Steamfast SF-623 User manual

ENGLISH |1
Mid-Size Fabric Steam Press Owner’s Guide
Guía Del Propietario De La Plancha A Vapor Para Tela De Medio Porte
Guide D’utilisation – Presse À Vapeur Pour Tissu De Taille Moyenne
MODEL SF-623
MODELO SF-623
MODÉLE SF-623
ENGLISH p. 2
ESPAÑOL p. 14
FRANÇAIS p. 26

2 |ENGLISH
READ AND SAVE THESE INSTRUCTIONS
DANGER
Any appliance is electrically live even when switched off. To reduce risk of electrical shock:
1. Always unplug power cord from electrical outlet when filling with water or emptying, or
when not in use.
2. Do not place or store unit where it can fall or be pulled into a sink or tub.
3. Do not place in, or drop into water or other liquid.
4. If unit falls into water, immediately unplug power cord. Do not reach into the water.
WARNING
To reduce risk of burns, electrocution, fire, or injury to persons:
1. Do not tamper with or modify this product in any way. The manufacturer assumes
no responsibility for damage or injury caused by failure to follow these instructions,
improper use, or unauthorized product modification. Any such actions will invalidate the
product warranty.
2. Use the Mid-Size Fabric Steam Press only for its intended purpose as indicated in
this manual.
3. If an extension cord is necessary, use a properly rated cord (15 ampere, 14 gauge). Use care
to position extension cord where it is least likely to be damaged or tripped over during use.
4. Before plugging power cord into electrical outlet, be sure that all electrical information on
rating label agrees with your power supply.
5. To reduce likelihood of circuit overload, DO NOT operate another high wattage appliance
on the same circuit as this unit.
6. To protect against risk of electrical shock, do not immerse unit in water or other liquids. Do
not use power cord as handle, let it hang over edges of counters, or be crimped or closed
in doors.
7. Never yank power cord to disconnect from outlet; instead, grasp plug and pull smoothly
to disconnect.
8. Do not operate unit with a damaged power cord or if the unit has been dropped or
damaged. To avoid risk of electrical shock, do not disassemble unit or attempt to repair
the appliance; contact Steamfast Consumer Service for examination and repair. Incorrect
reassembly can cause a risk of electrical shock when unit is used.
WARNING: To reduce risk of fire, electrical shock or injury, the following
basic safety precautions should always be followed when using an
electrical appliance.
WARNING: To reduce the risk of electrical shock, this appliance uses a
grounded (three-pronged) plug. This plug will fit in a grounded wall outlet
only one way. If the plug does not correctly fit in the outlet, contact a
licensed electrician to install a proper outlet. DO NOT attempt to modify
the plug or defeat this safety feature.
IMPORTANT SAFETY INSTRUCTIONS

ENGLISH |3
9. Close supervision is required for any appliance being used near children, pets and plants. Do
not leave unit unattended while plugged in.
10. This unit is not intended for use by persons (including children) with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge, unless they have been
given supervision or instruction concerning use of the unit by a person responsible for
their safety.
11. Do not use unit where aerosol-based products are being used, or where oxygen is
being administered.
12. Unit is only meant to be used with recommended Mid-Size Fabric Steam Press (model SF-
623) accessories. Using other types of attachments may cause damage to unit or injury.
13. Do not attempt to use unit without properly filling with water.
14. When filling unit, only water should be used – other cleaning agents could damage unit or
cause injury. Distilled or de-mineralized water is highly recommended, in order to minimize
potential build-up of mineral deposits.
15. To reduce risk of contact with hot water emitting from Pressing Plate, check appliance
before each use by positioning it away from body and turning it on. Do not operate unit if
Pressing Plate is blocked.
16. Burns can occur from touching hot parts, hot water, or steam. Do not touch Pressing Plate
or attempt to connect any accessories while unit is in use. Use caution when you turn unit
upside-down – there may be hot water inside.
17. When steaming any fabric for the first time, it is recommended that you consult the
manufacturer’s guidelines for the fabric being steamed. For items in question, test on an
inconspicuous area before proceeding.
18. Do not allow power cord to touch hot surfaces during use. Loop cord loosely around
appliance when storing.
19. Always allow Mid-Size Fabric Steam Press to cool (at least 30 minutes for complete cooling)
and empty Water Reservoir before storing.
This equipment may generate, use and/or radiate radio frequency energy that may cause
harmful interference to radio communications. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to contact Steamfast Consumer Service at
1-800-711-6617.
Please refer to our website for the most current version of our owner’s guide.
Questions or comments?
•steamfast.com
• [email protected]
•1-800-711-6617
Speak your mind! We invite you to review this product online:
steamfast.com/reviews

