STI FKF 200 Series User manual

sti-solar.de
SOLARE KOMPETENZ
AUS SACHSEN
ASSEMBLY INSTRUCTIONS
FKF 200 / 240 / 270 CONSOLE

2
Please read these instructions carefully before beginning the assembly.
Observe the warnings indicated by this sign:
They warn against dangers or errorneous actions. A disregard of the advices and regulations mentioned in the assembly instruction
may result in the invalidation of the warranty claim.
The collectors FKF 200, FKF 240 and FKF 270 are monitored according to the CEN-Keymark programme rules Solarthermal Products
and are certied with the registration numbers 011-7S1913/1914/1915 F.
The copyright of this instruction incl. graphical material remains property of the STI GmbH. The instruction can only be duplicated
completely or in parts with written authorisation of the STI GmbH. Subject to technical changes and misprints.
The collectors of the FKF series are marked with the environmental label RAL-UZ-73 for solar collectors („Blauer Engel“). The STI
GmbH is obliged to take back the products which are marked with the environmental label RAL-UZ-73 for solar collectors and to
consign them for recycling.
Table of contents
Contents Page
Safety regulations, instructions and guidelines 3
Tools 5
Product description 6
Collector eld dimensions 8
Hydraulic connections 10
Bottom support dimensions 11
Assembly bottom support on concrete block 13
Assembly bottom support with xed dowel 14
Assembly collectors 15
Assembly temperature sensor base console 17
Assembly base console on roof prole 18
Spacing roof hooks 19
Assembly roof-tile clamps 20
Assembly roof-tile clamps with lead cloth 22
Assembly roof-tile clamps plain tile 24
Assembly roof-tile clamps plain tile with lead cloth 25
Assembly roof-tile clamps for corrugated sheet 27
Assembly fastening proles / console 28
Assembly wall console 30
Assembly temperature sensor wall console 34
Collector connections 35
Hydraulic connection with manifold 36
Overview hydraulic connections Smart Lock System / accessories 37
Overview hydraulic connections Smart Lock System / accessories aluminium 38
Assembly intermediate plates 39
Assembly of the connecting pipe 40
Pipe dimension of the connecting pipe 41
Initial operation 43
Appendix 47

3
Safety regulations, instructions
and guidelines
The standards and guidelines applied at the installation location of the collectors have to be considered in the latest re-
lease.
Engineer standards and guidelines
• VBG 4 Unfallverhütungsvorschriften Elektrische
Anlagen und Betriebsmittel
• VBG 37 Unfallverhütungsvorschrift Bauarbeiten
• VBG 74 Leitern und Tritte
• ZVDH, Regelwerk
• LBO’s Landesbauordnungen der Bundesländer
• DIN 18299 Allgemeine Regelung für Bauarbeiten
jeder Art
• DIN 18334 Zimmer- und Holzbauarbeiten
• DIN EN 12828:2013-04 Heizungsanlagen in Gebäuden
• DIN 18338 Dachdeckungs- und
Dachabdichtungsarbeiten
• DIN 18339 Klempnerarbeiten
• DIN 18351 Fassadenarbeiten
• DIN 18360 Metallbauarbeiten, Schlosserarbeiten
• DIN 18381 Gas-, Wasser- und Abwasser-
installationsanlagen
• DIN 18451 Gerüstarbeiten
• DIN DIN 1055 – Einwirkungen auf Tragwerke - Teil 2:
Bodenkenngrößen
• DIN EN 1991 Einwirkungen auf Tragwerke Teil 1-7
• DIN 4708 Teil 3 Zentrale Brauchwasser-
erwärmungsanlagen
• DIN 4102 Brandverhalten von Bausto󰀨en und
Bauteilen
• DIN 4109 Schallschutz im Hochbau
• DIN EN 516 Einrichtungen zum Betreten des Daches
• EN 517 Sicherheitsdachhaken
• DIN 4753 Teil 1 Wassererwärmer und Wassererwär-
mungsanlagen für Trink- und Betriebswasser; Anforde-
rungen, Kennzeichnung, Ausrüstung und Prüfung
Teil 2: Sonnenheizungsanlagen mit organischen Wär-
meträgern; Anforderungen an die sicherheitstechnische
Ausrüstung
• DIN VDE 0100-510 Errichten von Starkstromanlagen
mit Nennspannungen bis 1000 V; Allgemeine Bestim-
mungen
• DIN VDE 0100-737 Errichten von Niederspannungsanla-
gen - Feuchte und nasse Bereiche und Räume und An-
lagen im Freien
• DIN EN 62305-1; VDE 0185-305 Blitzschutz
• DIN VDE 0105-100 Betrieb von elektrischen Anlagen
•DIN EN 12976: Thermische Solaranlagen und ihre Bau-
teile (vorgefertigte Anlagen)
•DIN EN 12977: Thermische Solaranlagen und ihre Bau-
teile (kundenspezisch gefertigte Anlagen)
•DIN 1988: Technische Regeln für Trinkwasser-Installation
Notes prior to the installation start
The installation and initial operation must be carried out by
an expert who is responsible for the correct installation and
operation. Before installing and putting the collectors into
service, please inform about the local engineer standards and
regulations.
Components of the collectors can reach temperatures of more
than
200 °C, there is a danger of burning and scalding! Furthermore
it has to be checked whether there are any load sources in
the area of the collector eld which may produce chemically
aggressive mediums. In condensate dissolved acids and bases
may cause permanent damage to the collector components.
Throughout the installation of a solar collector you directly
intervene into an existing roof cladding. Di󰀨erent roof coverings
such as tile, shingles or slate require additional measures (e.
g. sarkings) as a security against the ingress of moisture due
to rain or snow - especially in case of extended and occupied
top oors or in case of insu󰀩cient roof pitches (concerning the
covering).
Information on foliation
If the collectors are mounted with foil, this foil must be removed
from the collectors at the latest 3 months after delivery. After
that, residue-free removal can no longer be guaranteed.
The date of the delivery note counts.

