State Water Heaters 196114-000 Installation and user guide

1
PLACETHESEINSTRUCTIONSADJACENTTOHEATER
ANDNOTIFYOWNERTOKEEPFORFUTUREREFERENCE.
COMMERCIAL GAS WATER HEATER
Glass-Lined Tank-Type Water Heater
Instruction Manual
PART NO. 196114-000
•INSTALLATION •OPERATION •SERVICE • MAINTENANCE •LIMITED WARRANTY
PRINTEDINU.S.A. 0903
CAUTION
TEXTPRINTED OROUTLINED INRED CONTAINSINFORMATION
RELATIVE TO YOUR SAFETY. PLEASE READ THOROUGHLY
BEFORE INSTALLINGAND USING THISAPPLIANCE.

2
ROUGH-IN-DIMENSIONS
FOREWORD
The design of Model 65 complies with the latest version of ANSI
Z21.10.1/CSA 4.1 M98 as automatic storage type water heater.
Installation diagrams are found in this manual. These diagrams
will serve to provide the installer with a reference for the materials
and method of piping necessary. It is highly essential that all
water and gas piping be installed as shown on the diagrams.
In addition to these instructions, the equipment shall be installed
in accordance with those installation regulations in force in the
local area where the installation is to be made. These shall be
carefully followed in all cases. Authorities having jurisdiction
should be consulted before installations are made.
The installation must conform to these instructions and the local
code authority having jurisdiction. In the absence of local codes,
the installation must comply with the latest editions of the National
Fuel Gas Code, ANSI Z223.1/NFPA 54, in Canada CAN/CSA
B 149.1-00. Both are available from the Canadian Standards
Association,8501 EastPleasantValleyRoad,Cleveland,OH44131.
For Canadian customers, 178 Rexdale Blvd., Rexdale (Toronto),
Ontario, Canada M9W 1R3. The National Fuel Gas Code, ANSI
Z223.1/NFPA 54 is available from the National Fire Protection
Association, 1 Batterymarch Park, Quincy, MA 02269.
RECOVERYCAPACITIES
RECOVERYCAPACITIES
U.S. Gallons/Hrs. and Litres/Hr. at TEMPERATURE RISE INDICATED
Type
of Input Approx. F° 20F° 30F° 40F° 50F° 60F° 70F° 80F° 90F° 100F° 110F° 120F° 130F° 140F°
Model Gas Btuh KW Capacity C° 11C° 17C° 22C° 28C° 33C° 39C° 44°C 50C° 56C° 61C° 67C° 72C° 78C°
65,000 65 US Gals. GPH 299 200 150 120 100 86 75 67 60 54 50 46 43
19.0 246 Litres LPH 1133 756 567 453 378 324 283 252 227 206 189 174 162
55.000 65 US Gals. GPH 253 169 127 101 84 72 63 56 51 46 42 39 36
16.1 246 Litres LPH 959 639 479 384 320 274 240 213 192 174 160 48 137
65
65
Natural
Propane
DIMENSIONS
Model A B C D E F G H J
In. 63 1/2 61 26 22 4 8 3/4 1/2 53 3/4
mm 1613 1550 660 559 106 203 NPT NPT 1,365
65

3
TABLE OF CONTENTS
Page
ROUGH-INDIMENSIONS ....................................................................... 2
FOREWORD .......................................................................................... 2
GENERALSAFETYINFORMATION ...................................................... 3
Precautions....................................................................................... 3
LiquidPetroleum ............................................................................... 3
Chemical Vapor Corrosion ............................................................... 3
ImproperCombustion........................................................................ 3
Extended Non-use Periods .............................................................. 3-4
Insulation Blankets............................................................................ 4
INSTALLATIONINSTRUCTIONS ............................................................ 4
Required Ability ................................................................................ 4
Locating The Heater ......................................................................... 4
High Altitude Installations ................................................................. 4-5
Clearances ....................................................................................... 5
Hard Water ....................................................................................... 5
Air Requirements.............................................................................. 5
Combination Water (Potable) Heating and Space Heating .............. 5-6
Venting.............................................................................................. 6
Thermometers (Not Supplied) .......................................................... 6
Relief Valve....................................................................................... 6-7
Gas Piping......................................................................................... 7-8
Purging.............................................................................................. 8
Gas Pressure Regulation ................................................................ 9
OPERATION .......................................................................................... 9
Precautions...................................................................................... 9
Lighting Instructions ........................................................................ 10
Temperature Regulation .................................................................. 11
High Temperature Limit Switch........................................................ 11
Checking Venting.............................................................................11-12
SERVICEINFORMATION ...................................................................... 12
Pilot and Main Burner....................................................................... 12
Checking Gas Input .........................................................................12-13
Vent System .................................................................................... 13
Relief Valve...................................................................................... 13
Hot Water Odor ............................................................................... 13
Anode Rod Inspection ..................................................................... 13
Winter Protection ............................................................................. 13
Replacement Parts .......................................................................... 13
CHECKLIST ..........................................................................................13-14
LIMITEDWARRANTY ............................................................................Insert
Page
GENERAL SAFETY
INFORMATION
PRECAUTIONS
DONOTUSE THISAPPLIANCE IFANYPARTHAS BEEN UNDER
WATER. Immediately call a qualified service technician to inspect
the appliance and to replace any part of the control system and any
gas control which has been under water.
IF THE UNIT IS EXPOSED TO THE FOLLOWING, DO NOT
OPERATEHEATERUNTILALLCORRECTIVESTEPS HAVEBEEN
MADEBYAQUALIFIEDSERVICEMAN.
1. EXTERNALFIRE.
2. DAMAGE.
3. FIRINGWITHOUT WATER.
4. SOOTING
LIQUID PETROLEUM MODELS
WARNING
Water heaters for propane or liquified petroleum gas (LPG) are
different from natural gas models. A natural gas heater will not
functionsafelyon LPgasand noattemptshould bemadeto convert
a heater from natural gas to LP gas.
CHEMICAL VAPOR CORROSION
WARNING
CORROSION OF THE FLUEWAYS AND VENT SYSTEM MAY
OCCUR IF AIR FOR COMBUSTION CONTAINS CERTAIN
CHEMICAL VAPORS. SUCH CORROSION MAY RESULT IN
FAILUREANDRISKOFASPHYXIATION.
Spray can propellants, cleaning solvents, refrigerator and air
conditioning refrigerants, swimming pool chemicals, calcium and
sodium chloride (water softener salt), waxes, and process
chemicals are typical compounds which are potentially corrosive.
Do not store products of this sort near the heater. Also, air which is
brought in contact with the heater should not contain any of these
chemicals. If necessary, uncontaminated air should be obtained
from remote or outside sources. The limited warranty is voided
when failure of the water heater is due to a corrosive atmosphere.
(Refer to the limited warranty for complete terms and conditions.)
IMPROPER COMBUSTION
WARNING
ATTICAND/OREXHAUSTFANS OPERATINGONTHE PREMISES
WITHAWATER HEATER CAN RESULT IN CARBON MONOXIDE
POISONINGAND DEATH.
OPERATIONOFTHESEFANSCANPRODUCEANEGATIVEDRAFT
IN THE AREA OF THE WATER HEATER PREVENTING THE
PRODUCTS OF COMBUSTION FROM EXHAUSTING THROUGH
THECHIMNEYOR VENTPIPE.
The venting of the water heater should be inspected by a qualified
service technician at the time of installation and periodically
thereafter to ensure a down-draft condition does not exist.
DO NOT OBSTRUCT THE FLOW OF COMBUSTION AND
VENTILATING AIR. ADEQUATE AIR FOR COMBUSTION AND
VENTILATIONMUSTBE PROVIDEDFOR SAFEOPERATION.
EXTENDED NON-USE PERIODS
WARNING
HYDROGENGASCANBEPRODUCEDINAHOTWATERSYSTEM
SERVED BY THIS HEATER THAT HAS NOT BEEN USED FOR A
LONGPERIODOFTIME(GENERALLYTWOWEEKSOR MORE).
HYDROGENGAS ISEXTREMELYFLAMMABLE. Toreduce therisk
of injury under these conditions, it is recommended that the hot
water faucet be opened for several minutes at the kitchen sink
before using any electrical appliance connected to the hot water
system. If hydrogen is present, there will probably be an unusual
sound such as air escaping through the pipe as the water begins

