KT-LCD5 eBike
Display User Manual
KT-LCD5 eBike Display User Manual
Dear customer, please read this manual before you use KT-LCD5 instrument. The manual will guide you use the
instrument correctly to achieve a variety of vehicle control and vehicle status display.
1 UP Button
11
Riding speed(metric)
2SW Button Riding speed (imperial)
3DOWN Button MAX speed
4ASSIST PAS Level Average speed
5Battery Capacity Indicator
12
Distance(metric)
6Cruise function Distance (imperial)
7Power-assisted function Trip distance
8
Single trip time Total distance
Total trip time Battery voltage
9Throttle display 13 The brake display
10 6Km/H push power assist 14 Backlight and headlights
OPERATIONS
ON/OFF
Hold button long to turn on the power, and hold long for a second time to turn off the power. When the
motor stops driving and when the e-bike is not used for a consecutive 5 minutes, it will automatically shut down
and turn off the motor power supply.
Display 1
Hold button to start up and enter display 1.
Turn on backlight and headlights
Hold long to turn on backlight and headlights (the controller
should have headlight drive output function).
Hold long again to turn off the backlight and headlights.
Assist ratio gear (ASSIST) switch
Hold or shortly to switch 1-5 le gear. Gear 1 is for the
minimum power, gear 5 is for the highest power.
Each startup will automatically restore the gear shutdown last
time(the user can set randomly).
Gear 0 is without booster function.
THROTTLE display
Turn on throttle, THROTTLE display.
KT-LCD5 eBike Display User Manual starebike.it 21 starebike.it KT-LCD5 eBike Display User Manual
Cruise function
After the cruise function is turned on, the trip riding speed is greater
than 7 km/ h, hold long and enter cruise, the CRUISE lit. Brake or
hold any button to cancel.
Display and delete of single Data
After power on for 5 seconds, hold and at the same time,
single trip riding time (TM) and single trip distance (DST) ash, hold
button shortly, the content of both is cleared.
If failed holding the button within 5 seconds, it will automatically
return the display interface after 5 seconds, original content is
preserved.
Display 2 Hold button shortly in display 1 to enter display 2. In the riding
mode after 5 seconds, display 2 automatically returns to display 1.
Display 3 Hold button shortly in display 2 to enter display 3. In the riding
condition, ve seconds later, a single maximum speed (MXS) display
automatically returns to the real riding speed (Km/H).
In display 3, hold button shortly (SW),and the display will re-
enter display 1
Hold button to turn off the display and the power supply of controller.
Automatically prompt interface
Error Code Display
Error Code Denition
01 info Throttle Abnormality
02 info Motor hall signal Abnormality
03 info Motor or controller has short circuit
Abnormality
Electronic control system failure will display (ashing) fault code. Once the fault was removed, it automatically
exits from the fault code display interface.
GENERAL PROJECT SETTING
Set maximum riding speed
After power on for 5 seconds, hold and at the same time and
maximum riding speed Km/H and MXS ash, or shortly to set
hold the maximum riding speed (default 25Km/H).
button shortly and Hold go to the next parameter settings.
DO NOT SET ABOVE LOCAL SPEED LIMIT FOR THIS DEVICE
Wheel diameter setting
The wheel diameter will be set after nishing setting the maximum
riding speed, wheel diameter specications ashes. Hold and
shortly to set the specications of wheel diameter.
Select the range 6, 8, 10, 12, 14, 16, 18, 20, 22, 24, 26, 700c and
28 inches. Hold button shortly and go to the next parameter
settings.
FIREFLY WHEEL IS SET FOR 12” WHEEL DIAMETER
Set the metric units
The metric units will be set after nishing setting wheel diameter,
Km/H and Km ash. Hold and shortly and select the three
metric units of speed, mileage, and ambient temperature in
synchronization.
Km/H and Km stop ash after metric unit setting is completed.
Hold button shortly again to re-enter the maximum riding
speed setting interface; or hold button long to exit from setting
environment of routine projects and save the setting values,
returning to display 1.
All three routine project settings can exit from the setting environment and return to the display if hold button
long after each setting is completed, meanwhile the setting values are saved.
Under each setting interface, if the button failed holding for more than 1 minute, it will automatically return to
display 1, and the setting value is invalid.
