Star Trac Fitness™
E-TR Treadmill
OWNER’S MANUAL

2
TABLE OF CONTENTS
Introduction...........................................................................................................................................................
................................................................................................................................................................................4
ABOUT THIS MANUAL......................................................................................................................................
...............................................................................................................................................................................4
Important Safety Instructions................................................................................................................................
................................................................................................................................................................................5
ABOUT THIS MANUAL......................................................................................................................................
...............................................................................................................................................................................4
Assembly and Setup............................................................................................................................................
................................................................................................................................................................................16
UNPACKING........................................................................................................................................................
...............................................................................................................................................................................16
TOOLS REQUIRED .............................................................................................................................................
...............................................................................................................................................................................16
ASSEMBLY ..........................................................................................................................................................
...............................................................................................................................................................................16
Operating Instructions.........................................................................................................................................
................................................................................................................................................................................22
DISPLAY PANEL FEATURES ...........................................................................................................................
...............................................................................................................................................................................23
HINTS AND TIPS FOR GETTING STARTED...................................................................................................
...............................................................................................................................................................................24
COOLDOWN CYCLE...........................................................................................................................................
...............................................................................................................................................................................25
USING THE PERSONAL FAN ...........................................................................................................................
...............................................................................................................................................................................25
HEART RATE MONITORING ............................................................................................................................
...............................................................................................................................................................................25
LOCKOUT ID PROCESSING .............................................................................................................................
...............................................................................................................................................................................26
QUICK START .....................................................................................................................................................
...............................................................................................................................................................................26
PRESET PROGRAMS..........................................................................................................................................
...............................................................................................................................................................................27
ADVANCED WORKOUTS PROGRAMS ............................................................................................................
...............................................................................................................................................................................30
Training Information.............................................................................................................................................
................................................................................................................................................................................36
THE FIRST STEP TO A BETTER LIFESTYLE.................................................................................................
...............................................................................................................................................................................37
GETTING STARTED - WALKERS AND RUNNERS ........................................................................................
...............................................................................................................................................................................37
CLIMBING THE CONDITIONING LADDER - SUGGESTED PROGRAMS...................................................
...............................................................................................................................................................................38
PROGRAM VARIATION ON THE E-TR TREADMILL ................................................................................
...............................................................................................................................................................................39
TIPS TO STAY MOTIVATED..............................................................................................................................
...............................................................................................................................................................................40
Preventative Maintenance ...................................................................................................................................
................................................................................................................................................................................41
DAILY MAINTENANCE .....................................................................................................................................
...............................................................................................................................................................................41
WEEKLY MAINTENANCE.................................................................................................................................
...............................................................................................................................................................................41

3
BI-WEEKLY MAINTENANCE ...........................................................................................................................
...............................................................................................................................................................................41
MONTHLY MAINTENANCE..............................................................................................................................
...............................................................................................................................................................................41
ADJUSTMENTS ..................................................................................................................................................
...............................................................................................................................................................................41
REWAX BELT ......................................................................................................................................................
...............................................................................................................................................................................42
Manager / Maintenance Mode .............................................................................................................................
................................................................................................................................................................................44
MANAGER MODE...............................................................................................................................................
...............................................................................................................................................................................44
MAINTENANCE MODE .....................................................................................................................................
...............................................................................................................................................................................45
Troubleshooting ...................................................................................................................................................
................................................................................................................................................................................49
START-UP SERVICE MESSAGES.....................................................................................................................
...............................................................................................................................................................................49
Regulatory Information........................................................................................................................................
................................................................................................................................................................................50
FCC AND OTHER DOMESTIC / INTERNATIONAL REGULATIONS...............................................................
...............................................................................................................................................................................50
INTERNATIONAL REGULATIONS ..................................................................................................................
...............................................................................................................................................................................50
Copyright 2011 Star Trac by Core Industries, Inc. All rights reserved, including those to reproduce this book or parts thereof in any form without first obtaining
written permission from Star Trac.
Every effort has been made to keep this information current; however, periodically, changes are made to the information herein, and these changes will be
incorporated into new editions of this publication. All product names and logos are trademarks of their respective owners.

4
INTRODUCTION
Thank you for choosing the STAR TRAC E-TR TREADMILL. These Treadmills have been designed to provide the
user the most rewarding experience based upon the carefully planned features it possesses. The design elements of these
Treadmills will provide you with a comfortable, intuitive, safe and reliable experience, guiding you to a habit-forming
lifestyle. Our mission is to provide products to mold lifelong habits for health and fitness, and our Treadmills will provide the
path to meet your goals. Enjoy the ride.
ABOUT THIS MANUAL
This manual is applicable to the STAR TRAC E-TR TREADMILLS . The manual is divided into eight sections,
as follows:
Introduction
Provides an overview of each section within the manual.
Safety Instructions
Provides guidelines, in multiple languages, for safely operating the Star Trac E-TR Treadmills.
Assembly and Setup
Provides instructions for unpacking, assembling and setting up the Star Trac E-TR Treadmills.
Operating Instructions
Provides a detailed description of the Display Panel, and includes step-by-step instructions for operating the Star
Trac E-TR Treadmills.
Preventative Maintenance
Describes the preventative maintenance measures required
E-TR
condition.
Manager / Maintenance Mode
Provides step-by-step instructions for changing universal parameters on Star Trac E-TR Treadmills, and for
performing built-in testing procedures.
Troubleshooting
Describes the start-up and shutdown messages provided as a result of the self-test routine.
Regulatory Information
Provides regulatory information for the Star Trac E-TR Treadmills.
to keep the Star Trac Treadmills in top

