STI EZ-Path 33 Series Assembly instructions

3. Insert pathway slowly into opening until mounting clips contact the wall or floor
surface exercising care to make sure that the pathway is centered and properly
aligned with the opening. Apply pressure to the pathway until the mounting
clips lock into place within the opening and the plate rests flush with the surface
of the floor or wall (See Fig 4).
3. Insert pathway slowly into opening until mounting clips contact the wall or floor
surface exercising care to make sure that the pathway is centered and properly
aligned with the opening. Apply pressure to the pathway until the mounting
clips lock into place within the opening and the plate rests flush with the surface
of the floor or wall (See Fig 4).
GENERAL - READ COMPLETELY BEFORE INSTALLING
(Part No. EZP133K & EZDP133FK* )
Page 1 of 2 Installation Sheet • Kick-In Plate ZIS1006-3345
INSTALLATION SHEET
Kick-In Plate
TABLE A: Parts List
Qty. Description
1Kick-In Plate
2Ground Screws
15/64” Allen Key
10 8-2 x 1/4” lg. Set Screws
1EZD33FWS*
*Available in the EZDP133FK
TABLE A: Parts List
Qty. Description
1Kick-In Plate
2Ground Screws
15/64” Allen Key
10 8-2 x 1/4” lg. Set Screws
1EZD33FWS*
*Available in the EZDP133FK
Page 1 of 2 Installation Sheet • Kick-In Plate ZIS1006-3345
INSTALLATION SHEET
Kick-In Plate
FIG 4 FIG 4
FIG 3 FIG 3
This product is designed to facilitate
installation of the Series 33 EZ-Path®Fire
Rated Pathway (Cat. No. EZD33FWS) in
cored openings through walls and floors.
Plate when inserted into opening, utilizes
built-in locking mounting clips to securely
fasten it within the opening. No additional
fasteners are required.
This product is designed to facilitate
installation of the Series 33 EZ-Path®Fire
Rated Pathway (Cat. No. EZD33FWS) in
cored openings through walls and floors.
Plate when inserted into opening, utilizes
built-in locking mounting clips to securely
fasten it within the opening. No additional
fasteners are required.
NOTE: This product is designed for use in accurately cored 4” (102 mm) diameter openings
in concrete floors or walls. Installation of this plate requires a minimum unobstructed area of
3/4” (20 mm) completely around the cored opening. Plate pathway opening is asymmetrical
(keyed) and plate and pathway must be aligned. Rotate plate until the stamping “EZP133K”
aligns with the lid (labeled side) of pathway.
NOTE: This product is designed for use in accurately cored 4” (102 mm) diameter openings
in concrete floors or walls. Installation of this plate requires a minimum unobstructed area of
3/4” (20 mm) completely around the cored opening. Plate pathway opening is asymmetrical
(keyed) and plate and pathway must be aligned. Rotate plate until the stamping “EZP133K”
aligns with the lid (labeled side) of pathway.
FIG 2 FIG 2
FIG 1 FIG 1
GENERAL - READ COMPLETELY BEFORE INSTALLING
(Part No. EZP133K & EZDP133FK*)
2. Slide kick-in plate over pathway, making sure that pathway retaining flanges face
outward. Adjust plates to wall or floor thickness. Secure plate to pathway by
tightening set screws (See Fig 3).
2. Slide kick-in plate over pathway, making sure that pathway retaining flanges face
outward. Adjust plates to wall or floor thickness. Secure plate to pathway by
tightening set screws (See Fig 3).
2. Apply pressure to the plate, with the foam wedges facing the opening, until the plate is
flush with the top surface of the floor or one surface of the wall (See Fig 1).
2. Apply pressure to the plate, with the foam wedges facing the opening, until the plate is
flush with the top surface of the floor or one surface of the wall (See Fig 1).
3. Slide pathway into keyed plate, with label side going in first, and set it to the floor
or wall thickness. (See Fig 2). Secure plate to pathway by tightening set screws.
3. Slide pathway into keyed plate, with label side going in first, and set it to the floor
or wall thickness. (See Fig 2). Secure plate to pathway by tightening set screws.
