Stern Engineering Jupiter 2040 Product manual

1
JUPITER 2040
INSTALLATION AND MAINTENANCE GUIDE
ELECTRONIC FLUSH VALVE FOR URINALS

INDEX
OPERATION
Jupiter 2040 is a touch free electronic flush valve for urinal operated by sensor.
Water will start flushing once the user moves away from the urinal.
1 TECHNICAL DATA
2 PACK CONTENTS
3 PRE-INSTALLATION INFO
4-8 INSTALLATION
9 BATTERY REPLACEMENT INSTRUCTIONS
SETTINGS ADJUSTMENT
10-11 ADJUSTING THE SETTINGS WITH A REMOTE CONTROL
12 ADJUSTING THE SENSOR RANGE MANUALLY
13 MAINTENANCE
14 SPARE PARTS LIST
15 WARRANTY
16 TROUBLE-SHOOTING

1
Power supply Jupiter  /  H: internal V alkaline battery
Jupiter  E /  HE: V switching transformer
Operating water pressure: .. bar
Hygiene flush:  hours automatic flush aer last use.
Sensor range:  mm. Factory set. Adjustable manually with
remote control.
Flushing Time: 6 secs. Factory set. Adjustable:  to  secs.
Prior use Flush Mode: Optional feature.
TECHNICAL DATA
JUPITER  H
JUPITER  HE
JUPITER 
JUPITER  E


ØG/”
ØG/”

.
 
NUT G/”


ØG/”
ØG/”

.
 
NUT G/”

2
PACK CONTENTS - JUPITER 2040
1 x Box assembly with
concealed flush valve
Familiarize yourself with the part names and confirm that the parts are included:
1 x Plastic seat for
the cover plate 1 x Wall cover plate with
electronic unit (battery box
included in battery versions)
1 x Mud guard cover
1 x M4x10 Screw
Allen Key
4 x Screws

3
PACK CONTENTS - JUPITER 2040 H
1 x Box assembly with
concealed flush valve
Familiarize yourself with the part names and confirm that the parts are included:
1 x Plastic seat for
the cover plate 1 x Wall cover plate with
electronic unit (battery box
included in battery versions)
1 x Mud guard cover
1 x M4x10 Screw
Allen Key
4 x Screws

4
PRE-INSTALLATION INFO
CHECK CONTENTS
Separate all parts from packaging and check each part with the pack contents section.
Make sure all parts are accounted for before discarding any packaging material. If any
parts are missing, do not attempt to install the electronic flush valve until you obtain
the missing parts.
WARNINGS
Do not install the system facing a mirror or any other electronic system operated by an
infrared sensor.
To prevent reflection problems, it is recommended keep a minimum distance of
1.50 meters between the flush valve and other objects.
PREPARATION FOR INSTALLATION
Flush water supply lines thoroughly before installing the flush valve. Do not allow dirt,
Teflon tape or metal particles to enter the flush valve.
All plumbing is to be installed in accordance with applicable codes and regulations.

5
STEP 1 – INSTALLING THE FLUSH VALVE
1Shut o the water supply.
2
Cut an adequate opening in the
wall for the dimensions of the
box and the corrugated tube
(for E versions, not supplied).
3Insert the electronic flush valve
box through the opening.
4Connect the flush valve inlet to
the water supply.
5
Connect the flush valve outlet
nipple to the pipe leading to the
urinal’s inlet.
INSTALLATION
INLET
OUTLET

6
STEP 1 – INSTALLING THE FLUSH VALVE
6Turn on the water supply. Make
sure there is no leakage.
7
Assemble the mud guard cover
to protect the flush valve.
Note the MIN and MAX marks
on the box.
STEP 2 – CONNECTING THE POWER SOURCE
1
Once the electricity, plumbing
and tile works are nished, cut
the mud guard cover wherever
required by the installation.
INSTALLATION
MIN MAX

7
INSTALLATION
2
If your model is Jupiter ,
assemble the battery box
inside the box and proceed to
clause 4.
3
If your model is Jupiter E,
place the transformer near the
electricity plug and insert the
transformer cable wire through
the box.
OUTLET
4
Assemble the plastic seat for the
wall cover plate using the four
screws provided.