5
IMPORTANT SAFETY INSTRUCTIONS
When using an electrical appliance, basic precautions should always be followed, including the following: Please read
the owner’s manual in its entirety before operating the treadmill.
DANGER – To reduce the risk of electric shock:
1. Always unplug this appliance from the electrical outlet immediately after using and before cleaning.
WARNING – To reduce the risk of burns, fire, electric shock, or injury to persons:
1. An appliance should never be left unattended when plugged in. Unplug from outlet when not in use,
and before putting on or taking off parts.
2. This appliance is not intended for use by persons (including children) with reduced physical, sensory or
mental capabilities, or lack of experience and knowledge, unless they have been given supervision or
instruction concerning use of the appliance by a person responsible for their safety.
3. Close supervision is necessary when this appliance is used by, on, or near children, invalids, or
disabled persons.
4. Use this appliance only for its intended use as described in this manual. Do not use attachments not
recommended by the manufacturer.
5. Never operate this appliance if it has a damaged cord or plug, if it is not working properly, if it has
been dropped or damaged. Contact Star Trac service support for examination and repair.
6. Do not carry this appliance by supply cord or use cord as a handle.
7. Keep the cord away from heated surfaces.
8. Never operate the appliance with the air openings blocked. Keep the air openings free of lint, hair, and
the like.
9. Never drop or insert any object into any opening.
10. Do not use outdoors.
11. Do not operate where aerosol (spray) products are being used or where oxygen is being administered.
12. To disconnect, turn all controls to the off position, then remove plug from outlet.
SAVE THESE INSTRUCTIONS
WARNING
•You Star Trac E-TR series Treadmill is designed for aerobic exercise in a gymnasium or heath club
environment (FOR COMMERCIAL USE).
•You Star Trac series Treadmill is designed for aerobic exercise in the comfort of you home (FOR
HOUSEHOLD USE ONLY). Children should be supervised to ensure that they do not play with the
appliance.
•Please check with you physician prior to beginning any exercise program. Do not push yourself to excess.
Stop if you are feeling faint, dizzy, or exhausted.
•Use common sense when walking or running on a treadmill.
E-TR

6
GROUNDING INSTRUCTIONS
This product must be grounded. If it should malfunction or breakdown, ground provides a path of least
resistance for electrical current to reduce the risk of electrical shock. This product is equipped with a cord
having an equipment-grounding conductor and a grounding plug. The plug must be plugged into an appropriate
outlet that is properly installed and grounded in accordance with local codes and ordinances.
DANGER - Improper connection of the equipment-grounding conductor can result in a risk of electric shock.
Check with a qualified electrician or serviceman if you are in doubt as to whether the product is properly
grounded. Do not modify the plug provided with the product. If the product must be reconnected for use on a
different type of electric circuit, the reconnection should be made by qualified service personnel in order to avoid
a hazard.
For models rated 110V 20A
This product is rated more than 15 amperes and is for a circuit having a nominal rating of 120-
volt and is factory-equipped with a specific electric cord and plug to permit connection to a
proper electrical circuit. Make sure that the product is connected to an outlet having the same
configuration as the plug. No adapter should be used with this product. If the product must be
reconnected for use on a different type of electric circuit, the reconnection shall be made by
qualified personnel.
For models rated 110V 15A
This product is for use on a nominal 120-volt circuit and has a grounding plug that looks like the plug illustrated
in sketch A in the following figure. Make sure that the product is connected to an outlet having the same
configuration as the plug. If a grounding adapter is needed, the work should be made by qualified service
personnel. Sketch B shows a sample of an acceptable grounding method.

7
BEFORE YOU START
Safety precautions are provided in the following languages (in the order shown):
•English,
•Dutch,
•French,
•German,
•Italian,
•Portuguese,
•Spanish,
•Swedish

8
PRECAUTIONS
CAUTION: READ THE OWNER’S
MANUAL COMPLETELY BEFORE
OPERATING THIS TREADMILL.
STOP (OF ACTIVITY)
CAUTION: BEFORE CLEANING OR
SERVICING, DISCONNECT POWER
SUPPLY.
ON
OFF
I
O
ON
OFF
CAUTION: MOVING PARTS, KEEP
HANDS AND FEET FROM UNDER THE
TREADMILL WHEN OPERATING.
These safety notes are directed to you as the owner of the STAR TRAC E-TR TREADMILL. Please train all your
users and fitness staff to follow these safety instructions.
Do
•Do encourage your members to discuss their health
program or fitness regimen with a health care
professional, especially if they have not exercised for
several years, are over 35, or have known health
conditions.
•Do read all instructions in this manual before using
your treadmill.
•Do use your treadmill only for its intended use, as
described in this manual.
•Do check to ensure the belt is not moving prior to
using the treadmill.
•Do keep the belt surface clean and dry.
•Do stop operating your treadmill if you feel dizzy,
faint or exhausted.
•Do exercise slowly until you reach a level of comfort
and security.
•Do be aware of the location and proper use of the
emergency STOP key.
•Do perform regular preventive maintenance as
suggested in the manual.
•Do keep the electrical cord away from sources of
excessive heat.
•Do keep the treadmill air openings free of lint, hair,
etc.
•Do unplug your treadmill before doing any
maintenance or cleaning.
•Do warm up and cool down before and after each
workout.
•Do set your goals.
•Do complement your walking, jogging, and running
with a nutritious diet.
•Do try charting your progress using the feedback
from your treadmill.
•Do try using the incline feature to burn more
calories and strengthen your lower-body muscles.
Do Not
•Do not let children operate your treadmill. Supervise
invalids or disabled persons who use your treadmill.
•Do not leave your treadmill unattended when it is
plugged in. Unplug it from the outlet when it is not
in use, and before you remove or replace any parts
or accessories.
•Do not use your treadmill without athletic shoes.
•Do not wear loose or hanging clothing while using
the treadmill.
•Do not step or jump on or off your treadmill if the
belt is moving.
•Do not use or store your treadmill outdoors or in an
enclosed pool environment.
•Do not ever drop or insert any object, hands, or feet
into any opening, or underneath this equipment.
•Do not place water bottles or cups on your treadmill
unless you are using the designed holders for the
treadmill. Do not use your treadmill where aerosol
(spray) products are being used or where oxygen is
being administered.
•Do not use attachments or parts not recommended
by the manufacturer.
•Do not run the equipment with the motor shroud
removed, or modify the equipment in any way.
•Do not overtighten the running belt.
•Do not operate your treadmill if it has a damaged
cord or plug, if it is not working properly, if it has
been dropped or damaged, or if the display shows an
error code. Call your dealer or Star Trac at (800)
503-1221, or USA 1-714-669-1660 for service.