4
toflow. THERESHOULD BENOSMOKINGOROPEN FLAMENEAR
THEFAUCETATTHETIME ITIS OPEN.
INSULATION BLANKETS
Insulation blankets available to the general public for external use
on gas water heaters are not necessary with your commercial water
heater. The purposeof aninsulationblanket istoreduce thestandby
heat loss encountered with storage tank water heaters. Your
commercialwaterheater meetsorexceeds theASHRAE/IES90.1b-
1992 standards with respect to insulation and standby loss
requirement making an insulation blanket unnecessary.
WARNING
Should you choose to apply an insulation blanket to this heater, you
should follow these instructions. Failure to follow these instructions
can result in fire, asphyxiation, serious personal injury or death.
•Do not apply insulation to the top of the water heater, as this will
interfere with safe operation of the draft hood.
•Do not cover the outer door, thermostat or temperature &
pressure relief valve.
•Do not allow insulation to come within 2" (51 mm) of the floor to
prevent blockage of combustion air flow to the burner.
•Do not cover the instruction manual. Keep it on the side of the
water heater or nearby for future reference.
•Do obtain new warning and instruction labels from for placement
on the blanket directly over the existing labels.
•Do inspect the insulation blanket frequently to make certain it
does not sag, thereby obstructing combustion air flow.
INSTALLATION INSTRUCTIONS
REQUIRED ABILITY
INSTALLATIONORSERVICEOFTHISWATERHEATERREQUIRES
ABILITYEQUIVALENTTOTHATOFALICENSEDTRADESMAN IN
THE FIELD INVOLVED. PLUMBING,AIR SUPPLY, VENTINGAND
GAS SUPPLY WORKARE REQUIRED.
LOCATING THE HEATER
When installing the heater, consideration must be given to proper
location. Location selected should be as close to the stack or
chimney as practicable, with adequate air supply and as
centralized with the piping system as possible.
WARNING
THEREISA RISKINUSING FUELBURNINGAPPLIANCES SUCH
AS GAS WATER HEATERS IN ROOMS, GARAGES OR OTHER
AREAS WHERE GASOLINE, OTHER FLAMMABLE LIQUIDS OR
ENGINE DRIVEN EQUIPMENT OR VEHICLES ARE STORED,
OPERATED OR REPAIRED. FLAMMABLE VAPORS ARE HEAVY
ANDTRAVELALONG THEFLOORANDMAYBEIGNITED BYTHE
HEATER’SPILOTORMAINBURNERFLAMES CAUSINGFIRE OR
EXPLOSION. SOMELOCALCODESPERMITOPERATIONOFGAS
APPLIANCES IF INSTALLED 18 INCHES (457 mm) OR MORE
ABOVETHEFLOOR. THISMAYREDUCETHERISKIFLOCATION
IN SUCHANAREACANNOTBEAVOIDED.
DO NOT INSTALL THIS WATER HEATER DIRECTLY ON A
CARPETEDFLOOR. AFIREHAZARDMAYRESULT. Insteadthe
water heater must be placed on a metal or wood panel extending
beyond the full width and depth by at least 3 inches (76 mm) in any
direction. If the heater is installed in a carpeted alcove or closet,
the entire floor shall be covered by the panel. Also, see the drain
requirements.
THIS HEATER SHALL BE LOCATED OR PROTECTED SO IT IS
NOTSUBJECTTOPHYSICALDAMAGEBYAMOVINGVEHICLE.
WARNING
FLAMMABLE ITEMS, PRESSURIZED CONTAINERS OR ANY
OTHER POTENTIAL FIRE HAZARDOUS ARTICLES MUST
NEVERBEPLACEDONORADJACENTTOTHEHEATER. OPEN
CONTAINERS OF FLAMMABLE MATERIAL SHOULD NOT BE
STOREDOR USEDIN THESAME ROOMWITH THEHEATER.
THE HEATER MUST NOT BE LOCATED IN AN AREA WHERE IT
WILL BE SUBJECT TO FREEZING.
THE HEATER SHOULD BE LOCATED IN AN AREA WHERE
LEAKAGE FROM THE HEATER OR CONNECTIONS WILL NOT
RESULT IN DAMAGE TO THE ADJACENT AREA OR TO LOWER
FLOORS OF THE STRUCTURE.
WHEN SUCH LOCATIONS CANNOT BE AVOIDED, A SUITABLE
DRAIN PAN SHOULD BE INSTALLED UNDER THE HEATER.
Such pans should be fabricated with sides at least 2" (51 mm)
deep, with length and width at least 2" (51 mm) greater than the
diameter of the heater and must be piped to an adequate drain.
The pan must not restrict combustion air flow.
Drain pans suitable for these heaters are available from your
distributor.
For appliance installation locations with elevations above
2000 feet (610 meters), refer to HIGHALTITUDE INSTALLATIONS
section of this manual for input reduction procedure.
HIGH ALTITUDE INSTALLATIONS
WARNING
INSTALLATIONS ABOVE 2000 FEET (610 METERS) REQUIRE
REPLACEMENT OF THE BURNER ORIFICE IN ACCORDANCE
WITHSECTION 8.1.2OFTHE NATIONALFUELGASCODE(ANSI
Z223.1). FORCANADIAN INSTALLATIONSCONSULTCANADIAN
INSTALLATIONSCODESAND CAN/CSAB149.1-00. FAILURE TO
REPLACE THE ORIFICE WILL RESULT IN IMPROPER AND
INEFFICIENT OPERATION OF THEAPPLIANCE RESULTING IN
THE PRODUCTION OF INCREASED LEVELS OF CARBON
MONOXIDE GAS IN EXCESS OF SAFE LIMITS WHICH COULD
RESULT IN SERIOUS PERSONALINJURY OR DEATH.
You should contact your gas supplier for any specific changes
which may be required in your area.
As elevation above sea level is increased, there is less oxygen
per cubic foot of air. Therefore, the heater input rate should be
reducedathigh altitudesforsatisfactory operationwiththe reduced
oxygen supply. Failure to make this reduction would result in an
overfiring of the heater causing sooting, poor combustion and/or
unsatisfactory heater performance.

