Star Grill-Max 30SCHDM-120V Owner's manual

¸
¸
¸
®
ROLLER GRILLS
MODELS
30SCHDM-120V, 50SCHDM-120V,
75SCHDM-240V
Innite Controls
& Heated Bun Drawer
45SCHDEP-120V, 50SCHDEP-120V
50SCHDEM-120V, 50STHDE-120V,
75SCHDEM-120V
Electronic Controls
& Heated Bun Drawer
Installation and
Operation
Instructions
2M-Z11808 Rev. C 10/29/15
IL1541

2
2
These symbols are intended to alert the user to the presence of
important operating and maintenance instructions in the manual
accompanying the appliance.
RETAIN THIS MANUAL FOR FUTURE REFERENCE
NOTICE
Using any part other than genuine Star factory supplied parts relieves the
manufacturer of all liability.
Star reserves the right to change specications and product design without
notice. Such revisions do not entitle the buyer to corresponding changes,
improvements, additions or replacements for previously purchased
equipment.
Due to periodic changes in designs, methods, procedures, policies and
regulations, the specications contained in this sheet are subject to change
without notice. While Star International Holdings Inc., Company exercises
good faith efforts to provide information that is accurate, we are not
responsible for errors or omissions in information provided or conclusions
reached as a result of using the specications. By using the information
provided, the user assumes all risks in connection with such use.
MAINTENANCE AND REPAIRS
Contact your local authorized service agent for service or required maintenance.
Please record the model number, serial number, voltage and purchase date in the area below and have it
ready when you call to ensure a faster service.
SAFETY SYMBOL
Model No.
Serial No.
Voltage
Purchase Date
Business 8:00 am to 4:30 p.m. Central Standard Time
Hours:
Telephone: [phone]
Fax: [phone]
E-mail [email protected]
Website: www.star-mfg.com
Service Help Desk
Authorized Service Agent Listing
Reference the listing provided with the unit
or
for an updated listing go to:
Website: www.star-mfg.com
E-mail [email protected]
Mailing Address: Star International Holdings Inc., Company
10 Sunnen Drive
St. Louis, MO 63143
U.S.A

2M-Z11808: GRILL-MAX Roller Grills, Heated Bun Drawer
TABLE OF CONTENTS
PAGE NUMBER
GENERAL SAFETY INFORMATION 3
GENERAL INSTALLATION INFORMATION 4
Connection Load 4
GENERAL OPERATING INSTRUCTIONS
Bun Box 5
 InniteControls 5
 ElectronicControls 6
 Cleaning 7
WARRANTY
 OutsidetheUnitedStates 8
 UnitedStates 9
WIRINGDIAGRAM 8
EXPLODED VIEW 10 - 11
PARTS LIST
50 MODEL SERIES 12 - 13
GENERAL SAFETY INFORMATION
Thisequipmentisdesignedandsoldforcommercialuseonlybypersonneltrainedandexperiencedin
itsoperationandisnotsoldforconsumeruseinandaroundthehomenorforusedirectlybythegeneral
publicinfoodservicelocations.
Beforeusingyournewequipment,readandunderstandalltheinstructions&labelsassociatedwiththe
unitpriortoputtingitintooperation.Makesureallpeopleassociatedwithitsuseunderstandtheunits
operation&safetybeforetheyusetheunit.
Allshippingcontainersshouldbecheckedforfreightdamagebothvisibleandconcealed.Thisunithas
beentestedandcarefullypackagedtoinsuredeliveryofyourunitinperfectcondition.Ifequipmentis
receivedindamagedcondition,eitherapparentorconcealed,aclaimmustbemadewiththedelivering
carrier.
Concealeddamageorloss-ifdamageorlossisnotapparentuntilafterequipmentisunpacked,a
requestforinspectionofconcealeddamagemustbemadewithcarrierwithin15days.Becertainto
retainallcontentsplusexternalandinternalpackagingmaterialsforinspection.Thecarrierwillmakean
inspectionandwillsupplynecessaryclaimforms.
GENERAL INSTALLATION INFORMATION
Thegrillshouldbeconnectedtoawalltypereceptacle,adirectlineor
individualbranchcircuit.Anindividualbranchcircuitispreferred.If
connectedtoanoverloadedcircuitthegrillwillnotoperateproperly.
Theunitshouldbelevelwheninstalled.Modelsequippedwithbun
boxesmustbeleveltoutilizetheself-closingfeatureofthebun
drawer.Adjustable4-inchlegsarestandardonthe75seriesand
availableforallothermodels.
Thisgrillisequippedforthevoltageshownonthenameplate.Itwill
operateonalternatingcurrentonly,however,thespeciedvoltage
mustbeapplied.
DO NOT CONNECT TO DIRECT CURRENT (DC).
IMPORTANT
UNLEVEL UNITS COULD RESULT IN HAVING PRODUCT TRAVEL FROM ONE SIDE
TO THE NEXT, OVER A PERIOD OF TIME.
3
CAUTION
WARNING
CONNECTION LOAD
Innite Control
Model Series Wattage
30SCHDM 1380
45SCHDEP 1650
50SCHDEM 1565
50SCHDEP 1565
50SCHDM 1885
75SCHDEM-208/240 1920/2500
75SCHDM-208/240 1920/2500