9
VEILIGHEIDSINSTRUCTIES
VOORZICHTIG: NEEM DE STEKKER UIT
HET STOPCONTACT VOOR HET
RENIGEN OF ONDERHOULD.
STOPPEN (VAN ACTIE)
VOORZICHTIG: LEES HET
INSTRUCTIEHANDBOEK VOORDAT U DE
MACHINE BEDIENT.
ON
OFF
I
O
AAN
UIT
VOORZICHTIG: BEWEGENDE
ONDERDELEN, HOUD EN VOETEN
ONDER DE LOPENDE BAND VANDAAN.
Deze veiligheidsinstructies zijn aan u gericht als de eigenaar van de STAR TRAC E-TR-HARDLOOPBAND . Train uw
leden en fitness-personeel om deze veiligheidsinstructies te volgen.
LEES ALLE INSTRUCTIES VOORDAT U DE HARDLOOPBAND GEBRUIKT.
WAARSCHUWING: Om het resico van een elektrische schok te verminderen, dient u de stekker van de hardloopband
ALTIJD uit het stopcontact te nemen voordat u hem schoonmaakt.
Doe Dit Wel
•Stop de bediening van de hardloopband als u zich
duizelig voelt of het gevoel heeft dat u flauwvalt.
•Weet hoe ver u kunt gaan.
•Zorg ervoor dat het oppervlak van de band schoon en
droog blijft.
•Neem de stekker uit het stopcontact voordat u de
band reinigt of welk onderdeel dan ook verwijdert of
vervangt. Gebruik dit product alleen voor het
doeleinde vaarvoor het bestemd is.
•Zorg ervoor dat u weet waar de noodstop zit en hoe
deze werkt.
•Verricht regelmatig preventief onderhoud.
•Houd het snoer bij verwarmingssystemen vandaan.
•Wacht totdat de lopende band stil staat voordat u
van de hardloopband stapt.
•Houd luchtopeningen vrij van pluizen, haar etc.
Bedien de hardloopband nooit met beblokkeerde
luchtopeningen.
•Schakel de stroom uit bij de contactschakelaar.
Doe Dit Neit
•Laat kinderen niet zonder toezicht de hardloopband
bedienen.
•Ga de band niet op af terwijl deze loopt.
•Niet buiten gebruiken.
•Draag geen loszittende kleding als u de lopende
band bedient.
•Draai de lopende band niet te strak aan.
•Bedien de hardloopband niet als deze een
beschadigd snoer of stekker heeft, als hij niet goed
werkt of als hij gevallen of beschadigd is. Neem
contact op met uw geautoriseerde STAR TRAC
detailhandelaar of de onderhoudsafdeling van STAR
TRAC op [phone] of bezoek onze website
op http://www.startrac.com voor een onmiddellijke
inspectie of reparatie.
•Gebruid de hardloopband niet zonder gymschoenen.
Laat nooit objecten in het apparaat vallen en steek
geen objecten, handen of voeten in welke opening
van het apparaat dan ook of onder het apparaat.
•Plaats geen waterflessen of bekers op uw
hardloopband tenzij u een houder heeft die speciaal
ontworpen is voor hardloopbanden. Gebruik uw
hardloopband niet in een omgeving waar
spuitbussen worden gebruikt of waar zuurstof wordt
toegediend.
•Bedien het aparaat niet zonder de motorafscherming
of pas het apparaat op geen enkele wijze aan.
WAARSCHUWING
Dit prodkt is voor gebruik op een circuit met een nominale waarde van 220 volt en is in de fabriek uitgerust met een
speciaal elektrisch snoer en stekker om verbinding met een passend elektrisch circuit toe te staan. Zorg ervoor dat dit
produkt verbonden is met een stopcontact dat dezelfde configuratie heeft als de stekker. GEBRUIK GEEN ADAPTER BIJ
DIT PRODUKT. Als het produkt opnieuw verbonden moet worden met een ander type van elektrisch circuit, dan moet deze
verbinding gemaakt worden door gekwalificeerd onderhoudspersoneel.