5
U.S.REQUIREMENTS
Ratings specified by manufacturers for most appliances apply for
elevations up to 2000 feet (610 m). For elevations above 2000 feet
(610 m), ratings must be reduced at the rate of 4% for each 1000
feet (305 m) above sea level. For example, if a heater is rated at
65,000 Btuh (19 Kw) at sea level, to rate the heater at 4000 feet
(1219 m), you subtract 4 (once for each thousand feet) x.04
(4% input reduction) x 65,000 (original rating) from the original
rating. Therefore, to calculate the input rating at 4,000 feet (1219
m): 4 x .04 x 65,000 = 10,400 Btuh (3.0 Kw), 65,000
(19 Kw) - 10,400 (3.0 Kw) = 54,600 Btuh (16 Kw). At 6000 feet
(1829 m) the correct input rating should be 49,400 Btuh (14.5 Kw).
CANADIANREQUIREMENTS
Appliances with inputs up to and including 400,000 BTU
must be factory equipped with orifices for operation at specific
elevations. Standard (sea level) orifices permit operation up to
2000' (610 m) elevation. For operation between 2000' (610 m) and
4500' (1370 m) specify "HIGH ALTITUDE OPERATION" when
ordering the heater(s). For operation above 4500' (2370 m) consult
factory before ordering.
Field conversion for operation at altitudes other than that
specified on the heater rating plate is not permitted.
The input reduction is primarily achieved by reducing the size of
the main burner orifices. To do this, the main burner orifices require
replacement with orifices sized for the particular installation
elevation. Contact your local gas supplier for further information.
Upon completion of derating of the heater, adjustment to the gas
pressure regulator may be required. See CHECKING THE INPUT
section in this manual for inlet and manifold pressure
requirements.
Also due to the input rating reduction required at high altitudes, the
output rating of the appliance is reduced and should be
compensated for in the sizing of the equipment for application.
CLEARANCES
These heaters are approved for installation on combustible flooring
in a closet having a ceiling 18" (457 mm) above top cover and with
clearances to combustible construction of 6" (152 mm) from flue
or vent connector, 1" (25 mm) at the sides and rear and
4" (102 mm) to front to prevent a possible fire hazard condition. A
minimum of 4" (101.6 mm) shall be allowed for installation of
serviceable parts.
HARD WATER
Where hard water conditions exist, water softening or the threshold
type of water treatment is recommended. This will protect the
dishwashers, coffee urns, water heaters, water piping and other
equipment.
Contact your dealer or qualified service technician for more
information on this product.
AIR REQUIREMENTS
REFERTOTHELATESTEDITIONOFTHE "NATIONALFUELGAS
CODE"ANSIZ223.1/NFPA54. FORCANADACONSULTCAN/CSA
B149.1-00.
KEEP APPLIANCE AREA CLEAR AND FREE OF COMBUSTIBLE
MATERIALS,GASOLINEANDOTHERFLAMMABLES,VAPORSAND
LIQUIDS.
DO NOT OBSTRUCT THE FLOW OF COMBUSTION OR
VENTILATINGAIR.
WARNING
FOR SAFE OPERATION PROVIDE ADEQUATE AIR FOR
COMBUSTION AND VENTILATION. AN INSUFFICIENT SUPPLY
OF AIR WILL CAUSE RECIRCULATION OF COMBUSTION
PRODUCTSRESULTING INAIR CONTAMINATIONTHATMAYBE
HAZARDOUS TO LIFE. SUCH A CONDITION OFTEN WILL
RESULT IN AYELLOW, LUMINOUS BURNER FLAME, CAUSING
CARBONING OR SOOTING OF THE COMBUSTION CHAMBER,
BURNERS AND FLUE TUBES AND CREATES A RISK OF
ASPHYXIATION.
Where an exhaust fan is supplied in the same room with a heater,
sufficient openings for air must be provided in the walls.
UNDERSIZEDOPENINGS WILLCAUSE AIRTO BEDRAWN INTO
THE ROOM THROUGH THE CHIMNEY, CAUSING POOR
COMBUSTION. SOOTING MAY RESULT IN SERIOUS DAMAGE
TOTHE HEATERAND RISK OF FIRE OR EXPLOSION.
UNCONFINEDSPACE
In buildings of conventional frame, brick, or stone construction,
unconfined spaces may provide adequate air for combustion,
ventilation and draft hood dilution.
If the unconfined space is within a building of tight construction
(buildingsusingthe followingconstruction:weather stripping,heavy
insulation, caulking, vapor barrier, etc.), air for combustion,
ventilation and draft hood dilution must be obtained from outdoors.
The installation instructions for confined spaces in tightly
constructed buildings must be followed to ensure adequate air
supply.
CONFINEDSPACE
When drawing combustion and dilution air from inside a
conventionally constructed building to a confined space, such a
space shall be provided with two permanent openings, ONE IN
OR WITHIN 12 INCHES (30.50 cm) OF THE ENCLOSURE TOP
AND ONE IN OR WITHIN 12 INCHES (30.50 cm) OF THE
ENCLOSURE BOTTOM. Each opening shall have a free area of at
least one square inch per 1000 Btuh (2202.8 mm2/KW) of the total
input of all appliances in the enclosure, but not less than
100 square inches (645 cm2).
If the confined space is within a building of tight construction, air for
combustion, ventilation, and draft hood dilution must be obtained
from outdoors. When directly communicating with the outdoors or
communicating with the outdoors through vertical ducts, two
permanent openings, located in the above manner, shall be
provided. Each opening shall have a free area of not less than one
square inch per 4000 Btuh (550.7 mm2/KW) of the total input of all
appliances in the enclosure. If horizontal ducts are used, each
opening shall have a free area of not less than one square inch
per 2000 Btuh (1101.4 mm2/KW) of the total input of all appliances
in the enclosure. For Canadian installations consult CAN/CSA
B149.1-00.
COMBINATION WATER (POTABLE)
HEATING AND SPACE HEATING
1. All piping components connected to this unit for space heating
applications shall be suitable for use with potable water.