4
Safety regulations, instructions
and guidelines
The substructure as well as its connections to the building
have to be checked on site according to the local regulations.
The collectors have to be mounted in an angle of at least
20° to max. 70°.
The recommended heat transfer medium is a mixture of
glycol and water, e. g. Tyfocor L or similar. The collectors
must never be operated or tested with water under pressure.
To protect the system from overheating during standstill
and accelerated glycole-ageing, a self-draining system
(e. g.STI Drain Master or SolBox) is recommended.
It is necessary to pay attention that the back ow tempe-
rature is never lower than the ambient temperature. If ne-
cessary, take appropriate action (e. g. increase back ow
temperature to at least 30 °C).
To avoid a possible forming of condensate in the collector,
the installation has to be taken into operation hydraulically
within two weeks after termination of the assembly. At low
temperatures, the forming of condensate may cause frost
damages in the collector.
Lightning protection
Please note country-specic legislation!
Throughout the installation of metal fastening systems, a
check has to be done by an authorized qualied electrician.
The metallic pipes of the solar circle are connected with the
earth circuit connector via a copper pipe of at least 16 mm².
Please ensure su󰀩cient ventilation for each assembly
method. Do not close the ventilation openings. Especially
in case of a roof-integrated assembly, the ventilation
of the collector is denitely necessary. Appropriate
ventilation hoods are available from the supplier. Please
pay attention to the regulations of the ZVDH (Germany),
SVDW (Switzerland) as well as di󰀨erent local regulations
concerning the ventilation. If necessary, consult an expert.
Responsibilities
The constructor of the installation is responsible for the in-
tegration of the installation according to the regulations and
for the compliance with safety regulations.
The operator of the installation is responsible for its opera-
tion according to the regulations and for the consultation of
experts in case of problems.
This instruction is not subject to a service of modication. It
does not absolve the manufacturer and operator of the instal-
lation from his resposibilities to install and operate all parts of
the installation according to utmost professional knowledge.
The manufacturer of the installation is responsible for obser-
ving and keeping all appropriate regulations and instructions.
Statics
Before beginning the assembly it is vital to test the roof or
substructure on site for su󰀩cient load-carrying capacity.
Please pay increased attention to the possible durability of
the screw ttings to fasten the collectors as well as to the
quality of the substructure.
According to DIN EN 1991 or rather to the local engineer stan-
dards, it is necessary to check the whole system construction
on site, especially in snowy regions (note: 1m³ powder snow
~ 60 kg / 1 m³ wet snow ~ 200 kg) as well as in regions with
high wind speed. Before starting the assembly, all aspects
that may lead to incorrect load of the whole construction have
to be considered!
Install the collectors in such a way that a backlog of snow
(e. g. due to snow guards or other obstacles) is not possible.
In case of correct assembly, snow loads (pressure loads) up
to 2 kN/m² and wind loads (suction loads) up to 1,1 kN/m² ac-
ting on the collector are permitted.
Transport and stocking
Never store the delivered collectors unprotected at the buil-
ding site.
Always stock the collectors upright and leaning against a solid
surface.
If the collectors are stored outside they must be stood upright
with the backside leaned against the wall (glass forwards).
The collectors must be covered so that neither dust nor water
can enter the collectors.
If it is not possible to stand the collectors upright (e.g. at
roof), the collectors must be stacked with 2 square timbers
between each collector.
Never lay down the collectors onto a rough surface with over-
hanging pieces like stones, timbers etc.
The rigidity of the collectors is limited. During transport to the
building site always ensure a torsion-free transport. In case of
an elevated intermediate storage make sure that the collec-
tors are protected against sliding down.