10
MESURES DE PRECAUTION
ATTENTION: LISEZ SOIGNEUSEMENT
LE MANUEL D’UTILISATION AVANT
D’UTILISER CE TAPIS ROULANT.
ARRÊT (MISE HORS SERVICE)
ATTENTION: DÉBRANCHEZ A LA
SOURCE AVANT D’EFFCTUER UN
ENTRETIEN DU UNE RÉPARATION.
ON
OFF
I
O
OUVRE
FERME
ATTENTION: CONTIENT DES PIECES
MOBILES. GARDEZ LES MAINS ET LES
PIEDS A L’ECART DE LA PARTIE
INFERIEURE DU TAPIS ROULANT
PENDANT SON FONCTIONNEMENT.
Ces instructions sont destinées su propriétaire du TAPIS STAR TRAC E-TR . Assurez vous que votr personnel et vos adhérents
les suivent toujours.
À Faire
•Encouragez vos adhérents à parler de leur
programme d’entraînement à un médecin ou un
entraîneur, en particulier s’ils n’ont pas eu d’activité
sportive pendant plusieurs années, s’ils ont plus de
35 ans ou s’ils ont des kilos superflus.
•Lisez le manuel avant fair fonctionner le tapis.
•Utilisez le tapis exclusivement aux fins don’t il est
destiné. N’utilisez pas d’accessoires qui n’ont pas été
recommandés par le fabricant.
•Attachez toujours vos lacets ets vêtements quand
vous courez sur le tapis.
•Conserver la surface du tapis propre et sèche.
•Arrêtez si vous êtes pris de vertiges ou épuisé.
•Commencez toujours à une vitesse lente.
•Respectez les périodes d’échauffement et de
récupération.
•Vérifier où se trouve l’interrupteur STOP d’urgence
et comment l’utiliser correctement.
•Entrez vos objectifs.
•Complétez votre entraînement par un régime
alimentaire.
•Suivez votre progrès grâce aux informations du
tableau de bord.
•Essayez d’utiliser l’inclinaison afin de brûler plus de
calories et de renforcer les muscles de membres
inférieurs.
•Effectuez régulièrement l’entretien préventif du
tapis.
•Mettez les fils électriques à l’abri de chaleur.
•Enlevez poussière, cheveux etc. de l’aération.
À Ne Pas Faire
•Ne laissez pas d’enfants non-accompagnés sur le
tapis. Une surveillance très stricte est néecessaire si
des personnes invalides ou handicapées utilisent le
tapis.
•Ne laissez jamais le tapis sans surveillance s’il est
branché. Débranchez le tapis si vous ne l’utilisez pas
ou avant de monter ou démonter des pièces.
•Ne pas porter de vêtements larges ou pendants lors
de l’utilisation du tapis roulant.
•Utilisez le tapis uniquement avec des chaussures
appropriées.
•Ne descendez pas ou ne montez pas sur un tapis qui
est en fonction.
•N’utilisez ou ne stockez jamais le tapis à l’extérieur
ou près d’une piscine.
•Ne laissez rien rentrer dans les ouvertures. Ne posez
pas vos pieds sous l’appareil.
•Ne posez pas de bouteilles ou verres d’eau sur
l’appareil sans être équipé avec le en option.
•N’utilisez pas le tapis dans les endroits ou des
aérosols ou de l’oxygène ont été utilisés.
•Débranchez le tapis avant le nettoyage ou le
changement de fusibles.
•N’enlevez pas de vis, ne modifiez pas l’appareil.
•Ne serrez pas trop fort la suface caoutchoutée.
•N’utilisez pas cet appareil si les fils ou la fiche sont
endommagés, s’il est tombé ou cassé. Appelez votre
distributeur pour une révision ou réparation.

11
SICHERHEITSVORSCHRIFTEN
ACHTUNG: GERÄT VOR DEM REINIGEN
ODER WARTEN VON DER
STROMVERSORGUNG TRENNEN.
BEDIENUNG UNTERBRECHEN
ACHTUNG: VOR DER BENUTZUNG
SICHERHEITSVORCHRIFTEN LESEN.
ON
OFF
I
O
EIN
AUS
ACHTUNG: BEWEGLICHE TEILE, BEI
BETRIEB HÄNDE UND FÜSSE VOM
BEREICH UNTER HALB DES
LAUFBANDES FERN HALTEN.
Diese Sicherheitshinweise sind an Sie, den Besitzer des LAUFBANDES STAR TRAC E-TR , gerichtet. Bitte weisen Sie Ihre
Mitglieder und Ihre Fitneß-Mitarbeiter an, sich an die folgenden Sicherheitsvorschriften zu halten.
LESEN SIE ALLE ANWEISUNGEN VOR DER BENUTZUNG DEL LAUFBANDES.
WARNUNG: Um das Risiko eines elektrischen Schlages zu vermeiden, nehmen Sie den Stecker des Laufbands vor dem
Reinigen IMMER aus der Netzsteckdose.
Sie Sollten
•Die Benutzung des Laufbandes beenden, wenn
Schwindel oder Benommenheit aufritt.
•Au Ihre Grenzen denken.
•Das Laufband vor jeglichen Wartungsund
Reinigungsarbeiten abschalten.
•Das Gerät nur für den vorgesehenen
Verwendungszweck benutzen.
•Halten Sie die Oberfläche des Bandes sauber und
trocken.
•Informieren Sie sich über den Ort und die korrekte
Verwendung des Stoppschalters für den Notfall.
•Regelmäßige vorbeugende Wartungsarbeiten
durchführen.
•Die elektrischen Leitungen von Wärmequellen
fernhalten.
•Den Stillstand des Laufriemens abwarten, bevor Sie
das Laufband auseinanderbauen.
•Die Lüftungsöffnungen frei von Staub, Haaren und
Ähnlichem halten.
•Das Laufband niemals mit verdeckten
Lüftungsschlitzen betreiben.
•Die Stromversorgung immer am Netzschalter
abschalten.
Sie Sollten Niemals
•Kinder das Laufband unbeausfsichtigt benutzen
lassen.
•Schutzvorrichtungen entfernen oder das Gerät
umbauen.
•Tragen Sie keine lockere oder herabhängende
Kleidung, wenn Sie das Laufband benutzen.
•Das Gerät im Freien benutzen.
•Den Laufriemen überspannen.
•Das Laufband mit beschädigter Netzleitung betreiben,
wenn es nicht richtig funktioniert, heruntergefallen ist
oder beschädigt wurde. Für sofortige
Reparaturunterstützung kontaktieren Sie einen
autorisierten Händler oder den Kundendienst von
STAR TRAC telefonisch unter [phone], bzw.
Benutzen Sie unsere Web-Seite unter
http://www.startrac.com.
•Das Laufband ohne die passenden Sportschuhe
benutzen.
•Gegenstände in eine Öffnung am Gerät hineinfallen
lassen.
•Gegenstände, Hände oder Füße in eine Öffnung am
Gerät stecken oder diese unter das Gerät legen.
•Wasserflaschen oder Trinkbecher auf das Laufband
stellen, es sei denn, Sie haben ein speziell für diesen
Zweck und für dieses Laufband gedachtes
Zubehörteil.
•Das Laufband in Räumlichkeiten benutzen, in
denen Produkte in Aerosoldosen (Sprays)
angewandt werden oder in denen Sauerstoff
verabreicht wird.
•Das Laufband mit abgenommener Motorabdeckung
laufen lassen, oder das Gerät auf irgendeine Art und
Weise verändern.
WARNUNG
Dieses Produkt ist für den Gebrauch an einer passenden Netzsteckdose mit 220 Volt Spannung bestimmt und werkseitig
mit einer dafür vorgesehenen Netzleitung und einem Netzstecker ausgerüstet. Stellen Sie sicher, daß das Gerät nur an
einem Anschluß mit gleicher Bauart wie der Stecker angeschlossen wird. VERWENDEN SIE DEINEN ADAPTER FÜR
DEN BETRIEB DES PRO / PRO S. Wenn das Gerät zum Betrieb an einem anderen Stromnetz auf einen anderen
Netzstecker umgerüstet werden muß, sollte die Umrüstung durch einen qualifizierten Elektriker durchgeführt werden.