2M-Z11808: GRILL-MAX Roller Grills, Heated Bun Drawer
GENERAL OPERATING INSTRUCTIONS
BUN WARMER
Operatingthebundrawerrequiresllingthepanwithfreshbunsandremovingthestalebunsas
required.Theheatedbundrawerisnotmeanttotoastthebunsandthetemperatureshouldbeat
122°F(50°C).Todeterminethecorrectsetting,settheBunBoxKnobto#3,usingathermometer,
adjustuntilthecorrectsettingisreached.NO WATER IS REQUIRED OR RECOMMENDED.
Allunitsareequippedwithaneasilyremovedbunpanwhichcanberemovedbyliftingoutofthe
openbundrawer.Thismakesdailycleaningofthepaneasy.Itisnecessarytoremovethebun
drawerbeforeattemptingtoremovethedriptraywhenaccesstotherearoftheunitisobstructed.
Toremovethebundrawer,rstallowtheunittocool,removebunpan,thengrabthedrawerbyboth
sidesandpullitoutalltheway.Liftthefronttounhookthedrawerslidefromreardrawerroller.Pull
thedrawertheremainderofthewayout.Usecautionnottodropthedrawerwhenreachingtheend
ofthedrawerslidetravel.Toreinsertthedrawer,rsthookthedrawerslideovertherstrightside
rollerthenpushthedrawerinuntilthesecondrollerdropsin,doingonesideatatime.Repeatforleft
siderollers.Reinsertbunpan.Donotoperatethegrillwithoutthedriptrayinplace.
OPERATING PROCEDURES FOR INFINITE CONTROL GRILLS
Themainswitchlocatedonthecontrolpanelcontrolsallthepowertotheunit.Withthemainswitch
on,therollerswillturn,heatwillbesuppliedtothebunbox,butnoheatwillbesuppliedtotherollers
unlesstheheatcontrolsareturnedon.Theswitchislightedtoindicatewhentheunitisturnedon.
Forexibilitytheheatingsectionofthegrillisdividedintotwoindividuallycontrolledheatsections.
Therightcontrolregulatestheheattotherearsectionandtheleftcontrolregulatestheheattothe
frontsection.OnInnitecontrolgrillsasignallightisprovidedaboveeachheatcontroland
indicateswhentheheatedsectionison.Anadditionallightisprovidedontheendhousingoftheunit
thatindicatesthepositionofthemainpowerswitch.
COOKING
Theheatcontrolsprovideaninniterangeofsettingsforawidevarietyoffoodproductsand
installationconditions.Thesize,contentandshapeoftheproductandtheinstallationofanysanitary
foodshieldsorsneezeguardswilldeterminetheproperheatsetting.TheNationalSanitation
Foundationrequiresthatperishablefoodsbekeptat60°Coraboveduringservingperiods.Do
notkeepthefoodproductonalowsettingformorethantwohours.Theproductshouldbekept
refrigerateduntilreadyforuse.Cookingtimewillvarydependingonthestartingtemperatureandthe
qualityoftheproduct.Forbestresultswhencookinghotdogsuseahotdogmadeforgrilling.
4
Bun Warmer Front
Control
Power
Switch
Rear
Control
IL1540

