Bradley 1C TouchTime User manual

P.O. Box 309, Menomonee Falls, WI USA 53052-0309
PHONE 800.BRADLEY (800.272.3539) FAX [phone]
bradleycorp.com
Installation
215-1152 Rev. E; ECN 13-03-022
© 2014 Bradley
Page 1 of 4 1/9/2014
Bradley 1C TouchTime™
Individual Built-In Wall
Shower with Concealed
Supplies
Table of Contents
Pre-Installation Information and Rough-in...............2
Electrical Connections and Installation . . . . . . . . . . . . . . . . . 3
Cleaning and Maintenance ..........................4
IMPORTANT!
Read this entire installation manual to ensure proper installation. When finished with the
installation, file this manual with the owner or maintenance department. Compliance and
conformity to local codes and ordinances is the responsibility of the installer.
Separate parts from packaging and make sure all parts are accounted for before
discarding packaging material. If any parts are missing, do not begin installation until
you obtain the missing parts.
Make sure that all water supply lines have been completely turned off before beginning
installation.
Product warranties may be found under “Products” on our website at
www.bradleycorp.com.
Installation
THIS
SIDE
UP
Packing List
•
•
•
•

2
Bradley TouchTime™Individual Built-In Wall Shower with Concealed Supplies Installation
1/9/2014 Bradley • 215-1152 Rev. E; ECN 13-03-022
AB
C
Rough-in tempered water supply
piping to the solenoid valve as
required for your installation.
Rough-in wall openings for the
showerhead and pushbutton as
required for your installation.
Install two #10 wall
anchors (supplied
by installer) to
secure pushbutton
assembly.
Pre-Installation Information
Supplies Required for Installation
• 1/2" IPS piping and 1/2" IPS tempered water supply piping and fittings (for solenoid)
• four 1/4"-20 wall anchors for showerhead and two #10 wall anchors for pushbutton assembly
• Teflon tape or teflon pipe dope
• 110 VAC power source for 24 VAC Class II transformer or 110/24 VAC Class II transformer (available from
Bradley as an option)
Operation
The 1C Touch Time Shower controls water flow at each station through the use of solid state circuitry. When the
pushbutton is released, a signal is sent controlling the opening and closing of the fixture's solenoid valve. The valve
then delivers water to the fixture for a preset length of time (60 seconds or 180 seconds).
Recommended showerhead heights
Bradley 1C TT showers can be installed at any height (see
recommended heights below). NOTE: The heights listed below
are measured from finish floor to showerhead tip.
Components
Material: All exposed parts are stainless steel or polished chrome-plated brass.
Supply Inlet: The supply inlet to the solenoid valve is 1/2" IPS.
Solenoid Valve: Solenoid valves have few moving parts making them less prone to mechanical failure.
Rough-in
IMPORTANT: Your 1C TT Shower must be connected with a 24 VAC transformer power supply. Connection to
110 VAC will result in damage to the electronics and could result in personal injury.
IMPORTANT: Refer to recommended shower heights shown above.
Solenoid Valve
Solenoid Valve
2-7/8"
(73mm)
16"
(406mm)
2-7/8"
(73mm)
4-1/4"
(108mm)
2-3/8" (60mm)
1/2" (13mm)
1-1/2" (38mm)
3" (76mm)
5-7/8"
(149mm)
2-1/4" (57mm)
diameter
1/2" Supply Inlet
1/2" IPS Piping
(supplied by installer)
(2) #10-24 Screw
(supplied by
Bradley) and
(2)#10 wall
anchors (supplied
by installer)
Reducer
Inlet
Outlet
Showerhead
Escutcheon
(4) 1/4"-20 Anchors (supplied
by installer) and (4) screws
(supplied by Bradley)
Age Male Female
Adult 6' (1.83m) 5'6" (1.68m)
Teenage 6' (1.83m) 5'6" (1.68m)
Pre-Teen 5'6" (1.68m) 5'6" (1.68m)

