Sterling Trucks L7500 User manual

L-LINE AND A-LINE MAINTENANCE MANUAL
Models: L7500
L7501
L8500
L8511
L8513
L9500
L9501
L9511
L9513
L9522
A9500
A9522
STI-383-1 (10/08P) Published by
Daimler Trucks North America LLC
4747 N. Channel Ave.
Portland, OR 97217
Printed in U.S.A.
https://www.besttruckmanuals.com/

Foreword
Scheduled maintenance provides a key element for the safe operation of your vehicle. A proper
maintenance program also helps to minimize downtime and to safeguard warranties. This
maintenance manual provides information necessary for years of safe, reliable, and cost-efficient
vehicle operation.
IMPORTANT: The maintenance operations in this manual are not all-inclusive. Also
refer to other component and body manufacturers’ instructions for specific inspection
and maintenance instructions.
Perform the operations in this maintenance manual at scheduled intervals. Perform the pretrip
and post-trip inspections, and daily/weekly/monthly maintenance, as outlined in the vehicle
driver’s manual. Major components, such as engines, transmissions, and rear axles, are covered
in their own maintenance and operation manuals, that are provided with the vehicle. Perform any
maintenance operations listed at the intervals scheduled in those manuals. Your Sterling
Dealership has the qualified technicians and equipment to perform this maintenance for you.
They can also set up a scheduled maintenance program tailored specifically to your needs.
Optionally, they can assist you in learning how to perform these maintenance procedures.
IMPORTANT: Descriptions and specifications in this manual were in effect at the time of
printing. Daimler Trucks North America LLC reserves the right to discontinue models
and to change specifications or design at any time without notice and without incurring
obligation. Descriptions and specifications contained in this publication provide no
warranty, expressed or implied, and are subject to revision and editions without notice.
Refer to www.Daimler-TrucksNorthAmerica.com and www.SterlingTrucks.com for more informa-
tion, or contact Daimler Trucks North America LLC at the address below.
Environmental Concerns and Recommendations
Whenever you see instructions in this manual to discard materials, you should attempt to reclaim
and recycle them. To preserve our environment, follow appropriate environmental rules and
regulations when disposing of materials.
NOTICE: Parts Replacement Considerations
Do not replace suspension, axle, or steering parts (such as springs, wheels, hubs, and steering
gears) with used parts. Used parts may have been subjected to collisions or improper use and
have undetected structural damage.
© 1998–2008 Daimler Trucks North America LLC
All rights reserved. No part of this publication, in whole or in part, may be translated, reproduced,
stored in a retrieval system, or transmitted in any form by any means, electronic, mechanical,
photocopying, recording, or otherwise, without the prior written permission of Daimler Trucks
North America LLC. Daimler Trucks North America LLC is a Daimler company.
Daimler Trucks North America LLC
Service Systems and Documentation (POC-SSD)
P.O. Box 3849
Portland, OR 97208–3849
https://www.besttruckmanuals.com/

