StarTech.com ATXPW350HPCQ User manual

ATX12V 2.2 Power Supply for HP & Compaq Systems
ATXPW350HPCQ
ATXPW400HPCQ
Instruction Manual
Actual product may vary from photo
350 Watt ATX12V 2.2 Power Supply
400 Watt ATX12V 2.2 Power Supply

FFCCCCCCoommpplliiaanncceeSSttaatteemmeenntt
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
UUsseeooffTTrraaddeemmaarrkkss,,RReeggiisstteerreeddTTrraaddeemmaarrkkss,,aanndd
ootthheerrPPrrootteecctteeddNNaammeessaannddSSyymmbboollss
This manual may make reference to trademarks, registered trademarks, and other
protected names and/or symbols of third-party companies not related in any way to
StarTech.com. Where they occur these references are for illustrative purposes only and
do not represent an endorsement of a product or service by StarTech.com, or an
endorsement of the product(s) to which this manual applies by the third-party company in
question. Regardless of any direct acknowledgement elsewhere in the body of this
document, StarTech.com hereby acknowledges that all trademarks, registered
trademarks, service marks, and other protected names and/or symbols contained in this
manual and related documents are the property of their respective holders.

TTaabblleeooffCCoonntteennttss
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
Package Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Technical Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Warranty Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Instruction Manual
i

Instruction Manual
1
Thank you for purchasing a StarTech.com ATX12V 2.2 Power Supply. The perfect
replacement/upgrade for many Hewlett Packard and Compaq systems, this power supply
provides support for the component demands of today’s motherboards, and is backward
compatible with older Intel & AMD based systems.
IInnttrroodduuccttiioonn
Features
•Conforms to ATX12V 2.2 form factor
•Dual 12V output rails, providing dedicated output for today’s more advanced
processors
•Split 20+4 pin motherboard connector
•Over Current Protection (OCP), Over Voltage Protection, Over Temperature
Protection, Short Circuit Protection, Protection Reset and No Load operation
•Intelligent thermal fan speed control technology
•1 x ATX12V 2.2 Power Supply
Package Contents
•1 x Power Cord
•1 x Instruction Manual
This package should contain:

Instruction Manual
2
IInnssttaallllaattiioonn
1. Check the red switch on the rear of the power supply, next to the power cord plug. Be
sure it is set to the correct voltage for your country. In North America, it should read
"115". In Europe and Australia it should read "230". To change the switch, use a
screwdriver in the notch of the switch and slide it to the opposite side. If you are
unsure of the voltage used in your country, contact your electricity provider before
proceeding.
3. If you are replacing an old power supply in your computer, ensure the computer is
shut down and disconnect the power cord from the back of the old supply.
4. Open your computer case. In most designs, the case is opened by removing two or
three screws at the rear of the case and then sliding the covering panel backward until
it comes free. If your case is a tower style, ensure that you remove the panel that will
expose the top of the computer's motherboard. This is generally the left-side panel.
There are many different case designs, however, so if you are unsure of how to open
your particular case, consult the user manual for your case or contact your local
computer store for help.
5. With the computer case open, review the connectors being used from your old power
supply. If you are building a new computer, review the connectors that you will need to
use. Check the type of connector on your motherboard and connect the 20 pin
ATX power connector provided by the power supply. Should you need the additional 4
pin connector, please attach the additional 4-pin ATX power connector accordingly.
6. Disconnect the old power supply connections from inside your computer. Hard disk
drive, CD drive and floppy disk drive connectors disconnect by pulling on the
connector. The motherboard connector(s) have a clip that must be pressed while
pulling on the connector to release them. A rocking motion while pulling will aid in
getting the connectors loose. Never pull on the wires of a connector to unplug it.
7. Check that all the wires from your old power supply are free. Remove the four screws
on the rear of your old power supply to free it from the computer case. Support the
power supply with one hand if it could fall while removing the last screw. (Such as in a
tower style case.) Remove the power supply by sliding it back and then out through
the side of your case.
8. Install your new power supply by positioning it through the side or top of your case
NOTE: Installation of a power supply requires some mechanical skill and
requires that you open your computer case to disconnect and reconnect wires.
If you are unfamiliar with this kind of work, consider bringing your computer and
new StarTech.com power supply to your local computer store for help.
CAUTION: Computers contain sensitive electronic components that are easily
damaged by static electricity and excessive shock. When handling the power
supply and other components, ensure you are properly grounded using an anti-
static mat or similar device. If anti-static equipment is not available, ground
yourself by touching the exterior of the computer case or another large metal
surface before handling any peripherals.

