1” LED will illuminate (illustration 5). The unit
will then calibrate, followed by a beep and a
“READY” will appear on the LCD.
Detecting Wood or Metal Studs
1. Once the unit is calibrated, slide the unit across
the surface in a straight line horizontally.
As the unit gets closer to the stud, the cross will
appear and the indicator rings will illuminate in
–8–
ILLUSTRATION 9
114C IM 14Aug06 8/14/06 7:40 PM Page 9

–9–
ILLUSTRATION 11
ILLUSTRATION 10
Mark1 Mark2
Stud
Center Mark
Side
Direction
Side
Direction
Steps 1 & 2 Steps 3 & 4 Steps 5
Stud Being Detected
ILLUSTRATION 12
succession from the largest to the smallest as
shown in illustration 10. When the stud edge is
detected, the “stud” indicator and vertical “EDGE”
symbol will appear as shown in illustration 11.
The unit will also sound a constant tone.
2. Use the indicator line to mark the stud edge.
3. Continue sliding past the stud until the indicator
turns off and the unit stops beeping.
4. Repeat steps 1 and 2 in the other direction.
5. The midpoint between the two marks is the stud
center.
114C IM 14Aug06 8/14/06 7:40 PM Page 10

–10–
Detecting Live Wires
The Live Wire Detection feature is always on and the
“Live Wire” icon will be displayed on the LCD. When a
Live Wire is detected, the red live wire LED indicator
will be on.(see illustration 3 & 4)
Static electricity charges that can develop on drywall
and other surfaces will spread the voltage detection
area many inches to each side of the actual electrical
wire. To aid in locating the wire position, scan holding
the unit 1/2 inch away from the wall surface or place
other hand on surface approximately 12 inches from
sensor.
Warning: shielded wires or live wires in metal
conduits, casings, metalized walls or thick, dense
walls, will not be detected. Always turn AC power
off when working near wiring.
The IntelliLLaasseerr™PPrroois designed to detect 110 volts
(for USA version) and 230 volts for (European version)
AC in live electrical wires. It will also detect the
presence of live wires having greater than 230 volts.
Cautions on Operating
You should always use caution when nailing, cutting or
drilling in walls, ceilings and floors that may contain
wiring or pipes near the surface. Shielded, dead or
non-powered wiring will not be detected as live
wires. Always remember that studs or joists are
normally spaced 16 inches or 24 inches apart and are 1-
1/2 inches in width. To avoid surprises, be aware that
anything closer together or of a different width may be an
additional stud, joist or fire break.
When working near AC electrical wires, always
turn off the power.
114C IM 14Aug06 8/14/06 7:40 PM Page 11

1. Laser plane in the stud detection mode is
always on, a laser plane icon is also shown on the
LCD. It can be turned off by pressing “ ” button
once.
2. Laser plane can also be turned on individually by
pressing “ ” button once or pressing again to
turn it off.
3. The Laser plane will be auto - off after 1 hour.
4. The projected laser plane will coincide with
stud edge indicator.
5. The level vials are aligned to the laser plane.
When the bubble is centered, the laser plane
will be vertical/horizontal (depending on vial
used).
Operating Tips
IMPORTANT SAFETY NOTICE
Insure proper detection of live wires ALWAYS
hold the IntelliLLaasseerr™PPrrooin the handle area
only. Grasp between fingers and thumb while
maintaining contact with your palm.
–11–
Laser Aperture
Illustration 13
Vials
Laser Plane
114C IM 14Aug06 8/14/06 7:40 PM Page 12

–12–
Depth Setting Tips
If the unit is not quite detecting a stud in the current
depth mode setting, try the next higher depth
setting. I.E. when in 1/2” mode, try 1” mode.
If the unit is too sensitive, try using a lower depth
mode setting. I.E. when in 1” mode, try 1/2” mode.
Conventional Construction
Doors and windows are commonly constructed with
additional studs and headers for added stability. The
IntelliLLaasseerr™PPrroodetects the edge of these double studs
and solid headers and emits and holds an audio signal
as it crosses over them.
Surface Differences
Wallpaper—There will be no difference in the
function of the stud sensor on surfaces covered with
wallpaper or fabric unless the coverings contain
metallic foil or fibers.
Plaster and Lath —Unless the plaster and lath is
exceptionally thick or has metal mesh in it there will be
no problem with the unit functioning properly.
Ceiling or Textured Surfaces —When dealing with a
rough surface such as a sprayed ceiling, use a piece of
cardboard when scanning the surface. Run through the
calibration technique described earlier WITH the piece of
cardboard between the stud sensor and the surface. Also,
it is particularly important in this application to remember
to keep your free hand away from the unit.
114C IM 14Aug06 8/14/06 7:40 PM Page 13

