Steelcraft Swift 3 in 1 Baby Walker User manual
KEEP INSTRUCTIONS IN A SAFE PLACE FOR FUTURE REFERENCE
Swift 3 in 1 Baby Walker
series BG1113
Art No.4001346
Your new product has been manufactured to comply with the ASTM F977-09
THIS WARRANTY IS VALID IN AUSTRALIA AND NEW ZEALAND ONLY.
Each Steelcraft unit is thoroughly inspected in our Quality Assurance department
prior to delivery.In the unlikely case that you find any material or workmanship
that effects the units normal operation, we will repair the unit free of charge
within 12 months of purchase.You are required to present your receipt as proof
of purchase. For all concerns with your product please contact our Customer
Service Team.
Please read all the information carefully before using this product. This warranty
does not apply to failure due to improper care, or normal wear and tear caused
by product use.We reserve the right to inspect the unit.You may be charged for
repairs if the product has been damaged accidentally.
This warranty does not apply to a high chair used for commercial purposes.
2010 Copyright Britax Childcare Pty.Ltd. Australia
Due to our continuing program of development,Britax reserves the right to alter the specifications,colour
or design without any further notice.
The Steelcraft trademark is the property of Britax Childcare Pty.Ltd-Australia.
Due to the variations in the style and design of our products the illustrations used in this instruction
booklet are generic.
02 31
SAFETY WARNINGS
STAIR HAZARD AVOID SERIOUS INJURY OR DEATH.
BLOCK STAIRS/STEPS SECURELY BEFORE USING THE
WALKER.
• FOLLOW THE MANUFACTURERS INSTRUCTIONS.
• DO NOT USE WALKER UNTIL BABY CAN SIT UP BY ITSELF.
• NEVER LEAVE YOUR CHILD UNATTENDED, ALWAYS KEEP YOUR
CHILD IN VIEW WHILST IN THE WALKER.
• TO PREVENT INJURIES, ALWAYS ENSURE THE CHILD IS WELL CLEAR
OF ANY MOVING PARTS WHEN FOLDING OR UNFOLDING THE BABY
WALKER.
• NEVER ADJUST OR CARRY THE WALKER WITH THE CHILD IN IT.
• ENSURE THAT THE CHILD CAN TOUCH THE FLOOR WITH BOTH FEET,
AFTER ADJUSTING THE HEIGHT OF THE WALKER.
• DOUBLE CHECK ASSEMBLY BEFORE USING THE BABY WALKER.
• To avoid burns, keep the child away from hot liquids, ranges,
radiators, space heaters, fireplaces, etc.
• Use only on flat surfaces free of objects that could cause the
walker to tip over.
• Clean grip pads regularly to maintain stopping performance.
RETAIN FOR FUTURE REFERENCE.
READ ALL INSTRUCTIONS CAREFULLY BEFORE ASSEMBLY AND USE
OF THIS WALKER. ALWAYS FOLLOW THE INSTRUCTIONS.
THE CORRECT USE AND MAINTENANCE OF THIS PRODUCT IS
ESSENTIAL.
• To prolong the life of your walker keep it clean and do not leave it
in the direct sunlight for extended periods of time.
• Removable fabric covers and trims may be cleaned using warm
water with a household soap or mild detergent. Allow it to dry fully,
preferably away from the direct sunlight.
• DO NOT DRY CLEAN, OR USE BLEACH.
• Do not machine wash, tumble or spin dry, unless the care labelling
on the product permits these methods.
• Non removable fabric covers and trims may be spot cleaned using
a damp sponge with soap or a mild detergent. Allow it to dry
completely before folding or storing it away.
• In some climates the covers and trims may be affected by mould
and mildew. To help prevent this occurring, do not fold or store the
product if it is damp or wet. Always store the product in a well
ventilated area.
• Remove batteries before storing for a prolonged period of time.
Check the condition of batteries periodically for fluid leakage.
Do not use the walker if batteries are leaking.
• Always check parts regularly for tightness of screws, nuts, and other
fasteners - tighten if required. To maintain the safety of your nursery
product, seek prompt repairs for bent, torn, worn or broken parts.
THIS PRODUCT IS NOT INTENDED FOR COMMERCIAL USE.
WARNING CLEAN SAFETY GRIP PADS REGULARLY,
USING WARM WATER WITH A HOUSEHOLD SOAP OR MILD
DETERGENT TO MAINTAIN STOPPING PERFORMANCE.
• Do not allow children to stand on the seat.
• The baby walker should not be used by children who can walk
unaided.
• Discontinue use of the walker should any part become damaged
or broken.
• Do not store outdoors.
• Do not leave your child exposed to the sun.
• If used on carpets, the safety grip pads may reduce the walker
speed.
• Do not use accessories other than those tested and approved by
Britax.
• The weight of the child using this product should be less than
13kg and the height should be 81cm, or less.
03
30
NOTES
THIS PRODUCT IS NOT INTENDED FOR COMMERCIAL USE.
04 29
NOTESPARTS LIST
AB
CD
A1 x Upper Plate B 1 x Push bar
2 x Connectors
D1 x Padded Seat
F
F2 x Front Swivel Wheels
2 x Back Wheels
C1 x Seat Frame
E
E6 x Grip pads
Front Wheels
Back Wheels
05
28
NOTES PARTS LIST
GH
IJ
G1 x Foot Toy Pad H 1 x Toy Tray
J1 x Toy Car
I2 x Toy Poles
2 x Connectors
NOTES 01. TO ASSEMBLE THE WALKER (Cont)
26 07
CInsert the tab on the front of the seat frame into the slot on the
upper plate of the walker then press the back hook down onto
the push bar until you hear a‘click’ and it locks into place.