Daimler Trucks North America LLC distributes the following major service publications in paper and electronic
(via ServicePro®) formats.
Workshop/Service
Manual Workshop/service manuals contain service and repair information for all vehicle systems and components, except for major components such as engines, trans-
missions, and rear axles. Each workshop/service manual section is divided into
subjects that can include general information, principles of operation, removal,
disassembly, assembly, installation, and specifications.
Maintenance Manual Maintenance manuals contain routine maintenance procedures and intervals for
vehicle components and systems. They have information such as lubrication
procedures and tables, fluid replacement procedures, fluid capacities, specifica-
tions, and procedures for adjustments and for checking the tightness of fasten-
ers. Maintenance manuals do not contain detailed repair or service information.
Driver’s/Operator’s
Manual Driver’s/operator’s manuals contain information needed to enhance the driver’s understanding of how to operate and care for the vehicle and its components.
Each manual contains a chapter that covers pretrip and post-trip inspections,
and daily, weekly, and monthly maintenance of vehicle components.
Driver’s/operator’s manuals do not contain detailed repair or service information.
Service Bulletins Service bulletins provide the latest service tips, field repairs, product improve-
ments, and related information. Some service bulletins are updates to informa-
tion in the workshop/service manual. These bulletins take precedence over
workshop/service manual information, until the latter is updated; at that time, the
bulletin is usually canceled. The service bulletins manual is available only to
dealers. When doing service work on a vehicle system or part, check for a valid
service bulletin for the latest information on the subject.
IMPORTANT: Before using a particular service bulletin, check the current
service bulletin validity list to be sure the bulletin is valid.
Parts Technical Bulletins Parts technical bulletins provide information on parts. These bulletins contain
lists of parts and BOMs needed to do replacement and upgrade procedures.
Web-based repair, service, and parts documentation can be accessed using the following applications on the
AccessSterling.com website.
ServicePro ServicePro®provides Web-based access to the most up-to-date versions of the
publications listed above. In addition, the Service Solutions feature provides di-
agnostic assistance with Symptoms Search, by connecting to a large knowledge
base gathered from technicians and service personnel. Search results for both
documents and service solutions can be narrowed by initially entering vehicle
identification data.
PartsPro PartsPro®is an electronic parts catalog system, showing the specified vehicle’s
build record.
EZWiring EZWiring™makes Sterling, Freightliner, Freightliner Custom Chassis Corpora-
tion, Thomas Built Buses, and Western Star products’ wiring drawings and float-
ing pin lists available online for viewing and printing. EZWiring can also be ac-
cessed from within PartsPro.
Introduction
Descriptions of Service Publications
L-Line and A-Line Maintenance Manual, October 2008 I–1
https://www.besttruckmanuals.com/

Warranty-related service information available on the AccessSterling.com website includes the following docu-
mentation.
Recall Campaigns Recall campaigns cover situations that involve service work or replacement of
parts in connection with a recall notice. These campaigns pertain to matters of
vehicle safety. All recall campaigns are distributed to dealers; customers receive
notices that apply to their vehicles.
Field Service Campaigns Field service campaigns are concerned with non-safety-related service work or
replacement of parts. All field service campaigns are distributed to dealers; cus-
tomers receive notices that apply to their vehicles.
Introduction Descriptions of Service Publications
I–2 L-Line and A-Line Maintenance Manual, October 2008
https://www.besttruckmanuals.com/

For an example of an L-Line and A-Line Maintenance Manual page, see Fig. 1.
08/25/98 f020080
ABC
DE
A. Maintenance Operation Number consists of the Group Number followed by the Sequence Number
B. Group Title
C. Group Number
D. Release Date
E. Group Number/Page Number
Fig. 1, Example of an L-Line and A-Line Maintenance Manual Page
Introduction
Page Description
L-Line and A-Line Maintenance Manual, October 2008 I–3
https://www.besttruckmanuals.com/

Group No. Group Title
00...................... General Information
01................................ Engine
09.............................. AirIntake
13......................... AirCompressor
15................... Alternators and Starters
20................... Engine Cooling/Radiator
25................................ Clutch
26........................... Transmission
31 ................... Frame and Fifth Wheel
32............................ Suspension
33............................. Front Axle
35 ............................. Rear Axle
40........................ Wheels and Tires
41.............................. Driveline
42................................ Brakes
46............................... Steering
47 ................................. Fuel
49............................... Exhaust
54.......... Electrical, Instruments, and Controls
72................................ Doors
83................. Heater and Air Conditioner
88.............. Hood, Grille, and Cab Fenders
Introduction Maintenance Manual Contents
I–4 L-Line and A-Line Maintenance Manual, October 2008
https://www.besttruckmanuals.com/

Title of Maintenance Operation (MOP) MOP Number
Determining Scheduled Maintenance Intervals.............................................00–01
Initial Maintenance (IM) Operations.....................................................00–06
Lubrication and Fluid Level Check ..................................................... 00–04
M1 Maintenance Interval Operations Table ...............................................00–07
M2 Maintenance Interval Operations Table ...............................................00–08
M3 Maintenance Interval Operations Table ...............................................00–09
M4 Maintenance Interval Operations Table ...............................................00–10
Maintenance Operation Sets Table.....................................................00–05
Maintenance Service Table...........................................................00–02
Metric/U.S. Customary Conversion Tables................................................00–13
Noise Emission Controls Maintenance...................................................00–11
Torque Specifications Tables..........................................................00–14
Vehicle Maintenance Schedule Tables...................................................00–03
Verification of Inspections Log.........................................................00–12
General Information 00
Index, Alphabetical
L-Line and A-Line Maintenance Manual, January 2007
https://www.besttruckmanuals.com/