6
2. Toxic chemicals, such as those used for boiler treatment, shall
NEVER be introduced into this system.
3. This unit may NEVER be connected to any existing heating
system or component(s) previously used with a non-potable
water heating appliance.
4. When the system requires water for space heating at
temperatures higher than required for domestic water
purposes, a tempering valve must be installed (See Fig. 3).
CAUTION
Aclosedsystem willexist ifa checkvalve(without bypass),pressure
reducing valve (without bypass), or a water meter (without bypass)
is installed in the cold water line between the water heater and
street main (or well).
Excessive pressure may develop in such closed systems, causing
premature tank failure or intermittent relief valve operation. This is
not a warranty failure. An expansion tank or a similar device may
be required in the inlet supply line between the appliance and the
meter or valve to compensate for the thermal expansion of the
water.
SYSTEM CONNECTIONS
The system installation must conform to these instructions and to
the local code authority having jurisdiction. Good practice requires
that all heavy piping be supported.
VENTING
WARNING
THE INSTRUCTIONS IN THIS SECTION ON VENTING MUST BE
FOLLOWED TO AVOID CHOKED COMBUSTION OR
RECIRCULATIONOF FLUEGASES. SUCH CONDITIONSCAUSE
SOOTINGOR RISKSOFFIREANDASPHYXIATION.
Heater must be protected from freezing downdrafts.
Remove all soot or other obstructions from the chimney that will
retard a free draft.
Type B venting is recommended with these heaters.
This water heater must be vented in compliance with all local
codes, the current revision of the National Fuel Gas Code
(ANSI-Z223.1) and with the Category I Venting Tables. In Canada,
venting shall conform to the requirements of the current CAN/CSA
B149.1-00 installation code.
If any part of the vent system is exposed to ambient temperatures
below 35 degrees F (2 degrees C) it must be insulated to prevent
condensation.
• Do not connect the heater to a common vent or chimney with
solid fuel burning equipment. This practice is prohibited by
many local building codes as is the practice of venting gas
fired equipment to the duct work of ventilation systems.
• Where a separate vent connection is not available and the vent
pipe from the heater must be connected to a common vent
with an oil burning furnace, the vent pipe should enter the
smaller common vent or chimney at a point above the large
vent pipe.
FIGURE2
DRAFTHOOD
The draft hood furnished with this heater must be installed without
alteration. Provision must be made if it is installed in confined
space or a small room to accommodate draft hood spillage and
avoid risks described in previous steps. The upper air opening
called for in the AIR REQUIREMENTS section of this manual is for
this purpose.
Locate draft hood as seen in Figure 1. Position draft hood over the
flue tube. Align the draft hood legs with four holes surrounding the
flue. Insert tabbed end of legs into the corresponding holes and
twist to lock the draft hood in place.
When installing vent piping, secure the vent pipe to the draft hood
using at least three sheet metal screws in the draft hood outlet.
VENTCONNECTION
Vent connections must be made to an adequate stack or chimney.
Size and install proper size vent pipe. Do not reduce pipe size to
less than that of the draft hood outlet.
Horizontal runs of vent pipe must have a minimum upward slope
towardthe chimneyof1/4inchper foot(20 mmper meter). Dampers
or other obstructions must not be installed in between the heater
and the draft hood. Be sure that the vent pipe does not extend
beyond the inside wall of the chimney.
Where a continuous or intermittent back draft is found to exist, the
cause must be determined and corrected. A special vent cap may
be required. If the back draft cannot be corrected by the normal
methods or if a suitable draft cannot be obtained, a blower type
flue gas exhauster must be employed to assure proper venting
and correct combustion.
THERMOMETERS (Not Supplied)
Thermometers should be obtained and field installed.
Thermometers are installed in the system as a means of detecting
the temperature of the outlet water supply.
RELIEF VALVE
This water heater is equipped with a combination temperature-
pressure relief valve that complies with the standard for relief valves
and automatic gas shut-off devices for hot water supply system,
ANSI Z21.22, for Canada see CAN/CSA 149.1-00. FOR SAFE
OPERATION OF THE WATER HEATER, THE RELIEF VALVE(S)
MUSTNOTBE REMOVEDORPLUGGED.
ASMEratingscover pressure reliefcapacities. A.G.A.ratings cover
release rate with temperature actuation.

7
In addition to the appliance relief valve, each remote storage tank
which may be used in conjunction with this appliance shall also
be installed with a properly sized, rated and approved combination
temperature (ANSI) and pressure (ASME) relief valve(s).
WARNING
THE PURPOSE OF RELIEF VALVE IS TO AVOID EXCESSIVE
PRESSURE OR TEMPERATURE INTO THE STEAM RANGE,
WHICHMAYCAUSE SCALDINGATFIXTURES,TANKEXPLOSION,
SYSTEM OR HEATER DAMAGE. NO VALVE IS TO BE PLACED
BETWEENTHE RELIEFVALVEANDTANK.
Your local code authority may have other specific relief valve
requirements.
ADRAINLINE MUSTBECONNECTEDTOTHERELIEFVALVETO
DIRECTDISCHARGETOASAFELOCATIONTOAVOIDSCALDING
ORWATERDAMAGE. THIS LINEMUSTNOTBEREDUCEDFROM
THE SIZE OF THE VALVE OUTLET AND MUST NOT CONTAIN
VALVES, RESTRICTIONS NOR SHOULD IT BE LOCATED IN
FREEZINGAREAS. DO NOTTHREADORCAPTHEENDOFTHIS
LINE. RESTRICTED OR BLOCKED DISCHARGE WILL DEFEAT
THE PURPOSE OF THE VALVE AND IS UNSAFE. DISCHARGE
LINE SHALLBE INSTALLED TOALLOW COMPLETE DRAINAGE
OFBOTHTHEVALVEANDLINE.
See SERVICE INFORMATION section for procedure and
precautions.
The type, size and location of the relief valve(s) must be in
accordance with local codes. The location of the relief valve shown
in Figure 3 is typical. The heater has a factory installed high
temperature limit switch.
For circulating heaters, the separate storage vessel must have a
temperature and pressure relief valve installed. This valve shall
comply with the standard for relief valves and automatic gas shut-
off devices for hot water supply systems.
GAS PIPING
Contact your local gas service company to ensure that adequate
gas service is available and to review applicable installation codes
for your area.
FIGURE3
CIRCULATING RETURN LINE CONNECTIONS
TEMPERED WATER LOOP, IF USED, CONNECT TO POINT "A".
STORED TEMPERATURE WATER LOOP, IF USED, CONNECT TO
COLD WATER INLET.
CAUTION: IF BUILDING COLD WATER SUPPLY HASA BACK-FLOW
PREVENTER,CHECK VALVEORWATERMETER WITHCHECK VALVE,
PROVISIONS FOR THERMAL EXPANSION OF WATER IN THE HOT
WATER SYSTEM MUST BE PROVIDED.
WARNING
TEMPERATURE SETTING SHOULD NOT
EXCEED SAFE USE TEMPERATURE AT
FIXTURES. SEE TEMPERATURE REGULATION
ON PAGE 11. IF HIGHER PREHEAT
TEMPERATURES ARE NECESSARY TO OBTAIN
ADEQUATE BOOSTER OUTPUT, ADD AN
ANTI-SCALD VALVE FOR HOT WATER
SUPPLIED TO FIXTURES.
SINGLETEMPERATURE
Size the main gas line in accordance with Table 1. The figures
shown are for straight lengths of pipe at 0.5 in. W.C. pressure drop,
which is considered normal for low pressure systems. Note:
Fittings such as elbows, tees and line regulators will add to the
pipe pressure drop. Also refer to the latest version of the National
Fuel Gas Code. For Canadian installations consult Canadian
Installation Code CAN/CSA B149.1-00.
WARNING
THE HEATER IS NOT INTENDED FOR OPERATION AT HIGHER
THAN 10.5" W.C.(2.61 kPa) - NATURAL GAS, or 13.0" W.C.(3.23
kPa)-PROPANE GASSUPPLYGAS PRESSURE. EXPOSURETO
HIGHERSUPPLYPRESSUREMAYCAUSEDAMAGETOTHEGAS
VALVE WHICH COULD RESULT IN FIRE OR EXPLOSION. IF
OVERPRESSURE HAS OCCURRED SUCH AS THROUGH
IMPROPER TESTING OF GAS LINES OR EMERGENCY
MALFUNCTIONOFTHESUPPLYSYSTEM,THEGASVALVEMUST
BE CHECKED FOR SAFE OPERATION. MAKE SURE THAT THE
OUTSIDE VENTS ON THE SUPPLY REGULATORS AND THE
SAFETY VENTVALVESARE PROTECTEDAGAINSTBLOCKAGE.
THESE ARE PARTS OF THE GAS SUPPLY SYSTEM, NOT THE
HEATER. VENTBLOCKAGEMAYOCCURDURING ICESTORMS.
ITISIMPORTANTTOGUARDAGAINSTGASVALVEFOULINGFROM
CONTAMINANTSINTHEGASWAYS. SUCHFOULINGMAYCAUSE
IMPROPEROPERATION, FIREOR EXPLOSION.
IF COPPER SUPPLY LINES ARE USED THEY MUST BE
INTERNALLY TINNED AND CERTIFIED FOR GAS SERVICE.
BEFORE ATTACHING THE GAS LINE, BE SURE THATALL GAS
PIPE IS CLEAN ON THE INSIDE.
TOTRAPANYDIRTORFOREIGNMATERIALINTHE GASSUPPLY
LINE, A DIRT LEG (SOMETIMES CALLED SEDIMENT TRAP OR
DRIP LEG) MUST BE INCORPORATED IN THE PIPING (SEE FIG.
4). THE DIRT LEG MUST BE READILY ACCESSIBLE AND NOT
SUBJECT TO FREEZING CONDITIONS. INSTALL IN
ACCORDANCE WITH RECOMMENDATIONS OF SERVING GAS
SUPPLIERS. REFERTOTHELATESTVERSIONOFTHENATIONAL
FUEL GAS CODE. For Canadian installations consult Canadian
Installation Code CAN/CSA B149.1-00.
VACUUM RELIEF
VALVE
* INSTALL PER
LOCAL CODES

