StarTech.com RACKCONS1716 User manual

1U 17in Rack Mount LCD Console with Integrated 16 Port KVM Switch
StarTech ID: RACKCONS1716
This 1U Rack Mount LCD KVM Console features an integrated 16 Port Multi-Platform KVM Switch module, 17in active
matrix LCD monitor, full 106-key keyboard and mouse touchpad neatly combined into 1U of space in any standard rack
or cabinet 30in (or greater) in depth.
The KVM console offers a design similar to that of a rackmounted laptop computer - when the console is not in use, it's
as simple as folding the LCD display and keyboard/mouse up and sliding it back into the server rack on the sturdy
mounting rails (included).
A highly-scalable server control solution, each KVM console/switch module can control up to 136 computers by
cascading 8 additional 16 port KVM switches. To ensure further versatility, the console is compatible with virtually any
existing KVM switch as well as with most PC, Mac and Sun servers/systems.
Applications and Solutions
• Centralized control of up to 136 Servers
• Improving the internal space efficiency of existing cabinets
• Managing cabinet mounted servers

Features
• Auto Scan Mode lets you switch between computers for easy monitoring
• Cascadable design
• Compatible with PC, Mac and Sun servers and systems
• Durable design
• Hot-pluggable
• Login authentication restricts access to authorized users
• On Screen Display (OSD)
• Security features, including port locking and auto scan
• Supports PCs with USB or PS/2 keyboard and mouse connectors
• Universal 16 port KVM switch Module controls up to 16 computers directly and up to 136 computers by cascading 8
additional KVM switches

Technical Specifications
• Maximum Cascaded Computers: 136
• Maximum Analog Resolutions: 1280X1024 (SXGA)
• OSD & Hotkey Support: Yes
• Power Adapter Included: Yes
• Power Adapter - Amperage: 4
• Power Adapter - DC Voltage: 12
• Carton Quantity: 1
• Shipping (Package) Weight: 43.32 lb [19.6 kg]
• Connectors: 16 x HD15 female input connectors
• 1 x VGA female output connector
• 1 x PS/2 Keyboard 6-pin Mini-Din (Female)
• 1 x PS/2 Mouse 6-pin Mini-Din (Female)
• Operation Temprature: 0 – 50 degrees C / 32 – 122 degrees F
• Storage Temprature: 20 – 60 degrees C / -4 -140 degrees F
• Humidity: 10%~90%RH
• Contrast Ratio: 500:1
• Brightness: White 250cd/m2 (Center 1 point Typ)
• Multi Platform: Support PS/2, SUN and USB
• Panel Type: Active Matrix TFT LCD
• Pixel Pitch: Supports 0.098mm x 0.294mm
• Response Time: Rising Time 2ms, Decay Time 10ms
• Viewing Angle: Right-Left view 140 (Typ)
• Up-Down View 140 (Typ)
• Operating System: Dos, Windows (3.1, 9x, 2000, NT4, ME, XP, 2003 Server) Linux, Novell 3.12-6, HP UX, SUN
• Chassis Construction: Heavy duty steel materials
