Stansport 035 Manual

CAUTION:
Read all Warnings and Operating Instructions
before use and retain for future reference.
Owner’s Manual and Operating Instructions
for Stainless Steel Propane BBQ Grill
ITEM PART QTY
(PCS)
PART
NAME
11 HANDLE
3LEGS2
71
51
HEAT
DISTRIBUTION
PLATE
61 BURNER
81 HAMULUS
COOKING
GRATE
1 BODY
2
41REGULATOR
VALVE
1
ABURNER
SCREW
2
ESMALL
NUTS
2
GVENT
DOORS
2
1
H
I
VENT
SCREW
GRILL
HANDLE
2
BHANDLE
SCREW
6
CLEG
SCREW
8
DWING
NUTS
DANGER CARBON MONOXIDE HAZARD
This appliance can produce carbon
monoxide which has no odor.
Using it in an enclosed
space can kill you.
Never use this appliance in
an enclosed space such as a
camper, tent, car or home.
FOR YOUR SAFETY
Do not store or use gasoline or other liquids with flammable
vapors in the vicinity of this or any other appliance.
WARNING
FIRE OR EXPLOSION HAZARD
If you smell gas:
1. Do not attempt to light appliance.
2. Extinguish any open flame.
3. Disconnect from fuel supply.
4. Evacuate immediately
5. Allow gas to dissipate 5 minutes
before relighting the appliance
Failure to follow these instructions could result
in fire or explosion, which could cause property
damage, personal injury, or death
Model 035

Propane fuel is highly flammable and under pressure.
- Do not store in temperatures over 120°F.
- Never use a flame to check for leaks. Use soapy water.
- Keep out of the reach of children at all times.
- Keep cylinders upright with cylinder base equipped
for proper vapor withdrawal.
- The smell of gas indicates a leak. Close valve and check for
leaks by brushing soapy water on all joints.There is a leak if
bubbles appear.Tighten the joint until the bubbles quit.
- Always check all connections for dirt or damage
before assembling.
- Do not leave grill unattended while in use.
- If grill is stored indoors, detach and leave the
cylinder outdoors.
CAUTION
- FOR OUTDOOR USE ONLY.
- Supply plenty of fresh air when using the grill.
Do not obstruct the flow of combustion air or ventilation air.
- Do not use as a space heater.
- Grills produce heat. Keep grill away from burnable materials.
Do not place the grill any closer than 24” to combustibles.
- Use a flat, level support surface where the grill is safe
from accidental tipping.
- Use only 16.4 oz. propane cylinders marked per
USDOT-39 orTC CAN/CSA B339 standards.
- Use only with propane fuel
- Use only the regulator included with your grill.
Do not attempt to alter.
WARNING
WARNING
1. Read and follow these instructions carefully before assembly or use.
2. Failure to follow these instructions could result in death. Serious bodily injury and/or property loss.
3. For household outdoor use only. Not for commercial use.
4. The consumer should retain them for future use.
D
E
G
ASSEMBLY STEPS
CAREFULLY UNPACK AND CHECK ALL PARTS
a. Install the handle (1) to the lid (2) using 2pcs screws (B) and 2pcs nuts (D).
b. Install the vent doors (G) to the side of the lid (2) using 2pcs screws (H) and 2 pcs nuts (E).
c. Install the legs (3) to the fire bowl (2) using 6pcs screws (C) and 6pcs nuts (D).
d. Insert the burner (6) through the hole on the left side of the fire bowl, attach the screw
(A) from the bottom and tighten the burner.
e. Turn the regulator valve (4) and tighten with the burner.
f. Place the heat distribution plate (5) on the burner.
g. Place the cooking grate (7) on position.
BURNER SCREW
LEG SCREW
HANDLE SCREW
H VENT SCREW
2801 East 12th Street, Los Angeles, CA 90023