8
TABLE1- GASSUPPLYLINE SIZES(ININCHES)*
MAXIMUMCAPACITYOFPIPEIN
CUBICFEETPERHOUR
LENGTH NORMAL IRON PIPE SIZES (INCHES)
IN INPUT IN THOUSANDSBTU/HR
FEET 1/2" 3/4" 1" 1 1/4" 1 1/2" 2" 2 1/2" 3" 4"
10 175 360 680 1400 2100 3960 6300 11000 23000
20 120 250 485 950 1460 2750 4360 7700 15800
30 97 200 375 770 1180 2200 3520 6250 12800
40 82 170 320 660 990 1900 3000 5300 10900
50 73 151 285 580 900 1680 2650 4750 9700
60 66 138 260 530 810 1520 2400 4300 8800
70 61 125 240 490 750 1400 2250 3900 8100
80 57 118 220 460 690 1300 2050 3700 7500
90 53 110 205 430 650 1220 1950 3450 7200
100 50 103 195 400 620 1150 1850 3250 6700
125 44 93 175 360 550 1020 1650 2950 6000
150 40 84 160 325 500 950 1500 2650 5500
175 37 77 145 300 460 850 1370 2450 5000
200 35 72 135 280 430 800 1280 2280 4600
LENGTH NORMAL IRON PIPE SIZES (INCHES)
IN INPUT IN KW
METERS 1/2" 3/4" 1" 1 1/4" 1 1/2" 2" 2 1/2" 3" 4"
351 105 199 410 615 1160 1845 3221 6735
635 73 142 278 428 805 1277 2255 4626
928 59 110 225 346 644 1031 1830 3748
12 24 50 94 193 290 556 878 1552 3192
15 21 44 83 170 264 492 776 1391 2840
18 19 40 76 155 237 445 703 1259 2577
21 18 37 70 143 220 410 659 1142 2372
24 17 35 64 135 202 381 600 1083 2196
27 16 32 60 126 190 357 571 1010 2108
31 15 30 57 117 182 337 542 952 1962
38 13 27 51 105 161 299 483 864 1757
46 12 25 47 95 146 278 439 776 1610
53 11 23 42 88 135 249 401 717 1464
61 10 21 40 82 126 234 375 688 1347
To prevent damage, care must be taken not to apply too much
torque when attaching gas supply pipe to gas valve inlet.
Apply joint compounds (pipe dope) sparingly and only to the male
threads of pipe joints. Do not apply compounds to the first two
threads. Use compounds resistant to the action of liquefied
petroleum gases.
BEFORE PLACING THE HEATER IN OPERATION, CHECK FOR
GAS LEAKAGE. Use soap and water solution or other material
acceptable for the purpose in locating the leaks. DO NOT USE
MATCHES,CANDLES,FLAMEOROTHERSOURCESOFIGNITION
FOR THIS PURPOSE.
FIGURE4-GASPIPINGANDDIRTLEGINSTALLATION
DISCONNECTTHEHEATERANDITSMANUALGASShut-offVALVE
FROMTHEGASSUPPLYPIPINGSYSTEM DURINGANYSUPPLY
PRESSURE TESTING EXCEEDING 1/2 PSIG (3.45 Kpa). GAS
SUPPLYLINEMUSTBECAPPEDWHEN DISCONNECTEDFROM
THE HEATER. FOR TEST PRESSURES OF 1/2 PSIG
(3.45 Kpa) OR LESS THE APPLIANCE NEED NOT BE
DISCONNECTED,BUTMUSTBE ISOLATEDFROMTHESUPPLY
PRESSURETESTBYCLOSINGTHEMANUALGASShut-offVALVE.
PURGING
Gas line purging is required with new piping or systems in which
air has entered.
CAUTION
PURGING SHOULD BE PERFORMED BY PERSONS
EXPERIENCEDINTHISTYPE GASSERVICE. TOAVOID RISKOF
FIRE OR EXPLOSION, PURGE DISCHARGE MUST NOT ENTER
CONFINEDAREAS ORSPACESWHEREIGNITIONCANOCCUR.
THEAREAMUSTBEWELLVENTILATEDANDALLSOURCESOF
IGNITIONMUSTBEINACTIVATED ORREMOVED.
GASMETERSIZE—NATURALGASONLY
Be sure the gas meter has sufficient capacity to supply the full
rated gas input of the water heater as well as the requirements of
all other gas fired equipment supplied by the meter. If gas meter is
too small, ask the gas company to install a larger meter having
adequate capacity.
FIGURE 5-THERMOSTATFORNATURALGAS
GAS PRESSURE REGULATOR
The gas pressure regulator is built into the gas valve and is
equipped to operate on the gas specified on model and rating
plate. The regulator is factory adjusted to deliver gas to burner at
correct water column pressure allowing for a nominal pressure
drop through the controls.
The minimum gas supply pressure for input adjustment is
5.0" W.C. (1.24 kPa) for natural gas or 11.0" W.C. (2.74 kPa) for
propane gas.
Do not subject the combination gas valve to inlet gas
pressures of more than 10.5" W.C. (2.61 kPa) - natural gas or 13.0"
W.C. (3.23 kPa) - propane gas. A service regulator is necessary if
higher gas pressures are encountered.
Gas pressure specified in Table 2, refer to flow pressure taken at
pressure tap of automatic gas valve while heater is operating.