2M-Z11808: GRILL-MAX Roller Grills, Heated Bun Drawer
5
IL2010
Bun Box Front Control Rear Control Power Switch
LED
ElectronicControls
START-UP
Wheninitiallyturningonpowertotheelectroniccontrolled
grill,itwillbeintheHOLDmode.Thedisplayswillashuntil
thesetpointtemperatureisreached,heatwillbesupplied
tothebunbox.The grill will beep once when it is up to
temperature.  Innite controlled grills have no notication
whenoperatingtemperatureisreached.
HEATING
Thesize,content,andshapeoftheproductandtheinstallation
ofanysanitaryfoodshieldsorsneezeguardswilldetermine
theproperheatsetting.TheNationalSanitationFoundation
requiresthatallperishablefoodsbekeptat140°Forabove
duringservingperiods.
Theproductshouldbekeptrefrigerateduntilreadytouse.
Heatingtimesvarydependingonthestartingtemperature
andthequalitiesoftheproduct.Forbestresults,useahot
dogorproductsthatarermadeforgrilling.
Beforecookingforthersttime,washtherollerswithmildsoap
andwaterusingasoftcloth.Whentheelectroniccontroled
grillsareinitiallyturnedon,thedisplayswillashtheHOLD
temperatureuntilthegrillreachesthatsetpoint.
Withthegrillpreheatedtotheholdtemperature,loadwith
thedesiredproductandpresstheHEATbutton.Thegrillwill
thengointotheheatmodeandthedisplayswillashuntil
theHEATtemperatureisreached.Aftertheheatingcycle,
thegrillwillbeepfourtimesandthefoodproductwillbeat
theservingtemperature.Thegrillwillautomaticallyreturn
totheHOLDtemperature.
NOTE: Based on the product being heated, some
experimentation is required to nd the optimal HEAT
temperature and HEAT time to bring the product up to
temperatureinanacceptableamountoftime.
PROGRAMMING
Theelectronic controls provide programmable HEATand
HOLDsettingsforavarietyoffoodproductsandinstallation
conditions.
Toprogramtheelectronicrollergrill:
1. Withthegrillon,pushandholdthe and onthe
sideyouwishtoprogramtogetherforthreeseconds
untilthealarmbeepsonceandthedisplayblanks.
2. Tosettheheattemperatureand/orheattime,push
theheatbutton.Thelastsavedheattimewillbe
displayedandtheHEATLEDwillashandHEAT
TIMEindicatorwillbeON.Usethe and
buttonstoadjusttothedesiredtime,thenpressthe
HEATbuttonagain.TheHEATTIMELEDindicator
willturnoffandtheHEATTEMPLEDindicatorwill
nowbelit.WhenprogrammingtheHEATtemperature
iscomplete,pushtheHEATbuttononemoretimeto
exittheprogrammingmode.
3. Tosettheholdtemperature,repeatstep1above
thenpushtheHOLDbutton.Thelastsavedhold
temperaturewillbedisplayedandHOLDLEDwill
beON.Usethe and buttonstoadjusttothe
desiredtemperature,thenpresstheHOLDbutton
againtoexitprogrammingmode.
4. Toturntheheatofftothefrontorrearsection,press
andholdthe forthatsectionfor3seconds."OFF"
willbedisplayed.Toturnthesectionbackon,press
theHEATorHOLDbutton.
OPERATING PROCEDURES FOR ELECTRONIC GRILLS
