Steve Silver MOR950SS User manual

Item#: MOR950SS/ MOR950SC
Description: Morrison Pwr/ Pwr Sofa
Stone/ Camel
Product Size: 86.53" × 38.22" × 42.12"H
00353A(VN)

ASSEMBLY INSTRUCTIONS
MOR950SS/ MOR950SC
CAUTION:
STEP 1:
Back Receivers
Figure A
Figure B
Screwdriver required (not included)
Page 2
Attached to the top of the swivel base is the hardware bag that includes the power transfor
-mer, power cord and power transformer extension cord. Remove the parts from the bag and
attach the power cord to the transformer and the power transformer extension cord to the
matching end coming from the power transformer. Make sure to close the clip lock to prevent
the connection from coming loose during use. Set the assembly aside to be used in step 5.
STEP 2: Attaching the Recliner Back: Position the KD back(A) with the KD receivers positioned over
the mechanism post on the recliner body (B) as pictured below. Check to assure both sides
of the mechanism post are positioned inside of the KD receivers on the back frame, push in
a downward motion from the top of the back frame until a clicking sound is heard.
Transformer
and Cord
PLEASE READ ALL INSTRUCTIONS CAREFULLY BEFORE STARTING ASSEMBLY PROCESS. IT IS
RECOMMENDED TO USE TWO PEOPLE WHEN ASSEMBLING AND REMOVING THE INSIDE BACKS
TO AND FROM THE BASE OF THE FURNITURE.
Steel
Mechanism
Post

Product Size: 33.1” ×30.3” × 33.5”H
Page 3
STEP 4:
STEP 3:
STEP 5: Attach the outside back across the bottom rear of each seat rail with the pre attached Velcro.
The headrest leadwires are color coded and labeled Headrest.
The headrest leadwires are yellow.
Attach the leadwires found at the bottom of motion back to the leadwires at the rear of seat.
Yellow to Yellow. Make sure to close the clip locks to assure the connections will not come
loose during use.
Slide the metal inserts on recliner’s Left wing(C)and Right wing (D) into the metal sleeves on
the side of the recliner’s back. Slide the wings down until they are completely set on the backs
metal sleeves.
C
D

Page 4
TOOLS REQUIRED : NO TOOLS REQUIRED
PART LIST
NO Description Sketch Quantity
1
1
1
1
1
1
A
B
C
D
E
F
PMOR950SSLB
PMOR950SCLB
PMOR950SSRB
PMOR950SCRB
PMOR950SSMB
PMOR950SCMB
PMOR950SC
PMOR950SST
PMOR950SCT
PMOR950SSPC
PMOR950SCPC

Page 5
PRODUCT DETAILS
RECLINER CHAIR BODY
PRODUCT SIZE
CARTON SIZE
SEAT HEIGHT
SEAT DEPTH
NET WEIGHT
GROSS WEIGHT
CU.FT.
STEEL+PLYWOOD
L 86.53" x W 38.22"x H 42.12"
L 87.36" x W 29.79"x H 26.70"
25.6"
20.9"
256.96 LBS
289.50 LBS
40.94
Spare part for MOR950SS/ MOR950SC
FABRIC CONTENT: POLYESTER 100%
FABRIC CONTENT: POLYESTER
FRAME MATERAL: WOOD & IRON
FABRIC CLEANING CODE : S
USER MANUAL : SOLVENT AND / OR WATER BASED CLEANERS
This fabric is not machine washable.
Allow+/-3% residual shrinkage.
Do not use cleaning products containing brightening agents
PMOR950SST
PMOR950SCT
PMOR950SSPC
PMOR950SCPC
PMOR950SC
PMOR950SSLB
PMOR950SCLB
PMOR950SSRB
PMOR950SCRB
PMOR950SSMB
PMOR950SCMB

SIDE CONTROL USER’S MANUAL
Page 6
MADE IN VIETNAM
To recline: Sit on the furniture, and press the front of the button closest to the
footrest to smoothly raise the footrest and recline to any position. To lower the
footrest and return to an upright position, press the back side of the button
closest to the footrest.
To adjust headrest: Press the front of the button closest to the backrest to
smoothly raise and adjust the headrest to any position. To lower the headrest
and return it to its original position, press the back side of the button closest to
the backrest.
To close all: To simultaneously return the headrest, footrest, and lumbar support
to their original positions, press and hold the back side of the button closest to
the footrest.
HEADREST
CLOSE CLOSE
& HOME
OPEN OPEN
FOOTREST
USB
Product Protected By Following Patents:
Patented Ar�cula�ng Power Headrest
US Patent: 10,736,423