12
ISTRUZIONI DI SICUREZZA
ATTENZIONE: PRIMA DI PULIRE O
ESEGUIRE LA MANUTENZIONE,
TOGLIETE LA SPINA.
FERMA IL MOVIMENTO
ATTENZIONE: PRIMA DI USARE
LEGGETTE IL MANUALE DELLE
ISTRUZIONI.
ON
OFF
I
O
ACCESO
SPENTO
ATTENZIONE: PARTI IN MOVIMENTO.
DURANTE IL FUNZIONAMENTO DEL
TREADMILL ALLONTARE MANI E PIEDI
DAL SUO RAGGIO D’AZIONE.
Queste indicazioni sono indirizzate ai proprietari del TREADMILL STAR TRAC E-TR . Chiedete a tutti I membri della vostra
palestra e al vostro staff di seguire queste istruzioni di sicurezza.
LEGGETE TUTTE LE ISTRUZIONI PRIMA DI USARE IL TREADMILL.
ATTENZIONE: per redurre il rischio di scossa elettrica, staccate SEMPRE la spina della corrente del treadmill prima di
pulirlo.
Da Fare
•Fermate il treadmill se vi sentite svenire o avete
capogiri.
•Siate coscienti dei vostri limiti.
•Mantenere il nastro asciutto e pulito.
•Staccate la spina prima di pulire, spostare o
cambiare qualsiasi parte del treadmill.
•Usate questo prodotto solo per l’uso inteso.
•Assicurarsi di essere a conoscenza della posizione e
dell’uso corretto del pulsante di emergenza STOP.
•Eseguite la manutenzione regolare.
•Mantenete la corda elettrica lontana da fonti di
calore.
•Aspettate fino a quando il nastro è completamente
fermo prima di scendere dal treadmill.
•Pulite le prese d’aria da polvere, capelli e simili. Non
usate mai il treadmill con le prese d’aria bloccate.
•Spegnete la macchina tramite l’interruttore.
Da Non Fare
•Non permettete a bambini di usare il treadmill
senza sorveglianza.
•Non salite o scendete dal treadmill mentre è in
funzione.
•Non usatelo all’aperto.
•Durante l’uso del treadmill non indossare indumenti
che possano impigliarsi in organi in movimento.
•Non tirate troppo il nastro.
•Non usate il treadmill se il cavo elettrico o las spina
sono danneggiati, se non funziona come dovrebbe o
se è caduto o è danneggiato. Contattate il volstro
rivenditore autorizzato STAR TRAC o l’assistenze
clienti dello STAR TRAC al numero +1 714 669
1660 o visitate il nostro sito Internet a
http://www.startrac.com, per esame o riparazione
immediata.
•Usate il treadmill solo se calzate scarpe da
ginnastica.
•Non lasciate cadere oggetti e non inserite mani or
piedi nelle aperture o al di sotto del treadmill.
•Non appoggiate bottiglie d’acqua o bicchieri sul
treadmill a meno che non stiate usando un supporto
progettato appositamente per il treadmill.
•Non usate il treadmill in posti dove sono usati
prodotti aerosol (spray) o dove è somministrato
dell’ossigeno.
•Non accendete il treadmill con il coperchio del
motore remosso, e non modificatelo in nessun modo.
ATTENZIONE
Questo prodotto è da usare su un circuito elettrico con una tensione nominale di 220 volt ed è fornito dalla fabbrica con un
cavo elettrico e spina specifici per permettere il collegamento ad un circuito elettrico appropriato. Assicuratevi che il
prodotto sia collegato ad una presa che abbia la stessa configurazione della spina. NESSUN ADATTATORE DEVE
ESSERE USATO CON QUESTO PRODOTTO. Se il prodotto deve essere recollegato per l’uso su un circuito elettrico
diverso, il ricollegamento deve essere effettuato da un elettricista qualificato.

