Steinberg Steintec 100 9511 User manual

ASSEMBLY GUIDE
Schiess-Straße 30 • 40549 Düsseldorf • Tel.[phone] • Fax[phone]
[email protected] • www.steinberg-armaturen.de
Mounting frame 100 9511
Mounting plate 100 9411
Mounting frame with plate and water container
Universal mounting frame with plate with water container, for all deck mounted basin and bath tub mixers,
with 3 integrated connections (hot/cold/outlet), check-valve, fi xing kit including evacuation hose and
univertal T-connection

Schiess-Straße 30 • 40549 Düsseldorf • Tel.[phone] • Fax[phone]
[email protected] • www.steinberg-armaturen.de
1
2 3 4
• Distance between fi nished wall and rim-min. 140 mm.
• Set max. height via the screws on the side feeds.
A = Warm water input
B = Cold water input
C = Output for fi lling via waste and overfl ow
• Mark drill holes.
• Remove mounting box and drill holes in the ground.
• Place mounting box to the designated place and fi x it on the ground.
• Release screws on the stand, adjust height based on the height of the brick wall and
re-tighten screws.

• Mark drilling holes on the brick wall.
• Drill hole
• Fix mounting frame on brick wall
Schiess-Straße 30 • 40549 Düsseldorf • Tel.[phone] • Fax[phone]
[email protected] • www.steinberg-armaturen.de
• Place mounting plate.
• Final setting of the mounting plate via the screws (Bring to scale)
5 6 7
8 9

10
Warranty only applies if installed by a licensed professional plumber
Schiess-Straße 30 • 40549 Düsseldorf • Tel.[phone] • Fax[phone]
[email protected] • www.steinberg-armaturen.de
• connect hot water and cold water supply. In case that bathtub is fi lled via waste and over
fl ow , use Vérifi er l‘étanchéité des toutes les connexions outlet connection C. In case that
this exit is not used, please plug with 1/2 „ brass cap. Please pay attention to the guide
line for the waste and overfl ow provided by the manufacturer.
• waste pipe to be connected behind the drain and overfl ow to the sewer.
Check all connection for tightnessn.
• Insert faucet into the tiled mounting plate and connect it. Attention: always place the
hand-shower at the right side to insure easy move of the fl ex hose.
• Seal the mounting plate with silicone.
11