5
Tools
The following tools are needed for the assembly of the collectors:
Cordless screwdriver Angle grinder
diamond/stone disk
Drill
10 mm carbid metal
Chalk box
Securing devices,
protective equipment
Roof ladder
Allen screw SW 4 *, SW 6
Ratchet, lengthening and 13 mm
socket wrench, combination wrench
13 mm
Hammer Knife
* included in the STI tool kit 2014 1910101

6
1
2
3
4
6
5
7
Product description
Solar collector FKF
The solar thermal collector FKF uses the radiant
energy of the sun to heat a heat transfer medium.
This glycol-water mixture gives o󰀨 the heat to a
storage via a heat exchanger. The obtained energy
can be used for water heating and heating support.
Sectional model
1 Aluminium frame
2 Insulation
3 Insulation
4 Stucco back panel
5 Highly selective mono-material copper absorber
6 Glass
7 EPDM sealing

7
FKF 200 V FKF 240 V FKF 270 V FKF 200 H
FKF 240 H
FKF 270 H
Product description
Specications
The FKF collector has an absorber with meander shaped tubes as well as integrated manifolds. The hydraulic system
enables a connection of 15 collectors in one series and up to six collectors on one side. In one collector eld, up to 45
collectors can be connected in three rows.
Modell FKF 200 V 240 V 270 V 200 H 240 H 270 H
Gross surface 2,10 m² 2,52 m² 2,85 m² 2,10 m² 2,52 m² 2,85 m²
Apertur area 1,83 m² 2,22 m² 2,52 m² 1,83 m² 2,22 m² 2,52 m²
Length 1.746 mm 2.100 mm 2.373 mm 1.200 mm 1.200 mm 1.200 mm
Width 1.200 mm 1.200 mm 1.200 mm 1.746 mm 2.100 mm 2.373 mm
Height 85 mm 85 mm 85 mm 85 mm 85 mm 85 mm
Test pressure 10 bar 10 bar 10 bar 10 bar 10 bar 10 bar
Operating pressure 6 bar 6 bar 6 bar 6 bar 6 bar 6 bar
Fluid volume Co-Co / Al-Co 2,1 l 2,2 l 2,4 l 2,7 l 2,7 l 3,1 l
Fluid volume Al-Al 1,8 l 1,9 l 2,1 l 2,4 l 2,4 l 2,7 l
Flow per m215 - 40 l/h 15 - 40 l/h 15 - 40 l/h 15 - 40 l/h 15 - 40 l/h 15 - 40 l/h
Weight Co-Co 37 kg 39 kg 42 kg 37 kg 39 kg 42 kg
Weight Al-Co 35 kg 37 kg 40 kg 35 kg 37 kg 40 kg
Weight Al-Al 34 kg 35 kg 38 kg 34 kg 35 kg 38 kg
Loss of pressure(T=20°C / 30l/h) 6.141 Pa 8.522 Pa 11.217 Pa 4.082 Pa 6.297 Pa 7.988 Pa
Hyraulic system of the absorber

