stellar labs SEA36 User manual
Slow juicer Page 1
Slow Juicer
Instruction Manual
Model No. SEA36
Please read this instruction
manual carefully before use and
retain for future reference.
Unpack your Juicer carefully
and remove temporary packing
pieces, labels and stickers.
www.stellarcookware.co.uk
Slow Juicer
Page 2
1. Juicer Lid (SEA36JL)
2. Feeder Tube
3. Ingredient Pusher (SEA36IP)
4. Juicing Auger (SEA36JA)
5. Strainer (SEA36ST)
6. Rotating Wiper (SEA36RW)
7. Juicing Bowl (SEA36JB)
8. Juicing Bowl Lock
9. Juicer Spout with Cap
10. Pulp Spout
11. Juicer Jugs x2 (SEA36JJ)
12. Base Unit
13. Operator Switch
14. Mains cable and plug
15. Cleaning brush (SEA36CB)
1
2 3
4
5
6
7
9
10
11
12
13
14
15
8
Slow Juicer
Page 3
Disassembly
• Conrm that the Juicer is switched OFF and not connected during disassembly.
1. Remove the Juicer Lid 1by turning anticlockwise to unlock.
2. Lift the Juice Bowl Lock 8and turn anticlockwise to release from the Base
Unit 12
3. Clean all parts, following the instructions for Cleaning .
BEFORE FIRST USE
1. Remove any labels and/or swingtickets.
2. Clean all parts, following the instructions for Cleaning .
ASSEMBLY
• Conrm that the Slow Juicer is switched OFF and not connected during
assembly. Follow the steps below.
1. On the underside of the Juicing Bowl 7ensure the Silicone Plug Ain the
gure below is fully inserted into the Pulp Spout B.
2. Locate the Juicing Bowl 7onto the Base unit 12 (by lining up the 3 lugs) and
turn clockwise until the Juicing Bowl Lock 8clicks into place.
3. Place the Rotating Wiper 6into the Juicing Bowl 7.
4. Place the Strainer 5into the Rotating Wiper 6aligning its’ silver dot • with
the arrow on the outside of the Juicing Bowl 7.
5. Place the Juicing Auger 4into the Strainer 5, ensure it engages with the
gear in the base of the Juicing Bowl 7.
6. Locate the Juicer Lid 1onto the Juicing Bowl 7(by lining up the arrow
indicators) and turn it clockwise to align the interlock arrow Cwith the
Locked Symbol as in the gure below.
UNLOCKED LOCKED
A
B B
C
A
Slow Juicer
Page 4
HOW TO USE
1. Once assembled place the Slow Juicer on a smooth at stable surface. Ensure
that there is at least 10cm clearance all around the Slow Juicer. Ensure the
Slow Juicer is connected to the mains supply.
2. Place the Juicer Jugs 11 under each of the Pulp Spout 10 and Juicer Spout with
Cap 9.
3. Open the cap of the Juicer Spout with Cap 9.
4. Turn on the Slow Juicer by pressing ON on the Operator Switch 13 and simply
add the ingredients into the Feeder Tube 2gently pushing the ingredients
down with the Ingredients Pusher 3.
5. When complete close the Juicer Spout with Cap 9and decant your fresh
juice. Return the empty juicer jug and open the Juicer Spout with Cap 9and
gently pour half a cup of warm water down the Feeder Tube 2.
6. When you have nished juicing, set the Operator Switch 13 to the “0” (off)
position and disconnect the Mains Plug 14 from the mains.
7. If you are not using the juicer for the rest of the day then dissassemble and
clean.
• DO NOT ATTEMPT TO OPEN THE JUICER LID WHILST THE SLOW JUICER IS
RUNNING. IF YOU DO, THE SLOW JUICER WILL STOP AUTOMATICALLY.
HINTS
• The best results are obtained when using young and particularly fresh
vegetables and fruits. In general, the softer the vegetable and riper the fruit,
the thicker and less clear the juice will be.
• Wash fruits and vegetables and dry them well.
• Roll leafy vegetables into clumps.
• When making a mixed drink from more than one ingredient, use the softer
ingredients rst, then the harder ones.
• Vitamins disappear quickly after extraction of the juice, which should
therefore be consumed as soon as possible.
• Apple juice turns brown rapidly. A few drops of lemon juice will keep it from
turning brown too quickly.
• The residue pulp can be used as a base for soups, sauces, jams, and desserts.
• Fruits that are rich in starch such as avocado, bananas, coconut, gs and
papaya are not suitable for the Slow Juicer.