Determining Scheduled
Maintenance Intervals
Performing regular maintenance on your Sterling ve-
hicle will help ensure that your Sterling vehicle deliv-
ers safe reliable service and optimum performance
for years to come. Failure to follow a regular mainte-
nance program can result in inefficient operation and
unscheduled down time.
To determine the correct maintenance intervals for
your vehicle you must first determine the type of ser-
vice or conditions the vehicle will be operating in.
Generally, most vehicles operate under conditions
that fall within one of the three types of service de-
scribed. Before placing your new vehicle in service,
determine the type of service (Service Schedule I, II,
or III) that applies to the intended use of the vehicle.
After determining the vehicle’s type of service, refer
to the service schedule table or the vehicle mainte-
nance schedule table, to determine how often main-
tenance should be performed.
When the vehicle reaches the distance given for a
maintenance interval, see the "Maintenance Interval
Operations Table" for a list of the maintenance op-
erations to be performed at that maintenance inter-
val. Use the maintenance operation reference num-
bers to find detailed instructions in the manual on
each operation.
Types of Service
Service Schedule I (severe service) applies to ve-
hicles that annually travel less than 6000 miles (10
000 kilometers)
or that operate under severe condi-
tions. Examples of Schedule I (severe service) usage
include: operation on extremely poor roads or where
there is heavy dust accumulation; constant exposure
to extreme hot, cold, salt-air, or other extreme cli-
mates; frequent short-distance travel; construction-
site operation; city operation (fire truck); or farm
operation.
Service Schedule II (short-haul transport) applies to
vehicles that annually travel less than 60,000 miles
(100 000 kilometers) and operate under normal con-
ditions. Examples of Schedule II (short-haul trans-
port) usage are: operation primarily in cities and
densely populated areas; local transport with infre-
quent freeway travel; or high percentage of stop-
and-go travel.
Service Schedule III (long-haul transport) is for ve-
hicles that annually travel
more than 60,000 miles
(100 000 kilometers) with minimal city or stop-and-go
operation. Examples of Schedule III (long-haul trans-
port) usage are: regional delivery that is mostly free-
way miles; interstate transport; or any road operation
with high annual mileage.
NOTE: Maintenance instructions in this manual
are based on average vehicle use and normal
operating conditions. Unusual vehicle operating
conditions may require service at more frequent
intervals.
General Information 00
Determining Scheduled Maintenance Intervals: 00–01
L-Line and A-Line Maintenance Manual, January 2007 00/1
https://www.besttruckmanuals.com/

Maintenance Service Table
Service Schedule Maintenance Interval
Operation Maintenance Intervals
Frequency Miles km Hours
Schedule I*— (severe service) vehicles
that annually travel up to 6000 miles
(10 000 km)
Initial Maintenance (IM) first 1000 1600 100
Maintenance 1 (M1) every 1000 1600 100
Maintenance 2 (M2) every 5000 8000 500
Maintenance 3 (M3) every 10,000 16 000 1000
Maintenance 4 (M4) every 20,000 32 000 2000
Schedule II†— (short-haul transport)
vehicles that annually travel up to
60,000 miles (100 000 km)
Initial Maintenance (IM) first 9500 15 000
—
Maintenance 1 (M1) every 9500 15 000
Maintenance 2 (M2) every 37,500 60 000
Maintenance 3 (M3) every 75,000 120 000
Maintenance 4 (M4) every 150,000 240 000
Schedule III†— (long-haul transport)
vehicles that annually travel over
60,000 miles (100 000 km)
Initial Maintenance (IM) first 12,500 20 000
—
Maintenance 1 (M1) every 12,500 20 000
Maintenance 2 (M2) every 50,000 80 000
Maintenance 3 (M3) every 100,000 160 000
Maintenance 4 (M4) every 300,000 480 000
*For Schedule I (severe service) vehicles equipped with an hourmeter, use maintenance intervals based on hours of operation rather than distance traveled.
†Use Schedule I (severe service) maintenance intervals for vehicles that operate under severe conditions, such as extremely poor roads, heavy dust accumu-
lation, extreme climate, frequent short distance travel, construction-site operation, city operation (garbage truck), or farm operation.
Table 1, Maintenance Service Table
General Information00
Maintenance Service Table: 00–02
L-Line and A-Line Maintenance Manual, January 200700/2
https://www.besttruckmanuals.com/