Instruction Manual
3
(depending on your case style) and then back onto the power supply mounts. Check
that the orientation with the screw holes in your case is correct; all four holes must be
aligned. Support the power supply with one hand while threading a mounting screw
through the back of the case and into the power supply. The screw should thread
smoothly and should not require effort. Do not force it or you could damage the
mounting holes. If the screw won't thread smoothly, remove it and check to ensure the
mounting holes are correctly lined up. Repeat for the remaining three screws. Do not
fully tighten any of the screws until they all have been threaded into their mounting
holes. (Note: Consider Startech part SCREWTHUMB screws for easier installation.)
9. Tie unused wires away from fans and other moving parts.
10. Replace the case cover and secure it. You may wish to not replace the screws until
after you have checked that all connections are working.
11. Toggle the rear power switch on the power supply to off. (The "0" symbol on the
switch.) Connect the power cord to the power supply and plug it in to a grounded
power outlet. (The power supply MUST be connected to a grounded outlet.) Toggle
the rear power switch to on.
12. Start your computer. You should hear its fans and devices immediately begin to run.
If you do not, toggle the rear switch on the power supply to off, disconnect the power
cord, open the case and check that all connectors are well seated and secure.
13. When you have confirmed all connections are working, replace the screws in your
case.
14. Power supplies contain electrical and electronic components and should be disposed
of properly. If you replaced an old power supply follow your city's rules for proper
disposal of electronic equipment.

Instruction Manual
4
SSppeecciiffiiccaattiioonnss
ATXPW350HPCQ
AC Input
Voltage Current Frequency
100 - 127V ~
200 - 240V ~
10A
5A
60Hz
50HZ
DC Output +3.3V +5V +12V1 +12V2 -12V +5VSB PS - ON POK COM
18A 25A 16A 18A 1.0A 2.0A REMOTE P. G . RETURN
Max. 160W 216W 12W 10W _ _ _
328W 22W
ATXPW400HPCQ
AC Input
Voltage Current Frequency
100 - 115V ~
220 - 230V ~
10A
5A
60Hz
50HZ
DC Output +3.3V +5V +12V1 +12V2 -12V +5VSB PS - ON POK COM
28A 28A 16A 18A 1.0A 2.0A REMOTE P. G . RETURN
Max. 170W 252W 6W 10W _ _ _
384W 16W

Instruction Manual
5
General Specifications
ATXPW350HPCQ ATXPW400HPCQ
Output Power 350W 400W
Form Factor ATX12V Ver. 2.2
Fan 1 x 80mm Sleeve Bearing
Connectors
1 x (20+4)-pin ATX split
connector
1 x 4-pin extended ATX for
P4
2 x SATA
5 x LP4
1 x SP4
1 x (20+4)-pin ATX split
connector
1 x 4-pin extended ATX
for P4
2 x SATA
1 x PCI-E
5 x LP4
1 x SP4
MTBF 100,000 hours @ 25° C (77° F)
AC Input Voltage 110-115 V (AC); 220-
230V (AC)
110-115 V (AC); 220-
230V (AC)
Efficiency 65% @230V (AC) 70% @115/230V (AC)
Operation
Temperature 0 ~ 50° C (32° F ~ 122° F)
Storage Temperature -40° ~ 70° C (104°F ~158°F)
Product Dimensions
(L x W x H) 150 x 140 x 86 mm (5.9 x 5.5 x 3.4”)
Product Weight 1.3 kg (2.87lbs) 1.52 kg (3.35lbs)

Instruction Manual
6
TTeecchhnniiccaallSSuuppppoorrtt
StarTech.com’s lifetime technical support is an integral part of our commitment to provide industry-leading
solutions. If you ever need help with your product, visit www.startech.com/support and access our
comprehensive selection of online tools, documentation, and downloads.
WWaarrrraannttyyIInnffoorrmmaattiioonn
This product is backed by a two-year warranty. In addition, StarTech.com warrants its products against defects in
materials and workmanship for the periods noted, following the initial date of purchase. During this period, the
products may be returned for repair, or replacement with equivalent products at our discretion. The warranty covers
parts and labor costs only. StarTech.com does not warrant its products from defects or damages arising from
misuse, abuse, alteration, or normal wear and tear.
Limitation of Liability
In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their officers, directors,
employees or agents) for any damages (whether direct or indirect, special, punitive, incidental, consequential, or
otherwise), loss of profits, loss of business, or any pecuniary loss, arising out of or related to the use of the product
exceed the actual price paid for the product.
Some states do not allow the exclusion or limitation of incidental or consequential damages. If such laws apply, the
limitations or exclusions contained in this statement may not apply to you.

Revised: 30 July 2007 (Rev. A)