DTurn the frame upside down and insert the end of the swivel
wheel posts all the way into the holes located in each corner at
the front of the walker base. Insert the two pegs on each of the rear
wheels into the holes located in each corner at the back of the
walker.
Back hook
• To release the seat.
2
1
08 25
EConnect the grip pads in the positions shown in the picture by
inserting the two pegs on each grip pad into the holes located
around the base the of the walker. Push all the way in.
NOTES
01. TO ASSEMBLE THE WALKER (Cont)
02. TO INSTALL THE BATTERIES
24 09
IMPORTANT: USE THE APPROPRIATE SIZE
PHILLIPS HEAD SCREWDRIVER TO UNSCREW THE BATTERY
COVERS.
NOTES
IMPORTANT: BATTERIES ARE NOT INCLUDED.
3“AA” (1.5V) SIZE BATTERIES ARE REQUIRED FOR THE FOOT
PEDAL. 2“AA” (1.5V) SIZE BATTERIES ARE REQUIRED FOR
THE TOY CAR.
10 23
02. TO INSTALL THE BATTERIES (Cont)
AFOOT TOY PAD BATTERIES
To insert the batteries, locate the battery housing underneath
the foot toy pad. Unscrew the screw on battery cover then push
cover down firmly until you a ‘click.’Insert 3 “AA” batteries
observing the correct positive and negative positions. Refit the
battery cover by pushing upwards until it locks into place and
then insert the screw to secure in place.Test correct installation
by turning over and pressing the light and sound buttons.
IMPORTANT: NEVER REPLACE BATTERIES WHILE
THE WALKER IS OCCUPIED.
NOTES
3
1
2
4
BTOY CAR
To insert the batteries, locate the battery housing underneath
the toy car. Unscrew the battery cover and insert 2 “AA” batteries
observing the correct positive and negative positions and refit
the battery cover. Test correct installation by turning over and
pressing the light and sound button on top of the car.
IMPORTANT: NEVER REPLACE BATTERIES WHILE
THE WALKER IS OCCUPIED.
02. TO INSTALL THE BATTERIES (Cont)
Light and Sound button
NOTES
07. TO USE THE WALKER IN ‘STAND AND PUSH ALONG’MODE (Cont)
CThe walker is now ready to use in the‘Stand and Push Along’mode.
The push bar will give baby something extra to grip as your child
learns to stand,take their first steps and walk.
12 21
PLEASE NOTE: THERE ARE THREE FOOT TOY PAD POSITIONS.
THE FOOT TOY PAD MUST BE FITTED WITH THE CURVED EDGE
FACING OUTWARD AS SHOWN IN THE DIAGRAM.
A. FRONT - BENEATH THE UPPER TRAY
B. CENTRE - UNDER SEAT
C. REAR - BEHIND SEAT
AConnect the foot toy pad to the base of the walker by inserting
the pegs on the underside of the foot toy pad into the holes along
the inside edge of the base then twist the peg in the direction
shown to lock into place.
NOTES
03. TO INSTALL THE FOOT TOY PAD
A
B
B
C
C
PLEASE NOTE: POSITION C CANNOT BE USED WHEN THE WALKER
IS IN THE PUSH MODE.
07. TO USE THE WALKER IN ‘STAND AND PUSH ALONG’MODE (Cont)
BPosition and secure the foot toy pad at the front of the walker
(Position A) with curved edge facing towards the back of the
stroller, reverse the position of the push bar so it is now
located at the front of the walker and insert into the connectors
until the locking pins engage.
A
Position
20 13
www.britax.com.au www.britax.com.au
04. TO ASSEMBLE AND INSTALL THE TOY TRAY
AInsert the toy pole connectors into the holes on the toy tray and
push down until they lock into place.
B Insert the toy poles into the connectors and push down until
they lock into place.
07. TO USE THE WALKER IN ‘STAND AND PUSH ALONG’MODE
NOTE: The Stand and Push Along Mode is suitable for babies
who are learning to walk or walk freely.
(Approximately 12-24 months)
ATo convert the walker from a traditional Sit and Step walker to a
Stand and Push Along, remove the seat pad and seat frame, push
bar and foot toy pad.
1
2
3
14 19
www.britax.com.au www.britax.com.au
04. TO ASSEMBLE AND INSTALL THE TOY TRAY (Cont)
CAttach the toy car to the toy tray by inserting the front of the car
into the slot on the troy tray then push the back of the car down.
DLock the toy car onto the toy tray by moving the lever on the toy
tray in the direction shown.
2
1
LOCKLOCK
07. TO USE THE WALKER IN ‘SIT AND STEP’ MODE
NOTE: The Sit and Step Mode is suitable for babies who can
sit unassisted - Max weight 13kg, Maximum height 81cm
(Approximately 9-24 months)
APosition and secure the foot toy pad behind the baby’s seat
(Position C), to allow the child to touch the floor and take their
first steps.
C
Position
18 15
www.britax.com.au www.britax.com.au
04. TO ASSEMBLE AND INSTALL THE TOY TRAY (Cont)
EThe toy car also comes with an accessory strap. It can be
attached to other nursery or furniture items.
Accessory
strap
06. TO USE THE WALKER IN ‘SIT AND PLAY’ MODE
NOTE: The Sit and Play Mode is suitable for babies who can
sit unassisted (Approximately 4-9 months)
APosition the foot toy pad under the baby’s seat (Position B), to
allow the child to use their feet to touch the foot buttons and
discover the joy of music, vibration and lights.
B
Position