1st through 35th Vehicle Maintenance Intervals for Service Schedule I
Maint.
Number Required Maintenance Operation Interval Service Date Service I
Miles km Hours
1st Initial Maintenance (IM) and M1 1000 1600 100
2nd M1 2000 3200 200
3rd M1 3000 4800 300
4th M1 4000 6400 400
5th M1 and M2 5000 8000 500
6th M1 6000 9600 600
7th M1 7000 11 200 700
8th M1 8000 12 800 800
9th M1 9000 14 400 900
10th M1, M2 and M3 10,000 16 000 1000
11th M1 11,000 17 600 1100
12th M1 12,000 19 200 1200
13th M1 13,000 20 800 1300
14th M1 14,000 22 400 1400
15th M1 and M2 15,000 24 000 1500
16th M1 16,000 25 600 1600
17th M1 17,000 27 200 1700
18th M1 18,000 28 800 1800
19th M1 19,000 30 400 1900
20th M1, M2, M3 and M4 20,000 32 000 2000
21st M1 21,000 33 600 2000
22nd M1 22,000 35 200 2200
23rd M1 23,000 36 800 2300
24th M1 24,000 38 400 2400
25th M1 and M2 25,000 40 000 2500
26th M1 26,000 41 600 2600
27th M1 27,000 43 200 2700
28th M1 28,000 44 800 2800
29th M1 29,000 46 400 2900
30th M1, M2 and M3 30,000 48 000 3000
31st M1 31,000 49 600 3100
32nd M1 32,000 51 200 3200
33rd M1 33,000 52 800 3300
34th M1 34,000 54 400 3400
General Information 00
Vehicle Maintenance Schedule Tables: 00–03
L-Line and A-Line Maintenance Manual, January 2007 00/3
https://www.besttruckmanuals.com/

1st through 35th Vehicle Maintenance Intervals for Service Schedule I
Maint.
Number Required Maintenance Operation Interval Service Date Service I
Miles km Hours
35th M1 and M2 35,000 56 000 3500
Table 2, 1st through 35th Vehicle Maintenance Intervals for Service Schedule I
36th through 70th Vehicle Maintenance Intervals for Service Schedule I
Maint.
Number Required Maintenance Operation Interval Service Date Service I
Miles km Hours
36th M1 36,000 57 600 3600
37th M1 37,000 59 200 3700
38th M1 38,000 60 800 3800
39th M1 39,000 62 400 3900
40th M1, M2, M3 and M4 40,000 64 000 4000
41st M1 41,000 65 600 4100
42nd M1 42,000 67 200 4200
43rd M1 43,000 68 800 4300
44th M1 44,000 70 400 4400
45th M1 and M2 45,000 72 000 4500
46th M1 46,000 73 600 4600
47th M1 47,000 75 200 4700
48th M1 48,000 76 800 4800
49th M1 49,000 78 400 4900
50th M1, M2 and M3 50,000 80 000 5000
51st M1 51,000 82 000 5100
52nd M1 52,000 83 700 5200
53rd M1 53,000 85 300 5300
54th M1 54,000 86 900 5400
55th M1 and M2 55,000 88 500 5500
56th M1 56,000 90 100 5600
57th M1 57,000 91 700 5700
58th M1 58,000 93 300 5800
59th M1 59,000 94 900 5900
60th M1, M2, M3 and M4 60,000 96 500 6000
61st M1 61,000 98 200 6100
62nd M1 62,000 99 800 6200
63rd M1 63,000 101 400 6300
64th M1 64,000 103 000 6400
General Information00
Vehicle Maintenance Schedule Tables: 00–03
L-Line and A-Line Maintenance Manual, January 200700/4
https://www.besttruckmanuals.com/