13
INSTRUÇÕES DE SEGURANÇA
ATTENÇÃO: ANTES DE LIMPAR OU
FAZER MANUTENÇÃO, DESCONECTE O
APARELHO DA TOMA DA.
PARE (A AÇÃO)
ATTENÇÃO: LEIA O MANUAL DE
INSTRUÇÕES ANTES DE OPERAR A
ESTEIRA.
ON
OFF
I
O
1 LIGAR
O DESLIGAR
ATTENÇÃO: PROTEJA AS MÃOS E OS
PÉS AO MOVER PEÇAS COM A EST EIRA
EM FUNCIONAMENTO.
Estas observações de segurança destinam-se à você, proprietário de ESTEIRA STAR TRAC E-TR. Treine todos os membros e
funcionários que utilizarão o equipamento para que sigam estas instruções de segurança.
LEIA TODAS AS INSTRUÇÕES ANTES DE USAR SUA ESTEIRA
ADVERTÊNCIA: para reduzir os rescos de choque elétrico, SEMPRE desconecte a esteira da tomada antes de limpá-la
Faça
•Pare de usar a esteira se você se sentir fraco ou
com tontura.
•Conserve a superfície da correia limpa e seca.
•Reconheça seus limites.
•Desconecte a esteira da tomada antes de limpá-la
ou antes de remover ou substituir qualquer peça.
•Utilize este equipamento única e exclusivament
para o seu devido fim.
•Informe-se sobre a posição e o uso adequado da chave
de emergência STOP.
•Faça manutenção preventiva regularmente.
•Mantenha o fio afastado de superfícies aquecidas.
•Espere até que a esteira esteja completamente
parada antes de descer do aparelho.
•Mantenha as saídas de ar desobstruídas de fiapos
de tecidos, cabelos e outros objetos. Nunca opere a
esteira coma as saídas de ar bloqueadas.
•Desligue o aparelho com o interruptor de força.
Não Faça
•Não permita que crianças operem a esteira sem
supervisão de um adulto.
•Não suba ou desça da esteira enquanto ela estiver
em movimento.
•Não use roupas folgadas enquanto estiver
utilizando a esteira.
•Não utilize a esteira ao ar livre.
•Não estique demais o tapete da esteira.
•Não opere esta esteira se o cabo de alimentação ou
o plugue da tomada estiverem danificados, se ela
não estiver funcionando perfeitamente ou se tiver
sofrido queda ou danos. Procure seu revendedor
autorizado STAR TRAC ou o departamento de
assistência técnica STAR TRAC pelo telefone 1
714 669 1660 ou acesse nosso “web site” no
endereço http://www.startrac.com para fazer uma
consulta ou conserto imediato.
•Não utilize a esteira sem calçar tênis.
•Não deixe cair nem introduza nenhum objeto, as
mãos ou pés em nenhuma abertura do
equipamento ou debaixo deste.
•Não coloque garrafas d’água nem copos na esteira
se não estiver utilizando o devido acessório
projetado para esse fim. Não utilize a esteira onde
estejam sendo usados produtos de aerosol (spray)
ou em lugares onde esteja sendo administrado
oxigênio. Não opere o equipamento com a tampa
do motor removida nem faça nenhuma
modificação no equipamento.
ADVERTÊNCIA
Este produto deve ser usado em um circuito com tensão nominal de 220 volts. Ele foi fabricado com um cabo de alimentação
e plugue específicos para permitir a sua conexão com um circuito elétrico apropriado. Certifique-se de que o produto esteja
conectado a uma tomada com as mesmas configurações do plugue. NÃO UTILIZE ADAPTADORES PARA ESTE
PRODUTO. Se for necessário reconectar a produto para utilização em um tipo diferente de circuito elétrico, este
procedimento deverá ser executado por pessoal qualificad.