4 |ENGLISH
The following features and accessories are included with your steam press. Carefully inspect
packaging material as some parts are shipped inside Styrofoam packaging. To obtain possible
missing parts, refer to the Consumer Support section on page 10 of this manual.
Product Information
UNIT FEATURES
& ACCESSORIES
Handle
Steam Burst Buttons
Water Reservoir
Ironing Board
Pressing Plate
Ironing Board Cover
Temperature Control Dial
Locking Knob
On/Off Switch
Power Indicator Light (Red)
Pressing Indicator Light
Steam Burst Ready Indicator
Light
Measuring Cup
Spray Bottle
Pressing Cushion
1
2
3
4
5
6
7
8
9A
9b
10
11
12
13
14
12 13
14
1
2345
6
7
8
9a(9b)
10
11

ENGLISH |5
• The Handle (1) is used to safely lift up and lower the Pressing Plate, and carry the unit.
• The Steam Burst Buttons (2) are located on either side of the Handle, and produce a
powerful burst of steam when pressed.
• The Water Reservoir (3) is the tank in which water is stored for use by the unit. There must be
water in the Water Reservoir in order for the unit's steam burst function to work correctly.
• The Ironing Board (4) is the padded surface onto which fabric is placed during pressing.
• The Pressing Plate (5) is the large temperature-controlled surface that heats and
presses fabric.
• The Ironing Board Cover (6) is the durable cover that protects the Ironing Board. The fabric
cover is removable and can be washed.
• The Temperature Control Dial (7) is used to select a desired temperature, by turning it to the
fabric setting that matches the material that you are pressing.
• The Locking Knob (8) locks the Pressing Plate and Ironing Board together. This allows for
carrying and storage of the unit.
• The On/Off Switch (9a) activates and deactivates the unit.
• The Power Indicator Light (Red) (9b) illuminates when the On/Off Switch is set to the “On” (I)
position, providing you with a clear visual indication that the unit is powered on.
• The Pressing Indicator Light (Orange) (10) illuminates while the unit is heating to the selected
temperature. When deactivated, this indicates that you are ready to press.
• The Steam Burst Ready Indicator Light (Orange) (11) illuminates once the unit is ready to
produce bursts of steam, providing you with a clear visual indication that you can begin using
the Steam Burst Buttons.
• The Measuring Cup (12) is designed to assist you in easily filling the Water Reservoir with
distilled water.
• The Spray Bottle (13) allows you to moisten fabrics before pressing, which helps to make the
pressing process easier and more effective in certain instances.
• The Pressing Cushion (14) is a fabric-covered pad used for pressing gathered or contoured
areas such as sleeves, darts, or collars.

6 |ENGLISH
FILLING WATER RESERVOIR
1. Place Mid-Size Fabric Steam Press on a flat, level surface.
2. Turn Locking Knob to “Unlock” position to unlock Pressing Plate.
3. Lift up Pressing Plate using Handle. It will automatically stay in lifted position.
4. Pull Water Reservoir out. Note that Water Reservoir cannot be completely removed from
unit; do not attempt to force it free.
5. Using Measuring Cup (included), fill Water Reservoir up to the 150ml (5.07 oz) line
with water.
OPERATION
1. With Pressing Plate in lifted position, plug power cord
into electrical outlet, and set On/Off Switch to “On” (I)
position (FIGURE 1).
2. Identify type of fabric you are going to press, and select
corresponding temperature setting using Temperature
Control Dial. Note that it is best to start with the most
delicate fabrics first, as higher levels of heat will cause
damage to Nylon and Silk. Pressing Indicator Light
will illuminate.
3. A few minutes of heating time will be required to reach
selected temperature. Once Pressing Plate is heated,
Pressing Indicator Light will deactivate.You are now ready
to begin pressing.
4. Lay fabric flat on Ironing Board.
5. If pressing wool, cotton or linen you may choose to spray with a burst of steam. This function
is available once Steam Burst Ready Indicator Light illuminates.
NOTE: Do not activate burst of steam with unit completely closed, as this may damage
unit. Best results are obtained if Pressing Plate is held open approximately 3 in. (75 mm.)
above Ironing Board before pressing Steam Burst Button. For safety reasons, do not hold
Pressing Plate open more than 3 in. (75 mm.) when using steam burst function. Only use
burst of steam for 2-3 seconds for best results. If press is left on fabric for more than 10
seconds, it could result in damage to the fabric.
NOTE: When using the nylon or silk settings, no steam is produced.
6. To press, lower Pressing Plate gently onto fabric and Ironing Board. Hold there for 8-10
seconds, then lift up Pressing Plate. Repeat until you have achieved desired crease and
smoothness. See page 7 of this manual for more specific pressing tips.
7. Once pressing tasks are complete, immediately set On/Off Switch to “Off” (O) position and
unplug power cord from electrical outlet. Refer to page 8 of this manual for further
information about cleaning and storage of Mid-Size Fabric Steam Press.
FIGURE 1
I
O
Using Your Mid-Size
Fabric Steam Press