36th through 70th Vehicle Maintenance Intervals for Service Schedule I
Maint.
Number Required Maintenance Operation Interval Service Date Service I
Miles km Hours
65th M1 and M2 65,000 104 600 6500
66th M1 66,000 106 200 6600
67th M1 67,000 107 800 6700
68th M1 68,000 109 400 6800
69th M1 69,000 111 000 6900
70th M1, M2 and M3 70,000 112 700 7000
Table 3, 36th through 70th Vehicle Maintenance Intervals for Service Schedule I
71st through 100th Vehicle Maintenance Intervals for Service Schedule I
Maint.
Number Required Maintenance Operation Interval Service Date Service I
Miles km Hours
71st M1 71,000 114 300 7100
72nd M1 72,000 115 900 7200
73rd M1 73,000 117 500 7300
74th M1 74,000 119 100 7400
75th M1 and M2 75,000 120 700 7500
76th M1 76,000 122 300 7600
77th M1 77,000 123 900 7700
78th M1 78,000 125 500 7800
79th M1 79,000 127 100 7900
80th M1, M2, M3 and M4 80,000 128 700 8000
81st M1 81,000 130 400 8100
82nd M1 82,000 132 000 8200
83rd M1 83,000 134 000 8300
84th M1 84,000 135 200 8400
85th M1 and M2 85,000 137 000 8500
86th M1 86,000 138 400 8600
87th M1 87,000 140 000 8700
88th M1 88,000 141 600 8800
89th M1 89,000 143 200 8900
90th M1, M2 and M3 90,000 144 800 9000
91st M1 91,000 146 500 9100
92nd M1 92,000 148 100 9200
93rd M1 93,000 150 000 9300
94th M1 94,000 151 300 9400
General Information 00
Vehicle Maintenance Schedule Tables: 00–03
L-Line and A-Line Maintenance Manual, January 2007 00/5
https://www.besttruckmanuals.com/

71st through 100th Vehicle Maintenance Intervals for Service Schedule I
Maint.
Number Required Maintenance Operation Interval Service Date Service I
Miles km Hours
95th M1 and M2 95,000 153 000 9500
96th M1 96,000 155 000 9600
97th M1 97,000 156 100 9700
98th M1 98,000 157 700 9800
99th M1 99,000 159 300 9900
100th M1, M2, M3 and M4 100,000 160 900 10 000
Table 4, 71st through 100th Vehicle Maintenance Intervals for Service Schedule I
Vehicle Maintenance Intervals for Service Schedule II
Maint.
Number Required Maintenance Operation Interval Service Date Miles km
1st Initial Maintenance (IM) and M1 10,000 16 000
2nd M1 19,000 30 000
3rd M1 28,000 45 000
4th M1 and M2 38,000 60 000
5th M1 47,000 75 000
6th M1 56,000 90 000
7th M1 66,000 105 000
8th M1, M2 and M3 75,000 120 000
9th M1 84,000 135 000
10th M1 94,000 150 000
11th M1 103,000 165 000
12th M1 and M2 112,000 180 000
13th M1 122,000 195 000
14th M1 131,000 210 000
15th M1 141,000 225 000
16th M1, M2, M3 and M4 150,000 240 000
Table 5, Vehicle Maintenance Intervals for Service Schedule II
Vehicle Maintenance Intervals for Service Schedule III
Maint.
Number Required Maintenance Operation Interval Service Date Miles km
1st Initial Maintenance (IM) and M1 12,500 20 000
2nd M1 25,000 40 000
3rd M1 37,000 60 000
4th M1 and M2 50,000 80 000
General Information00
Vehicle Maintenance Schedule Tables: 00–03
L-Line and A-Line Maintenance Manual, January 200700/6
https://www.besttruckmanuals.com/