9
TABLE2
MANIFOLDPRESSURESETTING
Model Typeof Manifold
Number Gas Input Pressure
65 Natural 65,000 Btu/hr 4.0 in. W.C.
16.7 KW/hr 1.0 Kpa
65 Propane 55,000 Btu/hr 10.0 in. W.C.
16Kw 2.49kPa
OPERATION
It is recommended that a qualified person perform the initial firing
of the heater. At this time the user should not hesitate to ask the
individual any questions which he may have in regard to the
operation and maintenance of the unit.
WARNING
THEGASVALVEMUSTHAVE BEEN INTHEOFFPOSITION FOR
AT LEAST 5 MINUTES. This waiting period is an important safety
step. Its purpose is to permit gas that may have accumulated in
the combustion chamber to clear. IF YOU DETECT GAS ODORAT
THEENDOFTHISPERIOD DONOT PROCEEDWITHLIGHTING.
RECOGNIZE THAT GAS ODOR, EVEN IF IT SEEMS WEAK, MAY
INDICATEPRESENCE OFACCUMULATEDGAS SOMEPLACEIN
THEAREAWITHRISKOFFIREOREXPLOSION. SEETHEFRONT
PAGEFOR STEPSTOBE TAKEN.
Before lighting the pilot and operating the heater, the following
conditions must exist:
• Entire system filled with water.
• Air purged from all lines and no leaks (gas and water).
• All gas and water lines open.
PRECAUTIONS
DONOTUSE THISAPPLIANCE IFANYPARTHAS BEEN UNDER
WATER. The heater must be replaced.
IF THE UNIT IS EXPOSED TO THE FOLLOWING, DO NOT
OPERATEHEATERUNTILALLCORRECTIVESTEPS HAVEBEEN
MADEBYAQUALIFIEDSERVICEMAN:
1. EXTERNALFIRE.
2. PHYSICALDAMAGE.
3. FIRINGWITHOUTWATER.
4. SOOTING.
NEVEROPERATETHE HEATERWITHOUTFIRSTBEINGCERTAIN
IT IS FILLED WITH WATERAND ANA.G.A. TEMPERATUREAND
PRESSURERELIEFVALVE ISINSTALLED INTHE RELIEFVALVE
OPENINGOFTHE HEATER.
SHOULDOVERHEATING OCCURORTHE GASSUPPLY FAILTO
SHUT OFF, TURN OFFTHE MANUAL GAS CONTROLVALVE TO
THEAPPLIANCE.
A checklist is included in the SERVICE INFORMATION section of
this manual. By using this checklist the user may be able to make
minor operational adjustments and save himself unnecessary
service calls. However, the user should not attempt repairs which
are not listed in this section.

10
FORYOURSAFETYREADBEFORE LIGHTING
LIGHTINGINSTRUCTIONS
WARNING
If you do not follow these instructions exactly, a fire or explosion
may result causing property damage, personal injury or loss of life.
• If you cannot reach your gas supplier, call the fire
department.
C. Use only your hand to push in or turn the gas control
knob. Never use tools. If the knob will not push in or turn
by hand, don’t try to repair it, call a qualified service
technician. Force or attempted repair may result in a fire
or explosion.
D. Do not use this appliance if any part has been under
water. Immediately call a qualified service technician to
inspect the appliance and to replace any part of the
control system and any gas control which has been
under water.
A. This appliance has a pilot which must be lighted by
hand. When lighting the pilot, follow these instructions
exactly.
B. BEFORE LIGHTING smellall around the appliance area
for gas. Be sure to smell next to the floor because
some gas is heavier than air and will settle on the floor.
WHAT TO DO IF YOU SMELL GAS:
• Do not try to light any appliance.
• Do not touch any electric switch;
do not use any phone in your building.
• Immediately call your gas supplier from a neighbor’s
phone. Follow the gas suppliers instructions.
1. STOP! Read safety information above on this label.
2. Set the thermostat to lowest setting by turning the
water temperature dial clockwise ( ) to its lowest
temperature setting (with arrow on dial) as shown.
DONOT FORCE.
3. Remove outer door.
4. Turn gas control knob clockwise to “OFF”
position.Knob cannot beturned from“PILOT” to“OFF”
unless knob is depressed slightly. DO NOT FORCE.
5. Wait five (5) minutes to clear out any gas. If you
then smell gas, STOP! Follow “B” in the safety
information above on this label. If you don't smell gas,
go to next step.
6. Remove (or open) inner door located below gas
control unit.
7. Find pilot - follow metal tube from gas control. The pilot
is located in front of the burner or on the right hand
side of the burner.
8. If you don’t smell gas, turn knob on gas control counter
clockwise to “PILOT” position.
9. Push in control knob all the way and hold down.
Immediatelylight the pilotwith amatch. Continueto hold
control knob in for about one (1) minute after the pilot is
lit. Release knob and it will pop back up. Pilot should
remain lit. If it goes out, repeat steps 3 through 8.
• If knob does not pop up when released, stop
and immediately call your service technician
or gas supplier.
• If the pilot will not stay lit after several tries,
depress and turn the gas control knob
clockwise to “OFF” and call your
service technician or gas supplier.
10. Replace (or close) inner door. Replace outer
door if door does not cover gas control on/off
knob or temperature adjustment knob.
11. At arms length away, turn gas control knob
counter- clockwise to the full “ON”
position. WARNING: Do not use gas control
knob to regulate gas flow.
12. At arms length away, set the thermostat to
desired setting. The mark ( ) indicative of
approximate 120°F is preferred starting point.
Some local laws may require a lower starting
point. If hotter water is desired, see instruction
manual and “warning” below.
13. Replace the outer door if not replaced in step 10.
TOTURNOFF GASTOAPPLIANCE
1. Set the thermostat to lowest setting by turning the water
temperature dial clockwise ( ) to its lowest
temperature setting (with arrow on dial) as shown. DO
NOTFORCE.
2. Turn gas control knob clockwise to “OFF”
position. Knob cannot be turned from “PILOT” to “OFF”
unless knob is depressed slightly. DO NOT FORCE.
3. Replace outer door (if removed).
WARNING
Hotter water increases the risk of scald injury. Before changing temperature setting see instruction manual.
PILOT
BURNER OR
PILOT
BURNER
*THERMOCOUPLE