8
Field width
Lip (Collector covering)
Field height
Collector eld dimensions
Collectors which are mounted side by
side in one row are always connected by
means of stainless steel expansion joints
on the manifolds (see photo).
It is possible to assemble metal sheets between the collectors to achieve a homogeneous appearance of the installation.
The intermediate plates are assembled exclusively for optical aspects and do not have any inuence on the installation.
Therefore the intermediate plates can be ordered optionally and are not necessarily included in delivery.
Horizontal section across a collector eld
1300002 collector connection set hydraulical
Vertical section across a collector eld
In case of multi-row installations, the
collectors will always be mounted
on joint on top of each other. The
lip (collector covering) of the upper
collector has to be put onto the lower
collector. The lip (collector covering)
of the lower collector has to be
clamped into the joint area to ensure
an optimum water ow.

9
Collector eld dimensions
Collector type
Example
Six collectors FKF 240 H in two rows
Field width: 6.307 mm
Field height: 2.334 mm
Example
Three collectors FKF 240 V in one row
Field width: 3.607 mm
Field height: 2.067 mm
240 V Number of collectors 1 2 3 4 5 6 7 8
Field width in mm 1.167 2.387 3.607 4.827 6.047 7.267 8.487 9.707
Number of rows 1 2 3 4 5 6 7 8
Field height in mm 2.067 4.134 6.201 8.268 10.335 12.402 14.469 16.536
240 H Number of collectors 1 2 3 4 5 6 7 8
Field width in mm 2.067 4.187 6.307 8.427 10.547 12.667 14.787 16.907
Number of rows 1 2 3 4 5 6 7 8
Field height in mm 1.167 2.334 3.501 4.668 5.835 7.002 8.169 9.336
270 V Number of collectors 1 2 3 4 5 6 7 8
Field width in mm 1.167 2.387 3.607 4.827 6.047 7.267 8.487 9.707
Number of rows 1 2 3 4 5 6 7 8
Field height in mm 2.340 4.680 7.020 9.360 11.700 14.040 16.380 18.720
270 H Number of collectors 1 2 3 4 5 6 7 8
Field width in mm 2.340 4.733 7.126 9.519 11.912 14.305 16.698 19.091
Number of rows 1 2 3 4 5 6 7 8
Field height in mm 1.167 2.334 3.501 4.668 5.835 7.002 8.169 9.336
each additional collector
+ 1.220
+ 2.067
each additional collector
each additional collector
each additional collector
+ 2.120
+ 1.167
+ 1.220
+ 2.340
+ 2.393
+ 1.167
200 V Number of collectors 1 2 3 4 5 6 7 8
Field width in mm 1.167 2.387 3.607 4.827 6.047 7.267 8.487 9.707
Number of rows 1 2 3 4 5 6 7 8
Field height in mm 1.713 3.426 5.139 6.852 8.565 10.278 11.991 13.704
200 H Number of collectors 1 2 3 4 5 6 7 8
Field width in mm 1.713 3.479 5.245 7.011 8.777 10.543 12.309 14.075
Number of rows 1 2 3 4 5 6 7 8
Field height in mm 1.167 2.334 3.501 4.668 5.835 7.002 8.169 9.336
+ 1.220
+ 1.713
each additional collector
+ 1.766
+ 1.167

10
Hydraulic connections
Temperature sensor
Each collector has a sleeve for inserting a temperature sensor. The sleeve is directly connected with the absorber. If the
collectors are installed correctly, the sleeve is always located on the top of the collector on the left. The temperature sensor
can be inserted in any collector. Please pay attention to the maximum insertion depth of 4 cm and secure the sensor
against slipping out. Due to the measuring point on the absorber, the temperature measured by the sensor may di󰀨er from
the uid temperature.
Installations with one up to six collectors in one row
Connection F red
Connection BF blue
A or B
C or D
Close unused connections with
caps.
Installations with seven up to 15 collectors in one row
Connection bottom left / top right
BF = C / F = B
Connection top left / bottom right
BF = D / F = A
Close unused connections with
caps.
Connection F A + E / BF H + D
Connection F B + F / BF G + C
Close unused connections with
caps.
In case of multi-row installations as well as installations which include the STI Drain Back System, the connection
pipe must always be connected with the diagonal line to the external manifold (Tichelmann), e. g. bottom left and
top right.
F = Flow (from the collector to the storage) red grommet
BF = Backow (from the collector to the storage) blue grommet
In case of installing an air eliminator, install it at the opposite end
of the top ow connection!
Multi-row installations
Pipe routing by Tichelmann

