StarTech.com PCI2S650DVLP User manual

Dual Voltage Serial Card
PCI2S650DVLP Instruction Manual
Actual product may vary from photo
2 Port 16650 Low Profile Dual Voltage Serial Card

FFCCCCCCoommpplliiaanncceeSSttaatteemmeenntt
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
UUsseeooffTTrraaddeemmaarrkkss,,RReeggiisstteerreeddTTrraaddeemmaarrkkss,,aanndd
ootthheerrPPrrootteecctteeddNNaammeessaannddSSyymmbboollss
This manual may make reference to trademarks, registered trademarks, and other
protected names and/or symbols of third-party companies not related in any way to
StarTech.com. Where they occur these references are for illustrative purposes only and
do not represent an endorsement of a product or service by StarTech.com, or an
endorsement of the product(s) to which this manual applies by the third-party company in
question. Regardless of any direct acknowledgement elsewhere in the body of this
document, StarTech.com hereby acknowledges that all trademarks, registered
trademarks, service marks, and other protected names and/or symbols contained in this
manual and related documents are the property of their respective holders.

TTaabblleeooffCCoonntteennttss
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
Before You Begin . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
System Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Installing the Serial Card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Installing the drivers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Verifying installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
COM Port configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Troubleshooting Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Technical Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Warranty Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Instruction Manual
i

IInnttrroodduuccttiioonn
Thank you for purchasing a StarTech.com 16650 Dual Voltage Serial Card. This low
profile PCI I/O card allows you to add two RS232 DB-9M connections to any computer
with an available PCI or PCI-X slot. For maximum convenience, this product includes
WHQL certified drivers, to ensure compatibility with Microsoft Windows operating
systems.
FFeeaattuurreess
• Dual voltage card supports both 64-bit(3.3V) and 32-bit(5V) PCI
• High speed serial data transfers up to 921Kbps
• 128K transmit/receive FIFO buffer helps improve overall system performance
• IRQ sharing eliminates IRQ conflicts
• Low profile design saves space
BBeeffoorreeYYoouuBBeeggiinn
System Requirements
• A computer with an available PCI or PCI-X (64 bit PCI) port
• A computer running Windows 95/98SE/NT/ME/2000/XP/2003, Linux or DOS
• A CD-ROM, DVD-ROM, or other compatible optical drive (for software installation)
Contents
This package should contain:
• PCI Serial I/O card (1)
• Driver CD (1)
• Instruction Manual (1)
Instruction Manual
1

IInnssttaallllaattiioonn
Installing the Serial Card
1. Shut down all power connected to the computer, as well as all devices connected to
the computer peripherally (i.e. Printers, Monitors, Scanners etc.). As an added step to
ensure safe installation, unplug the power supply from the computer.
2. Remove the computer cover. For more detailed instruction on how to perform this
step, please refer to the documentation that was included with your computer at the
time of purchase.
3. Locate an empty PCI slot, removing the metal bracket covering the accompanying
empty port/socket.
4. Position the serial card above the open PCI slot, ensuring that the card is aligned with
the entire slot. Insert the card firmly into the slot, distributing force evenly across the
length of the board. Once inserted, secure the card into the adjoining socket
(previously covered by metal bracket), using the correct size screw (please consult
documentation that accompanied purchase of computer).
5. Replace the computer cover and re-connect all power to the computer.
Installing the drivers
Windows
Upon rebooting the computer for the first time following the installation of the serial card,
Windows will detect the PCI Serial card, and prompt for driver installation. When asked
to specify a location where the driver is located, insert the driver CD into your CD/DVD
ROM drive and browse to one of the following locations, based on the Operating System
installed on the computer. Once you have specified the correct file, click OK to complete
the driver installation.
Windows 95/98SE/ME: \IO\PCI IO\Win9x
Windows 2000/XP/2003: \IO\PCI IO\win2K_XP_2003
Windows NT4.0: \IO\PCI IO\WinNT
Linux
For detailed instructions on how to configure the serial card on the Linux Operating
System, please refer to the appropriate .pdf file located in \IO\PCI IO\Linux.
Instruction Manual
2
Figure 1-1