ENGLISH |7
STEAM BURST
1. Hold Pressing Plate approximately 3 in. (75 mm.) above Ironing Board.
2. Press Steam Burst Button to release a burst of steam onto fabric for 2-3 seconds.
3. Lower Pressing Plate onto fabric for 8-10 seconds, then raise once again. Note: If press is
left on fabric for more than 10 seconds, it could result in damage to fabric.
4. Repeat steps 1-3 above until fabric is smooth and wrinkle-free.
PRESSING AND STEAMING TIPS
Pressing Shirts And Blouses
1. Place shoulder yoke on Ironing Board first and press.
2. Next, place sleeves onto Ironing Board with fold parallel to long seam and press.
3. Place cuffs onto end of Ironing Board and press.
4. Place bottom of shirt behind Ironing Board. Begin by pressing the side with pocket. Pull shirt
towards you as you press each section.
5. Finish by pressing collar of shirt.
Pressing Pants
1. Place Pressing Cushion under waistband and press, repositioning waistband until
completely pressed.
2. To press inseam, place Pressing Cushion under area to be pressed.
3. Place pleated area on Ironing Board. Carefully fold pleats and press.
Other Techniques
• Placing Pressing Cushion between fabric and Pressing Plate may help with delicate fabrics.
• If you have older types of buttons or zippers, you may need to take special care to avoid
melting. In order to do so, place garment face-down and cover with Pressing Cushion
before pressing.
• Spray Bottle may be used to spray fabrics lightly. This will further help to remove
exceptionally stubborn wrinkles.
• Place a damp cloth over fabric before pressing, which will help with stubborn wrinkles or
heavy gauge fabrics.
• To press large pieces of fabric, place entire piece behind Ironing Board. Pull fabric towards
you, over Ironing Board, and lower Pressing Plate. Press fabric in sections until completed.
• Embroidery should be placed face down on Ironing Board to reduce wear and prevent
damage to delicate areas.

8 |ENGLISH
AUTO SHUT-OFF
The Auto Shut-Off feature deactivates electrical power to the heater when the Pressing
Plate has been left in closed position against the Ironing Board. The Pressing Indicator
Light (Orange) and Steam Burst Ready Indicator Light (Orange) does not illuminate. Heater
functionality is restored when the Pressing Plate is lifted back up.
IMPORTANT: Auto Shut-Off does not mean that power to the unit is totally cut off. Power
is always on, and the Power Indicator Light will remain illuminated until On/Off Switch is
set to “Off” (O) position (FIGURE 1, page 6).
CLEANING THE MID-SIZE FABRIC STEAM PRESS
1. Fill Water Reservoir with water using procedure on page 6 of this manual.
2. Place Pressing Cushion in the middle of Ironing Board.
3. Place a clean towel over Pressing Cushion and Ironing Board.
4. Set Temperature Control Dial to the highest setting (LINEN).
5. When Steam Burst Ready Indicator Light illuminates, lower Pressing Plate onto
Pressing Cushion.
6. Press Steam Burst Button six times.
7. Allow Pressing Plate to cool.
8. Clean Pressing Plate with damp cloth. Do not use abrasive materials, as this may damage
Pressing Plate.
9. Ironing Board Cover is removable for cleaning. Hand wash only with mild detergent.
PROPER STORAGE
1. Once pressing is complete, immediately turn unit off and unplug power cord from
electrical outlet.
2. Allow unit to cool completely (at least 30 minutes).
3. Lower Pressing Plate down, and turn Locking Knob to “Lock” position.
4. Store all accessories safely away, preferably near Mid-Size Fabric Steam Press.
5. Store Mid-Size Fabric Steam Press in a cool, dry place.
Storage & Care

