StarTech.com VGA2NTSCPRO System manual

VGA PC to TV Video Converter with Remote Control
StarTech ID: VGA2NTSCPRO
This High Resolution VGA to TV Video Converter/Scaler accepts your computer’s VGA signal and converts the
graphics data into TV video format (composite, S-Video, and analog RGB for SCART implementation).
A versatile video solution, the VGA to TV video converter/scaler supports NTSC, PAL and SECAM video systems,
acting as a VGA to NTSC/PAL Converter and features adjustable zoom, freeze, horizontal/vertical scaling, picture
positioning, brightness, sharpness, and flicker control - allowing you to tweak the video as needed to suit your
display.
A practical tool for synchronizing your monitor and television screens, the converter/scaler provides simultaneous
display on both TV screen and PC monitor, and features a handy remote control that allows you to make
adjustments from a distance.
Applications
Displays computer screen images on your TV
An inexpensive way to increase the size of a computer display
Use your TV to display computer presentations, surfing the Internet, playing video games and more
Great for boardroom meetings, tradeshows and lectures
intrl.startech.com

Features
True color quality
Simultaneous display on both TV screen and PC monitor
Supports NTSC, PAL and SECAM video systems. SECAM systems display by analog RGB output port
4 times zoom function support
Handy remote control allows you to make adjustments from a distance
Provides output in both composite and S-Video formats
Adjustable zoom, freeze, horizontal/vertical scaling, picture positioning, brightness, sharpness, and flicker
control
intrl.startech.com

Technical Specifications
Warranty 2 Years
Converter Type Processeur de mise à l'échelle
Prise en charge audio Non
Connecteur A 1 - VGA (15 pin; High Density D-Sub) Mâle
Connecteur B 1 - Composite Video (1 x RCA) Femelle
Connecteur B 1 - S-Video (4 pin; Mini-DIN) Femelle
Connecteur B 1 - VGA (15 pin; High Density D-Sub) Femelle
Résolutions analogiques max. 1152 x 864
Résolutions prises en charge 1152x864(=60Hz), 1024x768(=75Hz), 800x600(=85Hz), 640x480(=100Hz)
Plage de fréquences Vertical 50Hz - 100Hz
Horizontal 25KHz - 58.464KHz
Couleur Beige
Longueur du produit 6.5 in [165 mm]
Largeur du produit 4.1 in [105 mm]
Hauteur du produit 1 in [26 mm]
Poids du produit 7.7 oz [217 g]
Adaptateur d’alimentation inclus Oui
Tension d'entrée 115 AC
Tension de sortie 9 DC
Courant de sortie 0.6A
Center Tip Polarity Positif
Type de prise M
Poids brut 2.2 lb [1 kg]
Inclus dans le paquet 1 - VGA to NTSC/PAL Converter w/ Remote
Inclus dans le paquet 1 - CR2025 3V Battery
Inclus dans le paquet 1 - 4 pin M/M cable
Inclus dans le paquet 1 - RCA cable M/M
Inclus dans le paquet 1 - VGA cable 15 pin M/F
Inclus dans le paquet 1 - 9V DC Adapter
Inclus dans le paquet 1 - Manual
intrl.startech.com

Certifications, Reports and Compatibility