14
INSTRUCCIONES DE SEGURIDAD
ATENCIÓN: DESCONECTE EL
SUMINISTRO DE CORRIENTE ANTES DE
LIMPIAR O REPARAR.
PARAR (EL FUNCTIONAMIENTO)
ATENCIÓN: LEA EL MANUAL DE
INSTRUCCIONES ANTES DE SU
UTILIZACIÓN.
ON
OFF
I
O
ENCENDIDO
APAGADO
ATENCIÓN: PIEZAS EN MOVIMIENTO!
MANTENGA LAS MANOS Y LOS PIES
ALEJADOS DE LA PARTE INFERIOR DE
LA CINTA QUAND LA MISMA ESTÉ EN
FUNCIONAMIENTO.
Estas notas sobre seguridad van dirigidas a Vd. Como propietario del TAPIZ RODANTE STAR TRAC E-TR. Haga que todos
los usuarios y preparadores físicos cumplan estas instrucciones de seguridad.
LEA TODAS LAS INSTRUCCIONES ANTES DE UTILIZAR SU TAPIZ RODANTE.
ADVERTENCIA: Para reducir los riegos de sufrir una descarga eléctrica, desenchufe SIEMPRE el tapiz rodante antes de
limpiarlo.
Qué Hacer
•Detenga el tapiz rodante si se nota desfallecido o
mareado.
•Mantenga la superficie de la cinta seca y limpia.
•Conozca sus limitaciones.
•Desenchufe el tapiz rodante antes de limpiar, quitar
o cambiar alguna pieza.
•Asegúrese de saber dónde está el interruptor de
emergencia STOP y cómo utilizarlo adecuadamente.
•Utilice este producto sólo para los usos que está
diseñado.
•Realice un mantenimiento preventivo de manera
regular.
•Mantenga el cable separado de fuentes de calor.
•Espere a que la cinta móvil haya parado antes de
descender del tapiz rodante.
•Mantenga las entradas de aire libres de pelusa, pelo
y similares. No utilice nunca el tapiz rodante con las
entradas de aire bloqueadas.
•Desconecte de la corriente por medio del disyuntor.
Qué No Hacer
•No permita que los niños utilicen el tapiz rodante
sin supervisión.
•No suba o baje del tapiz rodante mientras está
funcionando.
•No lleve ropa suelta ni que cuelgue mientras utiliza
la cinta andadora.
•No debe utilizarse en exteriores.
•No tense demasiado la cinta móvil.
•No utilice este tapiz rodante si tiene el cable o el
enchufe dañados, si no funciona adecuadamente o si
ha sufrido algún golpe o deterioro. Póngase en
contacto con su vendedor autorizado de STAR
TRAC, con el departamento de servicios de STAR
TRAC llamando al número [phone] o
accediendo a nuestra página de la web en
http://www.startrac.com, para un examen o
reparación inmediatos.
•No utilice el tapiz rodante sin calzado deportivo.
•No deje caer ni introduzca ningún objeto, manos o
pies en ninguna abertura del aparato o debajo del
mismo.
•No deje botellas de agua ni tazas sobre su tapiz
rodante excepto si utiliza el accesorio adicional
diseñado para este fin. No. utilice su tapiz rodante
en lugares en los que se están usando productos
aerosoles (en spray) o en los que se está
administrando oxígeno.
•No encienda este aparato con la cubierta del motor
retirada, ni lo modifique de ninguna manera.
ADVERTENCIA
Este producto está preparado para utilizarse en un circuito de 220 voltios y se suministra equipado de fábrica con un cable y
un enchufe eléctricos específicos para permitir su conexión a un circuito eléctrico apropiado. Asegúrese de que el producto se
conecte a una toma de corriente con la misma configuración que el enchufe. NO UTILICE NINGÚN ADAPTADOR CON
ESTE PRODUCTO. Si este producto necesita ser modificado eléctricamente para utilizarse en un tipo diferente de circuito
eléctrico, dicha modificación debe ser realizada únicamente por el personal de servicio calificado.

15
SIKKERHEDSINSTRUKTIONER
FORSIGTIG: AFBRYD EL-KABLET, FØR
DU GØR RENT ELLER SERVICERER.
STOP (AF FUNKTION)
FORSIGTIG: LÆS
INSTRUKTIONSHÅNDBOGEN FØR BRUG.
ON
OFF
I
O
TÆND
SLUK
FORSIGTIG: RÖRLIGA DELAR – LÅT
INGA HÄNDER ELLER FÖTTER BEFINNA
SIG UNDER LÖPBANDET NÄR DET ÄR
IGÅNG.
Disse sikkerhedsbemærkninger henvendes til ejeren af STAR TRAC E-TR ÆDEMØLLEN . Sørg venligst for, at alle
medlemmer og alt kondipersonale kender og følger disse sikkerhedsregler.
LÆS ALLE INSTRUKTIONERNE, FØR DU BRUGER DIN TRÆDEMØLLE.
ADVARSEL: For at mindske risikoen for at få elektrisk stød, skal du ALTID trække trædemøllens stik ud af kontakten, før
du gør den ren.
Skal
•Stig af trædemøllen, hvis du bliver mat i kroppen
eller svimmel.
•Kend dine begrænsninger.
•Håll löpbandets yta torr och ren.
•Træk trædemøllens stik ud af kontakten, før du gør
den ren, eller fjerner eller udskifter en del.
•Brug kun produktet til det formål, det er beregnet
til.
•Foretag forebyggende vedligeholdelse med
regelmæssige mellemrum.
•Tänk på placeringen av löpbandet samt att du
endast använder nödknappen Stop när det är
nödvändigt.
•Holdledningen fri af varmeanlæg.
•Vent til løbebåndet standser, før du stiger af
trædemøllen.
•Hold ventilationsåbningerne fri for fnug, hår og
lignende. Brug aldrig trædemøllen med blokerede
luftventilationsåbninger.
•Sluk for elektriciteten på afbryderkontakten.
Må Ikke
•Tillad ikke børn uden opsyn at bruge trædemøllen.
•Stig ikke på eller af trædemøllen, mens den kører.
•Bär inga löst hängande kläder som kan fastna när
du använder löpbandet.
•Brug ikke trædemøllen udendørs.
•Stram ikke løbebåndet for meget.
•Brug ikke trædemøllen, hvis ledningen eller stikket
er beskadiget, hvis trædemøllen ikke fungerer
rigtigt, eller hvis den er faldet ned eller væltet og er
blevet beskadiget. Kontakt den autoreserede STAR
TRAC, forhandler eller serviceafdelingen hos STAR
TRAC Ring på [phone] eller du kan få fat i
os på vores web-site: http://www.startrac.com for
øjeblikkeligt eftersyn eller reperation.
•Brug ikke trædemøllen uden kondisko.
•Undgå at tabe eller at stikke genstande, hænder
eller fødder ind i en åbning i eller under udstyret.
•Stil ikke vandflasker eller kopper på trædemøllen,
medmindre du har dertil beregnet tilbehør, som er
specielt designet til trædemøllen. Brug ikke
trædemøllen på steder, hvor der bruges
aerosolprodukter (spray), eller hvor der administreres
ilt.
•Udstyret må ikke køre uden motorafskærmning, og
det er ikke tilladt at ændre udstyret på nogen måde.
ADVARSEL
Dette produkt er beregnet til brug i forbindelse med et el-net med nominel effekt på 220 volt. Det leveres med særlig
ledning og stik fra fabrikken, som kun passer til den korrekte type el-net. Sørg for, at produktet er sat til en stikkontakt,
som har samme konfiguration som stikket. DER MÅ IKKE BRUGES ADAPTER TIL DETTE PRODUKT. Hvis produktet
absolut skal omstilles til en anden slags el-net, skal omstillingen foretages af kvalificeret servicepersonale.