3
Installation Bradley TouchTime™Individual Built-In Wall Shower with Concealed Supplies
Bradley • 215-1152 Rev. E; ECN 13-03-022 1/9/2014
Make electrical connections
Complete Installation
1
2
A
B
A
B
C
D
Install a 24 VAC Class II transformer in a
remote location a safe distance from the
shower room. Connect the wire designated
24 VAC to the wire on the transformer.
NOTE: The connectors will only fit into the
transformer wire.
Connect the wire designated SOL-1 to the solenoid valve connectors.
NOTE: The wires can be connected to the solenoid in any order.
Secure the showerhead to the 1/4"-20 wall
anchors (supplied by installer) using the
screws provided.
Secure the pushbutton to the #10 wall
anchors (supplied by installer).
Turn on the water supply to your 1C TT
shower and check for leaking.
Turn on the 24 VAC power to the shower
and press the pushbutton several times to
purge air from the lines.
NOTE: Refer to figure below when making electrical connections
IMPORTANT: DO NOT put the 24 VAC Class II transformer in the shower room. Check local codes and
ordinances for proper location and connection requirements. Conformity to local codes is the
responsibility of the installer.
IMPORTANT: DO NOT turn 24 VAC power on to your shower until installation is complete.
IMPORTANT: Verify that the electrical source to the fixture is 24 VAC.
IMPORTANT: Connection of leads other than shown in figure below may cause permanent damage to
the electrodes.
Solenoid Valve
(the wires can be connected to the
solenoid valve in any order
110/24 VAC
Transformer
(Optional)
Pushbutton
Assembly
Connect either
black or brown
wire to either
terminal
Plug-in
Transformer
(Optional)
SOL-1
wires
24 VAC

4
Bradley TouchTime™Individual Built-In Wall Shower with Concealed Supplies Installation
1/9/2014 Bradley • 215-1152 Rev. E; ECN 13-03-022
Touch Time™Valve Parts List
For service please see service guides 215-1369-20 for solenoid valve and 215-1369-12 for TouchTime valve.
Cleaning Stainless Steel
Material Description: Stainless steel is extremely durable, and maintenance is simple and inexpensive. Proper care,
particularly under corrosive conditions, is essential. Always start with the simplest solution and work your way toward
the more complicated.
Routine cleaning: Daily or as often as needed use a solution of warm water and soap, detergent, or ammonia.
Apply the cleaning solution per the manufactures instructions and always use a soft cloth or sponge to avoid
damaging the finish.
Stubborn Stains: To remove stains from stainless steel use a stainless steel cleaner and polish such as Ball®
stainless steel cleaner or a soft abrasive. Always follow the manufactures instructions and apply in the same direction
as the polish lines.
IMPORTANT: Never use ordinary steel wool or steel brushes on stainless steel. Always use stainless steel
wool or stainless steel brushes.
Special Situations for Material
Fingerprints and Smears: To remove fingerprints or smears use a high quality stainless steel cleaner and polish in
accordance with the manufactures instructions. Many of these products leave a protective coating the helps prevent
future smears and fingerprints.
Grease and Oil: To remove grease and oil use a quality commercial detergent or caustic cleaner. Apply in
accordance to the manufactures instructions and in the direction of the polish lines.
Precautions: Avoid prolonged contact with chlorides (bleaches, salts), bromides (sanitizing agents), thiocyanates
(pesticides, photography chemicals, and some foods), and iodides on stainless steel equipment, especially if acid
conditions exist.
IMPORTANT: Do not permit salty solutions to dry and evaporate on stainless steel.
The appearance of rust streaks on stainless steel leads to the belief that the stainless steel is rusting. Look for the
actual source of the rust in some iron or steel particles which may be touching, but not actually a part of the stainless
steel structure.
NOTE:Strongly acidic or caustic cleaners may attack the steel causing a reddish film to appear. The use of these
cleaners should be avoided.
Brand Names: Use of brand names is intended only to indicate a type of cleaner. This does not constitute an
endorsement, nor does the omission of any brand name cleaner imply its inadequacy. Many products named are
regional in distribution, and can be found in local supermarkets, department and hardware stores, or through your
cleaning service. It is emphasized that all products should be used in strict accordance with package instructions.