–13–
Specifications
Utilizing the procedure of scanning and marking from
two sides, IntelliLLaasseerr™PPrroowill find the stud center
with 1/8” accuracy for wood and 1/4” accuracy for
metal.
When measuring a wood or metal stud, it is
recommended the IntelliSensor™to be used at 20-35%
relative humidity.
Battery (not included):
Main unit: (1) 9 volt
Laser pod: (2) AAA
Shock Resistance: up to 3 feet
Operating Temperature: +20°Fto +120°F
(-7°Cto +49°C)
Storage Temperature: -20°Fto +150°F
(-29°Cto +66°C)
Laser diode: 650nm Class IIIA (U.S. version) or
635nm Class 2M (Europe version)
Laser accuracy: 1/2” at 20 feet
Length of projected Laser Line: up to 20 feet
This is a Class IIIA (U.S. version) or 2M (Europe version)
laser tool and is manufactured to comply with
international safety rule IEC 285.
114C IM 14Aug06 8/14/06 7:40 PM Page 14

–14–
Warranty
The Stanley Works warrants the IntelliLLaasseerr™PPrrooagainst
defects in material and workmanship for one year from
the date of purchase. Deficient products will be repaired
or replaced at Stanley’s discretion if sent to:
The Stanley Works
Customer Service
Repair Department
480 Myrtle Street
New Britain, CT 06053
Stanley’s liability under this warranty is limited to repair
or replacement of the unit. Any attempt to repair the
product by other than factory authorized personnel will
void this warranty. Calibration, batteries and maintenance
are the responsibility of the user. Where permitted by
law, Stanley is not responsible for incidental or
consequential damages. Agents of Stanley cannot change
this warranty. Stanley is not responsible for damage
resulting from wear, abuse or alteration of this product.
The user is expected to follow ALL operating instructions.
This warranty may provide you with additional rights that
vary by state, province or nation.
114C IM 14Aug06 8/14/06 7:40 PM Page 15

IntelliLLaasseerrPPrroo
Détecteur de montant et niveau
à ligne laser
avec alarme de courant
alternatif continue
MODE
D’EMPLOI
7
77 7- -5 50 00 0
™
114C IM 14Aug06 8/14/06 7:40 PM Page 16

CONSIGNES DE SÉCURITÉ :
Ne pas suivre les avertissements peut résulter en
blessures corporelles.
Les avertissements suivants doivent être suivis pour
éviter des blessures :
•N’ENLEVEZ PAS les étiquettes d’avertissement.
• N’UTILISEZ AUCUN outil optique tel qu’un théodolite
pour voir le faisceau laser. De graves blessures
oculaires pourraient en résulter.
• NE PROJETEZ PAS le faisceau laser directement dans
les yeux d’autrui.
• NE REGARDEZ PAS directement dans le faisceau laser.
• NE PROJETEZ PAS le faisceau laser sur une surface
réfléchissante.
• N’UTILISEZ PAS l’outil laser autour des enfants ni ne
permettez pas aux enfants de l’utiliser.
• NE DÉMONTEZ PAS le laser.
• Éteignez toujours le laser quand l’outil n’est pas utilisé.
AVERTISSEMENTS :
IMPORTANT:Lisez toutes les instructions avant
d’utiliser l’IntelliLLaasseerrT
TM MPPrrooet N’ENLEVEZ AUCUNE
étiquette de l’outil.
Le 77-500 produit une ligne droite sur la surface sur
laquelle l’outil est posé. Tout reflet de la ligne sur une
autre surface devrait servir de référence.
–16–
Une étiquette
située sur
la face de
chaque unité
porte cet
avis de
précaution.
DANGER
Produit laser de la classe IIIA
Radiations laser émises de l’outil
Rendement d’énergie max. : < 5 mW
Longueur d’onde : 630-670 nm
Ne regardez pas dans le faisceau.
ÉVITEZ L’EXPOSITION DIRECTE DES YEUX.
CET OUTIL ÉMET DES RADIATIONS LASER.
114C IM 14Aug06 8/14/06 7:40 PM Page 17