CAUTION!
1. This BBQ Gas Grill is intended for OUTDOOR USE ONLY. Do not attempt to use this grill
in enclosed areas such as buildings, garage, or other enclosed area. This appliance shall
not be located under unprotected combustible constructions. Do not use this appliance
under extended awnings. Failure to comply could result in a fire or personal injury.
2. Place your BBQ Gas Grill outside on a firm, level surface away from wooden fences,
overhanging trees, or other flammable objects before igniting the gas burner.
Minimum clearance from grill to any combustible material must be 8” on the
rear and 12” on either side of the grill.
3. When cooking, the appliance must be on a level, stable surface in an area
clear of combustible material. An asphalt surface (blacktop) may not be
acceptable for this purpose.
4. When installing the gas regulator, completely tighten the regulator to the burner system.
The regulator is installed properly when the threads of the brass fitting on the regulator
are tight against the burner and no threads are visible.
5. Do not use or store any flammable liquid or gas within 25 feet of this appliance.
6. Use only commercially approved propane 1 pound propane gas canisters. Attach, use
and store the propane gas canister according to the product’s instructions. The propane
cylinder must be disconnected when the appliance is not in use.
7. After lighting the BBQ Gas Grill, do not leave the grill unattended.
8. Remember to keep children and pets away from the lit grill at all times.
9. To avoid harm to people, pets, or property do not move the BBQ grill once the
gas burner has been lit. Allow the unit to cool before moving or storing.
10. After the gas burner is lit the grill and surrounding surfaces become very hot.
Use proper outdoor cooking mitts and utensils. Avoid skin contact with all
hot metal surfaces of the grill.
11. To extinguish burner after cooking, push down on the dial and turn dial past the off
position until the dial pops out. Until the dial on the gas regulator pops out, the gas
is still on. Make sure you turn the gas off completely and remove the gas canister
before transporting or storing the unit.
12. After the BBQ Gas Grill has cooled, disconnect gas canister, cover, and store the
unit in a safe place away from children. Storage of an outdoor cooking gas appliance
indoors is permissible only if the cylinder is disconnected and removed from the appliance.
13. The pressure regulator provided with this appliance must be used.
14. The propane-gas cylinder to be used must be constructed and marked in accordance
with the specification for LP-gas Cylinders of the U.S. Department of Transportation (DOT).
Only 1 pound cylinders marked propane or LP-Gas are to be used with this appliance.
15. This grill is not for use on recreational vehicles and/or boats.
16. This appliance is not intended for commercial use.
17. The use of alcohol, prescription or non-prescription drugs may impair the
consumer’s ability to properly/safely operate the appliance.
18. In the event of a grease fire do not attempt to extinguish with water. Use Type
BC dry chemical extinguisher or smother fire with dirt, sand or baking soda.
19. The use and installation of this product must confirm to local codes. In absense of
local codes, use the National Fuel and Gas Code, ANSI Z223.1/NFPA 54, Storage and
Handling of Liquefied Petroleum Gases, ANSI/NFPA 58.
20. Always open grill lid carefully and slowly as heat and steam trapped within
grill can cause severe burns.
2801 East 12th Street, Los Angeles, CA 90023

LEAK TESTING
WARNING!
Always perform a leak test before each use. Leak test must be performed outside in a well-ventilated area.
NEVER perform a leak test on a grill while in use or hot. If you detect a gas leak that cannot be corrected by
using the leak test procedures below, DO NOT use the LP gas grill.
Supplies Needed for a Leak Test:
Clean paintbrush or basting brush, water, and dishwashing liquid.
Check for leaks:
Test for gas leaks each time while you connect the gas cylinder to your gas grill. NEVER use a flame to test for
a leak. Mix one cup of water with one cup of dishwashing liquid. Apply the solution to the connection at the top
of the gas cylinder and end of the regulator valve and also where regulator connects to the burner. If bubbles
form at either of these connections there is a leak present and must be corrected immediately! Remove the
soap solution with cold water and towel dry. Turn off the gas and wait 5 minutes for gas to clear. Attempt
to re-connect the gas cylinder.
DANGER!
To prevent fire or explosion hazard when testing for a leak:
- No smoking. Do not use or permit sources of ignition in the area while conducting a leak test.
- Conduct the leak test outdoors in a well-ventilated area.
- Do not use matches, lighters or flame to check for leaks.
- Do not use grill until any and all leaks are corrected.
- If you are unable to stop a leak, disconnect the propane supply.
Call a gas appliance Service man or your local propane gas supplier.
Match Ignition Hole
LIGHTING OPERATION & CONTROL OPERATION
WARNING!
Attempting to light the burner with the lid closed may cause an explosion!
1. Make sure there are no obstructions of airflow to the gas unit.
Spiders and insects can nest within the burner or orifices.
2. Clean burner holes with a pipe cleaner if obstructions are found.
3. Place a lighted match through the hole on the side of the unit or near the burner ports.
4. Turn the regulator valve to its “HIGH” setting. After lighting, please observe the burner flame; make sure all
burner ports are lit — a blue/yellow flame of 1-2 inches from the burner rod should appear. If burner does not
light after first try, turn the gas to its “OFF” position, and wait 5 minutes for gas to clear before trying again.
If burner flame goes out during operation, immediately turn the gas “OFF” and wait 5 minutes to allow gas
to clear, before attempt to re-light.
2801 East 12th Street, Los Angeles, CA 90023

DANGER!
Prior to connecting the propane gas cylinder, ensure the regulator valve is in the “LOCK OFF” position.
MAINTENANCE
CAUTION — All cleaning and maintenance should be done when the grill is cool and with the fuel supply turned
off at the control dial and the propane cylinder disconnected. Do not clean any grill part in a self cleaning oven.
The extreme heat will damage the finish.
1. Keep appliance area clear and free of any combustible material,
gasoline and other flammable vapors and liquids.
2. Do not obstruct the flow of combustion air.
3. Visually check burner flames. The correct
flame is shown in the picture to the right.
4. Grill should be cool to the touch before cleaning and storing.
5. Clean the appliance after each use using warm soapy water.
6. Outside surfaces of the grill should be cleaned using a
mild dishwashing detergent and hot water solution
to clean. Rinse with water and then dry.
7. Check the burner/venture before each use for insects
and insect nests. A clogged burner can lead to a fire.
2801 East 12th Street, Los Angeles, CA 90023