11
X X
200/240/270 H
200 V
270 V
100 mm
300 mm
20 mm
20 mm
240 V
150 mm
200/240/270 V
Bottom support dimensions
Bottom support
(top view)
The specied levels are reported without concrete
blocks. To determine the total height the height of the
concrete block (22 cm) must be added.
Please note the wind loads according to DIN 1055-1991 in the edge region of the roof. The emerging base load
has to be checked for the requirements of the wind loads on site.
Block distance center - center Dimensional chain, bottom bracket UK mounting
collector type distance Bottom support Bottom support attachment points (+ / - 30 cm)
X α δ ε
FKF 200 H 176,6 cm 1000 mm 100 mm 850 mm -
FKF 240 H 212,0 cm 1000 mm 100 mm 850 mm -
FKF 270 H 239,3 cm 1000 mm 100 mm 850 mm -
FKF 200 V 122,0 cm 1600 mm 100 mm 870 mm 1.420 mm
FKF 240 V 122,0 cm 1600 mm 100 mm 720 mm 1.470 mm
FKF 270 V 122,0 cm 1800 mm 100 mm 870 mm 1.620 mm
building height of collectors
collector
type
height H
20 ° 30 ° 45 ° 60 °
FKF 200 H 53 cm 71 cm 93 cm 110 cm
FKF 240 H 53 cm 71 cm 93 cm 110 cm
FKF 270 H 53 cm 71 cm 93 cm 110 cm
FKF 200 V 73 cm 91 cm 132 cm 156 cm
FKF 240 V 84 cm 116 cm 158 cm 180 cm
FKF 270 V 95 cm 130 cm 176 cm 211 cm
row spacing of collectors
collector
type
distance A
20 ° 30 ° 45 ° 60 °
FKF 200 H 220 cm 265 cm 315 cm 340 cm
FKF 240 H 220 cm 265 cm 315 cm 340 cm
FKF 270 H 220 cm 265 cm 315 cm 340 cm
FKF 200 V 328 cm 391 cm 462 cm 503 cm
FKF 240 V 439 cm 513 cm 598 cm 646 cm
FKF 270 V 460 cm 550 cm 640 cm 700 cm
The alignment of the concrete base
must be checked by means of the
stamping! The stamping must be
visible on the top of the concrete
base!
front
front
front
stamping
stamping
front

12
18 cm
22 cm
60 cm
P3
P1
P2
H
AC
B
Bottom support dimensions
concrete block 53 kg
console 8 kg
Declaration of the collector weight can be
found on page 7.
1420106 concrete block 53 kg
travers position
angle 20° 30° 45° 60°
position P1 - P2 P3 - P2 P1 - P2 P3 - P2
FKF 200/240/270 H 487 mm 487 mm 861 mm 861 mm
FKF 200 V 675 mm 675 mm 1.224 mm 1.224 mm
FKF 240 V 832 mm 832 mm 1.490 mm 1.490 mm
position P3 - P2 P3 - P2 P3 - P2 P3 - P2
FKF 270 V 659 mm 962 mm 1.405 mm 1.820 mm
distance of superstructures
parapet height B 30 cm 40 cm 50 cm 60 cm 70 cm 80 cm 90 cm 100 cm 110 cm
distance C 20 cm 40 cm 70 cm 100 cm 125 cm 150 cm 180 cm 205 cm 230 cm
All indicated values are a recommendation for an e󰀨ective sun angle of 20°.
Concrete base as
additional weight
concrete block
protection mat

