StarTech.com PCI1394B_3 User manual

Manual Revision: 01/30/2012
DE: Bedienungsanleitung - de.startech.com
FR: Guide de l'utilisateur - fr.startech.com
ES: Guía del usuario - es.startech.com
IT: Guida per l'uso - it.startech.com
NL: Gebruiksaanwijzing - nl.startech.com
PT: Guia do usuário - pt.startech.com
For the most up-to-date information, please visit: www.startech.com
PCI1394B_3
3 Port PCI 1394b FireWire Adapter Card
with Digital Video Editing Kit
*actual product may vary from photos

FCC Compliance Statement
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment
o and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit dierent from that to which the receiver is
connected.
Consult the dealer or an experienced radio/TV technician for help.
Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols
This manual may make reference to trademarks, registered trademarks, and other protected
names and/or symbols of third-party companies not related in any way to StarTech.com.
Where they occur these references are for illustrative purposes only and do not represent an
endorsement of a product or service by StarTech.com, or an endorsement of the product(s) to
which this manual applies by the third-party company in question. Regardless of any direct
acknowledgement elsewhere in the body of this document, StarTech.com hereby acknowledges
that all trademarks, registered trademarks, service marks, and other protected names and/or
symbols contained in this manual and related documents are the property of their respective
holders.

Instruction Manual i
Table of Contents
Introduction .......................................................................................................................................................1
Before Your Begin ............................................................................................................................................1
Package Contnets.....................................................................................................................................1
System Requirements ............................................................................................................................1
Installation............................................................................................................................................................2
Installing the Card.....................................................................................................................................2
Installing the Drivers ...............................................................................................................................2
Installing and Using Your VideoStudio Software .........................................................................2
Specications.....................................................................................................................................................3
Technical Support...........................................................................................................................................4
Warranty Information....................................................................................................................................4

Instruction Manual 1
Introduction
Thank you for purchasing a StarTech.com FireWire 800 card. Now you don’t have to worry about
having the right kind of FireWire port or fumbling with adapters for your devices: this card
features 9-pin FireWire 800 ports, as well as a 6-pin FireWire 400 port to support the full range of
FireWire devices. For even greater exibility, this card allows you to use your existing FireWire 400
devices while taking advantage of the new 800 Mbits/sec. speed of the FireWire 800 standard for
new devices.
Features
• Supports the FireWire 800 standard for the next generation of FireWire devices.
• Built-inportsforarangeofFireWireconnections:6-pin(FireWire400)and9-pin
(FireWire 800).
• Fully Plug and Play compatible for easy installation.
• Includes Ulead VideoStudio software for a complete video editing solution
Package Contents
• 1 x PCI FireWire Card
• 1 x FireWire 9-pin to 6-pin cable
• 1 x Ulead VideoStudio Software CD
• 1 x Instruction Manual
System Requirements
• OS Support: Windows 98SE/ ME/ 2000/ XP(32/64bit)/ 2003(32/64bit)/ Vista(32/64bit)/
7(32/64bit), Mac OS 10.2.4 and up, and Linux
• An available PCI slot (supports 32 and 64-bit, and 3.3v and 5v interfaces)
Note: A 64-bit PCI slot is required for a 800 Mbits/sec. data transfer rate
• Optical drive (CD or DVD-ROM) for software installation

Instruction Manual 2
Installation
WARNING! PCI cards, like all computer equipment, can be severely damaged by static electricity.
Be sure that you are properly grounded before opening your computer case or touching your PCI
card. StarTech.com recommends that you wear an anti-static strap when installing any computer
component. If an anti-static strap is unavailable, discharge yourself of any static electricity build-
up by touching a large grounded metal surface (such as the computer case) for several seconds.
Also be careful to handle the PCI card by its edges and not the gold connectors.
Installing the Card
1. Make sure that your computer power cord is unplugged and you are grounded.
2. Remove the cover of your system (see your computer’s user manual for details, if necessary)
and gently turn your computer onto its side.
3. Locate an empty PCI slot (usually white in color; a 64-bit slot will be longer than a 32-bit slot)
and remove the metal plate that covers the rear bracket. You may need a Phillips screwdriver
to perform this step.
Retain this screw! You will need it to secure the card later.
4. Gently insert the card into the empty slot, making sure it is rmly seated.
NOTE: If you are using the card in a 32-bit slot, make sure that the exposed end of the card is
not in contact with any conducting parts on your motherboard. Not all motherboards allow
64-bit cards to t into 32-bit slots.
5. Secure the card in place using the screw you removed in Step 3.
6. Put the computer case back on.
Installing the Drivers
Windows (all versions)
Windows will automatically install built-in drivers for this PCI FireWire card upon detection. For
any performance/compatibility issues, please download the latest drivers from the StarTech.com
website.
MacOS users
Your operating system includes support for the FireWire card without the installation of
additional software, with the limitations noted under“System Requirements” on page 1. The
operating system will automatically detect and congure the FireWire card.
Installing and Using Your VideoStudio Software
For detailed instructions on the installation and use of the digital editing software, consult
the Ulead VideoStudio manual available on the CD. From My Computer right click the icon for
your CD-ROM or other optical drive and select Explore. Open the Manual folder and select your
language. (Note: To view the manual, you will need Adobe Acrobat Reader, which is available as a
free download from the Adobe Web site, www.adobe.com.) StarTech.com recommends carefully
reading the instructions supplied by Ulead before attempting to install or use the software.

Instruction Manual 3
Specications
Host Interface 32/ 64-bit PCI
3.3v or 5v compatible
Form Factor Full Prole
Chipset Texas Instruments 3AA651W
Connectors 1 x FireWire 6-pin female
2 x FireWire 9-pin female
Standards Supported FireWire 400 (IEEE 1394A)
FireWire 800 (IEEE 1394B)
Maximum Data Transfer Speed 400 Mbits/sec. (FireWire 400)
800 Mbits/sec.* (FireWire 800)
Compatible Operating Systems
Windows 98SE/ ME/ 2000/ XP(32/64-
bit)/ 2003(32/64-bit)/ Vista(32/64-bit)/
7(32/64-bit), Mac OS 10.2.4 and up,
Linux
Regulatory Certications FCC Class B, CE, UL
*The card must be placed in a 64-bit PCI slot for a 800 Mbits/sec. data transfer speed. In a 32-bit
PCI slot, the card defaults to 400 Mbits/sec. as the data transfer speed for all attached peripherals,
including FireWire 800 devices.

Instruction Manual 4
Technical Support
StarTech.com’s lifetime technical support is an integral part of our commitment to
provide industry-leading solutions. If you ever need help with your product, visit
www.startech.com/support and access our comprehensive selection of online tools,
documentation, and downloads.
Warranty Information
This product is backed by a lifetime warranty.
In addition, StarTech.com warrants its products against defects in materials and workmanship for
the periods noted, following the initial date of purchase. During this period, the products may
be returned for repair, or replacement with equivalent products at our discretion. The warranty
covers parts and labor costs only. StarTech.com does not warrant its products from defects or
damages arising from misuse, abuse, alteration, or normal wear and tear.
Limitation of Liability
In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their ocers,
directors, employees or agents) for any damages (whether direct or indirect, special, punitive,
incidental, consequential, or otherwise), loss of prots, loss of business, or any pecuniary loss,
arising out of or related to the use of the product exceed the actual price paid for the product.
Some states do not allow the exclusion or limitation of incidental or consequential damages. If
such laws apply, the limitations or exclusions contained in this statement may not apply to you.
