Step Technica CUB-43PCI1 User manual

～ Read Me First ～
CUB-43PCI1 Setup Guide
■ Please check the bundled items.
Make sure that there is an accessory attached with the product.
● Interface board (with Low prole bracket)・・・1 pc
■ How to download the device driver and CUeditor43J_PCI
＊Do not touch the terminal contacts with your hands. It may cause the malfunction.
Terminal contact ＊
CUB-43PCI1
1
Download the device driver and CUeditor43J_PCI from StepTechnica website.
URL：https://www.steptechnica.com/en/download/index.html

2
1. Driver installation
■ Driver can be manually installed from downloaded driver le.
The conguration of downloaded driver le is shown in the table below.
Select the driver installer to execute according to your PC system environment.
This document describes how to install driver to 64-bit version of Windows 10.
①. Power-on PC, start Windows, and log on as an Administrator.
②. Execute "dpinst_x64" in "Driver_V1000 ＼ Win10 ＼ x64". Select 'Yes (Y)' in
the user account control dialog box.
③. Select 'Next (N)' in the driver installation dialog box.
④. Select 'Finish' in the next dialog box.
OS Driver installer storage location
Windows 7/ 8/ 8.1 64-bit version Driver_V1000\Win7_Win8.1\x64\dpinst_x64.exe
Windows 7/ 8/ 8.1 32-bit version Driver_V1000\Win7_Win8.1\x86\dpinst_x86.exe
Windows 10 64-bit version Driver_V1000\Win10\x64\dpinst_x64.exe
Windows 10 32-bit version Driver_V1000\Win10\x86\dpinst_x86.exe

3
2. Hardware installation
■ For how to put-on or remove a PC side panel and insert a PCI card to the PC slot, refer to your PC manual.
①. Power-o󱐯 the PC.
②. Remove all cables connected to the PC.
③. Remove the PC side panel.
(Refer to the PC manual for how to remove the side panel.)
④. The board is to be inserted to PCI slot,
so remove the cover of the slot to
insert.
(Refer to the PC manual for how to
remove the slot cover.)
⑤. Insert the board to PCI slot rmly.
(When using the PC with Low prole
slot, change the bracket to attached
one.)
⑥. Fix the bracket using the screw
attached with the PC.
⑦. Close the PC side panel in the reverse order of step 3.
⑧. Connect all cables removed in step 2.
(Do not connect the cable to this PCI connector.)

4
3. Check that the PCI card is correctly installed
Open 'Device Manager' rst to check the card has been correctly installed.
For Windows 10
①. Press 'Windows' and 'X' key to display
'Device Manager(M)' and click it.
②. Device Manager is displayed.
Select and double-click 'CUB Devices'
to show the devices listed in the
context menu and check 'CUB43PCI1
Device' is in the list.

5
For Windows 8 / 8.1
①. Press 'Windows' and 'X' key to display
'Device Manager(M)' and click it.
②. Device Manager is displayed.
Select and double-click 'CUnet
Devices' to show the devices listed
in the context menu and check
'CUB43PCI1 Device' is in the list.
For Windows 7
Open 'Device Manager' from the
'control panel'.
Select and double-click 'CUnet
Devices' to show the devices listed
in the context menu and check
'CUB43PCI1 Device' is in the list.

6
4. How to install CUeditor43J for CUB-43PCI1 editor software
■ Driver can be manually installed from downloaded CUeditor43J folder.
①. Execute 'setup.exe' in 'CUeditor43J'.
Select 'Yes' in the user account control dialog box.
②. Select 'OK' in 'CUeditor MKY43 PCI Setup' dialog box to continue.
③. Specify the install location of CUeditor MKY43 PCI.
Click 'Change Directory' to change the install location.
Click thick-squared button to start installation.

7
⑤. Click 'Continue' in 'CUeditor MKY43PCI - Choose Program Group' dialog box to
continue.
⑥. Click 'OK' button when the setup dialog box is displayed to nish the driver
installation.

8
Safety Precautions
Manufactured by : StepTechnica Co., Ltd.
Issued : May 2019
Document No：STD_CUB43PCI1SU_V1.0E
Warnings / Cautions
Contact
Visit our website or e-mail to StepTechnica's engineer.
Website E-mail to engineer
https://www.steptechnica.com/en/contact/index.html E-mail : [email protected]
O󱐰ce hour 9:00am to 5:30pm (Weekdays)
Product Specications
Item Description
CUnet device MKY43 × 1 pc
CUnet communication method Half-duplex
CUnet communication rate 12M/6M/3Mbps (Set in MKY43 register)
CUnet communication connector RJ45 type (8pin modular) × 2 pcs
Supported bus Based on PCI Ver 2.2, 32-bit, 33MHz expansion bus, 5.0V/3.3V supported
Owned resource 16KB serial memory area（ Automatically allocated by PnP）
Interrupt 1 line used（ Automatically allocated by PnP)
Supported OS
Windows10
Windows8.1
Windows8
Windows7
（64bit/32bit）
（64bit/32bit）
（64bit/32bit）
（64bit/32bit）
Power supply DC +5.0V
Consumption current 500mA or lower
Operating conditions Temperature 0 to 50℃ Humidity 20 to 90%（With no condensation）
Storage conditions Temperature 0 to 80℃ Humidity 0 to 90%（With no condensation）
Size 119.9mm(W) × 64.4mm(H) ※ Not including a panel (Low Prole supported)
Accessory Low prole bracket
