Steve Silver AH850C User manual

Item#: AH850C
Description: Athens 360 Swivel PWR
/PWR/PWR Recliner
Product Size: 32.5" x 41" x 42.5"H
00284A

ASSEMBLY INSTRUCTIONS
AH850C
CAUTION:
STEP 1:
Back Receivers
Steel
Mechanism
Post
Figure A
Figure B
Screwdriver required (not included)
Page 2
Attached to the top of the swivel base is the hardware bag that includes the power transfor
-mer, power cord and power transformer extension cord. Remove the parts from the bag and
attach the power cord to the transformer and the power transformer extension cord to the
matching end coming from the power transformer. Make sure to close the clip lock to prevent
the connection from coming loose during use. Set the assembly aside to be used in step 5.
STEP 2: Attaching the Recliner Back: Position the KD back(A) with the KD receivers positioned over
the mechanism post on the recliner body (B) as pictured below. Check to assure both sides
of the mechanism post are positioned inside of the KD receivers on the back frame, push in
a downward motion from the top of the back frame until a clicking sound is heard.
Transformer
and Cord
PLEASE READ ALL INSTRUCTIONS CAREFULLY BEFORE STARTING ASSEMBLY PROCESS. IT IS
RECOMMENDED TO USE TWO PEOPLE WHEN ASSEMBLING AND REMOVING THE INSIDE BACKS
TO AND FROM THE BASE OF THE FURNITURE.

STEP 4:
STEP 3:
Attach the outside back across the bottom rear of each seat rail with the pre attached Velcro.
Product Size: 33.1” ×30.3” × 33.5”H
Page 3
Both the headrest and lumbar leadwires are color coded and
labeled Headrest or Lumbar.
The headrest leadwires are yellow.
The lumbar leadwires are grey.
Attach the lead wires found at the bottom of motion back to the lead wires at the rear of seat.
Yellow to Yellow & Grey to Grey. Make sure to close the clip locks to assure the connections
will not come loose during use.

TOOLS REQUIRED : NO TOOLS REQUIRED
PART LIST
NO Description Sketch Quantity
PAH850CB
Backrest
PAH850CS
Seat
PAH850CT
Transformer
PAH850CPC
Power cord
PAH850CPT
Power transformer
extension cord
1
1
1
1
1
A
B
D
C
E
Page 4

Page 5
PRODUCT DETAILS
RECLINER CHAIR BODY
PRODUCT SIZE
CARTON SIZE
SEAT HEIGHT
SEAT DEPTH
NET WEIGHT
GROSS WEIGHT
CU.FT.
STEEL+PLYWOOD
L 32.5" x W 41"x H 42.5"
L 45.3"x W 26.8"x H 33.5"
20.5"
20.5"
136.7 LBS
154.3 LBS
23.53
FABRIC CONTENT: POLYESTER 100%
Spare part for AH850C
PAH850CB
Backrest
PAH850CW
Left Wing
PAH850CW
Right Wing
PAH850CT
Transformer
PAH850CPC
Power cord
PAH850CSC
SIDE CONTROL

SIDE CONTROL USER’S MANUAL
Page 6
MADE IN VIETNAM
To recline: Sit on the furniture, and press the front of the button closest to the
footrest to smoothly raise the footrest and recline to any position. To lower the
footrest and return to an upright position, press the back side of the button clos-
est to the footrest.
To adjust headrest: Press the front of the button closest to the backrest to
smoothly raise and adjust the headrest to any position. To lower the headrest and
return it to its original position, press the back side of the button closest to the
backrest.
To adjust lumbar support: Press the front of the center button to smoothly raise
and adjust the lumbar support to any position. To lower the lumbar support and
return it to its original position, press the back side of the center button.
To close all: To simultaneously return the headrest, footrest, and lumbar support
to their original positions, press and hold the back side of the button closest to the
footrest.
HEADREST
CLOSE CLOSE
& HOME
CLOSE OPEN
OPEN OPEN
LUMBAR FOOTREST
USB