IntelliLLaasseerr™PPrroo(77-500)
Unité laser/détection de montant
principale
L’IntelliLLaasseerr™PPrroode Stanley®utilise des signaux
électroniques pour trouver la position des montants,
solives ou fils électriques sous tension à travers les
murs de plâtre et autres matériaux communs. Une fois
le bord du montant détecté, l’écran à cristaux liquides
de l’IntelliLLaasseerr™PPrrooaffiche des indications et
l’appareil émet des sons vous permettant de facilement
situer la position des bords du montant. Une ligne fine
vous permet de rapidement relever l’emplacement des
bords du montant.
Le détecteur de montant IntelliLLaasseerr™PPrroode Stanley®
génère un plan laser vertical. L’unité peut aussi être
inclinée pour produire un plan laser à un angle
quelconque.
L’IntelliLLaasseerr™PPrroode Stanley®permet à l’utilisateur de situer
les montants de bois et métalliques au travers des matériaux
communs de mur d’une épaisseur n’excédant pas 3,81 cm
(1,5 po).
L’IntelliLLaasseerr™PPrroode Stanley®s’étalonne
automatiquement, comporte un écran à cristaux liquides et
éclairage de fond, s’éteint automatiquement et est
construit de plastique ABS très dur.
La profondeur de détection peut être réglée à l’aide du
bouton latéral à 12,7, 25,4 et 38,1 mm (0,5, 1 et 1,5 po).
–17–
114C IM 14Aug06 8/14/06 7:40 PM Page 18

IntelliLaser™ Pro (77-500)
Capsule laser
La capsule laser accroît la fonctionnalité du détecteur de
montant. L’unité peut être fixée au moyen des patins
adhésifs (compris). Les pattes rétractables séparent les
patins adhésifs de la surface pendant son
positionnement. La capsule laser peut être inclinée sur ±
10°une fois fixée à la surface sans enlever les patins
adhésifs. Ceci permet de changer facilement la position
du plan laser. La capsule laser peut être mise de niveau,
d’aplomb ou à tout autre angle requis. La capsule laser
fixée au mur horizontalement, vous pouvez librement
utiliser le capteur de montant principal et marquer la
hauteur et la position des montants en même temps.
La capsule laser de l’IntelliLLaasseerr™PPrroogénère un plan
laser vertical ou horizontal. Elle peut aussi être montée au
mur pour reproduire tout angle requis.
La capsule laser de l’IntelliLLaasseerr™PPrroo
est construite de plastique ABS très
dur et comporte de larges coussinets
de caoutchouc offrant une prise ferme
et une résistance supérieure aux
chocs.
Instructions de
fonctionnement
Remplacement de la pile
Ouvrez la portière du compartiment de la
pile au dos de l’unité et raccordez
une pile de 9 V (pas comprise) au
connecteur. Placez la pile dans le
compartiment et emboîtez la portière
en place. Il vous est conseillé de
remplacer la pile quand l’indicateur
de niveau bas de pile est allumé.
–18–
Portière du
compartiment
de pile
ILLUSTRATION 1
ILLUSTRATION 2
Portière du
compartiment
de pile
114C IM 14Aug06 8/14/06 7:40 PM Page 19

–19–
Indicateur de marque
Ampoules de nivelage
et mise d’aplomb
Voyant de fil sous tension
Écran à cristaux liquides
et éclairage de fond
Bouton de MARCHE/
sélection du mode de
profondeur de détection
ILLUSTRATION 3
Indicateur du mode de
profondeur de détection
Portière du
compartiment
de pile
ILLUSTRATION 1
Allumé quand
un fil sous tension
est détecté.
Indicateur de
niveau
bas des piles
Indicateur graphique
A B C
ILLUSTRATION 5
ILLUSTRATION 4
A= Détection de montant de bois ou métallique
à moins de 12,7 mm de profondeur
B = Détection de montant de bois ou métallique
à moins de 25,4 mm de profondeur
C = Détection de montant de bois ou métallique
à moins de 38,1 mm de profondeur
Unité
s’étalonnant
Étalonnage
fini, prêt
à balayer
Plan laser
allumé Fil sous tension
114C IM 14Aug06 8/14/06 7:40 PM Page 20