Vehicle Maintenance Intervals for Service Schedule III
Maint.
Number Required Maintenance Operation Interval Service Date Miles km
5th M1 62,000 100 000
6th M1 75,000 120 000
7th M1 87,000 140 000
8th M1, M2 and M3 100,000 160 000
9th M1 112,000 180 000
10th M1 125,000 200 000
11th M1 137,000 220 000
12th M1 and M2 150,000 240 000
13th M1 162,000 260 000
14th M1 175,000 280 000
15th M1 187,000 300 000
16th M1, M2 and M3 200,000 320 000
17th M1 212,000 340 000
18th M1 225,000 360 000
19th M1 237,000 380 000
20th M1 and M2 250,000 400 000
21st M1 262,000 420 000
22nd M1 275,000 440 000
23rd M1 287,000 460 000
24th M1, M2, M3 and M4 300,000 480 000
Table 6, Vehicle Maintenance Intervals for Service Schedule III
General Information 00
Vehicle Maintenance Schedule Tables: 00–03
L-Line and A-Line Maintenance Manual, January 2007 00/7
https://www.besttruckmanuals.com/

Table 7 summarizes all operations that must be per-
formed to complete lubrication and fluid level checks
in the M1 maintenance interval for all service sched-
ules.
Maintenance operation numbers given in the table
are reference numbers used to help you find detailed
instructions in the manual on the lubrication or fluid
check.
M1 Maintenance Operation 00–04, Lubrication and Fluid Level Check for Service Schedules I, II, and III
Maintenance
Operation
Number Operation Description Check
25–01 Clutch Release Bearing Lubricating
26–04 Transmission Breather and Oil Level Checking
31–02 Fifth Wheel Lubricating
31–05 Trailer Electrical Connector Lubricating
32–02 Suspension Lubricating
33–01 Knuckle Pin Lubricating
33–02 Tie-Rod End Inspecting and Lubricating
35–01 Axle Breather and Lubricant Level Checking
41–02 Driveline Lubricating
42–02 Automatic Slack Adjuster Lubricating and Checking
46–01 Steering Driveline Lubricating
46–02 Drag Link and Power Steering Cylinder Lubricating
46–03 Power Steering Reservoir Fluid Level Checking
46–05 TRW Power Steering Gear Lubricating, TAS Series
72–01 Door Latch and Door Hinge Lubricating
88–01 Hood Hinge Bushing Lubricating
Table 7, M1 Maintenance Operation 00-04, Lubrication and Fluid Level Check for Service Schedules I, II, and III
General Information00
Lubrication and Fluid Level Check: 00–04
L-Line and A-Line Maintenance Manual, January 200700/8
https://www.besttruckmanuals.com/

IMPORTANT: At each maintenance operation set, in
addition to the maintenance operations listed in this
table, perform all daily, weekly, and monthly mainte-
nance operations listed in Chapter 11, "Pretrip and
Post-Trip Inspections and Maintenance" of the
L-Line and A-Line Driver’s Manual .
The "Maintenance Operation Number" is a reference
number matching the text in this manual which pro-
vides detailed instructions on the maintenance opera-
tions to be performed.
NOTE: Maintenance operations appearing in italics in
this table are for noise emission control components.
Maintenance Operation Sets
Maintenance
Operation
Number Operation Description Maintenance Interval
IM M1 M2 M3 M4
01–01
Engine Rear-Support Assembly Checking ••
01–02
Engine Noise Panel Inspecting ••
01–03 Jacobs Engine Brake Wiring Inspecting • • •
01–04 Engine Drive Belt Inspecting ••
09–01 Air Cleaner Element Inspecting and Replacing • •
13–01 Bendix Air Compressor Inspecting • • • •
15–01 Alternator, Battery, and Starter Checking • • •
20–01 Radiator Cap Checking •••
20–02 Radiator Pressure Flushing and Coolant Changing •
20–03
Fan Drive and Clutch Checking •••
25–01 Clutch Release Bearing Lubricating • • • •
26–01 Allison Transmission Fluid and Filter Changing •
26–02 Manual Transmission Magnetic Plug Cleaning and Oil Changing • • • •
26–03 Transmission Air Filter/Regulator Checking, and Cleaning or Replacing • • •
26–04 Transmission Breather and Oil Level Checking • • • •
31–01 Fifth Wheel Inspecting • • • •
31–02 Fifth Wheel Lubricating • • • •
31–03 Frame Fastener Torque Checking •
31–04 Holland Fifth Wheel Sliding Mechanism Inspecting • • •
31–05 Trailer Electrical Connector Lubricating •••••
32–01 Suspension Inspecting •••••
32–02 Suspension Lubricating •••••
32–03 Suspension U-Bolt Torque Checking • • •
33–01 Knuckle Pin Lubricating • • • •
33–02 Tie-Rod End Inspecting and Lubricating • • • •
33–03 All-Axle Alignment Checking •
35–01 Axle Breather and Lubricant Level Checking • • • •
35–02 Axle Lubricant Changing, Oil Filter Replacing, and Magnetic Strainer Cleaning • • •
General Information 00
Maintenance Operation Sets Table: 00–05
L-Line and A-Line Maintenance Manual, January 2007 00/9
https://www.besttruckmanuals.com/

