Dometic Consul User manual

Portable grill
Operating manual . . . . . . . . . . . . . . . 7
Koffergrill
Bedienungsanleitung . . . . . . . . . . . . 25
Barbecue portable
Notice d’utilisation . . . . . . . . . . . . . . 43
Barbacoa con maletín
Instrucciones de uso . . . . . . . . . . . . 61
Barbecue portatile
Istruzioni per I’uso . . . . . . . . . . . . . . 79
Koffergrill
Gebruiksaanwijzing . . . . . . . . . . . . . 97
Kuffertgrill
Betjeningsanvisning. . . . . . . . . . . . 115
Koffertgrill
Bruksanvisning . . . . . . . . . . . . . . . 133
Koffertgrill
Bruksanvisning . . . . . . . . . . . . . . . 151
Laukkugrilli
Käyttöohje . . . . . . . . . . . . . . . . . . . 169
Grelhador de mala
Manual de instruções. . . . . . . . . . . . 187
Портативный гриль
Инструкция по эксплуатации. . . . 206
Grill walizkowy
Instrukcja obsługi. . . . . . . . . . . . . . 224
Kufříkový gril
Návod k obsluze . . . . . . . . . . . . . . 242
Kufríkový gril
Návod na obsluhu . . . . . . . . . . . . . 259
Hordozható grill
Használati utasítás . . . . . . . . . . . . . 276
EN
DE
FR
ES
IT
NL
DA
SV
NO
FI
PT
RU
PL
CS
SK
HU
Classic 1, Classic 2
Consul

Dometic Classic, Consul
3
11
9
10
1
5
Classic
6
7
8
3
4
2
1
Consul
11
9
10
12
5
12
6
7
8
3
4
13
2

Dometic Classic, Consul
4
2.
1.
6
3
5
23
1
4
7
A
B
Classic
3
2.
1.
6
3
5
23
8
1
4
7
A
B
9
9C
10
Consul
4

Dometic Classic, Consul
5
1
1
56
2
34
A B
C D
5
1
32
6

Dometic Classic, Consul
6
1
2
7
1
8
1
9

EN
Dometic Classic, Consul Explanation of symbols
7
Please read this manual carefully before installation and starting up the
device. Keep it in a safe place for future reference. If you pass on the
device to another person, hand over this instruction manual along with
it.
Contents
1 Explanation of symbols . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
2 General safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
3 Scope of delivery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
4 Optional extras. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
5 Intended use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
6 Technical description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
7 Before initial use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
8 Using the portable grill . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
9 Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
10 Cleaning the portable grill . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
11 Guarantee . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
12 Disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
13 Technical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
1 Explanation of symbols
!
!
WARNING!
Safety instruction: Failure to observe this instruction can cause
fatal or serious injury.
CAUTION!
Safety instruction: Failure to observe this instruction can lead to
injury.

EN
General safety instructions Dometic Classic, Consul
8
A
I
➤Action: This symbol indicates that action is required on your part. The
required action is described step-by-step.
✓This symbol describes the result of an action.
Fig. 15, page 3: This refers to an element in an illustration. In this case,
item 5 in figure 1 on page 3.
2 General safety instructions
The manufacturer accepts no liability for damage in the following cases:
Faulty assembly or connection
Damage to the product resulting from mechanical influences
Alterations to the product without express permission from the manu-
facturer
Use for purposes other than those described in the operating manual
2.1 General safety
!WARNING!
Only use category l3liquid gas (propane/butane). Do not use
any other fuel sources.
ANOTICE!
Use the device only as intended.
NOTICE!
Failure to observe this instruction can cause material damage and
impair the function of the product.
NOTE
Supplementary information for operating the product.

EN
Dometic Classic, Consul General safety instructions
9
2.2 Safety precautions when handling liquid gas
!WARNING!
Keep combustible materials away from heating or cooking
devices and other light or heat sources.
Compare the pressure information on the type plate with the
pressure information on the propane or butane gas cylinder.
Never store liquid gas cylinders in unventilated areas or below
ground level (funnel shaped holes in the ground).
Keep liquid gas cylinders away from direct sunlight. The temper-
ature may not exceed 50 °C.
2.3 Operating the device safely
!WARNING!
Beware of suffocation.
While burning liquid gas, the device also consumes oxygen.
When used indoors, there is a risk of suffocation due to insuffi-
cient oxygen.
Only use the device outdoors.
If you smell gas:
– Close the valve on the gas cylinder and keep it closed until
the error is rectified.
– Never attempt to find a gas leak with a naked flame.
Persons whose physical, sensory or mental capabilities or
whose lack of experience and knowledge prevent them from
using the device safely should not use it without supervision or
instruction by a responsible person.
Children must be supervised to ensure that they do not play with
the device.
Never leave the device unattended when in use for prolonged
periods of time.
Use long matches or a suitable lighter. Check the gas outlets
when you ignite the burners. Do not ignite the burners if you
cannot see them directly.
Take your hand away quickly once the burner is ignited.
Wear appropriate clothing when using the portable grill.
Do not wear loose-fitting clothing which could easily catch fire.

