Grill-Max Roller Grills with built in Bun Drawer
Model 30SCBD with Sneeze Guard
Model 50CBD with Sneeze Guard
S167/1121
GRILL-MAX®ROLLER GRILLS WITH
BUILT-IN BUN DRAWER
Model 30CBD, 30SCBD, 45CBD, 45SCBD, 50CBD, 50SCBD,
75CBD & 75SCBD
Features/Benefits:
★The Star Grill-Max®line of roller grills take presentation and
performance to its fullest potential morning, noon, and night.
★Built-in bun drawer saves space, reduces cost and provides sanitary
storage of bun.
★Unique “stadium seating” rollers slanted at 3° to 5° for the best
presentation of your products increasing sales and impulse
purchases.
★Slim-line design provides more grill surface in the same space.
Increased capacity means additional sales and greater profits.
★Infinite temperature controls provide more linear heat control for
better performance.
★Easy access control knobs provide sectional heating for front and
rear rollers.
★Exclusive Duratec coated non-stick rollers, the best non-stick high
performance coating for today’s high volume operations. Duratec
rollers meet the demands for improved durability, cleanability and
feature superior grip for improved rollability of today’s new Roller
Grill snack foods.
★Chrome rollers provide a durable cooking surface designed for
traditional cooking operations and easy cleanability.
★Seal-Max superior heavy-duty roller bearing and seal combination
provides smoother operation, longer life, low maintenance and
grease-free internal compartments.
★Colorful merchandising graphics to build impulse sales.
Applications:
Star Grill-Max Roller Grills, Bun Drawers and Sneeze Guards combine to
make the leading “Hot Dog Center” in the industry. These units, available
in a variety of styles and sizes, are perfect for use in snack bars, conven-
ience stores, recreational facilities, stadiums, and virtually any venue
where fast food is sold.
Quality Construction:
Constructed of heavy gauge stainless steel with options of Duratec or
Chrome rollers with incoloy sheath elements. Infinite temperature
controls for accurate cooking and holding from low to high. Heavy-duty
motor provides 360 rotation of rollers with stadium seating. Units ship
standard with a 6’ cord and plug.
Accessories:
Sneeze guards are formed polycarbonate and meet health department
requirements.
Warranty:
Grill-Max Roller Grills are covered by Star’s one-year parts and labor
warranty.
Phone: [phone] - FAX: [phone] - www.star-mfg.com
Star Manufacturing - 10 Sunnen Drive - P.O. Box 430129 - St. Louis, MO 63143-3800
Star Manufacturing

Dimensions Approximate Weight
(A) (B) (C)
Model Capacity Width Depth Height Voltage Wattage NEMA Amps Shipping Installed
No. Inches Inches Inches Plug lbs. lbs.
(cm) (cm) (cm) (kg) (kg)
30CBD & 30SCBD 30 Hot Dogs 23-3/4 20-5/8 12-1/2 120 1150 5-15P 9.5 61 45
32 Buns (60.3) (52.4) (31.8) 230 CEE7-7 5 (24.9) (20.4)
45CBD & 45SCBD 45 Hot Dogs 23-3/4 28-1/2 12-1/2 120 1650 5-15P** 13.8 78 62
32 Buns (60.3) (72.4) (31.8) 230 CEE7-7 7.2 (33.1) (28.1)
50CBD & 50CSBD 50 Hot Dogs 35-3/4 20- 5/8 12-1/2 120 1535 5-15P 12.8 81 64
120 1535 5-20P* 12.8
48 Buns (90.8) (52.4) (31.8) 230 CEE7-7 6.7 (34.0) (29.0)
75CBD & 75SCBD 75 Hot Dogs 35-3/4 28-1/2 15-1/2 120 1730 5-20P 14.4 120 87
48 Buns (90.8) (72.39) (39.3) 208/240 1810/2400 6-15P 8.7/10 (53.9) (39.4)
230 2210 CEE7-7 9.6
Roller Grills are constructed of all stainless steel and utilizes Duratec non-stick coated rollers or chrome rollers and tubular incoloy sheath
elements. Elements are mounted in a fixed and floating system allowing for lateral expansion to minimize warping. Infinite temperature
controls provide accurate cooking and holding from low to high. Unit has a heavy-duty motor and provides 360º rotation of rollers. The
rollers are arranged in stadium seating with a slope of 3º to 5º, and a graphic door provides better merchandising. The Roller Grill incor-
porates Seal-Max®, Star’s exclusive seal and bearing combination. Units have a pilot light and 6’ lead in cord with NEMA plug. UL-
Sanitation to NSF Std. #4 approved and UL listed. Printed in the U.S.A. Star Grill-Max grills patent #6,393,971 & #6,782,802. Printed in
U.S.A.
Model Specifications
Typical Specifications
C
AB
Grill-Max Roller Grills with built in Bun Drawer
GRILL-MAX ROLLER GRILLS WITH
BUILT-IN BUN DRAWER
Model 30CBD, 30SCBD, 45CBD, 45SCBD, 50CBD,
50SCBD, 75CBD & 75SCBD
Due to periodic changes in designs, methods, procedures, policies and regulations, the specifications contained in this sheet are subject to change without notice. While Star
Manufacturing exercises good faith efforts to provide information that is accurate, we are not responsible for errors or omissions in information provided or conclusions reached as
a result of using the specifications. By using the information provided, the user assumes all risks in connection with such use.
*Canadian Requirements **Not CUL Approved