Maintenance Operation Sets
Maintenance
Operation
Number Operation Description Maintenance Interval
IM M1 M2 M3 M4
40–01 Wheel Nut and Rim Nut Checking • • •
41–01 Driveline Inspecting •••••
41–02 Driveline Lubricating •••••
42–01 Camshaft Bracket Bushing Lubricating • • •
42–02 Automatic Slack Adjuster Lubricating and Checking • • • •
42–03 Bendix Air Dryer Checking (AD–IP or AD–9) • •
42–04 Bendix Air Dryer Desiccant Replacing (AD–9) •
42–05 Bendix Air Brake Valve Operation Checking (BP–R1 and E–12) • •
42–06 Bendix Air Brake Valve Disassembly, Cleaning, and Inspecting (Double Check
Valve, E–12, MV–3, PP–7, QR–1, SR–1, ST–3, TC–6, TP–5, TR–3) ••
42–07 Bendix Air Brake Valve Disassembly, Cleaning, Inspecting, and Lubricating (DV–2
and Single Check Valve) •••
42–08 Bendix Air Brake Valve Inspecting and Testing (MV–3 and TC–6) • •
42–09 Bendix Foot Brake Valve Actuator Lubricating and Leak-Testing (E–12) • •
42–10 Brake Inspection •••••
46–01 Steering Driveline Lubricating • • • •
46–02 Drag Link and Power Steering Cylinder Lubricating • • • •
46–03 Power Steering Reservoir Fluid Level Checking • • • •
46–04 Power Steering Reservoir Fluid and Filter Changing • • •
46–05 TRW Power Steering Gear Lubricating, TAS Series • • • •
47–01 Fuel Tank Vent Checking •••
47–02 Fuel Tank Band Nut Tightening •••••
47–03 Fuel Separator Sight Bowl Cleaning and Element Replacing • • •
49–01
Exhaust System Inspecting •••••
54–01 Electrical System Checking • • •
72–01 Door Latch and Door Hinge Lubricating • • • •
83–01 Air Conditioner Inspecting • • •
83–02 Air Filter Replacing*
88–01 Hood Hinge Bushings Lubricating • • • •
*Replace the HVAC filter every 6 months regardless of mileage.
Table 8, Maintenance Operation Sets
General Information00
Maintenance Operation Sets Table: 00–05
L-Line and A-Line Maintenance Manual, January 200700/10
https://www.besttruckmanuals.com/

IMPORTANT: After performing all operations listed in
this table, perform all daily, weekly, and monthly
maintenance operations listed in Chapter 11, "Pre-
trip and Post-Trip Inspections and Maintenance"
of the
L-Line and A-Line Driver’s Manual .
The "Maintenance Operation Number" is a reference
number matching the text in this manual which pro-
vides detailed instructions on the maintenance opera-
tions to be performed.
Initial Maintenance (IM) Operations for Service Schedules I, II, and III
Maintenance
Operation Number Operation Description Check
15–01 Alternator, Battery, and Starter Checking
26–02 Manual Transmission Magnetic Plug Cleaning and Oil Changing
31–03 Frame Fastener Torque Checking
32–01 Suspension Inspecting
32–02 Suspension Lubricating
32–03 Suspension U-Bolt Torque Checking
33–03 All-Axle Alignment Checking
35–02 Axle Lubricant Changing, Oil Filter Replacing, and Magnetic Strainer Cleaning
41–01 Driveline Inspecting
41–02 Driveline Lubricating
47–02 Fuel Tank Band Nut Tightening
54–01 Electrical System Checking
Table 9, Initial Maintenance (IM) Operations for Service Schedules I, II, and III
General Information 00
Initial Maintenance (IM) Operations: 00–06
L-Line and A-Line Maintenance Manual, January 2007 00/11
https://www.besttruckmanuals.com/