1. Start all set screws into flanges on the plate. 1. Start all set screws into flanges on the plate.
1. Start all set screws into flanges on the plate. 1. Start all set screws into flanges on the plate.
INSTALLATION INSTRUCTIONS INSTALLATION INSTRUCTIONS
ALTERNATE INSTALLATION INSTRUCTIONS ALTERNATE INSTALLATION INSTRUCTIONS

Page 2 of 2 Installation Sheet • Kick-In Plate ZIS1006-3345
INSTALLATION SHEET
Kick-In Plate
Page 2 of 2 Installation Sheet • Kick-In Plate ZIS1006-3345
Important Notice: All statements, technical information, and recommendations contained herein are based upon
testing believed to be reliable, but the accuracy and completeness thereof is not guaranteed.
WARRANTY: Specified Technologies Inc. manufactures its goods in a manner to be free of defects. Should any
defect occur in its goods (within one year), Specified Technologies Inc., upon prompt notification, will at its option,
exchange or repair the goods or refund the purchase price.
Limitations and Exclusions: THIS WARRANTY IS IN LIEU OF ALL OTHER REPRESENTATIONS EXPRESSED
OR IMPLIED (INCLUDING THE IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR USE)
AND UNDER NO CIRCUMSTANCES SHALL SPECIFIED TECHNOLOGIES INC. BE RESPONSIBLE FOR ANY
INCIDENTAL OR CONSEQUENTIAL PROPERTY DAMAGE OR LOSSES. PRIOR TO USE, THE USER SHALL
DETERMINE THE SUITABILITY OF THE PRODUCT FOR ITS INTENDED USE, AND THE USER ASSUMES ALL
RISKS AND LIABILITY FOR SUBSEQUENT USE. No statement or recommendation not contained herein shall
have any force or effect unless in an agreement signed by officers of seller and manufacturer.
MADE IN USA • PRINTED IN USA – COPYRIGHT © 2015 SPECIFIED TECHNOLOGIES INC.
Important Notice: All statements, technical information, and recommendations contained herein are based upon
testing believed to be reliable, but the accuracy and completeness thereof is not guaranteed.
WARRANTY: Specified Technologies Inc. manufactures its goods in a manner to be free of defects. Should any
defect occur in its goods (within one year), Specified Technologies Inc., upon prompt notification, will at its option,
exchange or repair the goods or refund the purchase price.
Limitations and Exclusions: THIS WARRANTY IS IN LIEU OF ALL OTHER REPRESENTATIONS EXPRESSED
OR IMPLIED (INCLUDING THE IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR USE)
AND UNDER NO CIRCUMSTANCES SHALL SPECIFIED TECHNOLOGIES INC. BE RESPONSIBLE FOR ANY
INCIDENTAL OR CONSEQUENTIAL PROPERTY DAMAGE OR LOSSES. PRIOR TO USE, THE USER SHALL
DETERMINE THE SUITABILITY OF THE PRODUCT FOR ITS INTENDED USE, AND THE USER ASSUMES ALL
RISKS AND LIABILITY FOR SUBSEQUENT USE. No statement or recommendation not contained herein shall
have any force or effect unless in an agreement signed by officers of seller and manufacturer.
MADE IN USA • PRINTED IN USA – COPYRIGHT © 2015 SPECIFIED TECHNOLOGIES INC.
Specified Technologies Inc.
Somerville, NJ 08876 USA
US Toll Free: [phone]
Outside US: + 1 908 526 8000
www.stifirestop.com
Specified Technologies Inc.
Somerville, NJ 08876 USA
US Toll Free: [phone]
Outside US: + 1 908 526 8000
www.stifirestop.com
INSTALLATION SHEET
Kick-In Plate
UNINSTALLING PLATE/PATHWAY ASSEMBLY
Mounting clips are designed to firmly lock the plate/pathway assembly into the cored opening.
To remove the assembly from the cored opening, the mounting clips must be disengaged.
Use the following procedure to disengage the clips:
1. While holding the pathway, loosen the set screws in the plate flanges.
2. Slide pathway out of plate.
3. Clips will disengage and plate can be removed.