EN
General safety instructions Dometic Classic, Consul
10
Leave the portable grill to cool down properly before you touch
it with bare hands.
Replace porous or damaged hoses immediately.
Never change the nozzles, injector or burners.
ANOTICE!
Never use the rack without the drip tray.
Hot parts should not be allowed to come into contact with oil,
water or any other liquids.
Never move the device when it is still hot.
Using the cooking rings (Classic only):
Only use pots and pans with a level base and a diameter of
10 to 20 cm.
Ensure that pots and pans are stable when cooking.
Never allow pot or pan handles to protrude over the edge of the
portable grill. Turn all the handles inwards. This reduces the risk
of spillage, the ignition of flammable materials and serious
scolding.
Proceed with caution when heating oil or fat, as they can ignite
under excessive heat.
Only use dry pot holders to avoid steam build-up. Do not use
towels or cloths as these can catch fire.
Never leave the portable grill unattended while in use. Pots
which boil over can cause smoke and fires.

EN
Dometic Classic, Consul Scope of delivery
11
3 Scope of delivery
No. in
fig. 1,
page 3
Quantity Designation
11Classic: Burner with hob
Consul: Infrared ceramic burner
2 2 Injector (on burner)
3 1 Drip tray with rack
4 1 Grill rack holder
54Classic: Legs
Consul: Adjustable legs
6 1 Roasting spit
7 2 Meat clamps
81Case
9 1 Handle
10 1 Lock
11 2 Side panel
12 2 Consul only: Handles
13 3 Consul only: Stop bolt
– 2 Screws and nuts M3
– 1 Screw and nut M4
– 1 Operating manual

EN
Optional extras Dometic Classic, Consul
12
4 Optional extras
Available as accessory (not included in scope of delivery):
5 Intended use
The Classic 1, Classic 2 and Consul portable grills from Dometic are intend-
ed for mobile use outdoors.
The Classic 1 and Classic 2 portable grills allow you to cook on cooking rings
at the top at the same time as barbecuing. The Consul portable grill contains
an infrared ceramic burner that you can also use as a radiant heater. You can
also connect the portable grill to a gas cylinder or gas socket of a mobile
home by means of a suitable gas hose (not included in delivery).
The portable grill must not be used for barbecuing or heating in enclosed
spaces (such as tents and awnings). Leave the portable grill to cool down
completely before putting it in a tent or awning.
Designation Item no.
Grill trays 9103300804
Grill basket midi 9103300800
Grill basket maxi 9103300801
Grill motor battery (1.5 V) 9103300802
Combination grill motor (1.5 V/230 V) 9103300807
Network motor battery (230 V) 9103300803
Grill cover Classic 1 and Consul 9103500360
Grill cover Classic 2 9103500361

EN
Dometic Classic, Consul Technical description
13
6 Technical description
The portable grill can be dismantled and is easy to transport. All the parts fit
into the case.
Category I3(propane/butane) liquid gas is used as fuel.
6.1 Specifications for the portable grill models
The portable grill is available in different models and with different connec-
tions:
Classic 1: portable grill with three cooking rings
Classic 2: portable grill with two cooking rings
Consul: Portable grill with an infra-red ceramic burners with three rings
and a safety valve (fig. 81, page 6)
All models are available with the following connections:
Connection pressure 50 mbar
Connection pressure 30 mbar
6.2 Gas pressure
The permitted gas pressure can be found on the type plate in the bottom of
the case.
Models with a gas cylinder connection must be used with a pressure reducing
valve.
Only use pressure reducing valves that have been specified and approved in
your country.
!WARNING! Beware of injury
The outlet pressure of the valve must always match the connec-
tion pressure (gas pressure) of the portable grill.

