StarTech.com ATXPOW350DF Manual

High-Performance Dual Fan 350-Watt
ATX Power Supply
ATXPOW350DF
Instruction Guide
The Professionals’ Source For Hard-to-Find Computer Parts
PC PPower SSupply
Revised:August 6, 2002

Technical Support
The following technical resources are available for this StarTech.com product:
On-line help:
We are constantly adding new information to the Tech Support section of our web site. To
access this page, click the Tech support link on our homepage, www.startech.com. In the
tech support section there are a number of options that can provide assistance with this
card.
Knowledge Base - This tool allows you to search for answers to common issues using
key words that describe the product and your issue.
FAQ - This tool provides quick answers to the top questions asked by our customers.
Downloads - This selection takes you to our driver download page where you can
findthe latest drivers for this product.
Call StarTech.com tech support for help: 1-519-455-4931
Support hours: Monday to Friday 9:00AM to 5:00PM EST (except holidays)
Warranty Information
This product is backed by a three-year warranty. In addition StarTech.com warrants its
products against defects in materials and workmanship for the periods noted below,
following the initial date of purchase. During this period, the products may be
returned for repair, or replacement with equivalent products at our discretion. The
warranty covers parts and labor costs only. StarTech.com does not warrant its products
from defects or damages arising from misuse, abuse, alteration, or normal wear and
tear.
Limitation of Liability
In no event shall the liability to StarTech.com Ltd. (or its officers, directors, employees or
agents) for any damages (whether direct or indirect, special, punitive incidental,
consequential, or otherwise), loss of profits, loss of business, or any pecuniary loss,
arising out of related to the use of the product exceed the actual price paid for
the product.
Some states do not allow the exclusion or limitation of incidental or consequential
damages. If such laws apply, the limitations or exclusions contained in this statement
may not apply to you.
5
FCC COMPLIANCE STATEMENT
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation.

Table of Contents
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Product Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Technical Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Warranty Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
1
Product Specifications
4
ATX Size 5.9 x 3.35 x 5.87 in (150 x 85 x 149 mm)
Weight 4.6 lbs (2.08 kg)
MTBF 60,000 hrs.
Safety Approvals FCC, UL, CSA, CE, TUV, CB
Connectors 6 x 4-pin-LP4-female
2 x small-internal-power
1 x 20-pin-ATX-motherboard-adapter
1 x 4-pin extended ATX power 12V plug and Aux
plug for Pentium 4
Input Voltage 115V (8A) 230V (4A)
(current) 50~60 Hz

Introduction
Thank you for purchasing a StarTech.com high-performance dual-fan 350-Watt ATX
power supply. With a super heavy-duty transformer and dual cooling fans, this power
supply offers the best in reliability and performance. The two ball-bearing “smart” fans
adjust their speed to provide optimal cooling for any operating environment.
Features
•Dual ball-bearing temperature-controlled smart fans
•Super heavy-duty transformer for longer life
•Additional drive power connectors
•Ideal for Pentium III, Pentium 4, Celeron, Duron and AMD Athlon
•Premium EMI/RFI filter improves power stability
•Backed by StarTech.com’s three-year warranty
WARNING! Computer parts can be severely damaged by static electricity. Be sure that
you are properly grounded before opening your computer case. StarTech.com
recommends that you wear an anti-static strap when installing any computer
component. If an anti-static strap is unavailable, discharge yourself of any static
electricity build-up by touching a large grounded metal surface (such as the computer
case) for several seconds. Also make sure that your computer is turned off and
unplugged before attempting to open your computer case.
Contents
This package should contain:
•1x ATXPOW350DF power supply
•1x power cord
2
Installation
NOTE: Check the power supply voltage before installation. It should be the same as
your local power voltage (115V for North America and 230V for most of the European
countries). Change the voltage setting if necessary.
1. Make sure that your computer is turned off and unplugged. Remove the power cord
from your old power supply.
2. Remove the cover of your system (see your computer's user manual for details, if
necessary).
3. Disconnect all the power connectors from the mother board and the peripheral
devices such as hard drives, floppy disks, etc. Make sure there are no devices
connected to the existing power supply.
4. Remove the existing power supply from your computer case and replace it with the
new StarTech.com power supply.
5. Connect the power connectors to your motherboard and peripheral devices.
6. Close your computer case.
7. Connect the power cord to the StarTech.com power supply.
ATXPOW350DF Connectors
3