DOS
Locate the install.exe file located in \IO\PCI IO\DOS. Double-click the executable file,
and follow the installation notes located in \IO\PCI IO\Manual.
Verifying installation
Once Windows has completed the driver installation, browse to the Device Manager to
verify that the additional ports are displayed. To locate this: Open the Control Panel,
System, Hardware, Device Manager. The new ports will appear under Ports (COM &
LPT).
COM Port configuration
1. From the Device Manager, select the PCI Serial Port you want to configure
(located under Ports (COM & LPT)). Using the right mouse button, click on
the port and select Properties.
2. Open the Port Settings tab, to configure the Bits per second, Data bits,
Parity, Stop bits and Flow control. For further information on the appropriate
settings in these fields, please consult the documentation that was included
with the purchase of the serial device.
3. To set advanced features on the newly installed port, click on the Advanced
button. From here, select from Enable Auto CTS/RTS Flow Control,
16/32/64 bytes FIFO length and Receive/Transmit Buffer trigger levels.
Please note, the FIFO length can only be modified from within Windows
XP/2000/2003.
Instruction Manual
3

SSppeecciiffiiccaattiioonnss
Pinout Assignment
General Specifications
Instruction Manual
4
PIN Signal
1DCD
2RD
3TD
4DTR
5GROUND
6DSR
7RTS
8CTS
9RI
1
9
6
5
DB9 Male
RS-232:
Certifications (Regulatory etc.) FCC, CE, RoHS, WEEE
Bus Type PCI. PCI-X
Maximum Data Transfer Rate 921.6 Kbps
Chipset SUN1889
Operating systems supported Windows 9x, ME, NT, 2000, XP, 2003, Linux 2.0.x/2.2.x/2.4.x/2.6.x, DOS
Operating temperature 0°C - 57°C
Storage temperature -20°C - 85°C
Baud Rate 75bps - 921.6Kbps
Data bits 4, 5, 6, 7, 8
Stop bits 1, 1.5, 2
Parity Even, Odd, None, Mark, Space
Flow Control None, Xon/Xoff, Hardware
Signal type TxD, RxD, RTS, CTS, DTR, DSR, DCD, RI, GND
Product dimensions 120 x 64mm (4.74” x 2.52”)
Product weights 58g (0.127lbs)

Troubleshooting Guide
If you’re having difficulty using the Serial Card, try the following solutions based on the
nature of the problem.
The Operating System is not recognizing the serial card:
1) Ensure that the card is properly seated within the assigned PCI slot. Try removing the
card and re-seating.
2) Re-install the necessary drivers by uninstalling the card from within the Device
Manager, and rebooting the computer. Upon rebooting, the computer should detect
the card and ask that the necessary drivers be installed. Follow the installation steps
outlined in Installation.
The peripheral device(s) connected to the serial card are functioning slowly/poorly:
From within the Device Manager, browse through the settings for the installed port.
Under Advanced Port Settings, set the Receive/Transmit Buffer to a higher value.
Note: If the CPU is not capable of handling the buffer, the system may become unstable.
Please lower the value of each buffer until the system resumes stability.
Instruction Manual
5

TTeecchhnniiccaallSSuuppppoorrtt
StarTech.com’s lifetime technical support is an integral part of our commitment to provide
industry-leading solutions. If you ever need help with your product, visit
www.startech.com/support and access our comprehensive selection of online tools,
documentation, and downloads.
WWaarrrraannttyyIInnffoorrmmaattiioonn
This product is backed by a lifetime warranty. In addition, StarTech.com warrants its
products against defects in materials and workmanship for the periods noted, following
the initial date of purchase. During this period, the products may be returned for repair, or
replacement with equivalent products at our discretion. The warranty covers parts and
labor costs only. StarTech.com does not warrant its products from defects or damages
arising from misuse, abuse, alteration, or normal wear and tear.
Limitation of Liability
In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their
officers, directors, employees or agents) for any damages (whether direct or indirect,
special, punitive, incidental, consequential, or otherwise), loss of profits, loss of business,
or any pecuniary loss, arising out of or related to the use of the product exceed the
actual price paid for the product.
Some states do not allow the exclusion or limitation of incidental or consequential
damages. If such laws apply, the limitations or exclusions contained in this statement
may not apply to you.
Instruction Manual
6

Revised: 15 August 2006 (Rev. B)
