Star Micronics TCP300V Series User manual

TCP300V
Series
Point Card System
Operation Manual
[First Edition]
Issued : July, 2004

Introduction
Thank you for purchasing Star's TCP300V series card reader/writer.
Carefully read this "Point Card System" manual prior to using the device, and always keep it handy for
reference while using this product. The information contained in this document will help you use the
system correctly. Refer to the "User’s Guide" that accompanied your new reader/writer for details on
the device.
The "User’s Guide" describes important safety information and should be read carefully.
It is recommended that after you nish reading this manual, store it safely with the "User’s Guide"
where you can easily refer to it.
Precautions
1. Unauthorized copying of any or all of the contents in this manual is strictly prohibited.
2. The contents of this document may change without prior notice because of functional
improvements.
3. Every effort was made to ensure the completeness and correctness of the information
contained herein. In the event that there are any areas of this manual which are difcult
to understand, or that are incorrect, contact us or our sales outlets.
This printer is considered a Class A Information Technology equipment according
to the standards as prescribed by the Voluntary Control Counsel for Interference by
Information Technology Equipment (VCCI). This printer may cause electrical wave
interference if used in a home environment. In such cases users should take the
appropriate precautions.

TABLE OF CONTENTS
Chapter 1 Before Use
Check the accessories.......................................................1
Features...............................................................................1
Names of Parts and Functions..........................................2
Front side..............................................................................2
Back side..............................................................................3
Tenkey ..................................................................................4
•
Allocation of Each Key..............................................................................................5
Installing and Removing the Compact Flash Card..........6
•
Installing a compact ash card..............................................................................6
•
Removing a compact ash card............................................................................6
Specications .....................................................................7
•
Card Specications ....................................................................................................7
•
Compatible modems ................................................................................................7
•
Limits on the number of digits and values that can be input....................7
Chapter 2 Operating the Reader/Writer
Operating procedures ........................................................8
Initial Operations and Settings..........................................9
•
Display immediately after turning the power on ...........................................9
•
Communicating with an ofce computer.........................................................9
Basic Operations .............................................................. 11
•
Adding points...........................................................................................................11
• When the multiplier of the points is not changed .............................................11
• When change the point multiplier
............................................................................12
•
Exchanging points ..................................................................................................14
•
Subtracting points by returning products.....................................................14
• When the multiplier of the points is not changed .............................................14
• When change the point multiplier
............................................................................15
•
Inputting a password............................................................................................16

•
Correcting previous point operations .............................................................17
•
Re-writing a member card ...................................................................................18
•
Issuing a new member card ................................................................................ 18
•
Registering a member...........................................................................................19
•
Re-issuing a member card ...................................................................................20
•
Exchanging a member card ................................................................................22
•
Invalidating a member card ................................................................................23
•
Cleaning......................................................................................................................24
•
Automatic communication..................................................................................25
•
Manual transmission..............................................................................................25
•
Delete history ........................................................................................................... 26
•
Delete all history......................................................................................................27
Welcome point only..........................................................28
•
Adding points...........................................................................................................28
•
Delete all history......................................................................................................29
•
Cleaning......................................................................................................................29
•
Adjusting the display.............................................................................................29
Check Operations.............................................................30
•
Checking the current settings ............................................................................ 30
•
Checking the compact ash card......................................................................33
•
Checking the journal data.................................................................................... 33
Settings and Making Setting Changes ...........................36
•
Setting the date and time ....................................................................................36
•
Setting messages .................................................................................................... 37
•
Changing settings relating to points ...............................................................38
•
Changing the password........................................................................................40
•
Setting the system..................................................................................................41
• How to make settings without using a system setting card ...........................41
If [Normal] is selected........................................................................................42
• How to set using the system setting cards
............................................................49
If [Welcome point only] is selected..................................................................51
•
Adjusting the display.............................................................................................53

Chapter 3 Troubleshooting and Maintenance
Cleaning ............................................................................54
•
Frequency of cleaning...........................................................................................54
•
Cleaning procedures in terminal mode .......................................................... 54
•
Cleaning procedures in stand-alone mode ...................................................54
When trouble occurs........................................................56
•
Display messages....................................................................................................56
•
Trouble when turning on the power................................................................ 58
•
Trouble when operating....................................................................................... 59
Meaning of Symbols Used in This Manual
The information symbols used in this manual provide additional and precautionary
information.
This indicates areas where you should use caution when using the device.
This indicates areas where you should know about the device for use.
This indicates page numbers of related information or pages for reference.

