STI EZ-Path 33 Series Assembly instructions

SERIES 33 CIRCULAR
MOUNTING PLATES
EZP133CW 1
Cat. No. Qty.
Specied Technologies Inc.
Somerville, NJ 08876 USA
Toll Free US: 800.992.1180 • Outside US: [phone]
WWW.STIFIRESTOP.COM • ZIS1008-3375
MADE IN USA • PRINTED IN USA
LIMITED WARRANTY: STI warrants that its products will be free of defects for
one year from the date of purchase. In the event a product does not conform to
this warranty, the sole and exclusive remedy is, at STI’s option, replacement of
the product or refund of the purchase price. The warranty provided herein shall
be void and of no effect in the event that the product is not installed in accordance
with STI’s published instructions, listed systems and applicable building and safety
codes. THIS WARRANTY IS IN LIEU OF ALL OTHER REPRESENTATIONS AND
EXPRESSED OR IMPLIED WARRANTIES (including the implied warranties of
merchantability or tness for a particular use) AND UNDER NO CIRCUMSTANCES
SHALL STI BE LIABLE FOR ANY DIRECT, INDIRECT, SPECIAL, INCIDENTAL OR
CONSEQUENTIAL DAMAGES OR LOSSES, INCLUDING, WITHOUT LIMITATION,
ANY LOSS OF REVENUE, PROFIT OR USE. Prior to use, the user shall determine
the suitability of the product for its intended use, and the user assumes all risks and
liability for subsequent use. No person other than an ofcer of STI is authorized
to bind STI to any other warranty for any product for which this warranty is issued.
COPYRIGHT © 2015 SPECIFIED TECHNOLOGIES INC.
Specied Technologies Inc.
Somerville, NJ 08876 USA
Toll Free US: 800.992.1180
Outside US: [phone]
WWW.STIFIRESTOP.COM
Installation Sheet • Circular Mounting Plates • ZIS1008-3375
®
2 - Circular Mounting Plates
(Pre-installed set screws)
1 - 5/64” Allen Key
2 - Intumescent Gaskets
4 - 8-32 x 1/4” lg. Set Screws (Extra)
2 - Ground Screws
Package Contents:
ZIS1008 3375 EZD33 CWK.indd 1 12/3/15 2:32 PM

GENERAL – READ COMPLETELY BEFORE INSTALLING
(Part No. EZP133CW)
This product is designed to facilitate installation of the EZ-PATH®Fire Rated Pathway
(Cat. No. EZD33FWS) in accurate 4” (102 mm) diameter openings or nominal 3-1/8”
(80 mm) square openings through concrete or gypsum wallboard walls.
NOTE: Installation of this plate requires a minimum unobstructed area of 3/4” (20 mm)
completely around the openings.
1. Locate suitable area of the wall to penetrate making sure that there are no studs,
wires, pipes or other obstructions located within wall.
2. Cut, form or core-drill an accurate 4” (102 mm) diameter opening or a nominal
3-1/8” (80 mm) square-opening in wall. NOTE: Exercise care to align both openings
in gypsum wallboard walls.
3. Install a wall plate around device making sure that set screw anges are facing towards
the end of the device.
NOTE: Position plate so that the marking (EZP133CW) stamped on the plate aligns with the
lid of the device. Pre position and fasten wall plate to one side of pathway (g. 1) roughly
centering pathway within barrier. When properly adjusted, tighten set screws using Allen
wrench (provided) to lock plate onto device (See Fig. 1).
4. Place one of two provided gaskets around opposite end of device and carefully
slide it back to t snugly against back side (wall side) of plate.
5. Insert device through wall (with black device label facing upwards) using previously
installed wall plate and gasket as a stop (See Fig. 2).
6. Moving to the opposite side of the wall, install remaining gasket and wall plate
around device and slide toward wall. Tighten set screws to lock plate onto device and
complete the installation.
INSTALLATION SHEET - CIRCULAR MOUNTING PLATES
Installation Sheet • Circular Mounting Plates • ZIS1008-3375
Fig 2
Installation Sheet • Circular Mounting Plates • ZIS1008-3375
Fig 1
®
INSTALLING or PULLING CABLES
A resilient liner provides an adjustable seal within the pathway device.
Liner must be protected from damage while adding or removing cables.
Wrap cable ends with a suitable low friction tape before inserting into
the pathway. Where cable lubricants are used, low solids, water-based
products are recommended. This device is designed to be fully functional
at all cable loadings from completely empty to visually lled, and cables
should easily slide through the pathway using minimal effort. IF RESISTANCE
IS ENCOUNTERED, DO NOT FORCE CABLES OR CABLE BUNDLES
THROUGH THE PATHWAY. DAMAGE MAY RESULT. Upper curved liner
may be depressed when inserting cables, if necessary, using a at, smooth
implement and then removing it after cables are installed. The rectangular
shape of the loading area coupled with gentle pressure exerted by resilient
liners will naturally distribute the cables at a relatively uniform height across
the width of the device. The use of a cable dressing/combing instrument to
straighten and organize cables may help to maximize usable space within
the pathway device.
ZIS1008 3375 EZD33 CWK.indd 2 12/3/15 2:32 PM