8
STEP 2 – CONNECTING THE POWER SOURCE
5
Connect the electronic unit connectors to the solenoid valve connector
and the power source connector.
STEP 3 – COMPLETING THE INSTALLATION
6
Assemble the panel to
the cover seat and lock it
with the bottom screw.
INSTALLATION

9
INSTALLATION
7Remove the protecting sticker
that covers the sensor.
IMPORTANT: WAIT A FEW SECONDS BEFORE ACTIVATING THE FLUSH VALVE TO
AVOID ENTERING INTO “ADJUSTING MODE”.
8
Move away and the flush valve
will flush a few seconds aer
your departure.
9
If needed adjust the flow
capacity by turning the
regulating valve.
IF THE RANGE IS UNSATISFACTORY, REFER TO THE SECTION ENTITLED
“SETTINGS ADJUSTMENT”

10
BATTERY REPLACEMENT
Battery replacement instructions – Jupiter 2040 only
When the battery weakens, the red indicator light will blink at a constant rate.
The battery must be replaced within two weeks.
To replace the battery:
1
Release the screw at the
bottom of the cover plate and
remove the cover plate.
2
A. Disconnect the water proof
connector between the battery
box and the electronic unit.
B. Pull out the battery box
from the battery box holder
by releasing the bottom clip.
C.
Pull out the battery cover.
3
D. Replace the used battery with
a new V battery (Lithium
battery is recommended).
E. Close the battery box and
slide it back on the battery
holder starting from the
bottom upwards.
F. Connect the connectors.
D E F
4
IMPORTANT: Wait a few seconds
before activating the flush
valve to avoid entering into
“adjusting mode”.
Close the battery compartment
and ret the cover plate.
AB C

11
SETTINGS ADJUSTMENT
WITH REMOTE CONTROL
ADJUSTING THE SETTINGS WITH THE REMOTE CONTROL
If necessary, the sensor settings can be adjusted as following:
Shut o the water supply. In order to adjust the sensor with the remote control,
hold the remote control straight in front of the sensor in a distance of about 6-8”
(15-20cm). Choose the function you want to adjust by pressing once on one of the
function buttons. Aer pressing once on a specic function button, a quick flashing
of the red light at the front of the sensor will occur. At this stage, you can change the
setting by pressing the (+) or the (-) buttons, every push will increase or decrease one
level. Aer nishing the adjustment, turn the water supply back on.
DETECTION RANGE
DELAY IN TIME
SECURITY TIME
LOCK OUT TIME
DELAY OUT TIME
TEMPORARY OFF
FUNCTION
RESET
DETECTION RANGE: If necessary, use the remote control to adjust
the sensor range as follows:
Press the RANGE button. Wait until a quick flashing of the red light
of the sensor eye is perceived. Then, press + to increase one level
and – to reduce it every push will increase or decrease one level.

12
SETTINGS ADJUSTMENT
WITH REMOTE CONTROL
FLOW TIME: This function determines the water flushing time once
the user leaves the urinal.
Press the two waves button. Wait until a quick flashing of the red
light of the sensor eye is perceived. Then, press + to increase the
flow time and – to reduce it.
DELAY IN TIME: If required, the delay in time can be modied as
follows:
Press the IN button. Wait until a quick flashing of the red light of the
sensor eye is perceived. Then, press + to increase the delay in time
and – to reduce it.
DELAY OUT TIME: This button changes the time interval the water
starts to flush aer the user has le the urinal.
If required, the delay out time can be modied as follows:
Press the OUT button. Wait until a quick flashing of the red light of
the sensor eye is perceived. Then, press + to increase the delay out
time and – to reduce it.
 HOUR HYGIENE FLUSH: If you have a compatible model with a 24
hours hygiene flush it is possible to enable and disable it.
To activate the hygiene flush, press the clock button. Wait until a
quick flashing of the red light of the sensor eye is perceived. Then
press + to activate the hygiene flush or – to deactivate it.
TEMPORARY OFF FUNCTION: This function is ideal to perform any
kind of activity in front of the sensor without operating the system
(for example, cleaning).
Urinals will remain shut for 1 minute when this button is pressed
once. To cancel this function and to return to normal operation press
the On/O button again or wait 1 minute.
RESET BUTTON: This function allows the sensor to return to the
original factory preset settings.
If required, press the Reset button and without releasing it, press the
+ button once.

13
RANGE ADJUSTMENT
The sensor range is the range an object can be away from the sensor in order to activate
the flush valve. The sensor is factory preset. If necessary, it can be adjusted as follows:
Adjusting the sensor range manually:
. Disconnect the battery or switch o the electricity supply to the sensor.
. Present your hand in front of the sensor and ensure it blinks once. If the sensor
does not blink, proceed to step 3. Hold your hand in front of the sensor
for 10 seconds.
. Reconnect the power supply to the sensor.
. To enter into the adjusting mode, put your hand in front of the sensor at a distance
of  “(cm) within  seconds from the re-connection of the power supply.
Note: If you will not put your hand in front of the sensor aer connecting the power
supply, the sensor will not enter into the adjusting mode and the previous adjustment
will continue.
. When the sensor enters into the adjusting
mode and your hand is in front of the sensor,
the red light in front of the sensor will flash
slowly.
. Keep your hand in front of the sensor until
the slow flashing changes to quick flashing,
At this point move your hand to the required
distance from the sensor and wait until the
red light will stop flashing.
. When the red light has turned o, the sensor
is adjusted to the required distance.
. Check the distance you have set and if it is
not satisfactory, repeat the procedure.