11
TEMPERATURE REGULATION
DANGER
THIS WATER HEATER IS EQUIPPED WITH AN ADJUSTABLE
THERMOSTAT TO CONTROL WATER TEMPERATURE. HOT
WATER TEMPERATURES REQUIRED FOR AUTOMATIC
DISHWASHER AND LAUNDRY USE CAN CAUSE PAINFUL
SCALDINGWITHPOSSIBLESERIOUSANDPERMANENTINJURY.
THETEMPERATUREATWHICHINJURYOCCURSVARIESWITH
THE PERSON’S AGE AND THE TIME OF THE EXPOSURE. THE
SLOWERRESPONSE TIMEOF CHILDREN,AGED ORDISABLED
PERSONSINCREASESTHE HAZARDSTOTHEM.NEVER ALLOW
SMALL CHILDREN TO USE A HOT WATER TAP, OR TO DRAW
THEIROWNBATHWATER. NEVERLEAVEACHILDORDISABLED
PERSON UNATTENDED INABATHTUB OR SHOWER.
THEWATERHEATERSHOULDBELOCATEDINANAREAWHERE
THEGENERALPUBLICDOESNOTHAVEACCESS.IFASUITABLE
AREAISNOTAVAILABLE,ACOVERSHOULDBEINSTALLEDOVER
THE THERMOSTAT TO PREVENT TAMPERING. Suitable covers
are available from your distributor.
It is recommended that lower water temperatures be used to avoid
the risk of scalding. It is further recommended, in all cases, that
the water temperature dial be set for the lowest temperature which
satisfies your hot water needs. This will also provide the most
energy efficient operation of the water heater. The water
temperature adjusting dial was factory set at the lowest
temperature; all the way clockwise to the mechanical stop. Turning
the dial counterclockwise increases temperature and clockwise
reduces temperature.
SETTINGTHE WATERHEATERTEMPERATUREAT120°F (49°C)
(APPROX." " MARKONFACEOFTHERMOSTAT)WILLREDUCE
THE RISK OF SCALDS. Some states require settings at specific
lower temperatures.
Figure 6 shows the approximate water temperatures produced at
various thermostat dial settings. Short repeated heating cycles
caused by small hot water uses can cause temperatures at the
point of use to exceed the thermostat setting by up to 30°F (17°C).
If you experience this type of use you should consider using lower
temperature settings to reduce scald hazards.
Valves for reducing point of use temperature by mixing cold and
hot water are available. Also available are inexpensive devices
that attach to faucets to limit hot water temperatures. Contact a
licensed plumber or the local plumbing authority.
SHOULDOVERHEATING OCCURORTHE GASSUPPLYFAILTO
SHUTOFF,TURN OFFTHEMAINMANUALGASShut-offVALVETO
THEAPPLIANCE.
Temperature Time to Produce 2nd & 3rd
Setting Degree Burns on Adult Skin
VERYHOT= APPROX.180°F (82°C) Nearly instantaneous
D = APROX. 160°F (71°C) About 1/2 second
C=APPROX.150°F (66°C) About 1 1/2 seconds
B= APPROX.140°F (60°C) Less than 5 seconds
A= APPROX.130°F (54°C) About 30 seconds
=APPROX.120°F (49°C) More than 5 minutes
LOW= APPROX.100°F (38°C) - - - - - - - -
FIGURE6
HIGH TEMPERATURE LIMIT SWITCH
(Single-Use Type Energy Cut Off)
The thermostat has a built-in limit switch which will extinguish the
pilot light in case of excessive water temperatures. The pilot cannot
be relit until the entire thermostat (labeled as single use type) is
replaced. It is important that a serviceman be called to determine
the reason for limit operation and thus avoid repeated thermostat
replacement. Lower the temperature adjustment dial setting on
new control.
CHECKING VENTING
The following steps shall be followed with each appliance
connected to the venting system placed in operation, while any
other appliances connected to the venting system are not in
operation.
1. Seal any unused openings in the venting system.
2. Inspect the venting system for proper size and horizontal pitch,
as required in the National Fuel Gas Code, ANSI Z223.1 or the
CAN/CGA B149 Installation codes and these instructions.
Determine that there is no blockage or restriction, leakage,
corrosion and other deficiencies which could cause an unsafe
condition.
3. So far as is practical, close all building doors and windows
and all doors between the space in which the water heater(s)
connected to the venting system are located and other spaces
of the building. Turn on all appliances not connected to the
venting system. Turn on all exhaust fans, such as range hoods

12
and bathroom exhausts, so they shall operate at maximum
speed. Close fireplace dampers.
4. Follow the lighting instruction. Place the water heater being
inspected in operation. Adjust thermostat so appliance shall
operate continuously.
5. Test for draft hood spillage at the relief opening after 5 minutes
of main burner operation.
6. After it has been determined that each appliance connected to
the venting system properly vents when tested as outlined
above, return doors, windows, exhaust fans, fireplace dampers
andanyother gasburning appliance totheir previousconditions
of use.
7. If improper venting is observed during any of the above tests,
the venting system must be corrected.
WARNING
FAILURE TO CORRECT BACK DRAFTS MAY CAUSE AIR
CONTAMINATIONAND UNSAFECONDITIONS.
• If the back draft cannot be corrected by the normal method or if
a suitable draft cannot be obtained, a blower type flue gas
exhauster must be employed to assure proper venting and
correct combustion.
SERVICE INFORMATION
The installer may be able to observe and correct certain problems
which may arise when the unit is put into operation. HOWEVER, it
is recommended that only qualified servicemen, using appropriate
test equipment, be allowed to service the heater.
FOR YOUR SAFETY AND SATISFACTORY OPERATION, IT IS
RECOMMENDED THAT THIS HEATER BE CHECKED ONCE A
YEARBY ACOMPETENTSERVICEPERSON.
USERS OF THIS APPLIANCE SHOULD BE AWARE THAT GAS
COMPONENTSWEAR OUTOVER APERIOD OFTIME. THEGAS
CARRYING COMPONENTS OF THIS APPLIANCE SHOULD BE
INSPECTED FOR PROPER OPERATION PERIODICALLY BY A
QUALIFIEDSERVICETECHNICIAN.
PILOT AND MAIN BURNER
Check pilot, figure 7, and main burner at least every 6 months for
proper flame characteristics. The main burner should display the
following characteristics:
1. Provide complete combustion of gas.
2. Causerapidignition andcarryover offlameacross entireburner.
3. Give reasonably quiet operation during ignition, burning and
extinction.
4. Cause no excessive lifting of flames from burner ports.
If preceding burner characteristics are not evident, check for
accumulation of lint or other foreign material that restricts or blocks
the air openings to the heater or burner.
WARNING
SOOT BUILD-UP INDICATES A PROBLEM THAT REQUIRES
CORRECTION BEFORE FURTHER USE. CONSULT WITH A
QUALIFIEDSERVICETECHNICIAN.
Should the main burner or burner air openings require cleaning,
remove the burner and clean with a soft brush. Clean main burner
orifice with a suitable soft material. Do not disassemble burner
head unless necessary.
CHECKFOR GOODFLOW OFCOMBUSTIONANDVENTILATING
AIRTOTHEUNIT. MAINTAINACLEAROPENAREAAROUNDTHE
HEATER AT ALL TIMES. DO NOT STORE COMBUSTIBLES OR
FLAMMABLELIQUIDS NEARORAROUNDANAPPLIANCE.
PILOTANDMAINBURNER
FIGURE7
CHECKING GAS INPUT
For appliance installation locations with elevation above 2000
ft.(610m) refer to HIGHALTITUDE INSTALLATIONS section of this
manual for input reduction procedure.
With this heater in operation, determine whether it is receiving the
full rated input of gas. This may be done by timing the gas meter
and measuring gas pressure with a gauge or manometer. When
the heater is operating at full capacity (full gas input) it should
consume approximately 1 cubic foot of gas in the time shown in
table 3.
TABLE 3
INPUTCHECKTIMEREQUIRED TO
CONSUME1CU.FT. OFGAS
Time Required To
Type of BTU Per Consume 1 Cu. Ft.
Model Gas Cu.Ft. of Gas
65 Natural 1050 58.2 sec.
65 Propane 2500 163.7 sec.
Use this formula to “clock” the meter. Be sure that other gas
consuming appliances are not operating during this interval.
3,600 X H = Btuh
T
T = Time in seconds needed to burn one cubic foot of gas.
H = Heating value of gas in Btu’s per cubic foot of gas.
Btuh = Actual heater input rate.
Example: (Using 65 heater)
T = 58.2 seconds/ft3
H = 1,050 Btu/ft3(natural gas)
Btuh = ?
3,600 X 1,050 = 64.948 Btu/hr (19.0 KW)
58.2

