Stanley TMS-DS1113T User manual

Model: TMS-DS1113T
TV Mount Installation Guide
Thank you for choosing Stanley – the hardware of choice
for Architects, Contractors, and Home Owners for its quality,
performance and dependability.
Enclosed are your step-by-step instructions for an install made
easy.
If you get stuck, give customer service a call at 1-855-816-6868
You can also reach us at [e-mail]
www.stanleymounts.com

2
Getting Started
Before we start lets make sure we have the correct mount and all
the required tools and hardware to complete the installation.
The TV is a Flat Panel TV is between 32” - 70” and weighs no more than
90lbs.
The Wall the TV will be mounted on is either concrete or dry wall with
wood studs.
You have all of the following tools:
If you answer “Yes” to all the questions above then you are ready
to begin the TV Mount installation!
!Caution: Please read the entire manual before proceeding
View warranty and disclaimer on page 13
Drill Screwdriver Pencil Level Stud Finder Tape Measure Hammer Wrench Drillbit
Check out our free level app in the app store!

3
Parts & Hardware
Caution: Before starting assembly, verify all parts are included and undamaged. If any parts are missing or
damaged, do not return the damaged item to your dealer; contact Customer Service. Never use damaged
parts or previously used parts!
A6 x4 B1 x4 B2 x4 B3 x4
A2 x4 A3 x4 A4 x4 A5 x4
Wall Plate
!
For attaching Brackets to TV
Spacers Lag Bolts
Concrete
Anchors Washers
Caution: This product contains small items that could be a choking hazard if swallowed.
!
A1 x4
M8 x 25mm
TV Screws
M6 x 25mm
M5 x 25mm
M4 x 25mm
Square
Washers
For attaching Wall Plate
TV Bracket x2

4
Hand thread screws into the
threaded inserts on the back
your TV to determine which
Screw diameter to use.
Determine whether your TV
or obstructed back.
Select TV Screws
1
1
2
Too Short Too LongCorrect
If the back of your TV is Flat
Mount the spacers A5
above the TV bracket.
If the back of TV is
Irregular/Round;
Inset holes:
Mount the spacers A5
under the TV bracket.
2Flat Back
TV bracket.
A5
A6
Irregular back
Insert Hole
A5
A6
TV bracket.
A2 A3 A4A1
M8 x 25mm
M6 x 25mm
M5 x 25mm
M4 x 25mm
or or or

Install TV bracket with the screw
and washer or spacer you selected
for your TV.
Tools Required:
2
Step 1: Attach TV Bracket
Position your TV bracket over your
TV hole pattern, making sure the
brackets are vertically centered and
level.
A5 A6
A1 or A2 or A3 or A4
Screwdriver
A5
A6
A1or A2 or A3 or A4
TV with Flat Back:
Mount the spacers A5
above the TV bracket.
Mount the spacers A5
under the TV bracket.
5
1
TV with Irregular/Round back; Inset holes:TV with Flat Back
Caution: Hand tighten with screwdriver only,
over tightening may damage the TV!
!Do not use a power tool for this step!
Caution: If you are unable to line up the hardware
with the TV, please call: 1-855-816-6868
!
I

Note: For Concrete skip to Step 2B
Use the stud nder to locate
2 studs, and then draw
a vertical line on the center of
each stud.
Level wall plate and align
at center of studs. Make 4
pencil marks to indicate
where to drill.
Tools Required:
1
2
2
Pencil Level Stud Finder Caution:
The minimum size of the wood stud must be
1 1/2”x 3 1/2”(38x 89mm)
The thickness of dry wall must not exceed
5/8”(16mm).
!
6
Step 2A: Install Wall Plate on Drywall with Wood Stud
!Min. 1 1/2”
(38mm)
!
Min. 3 1/2”
(89mm)
!Max. 5/8”
(16mm)
1
Caution:
not all walls have conventional
16”(406mm) or 24”(610mm)
standard stud spacing.
!

43
Remove the wall plate and
drill the pilot holes with a
3/16” drill bit
Align the wall plate with the
pilot holes and insert 4 bolts
through the washer in the
pilot holes and tighten.
Tools Required:
3
4
Drill 3/16” Drill Bit
7
3 in.
(75 mm)
3/16 in.
(5 mm)

Level the wall plate and
make 4 marks with pencil to
show where to drill the pilot
holes.
Remove the wall plate and
drill the pilot holes with a 3/8”
drill bit.
Tools Required:
1
2
1 2
Pencil Level Drill
3/8” Drill Bit
Caution: The minimum depth of the concrete must be 8”.
Do not drill pilot holes into the mortar between the concrete.
!
8
Step 2B: Install Wall Plate on Concrete
3/8 in.
(10 mm)
3 in.
(75 mm)