ENGLISH |9
PROBLEM POSSIBLE CAUSE SOLUTION
Unit fails to heat up and steam.
Power Indicator Light does
not illuminate.
Unit is not plugged in. Plug into electrical outlet.
Household Circuit Breaker/
Ground Fault Interrupter has
tripped or blown a fuse.
Reset Circuit Breaker/Ground
Fault Interrupter, or replace fuse.
If you need assistance, contact a
licensed electrician.
Unit fails to heat up and
steam. Power Indicator Light
does illuminate.
Auto Shut-Off has engaged. Refer to Auto Shut-Off section on
page 8 of this manual for proper
procedure.
Water Reservoir is empty. Refill Water Reservoir using
procedures on page 6 of this manual.
Unit is damaged or
malfunctioning.
Immediately cease usage and contact
our Customer Support Department.
Steam Burst output is weak
or intermittent.
Pressing Plate needs to be
cleaned.
Refer to Cleaning the Fabric Steam
Press section on page 8 of this
manual for proper procedure.
Troubleshooting

10 |ENGLISH
CONSUMER SERVICES
For problems with your Fabric Steam Press, please refer to the troubleshooting guide located
on Page 9 of this manual. Additional inquiries should be directed to our consumer support
services through our Web site, www.steamfast.com.
If you do not have internet access, you may also contact our Consumer Service Department by
telephone, at 1-800-711-6617.
NOTE: In order for our Consumer Service representatives to help you as quickly and
efficiently as possible, please have the following information ready before calling:
• Purchase information (where and when you purchased this product)
• Copy of purchase receipt / proof of purchase
• Product serial number (located on electrical specification label on back of unit)
For information regarding your 1 year limited warranty, refer to Page 12 of this manual.
PRODUCT SPECIFICATIONS
SF-623
120V
1500W
12.5A
5.07 OZ. (150 ML.)
12.79 LBS. (5.80 KG.)
20.47” (52 CM.) x 17.16” (43.6 CM.) x 6.73” (17.1 CM.)
6.6’ (201.0 CM.)
MODEL
VOLTAGE
WATTAGE
AMPERAGE
WATER CAPACITY
UNIT WEIGHT
UNIT DIMENSIONS
POWER CORD LENGTH
Product Support

ENGLISH |11
SPRAY BOTTLE
A660-005
ACCESSORIES & PARTS
When ordering accessories and parts for your Fabric Steam Press, you may refer to the part
numbers below. Replacement parts may be ordered through our Web site:
www.steamfast.com
You may also contact Consumer Service directly:
[email protected] or 1-800-711-6617
PRESSING CUSHION
A660-003
FUNNEL
CUP
A660-006