• Do not operate continuously for more than 20 minutes to avoid overheating.
After each use, allow the Juicer to cool for 5 minutes.
• If the Slow Juicer becomes clogged and stops the Operator Switch has a
reverse function ‘R’ and should be operated to clear the obstruction. If this
fails dissasemble and clean following the Cleaning instructions.
• Prompt cleaning makes a world of difference. Fresh juice and pulp will easily
wash away with a brush and warm water. However, juice and pulp that is
allowed to dry will become “glued” to the walls and be much more difcult to
remove.
Slow Juicer
Page 5
CLEANING
1. Wash all items except the Base Unit 12 in a solution of liquid detergent and
warm water, using the Cleaning Brush 15 as necessary, then rinse and dry
thoroughly.
• All the items except the Base Unit 12 can also be cleaned in a dishwasher.
2. Wipe to clean the Motor Housing 6using a cloth, slightly dampened with
liquid detergent and warm water. Dry thoroughly.
• DO NOT IMMERSE ANY PART OF THE BASE UNIT IN WATER.
• Do not use harsh abrasive cleaners, steel wool scourers or metal implements.
CAUTIONS
• Check that the electrical supply ratings of the appliance are correct for your
home (see Specications).
• The appliance must be connected via a mains socket, which should have an
individually rated load of above 10A. Ensure that the plug is fully inserted.
• Do not insert plug with wet hands.
• This appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities or lack of experience or
knowledge, unless they have been given supervision or instruction concerning
use of the appliance by a person responsible for their safety.
• This appliance is not intended to be operated by means of an external timer or
a separate remote-control system.
• Always keep the appliance out of the reach of children.
• Do not place the appliance near a hot gas or electric burner.
• The appliance should be placed on a level stable worktop at least 10cm from
walls or other solid obstructions.
• Do not use the appliance on a carpet or tablecloth.
• Do not move the appliance whilst in operation.
• Do not put ngers or other objects into Juicer openings while it is in operation.
• Do not use the appliance if the Strainer 5is damaged.
• The appliance incorporates a safety interlock to prevent operation until
the locking tab is in position. Do not attempt to use the appliance unless
assembled.
• Never move the appliance by pulling the Mains Cable 14 .
• Ensure that the Mains Cable 14 does not trail over the edge of the worktop,
is positioned where it cannot be accidentally pulled or snagged, and that it is
kept away from any hot object.
• Never use the appliance when it shows damage (including to the power cable)
or does not function properly; contact STELLAR at the address given. Do not
attempt to repair the appliance yourself.
• Use the appliance only for its intended purpose.
Slow Juicer
Page 6
SPECIFICATIONS
• Power Supply: 220V-240V 50H/60z
• Wattage: 100W
AFTER SALES SERVICE
Do not attempt to repair any part of this appliance. Please refer any problem to
STELLAR Customer Services.
WARRANTY
The STELLAR warranty covers the product to be free of defects in materials
and workmanship for period of two years from the date of original retail
purchase. During this period, STELLAR will, at our option, repair or replace
defective parts of the product, or replace the product, providing the Use Care &
Safety Instructions have been followed. The warranty does not cover damage,
defect or failure caused by or resulting from accidents, external damage,
alteration, modication, abuse, misuse or misapplication. The appliance is for
Domestic Use only. The warranty does not cover any damage caused by taking
the appliance apart yourself, or attempting to repair the appliance yourself.
Please keep your purchase receipt and contact us directly if you encounter any
problems with your product.
STELLAR CUSTOMER SERVICES
HORWOOD
AVONMOUTH WAY
BRISTOL
BS11 9HX
GREAT BRITAIN
customerservice@horwood.co.uk
Tel: 0117 940 0000
www.stellarcookware.co.uk
HORWOOD SHALL NOT BE LIABLE FOR INCIDENTAL OR CONSEQUENTIAL
DAMAGES RESULTING FROM THE USE OF THIS PRODUCT (INCLUDING
COLOUR FADING, SCRATCHES OR ACCUMULATED DIRT THROUGH
COMMERCIAL USE) WITHOUT FOLLOWING THE USE, CARE
& SAFETY ADVICE.
FOR DOMESTIC USE ONLY
CORRECT DISPOSAL OF THIS PRODUCT
This marking indicates that this product should not be disposed with other household wastes throughout
the EU. To prevent possible harm to the environment or human health from uncontrolled waste disposal,
recycle it responsibly to promote the sustainable reuse of material resources. To return your used device,
please use the return and collection systems or contact the retailer where the product was purchased.
They can take this product for environmentally safe recycling.