EN
Before initial use Dometic Classic, Consul
14
7 Before initial use
Classic: fig. 1, page 3
Consul: fig. 2, page 3
➤Classic: Remove the protective film from the top of the burner (1).
➤Screw the handle (9) into the lower part of the case with both the screws
M3.
➤Attach the lock (10) to the lid of the case with the screw M4.
➤Clean the rack and the drip tray with a standard cleaning agent.
➤Only when connecting to gas cylinders:
– Use a suitable gas hose and a pressure reduction valve (both not
included in delivery).
– Connect the pressure reduction valve to the free end of the gas hose.
➤Only when connecting to gas sockets: Use a suitable gas hose (not
included in delivery).
➤Connect the gas hose to the injector (2).
Table of adapters
ANOTICE! Beware of damage
To ensure proper operation, an adapter supplied by the manufac-
turer (item no. 9103300168 or 9103300169) must be used. If you
have any questions, please contact the manufacturer's branch in
your country (see the back for the addresses).
Country Adapter
k a h –
l m q L T U 9103300168
Rest of Europe 9103300169

EN
Dometic Classic, Consul Using the portable grill
15
8 Using the portable grill
8.1 Mounting the portable grill
Classic: fig. 3, page 4
Consul: fig. 4, page 4
When selecting the location for barbecuing, observe the following instruc-
tions:
Set up the portable grill outside in a well-ventilated place. Do not place it
in a dip to prevent any gases from accumulating there.
The ground must be firm, level and stabile.
Keep the portable grill protected from the wind.
Never place the portable grill near flammable materials, even when cool-
ing down. Keep a distance of at least 20 cm.
Observe the safety instructions, see “Safety precautions when handling
liquid gas” on page 9.
➤Screw the stands (1) onto the base.
➤Gather all the individual parts and put them to one side.
➤Consul only: Adjust the legs (2) to a suitable height:
– Unscrew the lower part in anti-clockwise direction.
– Extend the leg to the required length.
– Tighten the lower part in clockwise direction.
➤Turn the stand (2) by hand in the fastening plates.
➤Attach the side panels:
– Hang the side panel (3) in the slot in the upper part of the portable
grill (1)(A).
– Fold it down.
– Hook the side panel onto the front of the grill base (B).
–Consul only: Screw two stop bolts (10) to the inside of the right side
section and one to the inside of the left side section (C).
ANOTICE!
Never use the device without the drip tray. Without a drip tray the
signs in the base of the portable grill could get dirty, damaged
from the heat and illegible.

EN
Using the portable grill Dometic Classic, Consul
16
➤Always slide the rack in at the required height together with the drip tray
(4).
➤If required, insert the roasting spit (5) into the rails on the side panels.
8.2 Installing the burner
Classic (fig. 3, page 4)
➤Place the burners (7) onto the side panels.
➤Insert the injector (6) into the burner (7) until you hear it click.
Consul: Installing the burner in barbecuing position (fig. 4, page 4)
➤Install the burner in the barbecuing position:
– Insert the bolts of the burner (7) horizontally into the in guide slots in
the side parts (3) in barbecuing position. You need to bend the side
parts apart gently to do this.
– Hook the burner into the two holding bolts (10).
– Push the handles (9) onto the bolts of the burner from outside.
➤Insert the injector (6) into the burner (7).
➤Fix the injector with the retaining clamp (8).
Consul: Bringing the burner into the heating position (fig. 5, page 5)
!
➤Lift the burner (1) by the handles (2) and tilt it backwards slightly (A).
➤Pull the burner forwards slightly in the guide slots until the bolt (4) is no
longer in the guide (3) of the burner (B).
➤Turn the burner (1) by around 90° until the ceramic surfaces (5) are facing
forward (C).
➤Push the burner back again in the guide slots (D).
✓The burner is kept in the heating position by the bolt (6).
➤To return the burner to the barbecuing position, repeat this sequence in
reverse order.
WARNING! Beware of burns
The burner becomes very hot when it is running. Always hold the
burner by the handles when turning it into the heating position and
back.