43
9
Insert the anchors into the
4 pilot holes. Tap with
hammer
Align wall plate with pilot
holes and anchors. Insert
4 bolts through washers and
anchors then tighten with
wrench.
Tools Required:
3
4
Hammer Wrench

Step 3: Hang Your TV
To hang your TV, clip the TV
Rails to the mounted wall
plate.
After the TV is hanging properly
on the wall mount, press on
the bottom of the TV to lock it
in place.
1
2
1
3
2
Warning: TV should always be lifted by 2 people.
10
Fasten 2 screws to secure
the bracket.
!
Fasten 2 screws to secure the
bracket.
3

Usage: Tilt
12 11
otnwodropuVTtliT
achieve the best angle of
view. No tools required.
1
11

Removing the TV
12
Disconnect all cables from
the TV.
Unlock the secure screws.
1
2
Pull bottom of TV from wall,
allow enough space to lift TV
up and off wall plate.
3
To rehang TV, follow procedures
on STEP 3 of PAGE 10.
2 3
Warning: TV should always be lifted by 2 people.

SUNCRAFT SOLUTIONS INC. LIMITED WARRANTY
SUNCRAFT SOLUTIONS INC. LIMITED WARRANTY
SUNCRAFT SOLUTIONS, INC. warrants its products to be free of defects in material and
workmanship for the product’s Warranty Period. The Warranty Period commences on the original
purchase date of the product and the sales receipt serves as proof of purchase.
All SUNCRAFT SOLUTIONS, INC. products are covered by a limited product warranty of three (3)
This Limited Warranty extends only to the original purchaser and is non-transferable. It is
way, improperly or incompletely installed, usage of non-supplied hardware and used in a non
conventional method, exceeding the weight capacity or size restrictions. SUNCRAFT SOLUTIONS,
INC. products are intended for indoor applications for consumer or commercial use. Any outdoor
voids this Limited Warranty.The Limited Warranty for all mounts is void if the mount is transferred
from one location to another. To the maximum extent permitted by applicable law, SUNCRAFT
for a particular purpose and warranties of merchantability. SUNCRAFT SOLUTIONS, INC. will not
be liable for any damages whatsoever arising out of the use or inability to use its products, even if
SUNCRAFT SOLUTIONS, INC. has been advised of the possibility of such damages. To the maximum
extent permitted by applicable law, SUNCRAFT SOLUTIONS, INC. disclaims any responsibility for
incidental or consequential injuries, damages to persons, properties and other items.
For warranty claims made during the stated warranty period, SUNCRAFT SOLUTIONS, INC. will
replace any defective product part free of charge. Contact SUNCRAFT SOLUTIONS, INC. at 1-855-
816-6868 to make a warranty claim or e-mail w[email protected]. Proof of warranty is
required.This Limited Warranty does not cover the costs of removing and replacing defective parts
from your SUNCRAFT SOLUTIONS, INC. product. SUNCRAFT SOLUTIONS, INC. assumes no liability
for any installation, adjustment or other costs.
13
application, subject to high humidity, water vapor or exposure to elements therefore

is damaged or missing. In the event that replacement parts or hardware are needed, please contact
Customer Service at 1-855-816-6868 or [e-mail] . International customers
needing assistance should contact the Dealer from which they purchased the product.
The included hardware is designed for use on vertical walls constructed of wood studs or solid
by 3.5” deep 51 x 102 mm) with a maximum of 5/8” (16 mm) drywall.The included hardware is not
designed for use with metal studs or cinderblock walls. If you are uncertain or unknowledgeable
installer for assistance.The wall you are mounting to must support 4 times the weight of the total
If not, then the surface must be reinforced to meet this standard. The installer is responsible for
verifying that the wall structure and hardware used in any installation method will safely support
the total load.
GENERAL DISCLAIMER
General Disclaimer
Disclaimer – Suncraft Solutions Inc. has extended every effort to ensure the accuracy and
completeness of this manual. However, Suncraft Solutions Inc. does not claim that the information
covers all installation, situational or operational variables. The information contained in this
the information contained herein, Suncraft Solutions Inc. makes no representation of warranty,
information contained in this document.
WARNING: FAILURE TO READ, THOROUGHLY UNDERSTAND, AND FOLLOW ALL INSTRUCTIONS
CAN RESULT IN SERIOUS PERSONAL INJURY, DAMAGE TO PERSONAL PROPERTY, OR VOIDING OF
LIMITED WARRANTY!
It is the responsibility of the installer of this product to ensure all components are properly
assembled and installed using the instructions provided. If you do not understand these instructions
or have any questions or concerns, please contact customer service at 1-855-816-6868 or service@
suncraftsolutions.com. Do not attempt to install or assemble this product if the product or hardware
14