13
Assembly bottom support
on concrete block
1420003 fastening set for bottom support
1420106 concrete block 53 kg
Now remove the protective caps for the integrated threaded
sleeves from all concrete blocks.
Afterwards place the base console on the concrete block and
secure them with the enclosed screws M10. All further consoles
have to be oriented exactly in row (e.g. by a line mark).
Afterwards place the concrete block. Pay attention to the exact
observance of the specied clearances between the concrete
blocks. If necessary, the usage of a separation layer between
concrete block and subsurface has to be considered.
The short distance between threaded sleeve and block edge
(10 cm) shows the front of the block. Make sure that every
concrete block is on the same mounting position and aligned in
a row (e.g. by a line mark).
1420106 concrete block 53 kg
First of all install the base console in accordance to the
requirements of the dimensions of bottom support.
1420114 bottom support 20°/30° 200 V 2014
1420124 bottom support 45°/60° 200 V 2014
1420118 bottom support 20°/30° 240 V 2014
1420122 bottom support 45°/60° 240 V 2014
1420160 bottom support 20° 270 V 2014
1420161 bottom support 30° 270 V 2014
1420162 bottom support 45° 270 V 2014
1420163 bottom support 60° 270 V 2014
1420111 bottom support 20°/30° 200/240/270 H 2014
1420120 bottom support 45°/60° 200/240/270 H 2014
Now weight down the concrete block with an additional concrete
block (optional). Prepare all consoles as described above for
the assembly of the collectors. Alternative, a concrete element
provided by the customer can be used for securing the base
load.

14
Assembly bottom support
with xed dowel
Fully assembled xed dowel pin and console (see illustration
alongside)
Following place the base consoles on the ground and secure it
with the added xed dowel pins M10. All other consoles have to
be oriented exactly in one row (e.g. by a line mark).
Drill two holes per base console in the existing surface to x
the xed dowel pin M10. Pay attention to precise alignment of
the two holes. In addition, all further holes have to be oriented
exactly in one row (e.g. by a line mark).
1420004 fastening set for concrete blocks
(with xed dowel pin M10)
First install the base console in accordance with the
requirements (see page 13).
1420114 bottom support 20°/30° 200 V 2014
1420124 bottom support 45°/60° 200 V 2014
1420118 bottom support 20°/30° 240 V 2014
1420122 bottom support 45°/60° 240 V 2014
1420160 bottom support 20° 270 V 2014
1420161 bottom support 30° 270 V 2014
1420162 bottom support 45° 270 V 2014
1420163 bottom support 60° 270 V 2014
1420111 bottom support 20°/30° 200/240/270 H 2014
1420120 bottom support 45°/60° 200/240/270 H 2014
Reliable anchoring of the bottom support with the xed dowel pin is possible in concrete <c25/25 as well as in natural stone
that is resistant to pressure.

15
Assembly collectors
For the assembly of the collectors rst place the outside right
or ouside left collector on top of the mounted and xed base
consoles. When assembling the collector, pay attention that
the outside base console needs to be overlapped about 50%
by the collector.
Before the following collector can be mounted, the hydraulical
collector connection must be installed at the concisely
protruding ange.
1300002 collector connection set hydraulical
When the consoles are ush mounted with the outer collectors
they will be safed with the provided fastening plates from the
„collector fastening set onto support edge“ in conclusion. For
this install the fastening plates at the upper and lower end of
the console in the designated holes.
When necessary, the consoles can be indented up to 20cm
from the collector edge.
1400008 collector fastening set onto support edge
(4 pieces)
Afterwards mount the fastening plate „double“ on the next
console in the upper and lower elongated hole. The nal
xation takes place after the assembly of the next collector.
1400106 collector fastening set onto support 2014
The mounting plate at the bottom of the consoles must be
hung up with the broad side in the collector frame.

16
Assembly collectors
Insert the hydraulical collector connection into the manifold. Pay
attention that both O-rings are mounted. Push the connection
all the way to the stop and fasten it with the locking spring.
At the upper and lower collector connection, the hydraulical
collector connection will be preassembled as to the image
alongside.
Push the next collector towards the already placed collector.
Attention needs to be paid that the compensators are inserted
into the collector manifold properly all the way to the stop.
Pay attention that the fastening plate „double“ hooks into the
collector prole on both sides. Afterwards, secure the fastening
plate.
Finally, mount both outer fastening plates the way as assem-
bled at the rst collector.