EN
Dometic Classic, Consul Using the portable grill
17
8.3 Connecting the portable grill to the gas cylinder
(only certain models)
!
➤Place the gas cylinder (fig. 61, page 5) upright and at least 50 cm
away from the portable grill.
➤Check that the valve (fig. 62, page 5) on the gas cylinder is closed.
➤Screw the pressure reducing valve (fig. 63, page 5) onto the gas cylin-
der firmly by hand.
➤Make sure that the gas hose
– is not crushed or kinked
– is a safe distance from the burner
➤After connecting the device to the gas supply, check the gas pipe for leak-
age using a foaming agent, e. g. with soap.
8.4 Connect the portable grill to the gas socket
➤Plug the gas hose into the gas socket.
➤Make sure that the gas hose
– is not crushed or kinked
– is a safe distance from the burner
➤After connecting the device to the gas supply, check the gas pipe for leak-
age using a foaming agent, e. g. with soap.
WARNING! Beware of injury
Only use propane or butane gas cylinders with an approved
pressure reducing valve and a suitable head.
Compare the pressure information on the type plate with the
information on the pressure reducing valve.

EN
Using the portable grill Dometic Classic, Consul
18
8.5 Igniting the portable grill
!
I
Classic
➤Turn on the gas supply.
➤Ignite the burner straight away at the gas outlet (fig. 71, page 6) using
a long match or a suitable lighter.
Remove your hand quickly as soon as the burner is lit.
➤After lighting, check that the burner is burning properly. The flames must
be burning along the whole length of both sides of the burner pipe
(fig. 72, page 6).
Consul
➤Turn on the gas supply.
➤Push the safety valve (fig. 81, page 6) and hold it down.
➤Ignite the burner straight away at one of the ceramic hobs (fig. 91,
page 6) using a long match or a suitable lighter.
Remove your hand quickly as soon as the burner is lit.
➤Let go of the safety valve after approx. 10 sec.
➤After lighting, check that the burner is burning properly. All ceramic rings
(fig. 91, page 6) must be lit and be glowing after a short time.
WARNING! Beware of injury
Do not leave the portable grill unattended while in use.
Ignite the burners as soon as you have turned on the gas sup-
ply. Otherwise gas can accumulate in the burner area and
could cause an explosion.
The complete ignition process must be visible from above and
must not be hidden by pots placed on top of the hob.
NOTE
While it is operating, you will be able to hear a slight noise
caused by the gas flowing out. This is completely harmless.
Smoke can occur when using it for the first time. This is caused
by deposits of machine oil burning and stops after approx.
10 minutes.
Classic: The stainless steel burners turn blue from the high
temperature. This does not affect the operation or the quality
of the material.

EN
Dometic Classic, Consul Using the portable grill
19
8.6 Barbecuing
Please observe the following instructions when barbecuing:
!
When barbecuing, control the temperature by raising or lowering the drip
tray and rack using the holder.
The very top recesses at the sides are intended for barbecuing steaks
quickly with intense heat.
Never use the device without the drip tray. Without a drip tray the signs in
the base of the portable grill could get dirty, damaged from the heat and
illegible.
Using the drip tray also allows the heat from the burners to be used more
efficiently.
Attach the food, such as poultry or a joint for roasting, with the two meat
clamps on the spit. Place the spit in the holders on the portable grill.
A grill motor (optional extra) is ideal here for turning the joint. First attach
the grill motor to the left side panel by putting the fastener into the keyhole.
Then plug in the head of the roasting spit into the motor.
When barbecuing with the roasting spit, the meat juices in the drip tray
can be used for making sauces according to taste.
8.7 Cooking (Classic only)
Please observe the following instructions when cooking:
Do not use any pots with curved bases.
Only use pots with a diameter between 10 cm and 20 cm.
CAUTION! Danger of burns
Always use the grill rack holder when you want to raise or low-
er the drip tray and spit while hot.
Remove the grill rack holder while you are barbecuing.
Otherwise it gets very hot.

EN
Using the portable grill Dometic Classic, Consul
20
8.8 Heating (Consul only)
!
Please observe the following instructions when heating:
Use the portable grill only in vertical position to provide heating for per-
sons.
Always use the handles to turn the burner.
8.9 Switching off the portable grill
➤Turn off the gas supply.
✓The flames go out.
8.10 Dismantling the portable grill
!
➤Disconnect the portable grill from the gas supply.
➤Dismantle the portable grill once it has cooled down.
➤Clean the individual parts (see “Cleaning the portable grill” on page 22).
➤Store the individual parts in the case.
➤Close the case with the zip.
WARNING! Beware of burns
The burner becomes very hot when it is running. Always hold the
burner by the handles when turning it into the heating position and
back.
CAUTION! Beware of burns
The portable grill is very hot when you use it. Leave the portable
grill to cool down before you clean, dismantle or transport it.