The "M1 Maintenance Interval Operations" table lists
all maintenance operations that are to be performed
at the M1 maintenance interval. The "Maintenance
Operation Number" is a reference number matching
the text in this manual that provides detailed instruc-
tions on the maintenance operations to be per-
formed.
IMPORTANT: After performing all operations listed in
this table, perform all daily, weekly, and monthly
maintenance operations listed in Chapter 11, "Pre-
trip and Post-Trip Inspections and Maintenance"
of the
L-Line and A-Line Driver’s Manual .
M1 Maintenance Interval Operations for Service Schedules I, II, and III
Maintenance
Operation Number Operation Description Check
00–04 Lubrication and Fluid Level Check (includes the following):
•Clutch Release Bearing Lubricating
•Transmission Breather and Oil Level Checking
•Fifth Wheel Lubricating
•Trailer Electrical Connector Lubricating
•Suspension Lubricating (Front and Rear)
•Knuckle Pin Lubricating
•Tie-Rod End Inspecting and Lubricating
•Axle Breather and Lubricant Level Checking
•Driveline Lubricating
•Automatic Slack Adjuster Lubricating and Checking
•Steering Driveline Lubricating
•Drag Link and Power Steering Cylinder Lubricating
•Power Steering Reservoir Fluid Level Checking
•TRW Power Steering Gear Lubricating, TAS Series
•Door Latch and Door Hinge Lubricating
•Hood Hinge Bushings Lubricating
13–01 Bendix Air Compressor Inspecting
31–01 Fifth Wheel Inspecting
32–01 Suspension Inspecting
41–01 Driveline Inspecting
42–10 Brake Inspecting
47–02 Fuel Tank Band Nut Tightening
49–01
Exhaust System Inspecting
Table 10, M1 Maintenance Interval Operations for Service Schedules I, II, and III
General Information00
M1 Maintenance Interval Operations Table: 00–07
L-Line and A-Line Maintenance Manual, January 200700/12
https://www.besttruckmanuals.com/

The "M2 Maintenance Interval Operations" table lists
all maintenance operations that are to be performed
at the M2 maintenance interval. The "Maintenance
Operation Number" is a reference number matching
the text in this manual which provides detailed in-
structions on the maintenance operations to be per-
formed. All M1 maintenance interval operations must
be completed before performing M2 maintenance
interval operations.
NOTE: Maintenance operations appearing in italics in
this table are for noise emission control components.
M2 Maintenance Interval Operations for Service Schedules I, II, and III
Maintenance
Operation Number Operation Description Check
00–07 Perform all M1 Operations
01–03 Jacobs Engine Brake Wiring Inspecting
20–01 Radiator Cap Checking
20–03
Fan Drive and Clutch Checking
26–02 Manual Transmission Magnetic Plug Cleaning and Oil Changing
26–03 Transmission Air Filter/Regulator Checking, and Cleaning or Replacing
31–04 Holland Fifth Wheel Sliding Mechanism Inspecting
40–01 Wheel Nut and Rim Nut Checking
42–01 Camshaft Bracket Bushing Lubricating
42–07 Bendix Air Brake Valve Disassembly, Cleaning, Inspecting, and Lubricating (DV–2 and
Single Check Valve)
46–04 Power Steering Reservoir Fluid and Filter Changing
47–01 Fuel Tank Vent Checking
47–03 Fuel Separator Sight Bowl Cleaning and Element Replacing
83–01 Air Conditioner Inspecting
83–02 Air Filter Replacing*
*Replace the HVAC filter every 6 months regardless of mileage.
Table 11, M2 Maintenance Interval Operations for Service Schedules I, II, and III
General Information 00
M2 Maintenance Interval Operations Table: 00–08
L-Line and A-Line Maintenance Manual, January 2007 00/13
https://www.besttruckmanuals.com/