17
Cut rubber tip to be able to insert
temperature sensor
Temperature sensor setting
Assembly temperature sensor base console
Each collector has a sleeve for inserting a temperature sensor.
The sensor is positioned below the upper left manifold or next
to the label with the description „top“ on the outside of the
collector frame.
The sleeve for inserting the sensor is protected with a silicon
lip which has to be opened in the middle, using a knife or a
screwdriver, before inserting the sensor.
The insertion depth of the sensor is limited to 4 cm. An additional
protection against slipping out is recommended.
Contingent on the measuring point at the absorber the
temperature sensor may be installed at any desired collector
of the eld.
The error of measurement of the recorded temperature
compared to the uid temperature is ±2 K.
Assembly collectors
Now mount the next collector upon the consoles.

18
1400035 prole set alu to 200 H
1400027 prole set alu to 240 H
1400028 prole set alu to 270 H
1400026 prole set alu 200/240/270 H
1400022 connection set for prole set
Assembly base console on roof prole
For roof-mounted installations prole sets dependent on the collector type are delivered. For multiple collectors in one row
a connection set is required for each collector transition.
For multiple-row installations the minimum distances between the rows need to be adhered to (see table „row spacing of
collectors“, bottom support dimensions).
Please pay attention that for the assembly of such a system a water-proof roof underneath needs to be built.
For this it is necessary that the designated roof is provided with metal sheets, welding line, or plastic web
from the eave to the crest.
Otherwise melted snow from the collector eld may generate elds of ice. These may spread underneath the
roof cladding and result in possible water damages in rooms below.

19
Initial position:
top edge roof-tile
Initial position:
top edge roof-tile
roof-tiles in roof
cladding for FKF 200/240/270 V
A - 20 cm A +/- 20 cm
2 x A - 20 cm
2
for FKF 200/240/270 H
A-20cm A+/-20cm
2x A-20cm
Spacing roof hooks
Distance measures roof-tiles
For each horizontal collector two rows of roof-tiles are installed and for vertical collectors three rows of roof-tiles are
necessary. The vertical measurements H are each measured from the top edge of the roof-tile.
If high snow loads can be expected, the roof-tiles have
to be mounted above the rafters (the supportive wood
has to lie on the rafter). Alternatively, an increased
amount of roof-tiles may be considered according to
the load demand.
When the load capacity in the area of the lath is not
given the assembly should happen on top of the rafter.
Initial position
Horizontal size FKF 200 H FKF 240 H FKF 270 H
Measure A88,3 cm 106 cm 119,7 cm
Vertical size
Tolerance
FKF 200 H
+ / - 4 cm
FKF 240 H
+ / - 4 cm
FKF 270 H
+ / - 4 cm
Measure H76 cm 76 cm 76 cm
Horizontal size FKF 200 V FKF 240 V FKF 270 V
Measure A122 cm 122 cm 122 cm
Vertikal size
Tolerance
FKF 200 V
+ / - 4 cm
FKF 240 V
+ / - 4 cm
FKF 270 V
+ / - 4 cm
Measure H 1 76 cm 76 cm 76 cm
Measure H 2 55 cm 55 cm 75 cm
1410002 roof-tile bracket V2 without lead
1410003 roof-tile bracket V2 with lead
1410004 roof-tile bracket (plain tile clamps)
V2 without lead
1410005 roof-tile bracket (plain tile clamps)
with lead

20
grinding
section for the
supportive screw
Assembly roof-tile clamps
Removal of the tiles after previous determination of the
placement of the roof-tile clamps (see page 11 „Spacing multi-
row collector elds“).
Fixing of the lower lath 24 x 80 x 600 mm with two screws
5x 60 mm.
If the lath is placed near the counter lath, the lath
24 x 80 x 600 mm must not be applied.
1410002 roof-tile brachet V2 without lead
The lower roof-tile must be remounted.
Before covering, the lower roof-tile must be coarsly ground. To
avoid breaking of the tile the roof-tile clamp must not rest on
the tile.
The lath must be positioned in a way forcing the
hook to be mounted in the brick vale.
Completely tiled roof.
When mounting the eld in regions with high snow
load zone of 2 kN/m² it is necessary to place the roof
hooks in the rafter area.
Mount the tile clamp support 80x270x30 mm and x it with two
screws 5x60 mm.