12 |ENGLISH
1-YEAR LIMITED WARRANTY
What is covered
Steamfast, a division of Vornado Air, LLC (“Steamfast”). Subject to the terms and conditions of
this 1-Year Limited Warranty (“Warranty”) as set forth below, Steamfast warrants to the original
consumer or purchaser (“Buyer”) that this Steamfast®-branded steam product, excluding
all accessories and attachments, (the “Product”) is to be free from defects in material and
workmanship for a period of one (1) year from the date of purchase when used and maintained in
accordance with the Owner’s Guide (the “Warranty Period”). In the event Buyer notifies Steamfast
of a defect in the Product within the Warranty Period, Steamfast will replace the Product and/
or defective component parts, as applicable and necessary. Any such replacement will be made
at no charge to Buyer for parts or labor, provided that Buyer shall be responsible for all shipping
and transportation costs associated with returning the Product to Steamfast for inspection and
covered replacement.
What is not covered
This Warranty shall not be applicable to damage or loss caused in whole or in part by:
• Repairs, modifications or alterations to the Product by anyone other than Steamfast.
• Use or operation of the Product outside the permitted or intended uses described by
Steamfast in the Owner’s Guide, or other careless operation, handling, misuse, or abuse of
the Product.
• Lack of proper maintenance or timely cleaning of the Product as specified in the
Owner’s Guide.
• Use of the Product other than for normal household purposes.
• Normal wear and tear.
• Used consumable parts, accessories and attachments, including, but not limited to, brushes,
hangers, scrub pads and mop pads.
• Use of parts and accessories other than those produced or recommended by Steamfast.
• Cosmetic damage, such as scratches, nicks and dents.
• Damage caused by accident, water, flood, fire or other acts of nature or external causes.
Warranty limitations and exclusions
• NO OTHER EXPRESS WARRANTY IS GIVEN BY STEAMFAST TO BUYER AND NO
REPRESENTATIVE HAS THE AUTHORITY TO MAKE REPRESENTATIONS OTHER THAN THOSE
PROVIDED HEREIN.
• THERE ARE NO WARRANTIES WHICH EXTEND BEYOND THE DESCRIPTION ON THE FACE
HEREOF AND ALL IMPLIED WARRANTIES, SPECIFICALLY THE IMPLIED WARRANTIES OF
MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, ARE HEREBY EXPRESSLY
LIMITED TO THE DURATION OF THE WARRANTY PERIOD, UNLESS A SHORTER PERIOD IS
PERMITTED BY LAW.
• STEAMFAST’S REPLACEMENT OF THE PRODUCT IS THE EXCLUSIVE REMEDY. UNDER NO
CIRCUMSTANCES SHALL STEAMFAST BE LIABLE TO BUYER OR ANY OTHER PERSON FOR
ANY INCIDENTAL, SPECIAL, CONSEQUENTIAL, OR OTHER DAMAGES, EVEN IF STEAMFAST
HAS BEEN ADVISED OF OR COULD REASONABLY FORESEE THE POSSIBILITY OF SUCH
DAMAGES, INCLUDING, BUT NOT LIMITED TO, LOSS OF PROFITS OR DAMAGE, WHETHER
RISING OUT OF BREACH OF WARRANTY, BREACH OF CONTRACT OR UNDER ANY OTHER
THEORY OF LAW.
Warranty Information

ENGLISH |13
• THIS WARRANTY GIVES BUYER SPECIFIC LEGAL RIGHTS. BUYER MAY ALSO HAVE OTHER
RIGHTS WHICH VARY FROM STATE-TO-STATE. SOME STATES DO NOT ALLOW THE
EXCLUSION OR LIMITATION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES, AND SOME
STATES DO NOT ALLOW LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY LASTS, SO
THE ABOVE LIMITATION OR EXCLUSION MAY NOT APPLY TO BUYER.
How do you register the Warranty
Buyer must complete an application to register this Warranty within sixty (60) days following date
of purchase. Buyer may either visit Steamfast’s website at steamfast.com and complete an online
application or mail a completed application to Steamfast. Failure to register this Warranty within
sixty (60) days following date of purchase will render this Warranty null and void.
Warranty service
For warranty service, call 1-800-711-6617 or email [email protected] to obtain a
Return Authorization (“RA”) form. Include the Product model number and serial number, as well
as Buyer’s name, address, city, state, zip code and phone number when contacting Steamfast
for warranty service. Buyer may be required to provide the original sales receipt for purposes of
verifying date of purchase. After receiving the RA form, the Product must be shipped, postage
prepaid by Buyer, to:
Steamfast
Attn: Warranty & Repair
415 E. 13th Street
Andover, KS 67002
To assure proper handling, packages must be clearly marked with the RA number. Packages not
clearly marked with the RA number may be refused at the receiving dock.
Important: After receiving return authorization, carefully pack the Product to avoid damage in
shipping. Damage in shipping is not covered by the Warranty and shall be the sole responsibility
of Buyer. Damage or loss not covered by this Warranty or occurring outside the Warranty Period
will require a fee to cover the cost of handling and shipping. All such fees and costs shall be the
sole responsibility of Buyer.
Please allow at least 1-2 weeks for return of the Product after it is received by Steamfast. For ease
of recordkeeping, it is recommended that Buyer staple or attached the original sales receipt to
this Owner’s Guide and record the Product serial number (located on the Product specifications
decal) here:
________________________________________________
© 2016 Vornado Air, LLC • Andover, KS 67002
Specifications subject to change without notice.
Steamfast® is a trademark owned by Vornado Air, LLC.
Manufactured in China.
Steamfast Consumer Service
W: steamfast.com • P: 1-800-711-6617 • E: [email protected]

review this product online
evalúe este producto en línea
évaluer ce produit en ligne
www.steamfast.com/reviews
Steamfast
415 East 13th Street, Andover, KS 67002
1-800-711-6617 www.steamfast.com [email protected]
T623-005 R-, V01