1
Check the accessories
Check that all of the following items have been included in the package.
If any item was not included contact the sales outlet.

Chapter 1 Before Use
Features
High-speed rewriting
(Approximately 3 seconds)
The industry's fastest processing speed.
Opaque type rewrites in 3 seconds.
Large external memory (Optional)
Has slot for commonly used compact ash. This
makes it easy to save data and read using a PC.
256 MB cards can be used; Saves hundreds of
thousands to millions of transaction data.
Easy-to-read display
Large display can display up to six lines of
20 characters (single byte characters). Also
includes a tilting mechanism to adjust to any
angle for easier viewing.
Multi-system function member
Issues, reissues or invalidates card. Enables
setting xed-term points and applies
ECO-points.
Points can be converted or their multipliers
changed.
Member card data has functions for preventing
falsication of remaining points.
Terminal units can be provided with individual
numbers. This makes it possible to organize
point increases/decreases and correction logs
for each device, and to get transaction data
of each device, such as sales and purchase
records.
Transaction data can be collected on a host via
communications.
Can be set as a dedicated ‘welcome point’
device.
Chinese character conversion input
Includes a function for converting Chinese
characters using a tenkey system. Enables
customer name input and messaging to
promote sales.
TCP300V 1 unit
Cleaning uid 1 bottle Cleaning cards 2 cards
User’s manual 1 booklet

2
3
   
    
  

  
  
     
 
      
   
 

     
  
� � 
Names of Parts and Functions

Front side

2
3
     
   
 
     
 
    
 
 
  
Names of Parts and Functions
Back side

4
5
˜
˜







˜
Names of Parts and Functions
KeysName and FunctionKeysName and Function
1
Numerical keys
Used to input amounts (of money),
points and characters.
( See page 5)
6
RTN key
Used to subtract points when a
product is returned.
2
OK key
Used to confirm the input. Used to
select Y in the (Y/N) confirmation display.
7
EXCH key
Used to convert accumulated points
for products or gift certicates.
3
CLR key
Used to delete input information,
terminate processing, initialize the
system and return to the previous
menu. Used to select N in the (Y/N)
conrmation display.
8
(F1 and F2) Function keys
Used to display the list of functions.
The F1 key is used to switch the
character input modes.
9
(F3 and F4) Function keys
Used to select functions.
The F3 key is used to temporarily
conrm or select previous
candidate character when
inputting characters; and the F4
key is used to convert characters or
show the next candidate character
when inputting characters.
4
SET key
Used to conrm system settings.
5
RATE key
Used to change the multiplier of
the points.
Tenkey

4
5
Names of Parts and Functions
• Allocation of Each Key when Inputting Characters
The characters change in the following order when each key is pressed.
After switching to the "symbol" mode by displaying the symbols using the F1 key, switch the
symbols using the F4 key after pressing any tenkey.
The display does not return to the top symbol with F4 after the last symbol is displayed.
KeysEnglishNumber
7
A ⇒B ⇒C ⇒a ⇒b ⇒c8
D ⇒E ⇒F ⇒d ⇒e ⇒f9
G ⇒H ⇒I ⇒g ⇒h ⇒i4
J ⇒K ⇒L ⇒j ⇒k ⇒l5
M ⇒N ⇒O ⇒m ⇒n ⇒o6
P ⇒Q ⇒R ⇒S ⇒p ⇒q ⇒r ⇒s1
T ⇒U ⇒V ⇒t ⇒u ⇒v2
W ⇒X ⇒Y ⇒Z ⇒w ⇒x ⇒y ⇒z3
0