14
MAINTENANCE
Filter cleaning instructions
This flush valve is provided with a stainless steel lter preventing foreign particles
to enter the lines. If the water flow has decreased, this may be because the lter is
clogged. The lter can be cleaned as follows:
. Turn o the regulating valve.
. Disassemble the solenoid valve by opening the nuts.
. Remove the lter and wash it under running water.
. Reassemble the lter.
. Reassemble the solenoid valve.
. Turn on the regulating valve and adjust the flow capacity.
. Make sure that there is no water leakage.
Care and cleaning of chrome and special nishes
DO NOT use steel wool or cleansing agents containing alcohol, acid, abrasives, or the
like. Use of any prohibited cleaning or maintenance products or substances could
damage the surface of the flush valve. For surface cleaning use ONLY soap and water,
then wipe dry with clean cloth or towel. When cleaning bathroom tile, the flush valve
should be protected from any splattering of harsh cleansers.
If system chemical disinfection is practiced, chlorine can be used (calculated
chlorine concentration of 50mg/l maximum in water per one hour dwell time) at
service interval frequency.

15
SPARE PARTS LIST
Panel Kit Jupiter , E 
Panel Kit Jupiter H, HE 
-pack Sensor Kit Jupiter 2040 
8-Pack Solenoid & Housing Kit 
Nipple Kit 
Filter 
Switching transformer 

16
WARRANTY
Y. Stern Engineering Ltd. warrants that its electronic faucets, flush valves and
controls will be free of defects in material and workmanship during normal use for
two years from the date the product is purchased.
If a defect is found in normal use, Y. Stern Engineering Ltd. will, at its discretion,
repair, provide a replacement part or product, or make appropriate adjustments.
Damage caused by accident, misuse, or abuse is not covered by this warranty.
Improper care and cleaning will void the warranty. Proof of purchase (original sales
receipt) must be provided to Stern Engineering Ltd. with all warranty claims.
Stern Engineering Ltd is not responsible for labor charges, installation, or other
incidental or consequential costs other than those noted above. In no event shall the
liability of Stern Engineering Ltd. exceed the purchase price of the faucet, valve or
control.
If you believe that you have a warranty claim, contact your Stern Distributor,
Dealer or Plumbing Contractor. Please be sure to provide all pertinent information
regarding your claim, including a complete description of the problem, the product,
model number, the date the product was purchased, from whom the product was
purchased and the installation date. Also include your original invoice.
Y. STERN ENGINEERING AND/OR SELLER DISCLAIM ANY LIABILITY FOR SPECIAL,
INCIDENTAL OR CONSEQUENTIAL DAMAGES. This warranty excludes product damage
due to installation error, incorrect maintenance, wear and tear, battery, water
composition, product abuse, or product misuse, whether performed by a contractor,
service company, or the consumer. This warranty does not cover product damage
caused by the following:
- Incorrect installation, inversions of supply pipes.
- Pressures or temperatures exceeding recommended limits.
- Improper manipulation, tampering, bad or lapsed maintenance.
- Foreign bodies, dirt or scale introduced by the water supply.

17
TROUBLESHOOTING
SOLUTIONCAUSEINDICATORPROBLEM
Replace battery.Low battery.Sensor flashes
continuously when
user steps within
the sensor range.
Valve does
not flush
Increase the range.. Range is too short.Red light in the
sensor does not
flash when user
steps within the
sensor range.
Decrease the range.. Range is too long.
Replace battery.
. Battery is completely used up.
Eliminate cause of
reflection.
. Sensor is picking up
reflections from mirror or other
object.
Connect the connectors
of the electronic unit to
the solenoid valve.
. Connectors between the
electronic unit and the solenoid
valve are disconnected.
Red light in the
sensor flashes when
user steps within
the sensor range. Unscrew solenoid,
pull out the plunger
and the spring from
solenoid. Clean them
with pressure or use
scale remover material if
needed.
. Debris or scale in solenoid.
Clean the orice or
replace diaphragm.
. The central orice in the
diaphragm is clogged or the
diaphragm is torn.
Reduce the water supply
pressure.
. The water supply pressure is
higher than 8 bars.
Clean the orice or
replace diaphragm.
Debris or scale in diaphragm or
the diaphragm is torn.
. Sensor flashes
when user steps
within the sensor
range.
Valve does
not shut o
Clean or eliminate case
ot interference.
Sensor is dirty or covered.. Red light in the
sensor does not
flash when user
steps within the
sensor range.
Decrease the range
or eliminate cause of
reflection.
Sensor is picking up reflections
from mirror or another object.

18
. 
 Gan Rave Blvd., 81222 Gan Rave, Yavne, Israel
Tel: , Fax: , [e-mail]
www.sternfaucets.com