13
Compare the actual input rate to that given on the heater’s rating
plate. In the example, the 65 full input rate should be
65,000 Btuh (19.0 KW) for natural gas.
VENT SYSTEM
Examine the venting system every 6 months for obstructions and/
or deterioration of vent piping.
RELIEF VALVE
At least once a year the temperature and pressure relief valve
should be checked to ensure that it is in operating condition.
(During manual operation of this valve, avoid any contact with hot
water and take preventive steps for water damage). Lift the lever at
the top of the valve several times until the valve seats properly and
operates freely.
WARNING
THE WATER PASSING OUT OF THE VALVE DURING THIS
CHECKING OPERATION MAY BE EXTREMELY HOT. AVOID
CONTACT AND DISCHARGE SAFELY TO PREVENT WATER
DAMAGE.
Ifthetemperature andpressure reliefvalve ontheheater discharges
periodically or continuously, a problem exists. This may be due to
unusually high water temperatures or pressures in the system, or
to a faulty relief valve. Contact your dealer or a qualified service
technician to find the cause of the problem and to correct it. This
may also be due to thermal expansion in a closed water supply
system. Contact the water supplier or local plumbing inspector on
how to correct this situation. DO NOT PLUG THE TEMPERATURE
ANDPRESSURERELIEF VALVE.
WARNING
SHOULDOVERHEATING OCCUROR THEGAS SUPPLYFAILTO
SHUT OFF, TURN OFF THE MANUALGAS CONTROLVALVE TO
THEAPPLIANCE.
HOT WATER ODOR
On occasion, hot water may develop a strong odor. If this occurs
drain the heater completely, flush thoroughly, and refill. If the
problem persists, chlorination of the heater and replacement of
the factory installed magnesium anode with an aluminum anode
may correct the condition.
Occasionally water softener companies recommend removal of
heater anodes for odor reasons.
CAUTION
Unauthorized removal of heater anode will void the warranty.
Replace the anode as necessary to maintain corrosion protection.
For further information contact your dealer.
ANODE ROD INSPECTION
The heater tank is equipped with an anode rod to provide corrosion
control. At least once a year the anode rod should be checked to
determine if replacement is necessary. Initially the anode rod is
approximately 7/8" (22mm) in diameter with a 1/8" (3mm) diameter
steel core wire running down the center of the anode material.
THE ANODE SHOULD BE REPLACED when the 1/8" (3mm)
diameter core wire is visible as this means that the anode material
has been expended in the control of corrosion.
NOTE: Anode rod inspection may need to be made more
frequently in areas subject to acid rain that obtains their water
supply from surface water as the low pH will accelerate anode
activity.
CAUTION: Close cold water inlet valve serving heater and open
nearby hot water faucet to relieve the pressure in the heater
before attempting to remove anode(s) for inspection.
WINTER PROTECTION
In regions where freezing weather is encountered, all water must
be drained from unit and piping when out of service (water shut
off). Drain valve must be left open until unit is returned to service.
REPLACEMENT PARTS
Now that you have purchased this water heater, should a need
ever exist for repair parts or service, simply contact the company it
was purchased from or direct from the manufacturer listed on the
rating plate on the water heater.
Be sure to provide all pertinent facts when you call or visit.
Selling prices will be furnished on request or parts will be shipped
at prevailing prices and you will be billed accordingly.
The model number of your gas water heater will be found on the
rating plate located above the gas control valve.
WHEN ORDERING REPAIR PARTS, ALWAYS GIVE THE
FOLLOWINGINFORMATION:
• MODELNUMBER
• TYPEGAS (NATURALOR PROPANE[L.P.])
• SERIALNUMBER
• PARTDESCRIPTION
CHECKLIST
Before contacting your dealer, check the water heater to see if the
apparent malfunction is caused by some external fault. Consulting
this checklist may eliminate the need for a repair call and restore
hot water service.
NOTENOUGHORNOHOTWATER
1. Check to see if the pilot flame is lit.
• To relight the pilot, follow the instructions on the heater or
in this manual.
• Check to see if the main gas Shut-off valve in the gas
supply pipe is partially closed or the water temperature
dial is set too low.
2. Look forleakingor openhot waterfaucets. Check forexcessive
usage.
3. Your gas company can check the gas input to the heater to see
that it is correct. An underfired heater will not produce hot
water at its normal recovery rate.

14
4. If the heater was installed when incoming water temperatures
were warm, colder incoming temperatures will create the effect
of less hot water.
5. The thermostat water temperature adjusting dial may be set
too low.
6. If you cannot determine the cause of the problems, contact
your dealer.
WATERTEMPERATUREISTOOHOT
1. The thermostat water temperature adjusting dial may be set
too high.
2. If lowering control setting does not reduce the water
temperature contact your dealer.
GASSMELLATTHEHEATER
1. Close the main Shut-off valve in the gas supply pipe near the
heater, see fig. 4 on page 8. The thermostat includes a gas
control (top knob) which can also be closed.
2. Call your gas company.
WATERLEAKAGEISSUSPECTED
1. Check to see if the heater drain valve is tightly closed.
2. The apparent leakage might be condensation. In warm or
humid locations, condensation can accumulate and run from
within the heater or its piping.
• When a water heater is first installed and filled, the bottom
of the tank might condense water. The water accumulation,
if excessive, can drip into the floor shield. Also, during
normal operation there may be occasions when large
quantities of water are drawn, chilling the tank bottom.
This too can result in condensation.
• Condensation, appearing in the vent pipe (water dripping
from draft diverter) during heater operation is evidence of
poor vent action. Possible causes are too long a vent pipe
or improper chimney operation.
3. If the leakage is from the temperature and pressure relief valve
or its discharge pipe, it may represent a normal condition.
However, see RELIEF VALVE section on page 12. DO NOT
PLUGTHETEMPERATUREANDPRESSURE RELIEFVALVE.
Also, the leakage could be due to unusually high water
pressures or temperatures in the system, or to a faulty relief
valve. Your dealer or a qualified service technician should be
called to determine the cause of the problem and to correct it.
4. If you cannot identify or correct the source of water leakage:
• Close the main Shut-off valve in the gas supply pipe at the
heater. See fig. 4, page 8.
• Close the valve which feeds water to the cold water inlet at
the top of the heater.
• Contact your dealer.
WATERHEATERMAKESSOUNDS
1. Occasional excessive condensation, as explained under
LEAKAGE, can cause a sizzling sound as the moisture is
vaporized by the gas flame. This is a normal sound and may
be disregarded.
2. Sediment and water scale accumulations may cause rumbling
noises. Contact your dealer for details of flushing the heater.
3. If you cannot identify or remedy the condition, contact your
dealer.

15
NOTES

16