16
ASSEMBLY AND SETUP
Use the following procedures to unpack and assemble your STAR TRAC E-TR TREADMILL . Assembly procedures
are the same for all E-TR TREADMILLS .
UNPACKING
Open the shipping carton, remove all parts from the carton and foam inserts, and verify that the following parts are included
in your shipment:
Main Subassemblies Description Qty
1. Base Assembly 1
2. Display Console Assembly 1
3. Neck (and Grommet) 1
4. Handrail (and Grommet) 2
5. Power Cord 1
6. Manual and Warranty Card 1
n/a Hardware Kit 1
Hardware Kit Description Qty
Screw 5/16"-18 x 1 3/4" 4
Washer, Lock, 5/16" 16
Washer, Flat, 5/16" I.D. x 1/2" O.D. 16
Screw 1/4"-28 x 3/8", Button Head 4
Screw 5/16"-18 x 1", Socket Head 12
Screw #10-16 x 1/2" Tapping Pan Head 6
Screw M4 x 0.7 x 19mm, Pan Head 14
TOOLS REQUIRED
Most STAR TRAC treadmills can be assembled using the following tools:
•1/4” Hex Key (included)
•5/32” Hex Key (included)
•#2 Phillips Head Screwdriver (included)
•Torque Wrench (not included)
ASSEMBLY
1. Unpack and Position the Base Assembly
CAUTION: The motor end of the base assembly is very heavy. It is recommended that two people lift this end when
moving the base assembly.
Remove all packaging material so the base assembly is sitting on the shipping crate platform. With a helper, lift the
base assembly from the shipping crate platform, and place it in the location where it will be used. Be sure the
selected location is level, and close to a power outlet. Remove the motor shroud for installation of the handrails.
7. Handrail Collar 1

17
Locate the neck assembly (Qty. 1) and neck grommet (Qty 1) with console cables pre-installed inside. Remove
packing material and slide the neck grommet over the neck. Position the neck in place on the motor end of the base
assembly and secure with four 5/16"-18 x 2.0" socket head bolts, 5/16 lock washers, and 5/16" flat washers. Install all
four bolts then tighten securely.
3. Install the Display Console
Locate and position the display console on the neck, taking care not to pinch the display cable between the neck and
the console. Once the console is properly positioned, secure the console to the neck using four 5/16"-18 x 1.0" socket
head bolts, 5/16 lock washers, and 5/16" flat washers. Install all four bolts then tighten securely.
5/16-18 x 1 3/4” Socket Head Bolts
5/16 Lock Washers
5/16 Flat Washers
5/16-18 x 1” Socket Head Bolts
5/16 Lock Washers
5/16 Flat Washers
2. Install the Neck

18
4. Install the Handrail
NOTE: Both handrails are installed in a similar manner.
Locate the handrails (Qty. 2) and handrail grommets (Qty. 2), slide the grommet onto each handrail. Insert the
connecting tube of the handrail into the handrail stub in the display console. Now slide the handrail fully into the
console. Secure the handrail to the treadmill base assembly with four 5/16"-18 x 1.0" socket head bolts、5/16 lock
washers, and 5/16" flat washers. Secure the handrail to the display console with two 1/4"-28 x 3/8" button head bolts.
Install the remaining handrail in similar manner.
5. Connect the Display Cable
Connect the main interface ribbon cable and DC power cable to corresponding connectors on the console.
At the treadmill base connect the main interface ribbon cable and DC power cable to the corresponding MCB
connectors.
ConsoleCableConnection BaseCableConnection
5/16-18 x 1” Socket Head Bolts
5/16 Lock Washers
5/16 Flat Washe
r
s
1/4-28 x 3/8” Socket Head Bolts
DC Power
I/O Ribbon Cable
I/O Ribbon Cable
This plug is only used
when installing PVS kit

19
6. Install Rear Console Top and Bottom Shrouds
Secure rear console bottom shroud to console in the correct position with six M4 x 0.7 x 19mm, Pan Head Screws,
then secure console top rear shroud to console in correct position with eight M4 x 0.7 x 19mm, Pan Head Screws,
tighten all screws securely.
7. Install Side Treads on Base Assembly
Remove the paper layer of the adhesive tape located on the back of side tread plates, now install the tread into
position on the base assembly with one #10-16 x 1/2" tapping pan head screw.
Install the remaining tread in similar manner.
M4x19mm, Pan
Head Screw
#10-16 x 1/2" Pan Head Screws

20
8. Install Motor Top Cover
Remove the paper layer of the adhesive tape located on the back of the motor top cover, secure the front end of the
cover to base assembly with two #10-16 x 1/2" tapping pan head screws, then secure the back end of cover to base
assembly with two #10-16 x 1/2" tapping pan head screws.
Note: Slide both handrail grommets down into position on the base assembly after motor top cover is installed.
9. Install Motor Cover Trim Ring
Snap the motor front cap on the motor shroud and slide the neck grommet down into position.
#10-16 x 1/2" Pan Head Screws
