OPERATION AND INSTALLATION
Floorstanding DHW cylinder
» SBB 301 WP (GB)
» SBB 302 WP (GB)
» SBB 401 WP SOL (GB)
» SBB 501 WP SOL (GB)

2| SBB 301-302 WP (GB) | SBB 401-501 WP SOL (GB) www.stiebel-eltron.com
CONTENTS | OPERATION
General information
OPERATION
1. General information
The chapter “Operation” is intended for appliance users and heat-
ing contractors.
The chapter “Installation” is intended for heating contractors.
Note
Read these instructions carefully before using the appli-
ance and retain them for future reference.
Pass on the instructions to a new user if required.
1.1 Further applicable documents
Heat source operating and installation instructions
Solar controller operating and installation instructions
1.2 Safety instructions
1.2.1 Structure of safety instructions
!
KEYWORD Type of risk
Here, possible consequences are listed that may result
from failure to observe the safety instructions.
f Steps to prevent the risk are listed.
1.2.2 Symbols, type of risk
Symbol Type of risk
Injury
Electrocution
Burns
(burns, scalding)
1.2.3 Keywords
KEYWORD Meaning
DANGER Failure to observe this information will result in serious
injury or death.
WARNING Failure to observe this information may result in serious
injury or death.
CAUTION Failure to observe this information may result in non-seri-
ous or minor injury.
!
OPERATION
1. General information �����������������������������������������2
1.1 Further applicable documents �������������������������������� 2
1.2 Safety instructions����������������������������������������������� 2
1.3 Other symbols in this documentation ����������������������� 3
1.4 Units of measurement ������������������������������������������ 3
2. Safety����������������������������������������������������������3
2.1 Intended use������������������������������������������������������ 3
2.2 Safety instructions����������������������������������������������� 3
2.3 Test symbols ������������������������������������������������������ 3
3. Appliance description ���������������������������������������3
4. Cleaning, care and maintenance ���������������������������4
4.1 Signal anode consumption indicator ������������������������ 4
4.2 Scaling ������������������������������������������������������������� 4
5. Troubleshooting ����������������������������������������������4
INSTALLATION
6. Safety����������������������������������������������������������4
6.1 General safety instructions ������������������������������������ 4
6.2 Regulations, standards and instructions�������������������� 4
6.3 Water installation������������������������������������������������ 4
7. Appliance description ���������������������������������������5
7.1 Standard delivery������������������������������������������������ 5
7.2 Accessories�������������������������������������������������������� 5
8. Preparations ��������������������������������������������������5
8.1 Installation site��������������������������������������������������� 5
8.2 Transport ���������������������������������������������������������� 6
9. Preparing for installation �����������������������������������6
9.1 Removing / fitting the cylinder casing ���������������������� 6
9.2 Checking the signal anode ������������������������������������� 6
9.3 Heating installation ��������������������������������������������� 6
9.4 Fitting the water connection and the safety assembly��� 7
9.5 Fitting the thermometer and DHW sensor������������������ 7
9.6 Connecting the high limit safety cut-out �������������������� 8
10. Commissioning �����������������������������������������������8
10.1 Appliance handover ��������������������������������������������� 9
11. Shutting down������������������������������������������������9
12. Troubleshooting ����������������������������������������������9
13. Maintenance ��������������������������������������������������9
13.1 Checking the safety valve �������������������������������������� 9
13.2 Draining the appliance ����������������������������������������� 9
13.3 Replacing the signal anode������������������������������������ 9
13.4 Cleaning and descaling the appliance����������������������� 9
13.5 Resetting the high limit safety cut-out ���������������������� 9
14. Specification ������������������������������������������������ 10
14.1 Dimensions and connections ��������������������������������� 10
14.2 Heat sources ����������������������������������������������������� 14
14.3 Hydraulic diagram���������������������������������������������� 15
14.4 Wiring diagram ������������������������������������������������� 15
14.5 Details on energy consumption������������������������������ 16
14.6 Data table �������������������������������������������������������� 16
GUARANTEE
ENVIRONMENT AND RECYCLING

OPERATION
Safety
www.stiebel-eltron.com SBB 301-302 WP (GB) | SBB 401-501 WP SOL (GB) | 3
1.3 Other symbols in this documentation
Note
General information is identified by the symbol shown
on the left.
f Read these texts carefully.
Symbol Meaning
Material losses
(appliance, consequential, environment)
Appliance disposal
f This symbol indicates that you have to do something. The ac-
tion you need to take is described step by step.
1.4 Units of measurement
Note
All measurements are given in mm unless stated oth-
erwise.
2. Safety
2.1 Intended use
The appliance is specifically designed for heating DHW with heat
pumps.
This appliance is designed for domestic use. It can be used safely
by untrained persons. The appliance can also be used in a non-do-
mestic environment, e.g. in a small business, as long as it is used
in the same way.
SBB WP (GB) | SBB WP SOL (GB) must only be connected to speci-
fied heat pumps and solar pump assemblies. (see chapter “Spec-
ification / Heat sources”.
Any other use beyond that described shall be deemed inappro-
priate. Observation of these instructions is also part of the correct
use of this appliance. Any modifications or conversions to the
appliance void all warranty rights.
2.2 Safety instructions
WARNING Burns
There is a risk of scalding at outlet temperatures in ex-
cess of 43 °C.
!
WARNING Injury
The appliance may be used by children aged 8 and up
and persons with reduced physical, sensory or mental
capabilities or a lack of experience provided that they
are supervised or they have been instructed on how to
use the appliance safely and have understood the result-
ing risks. Children must never play with the appliance.
Children must never clean the appliance or perform user
maintenance unless they are supervised.
Note
The appliance is under pressure.
During the heating process, expansion water will drip
from the expansion valve or the T&P valve into the
tundish. If water continues to drip when heating is com-
pleted, please inform your heating contractor.
2.3 Test symbols
See type plate on the appliance.
3. Appliance description
The heat from the heat pump‘s heating water is transferred to the
DHW by smooth-tube indirect coil.
The internal steel cylinder is coated in “anticor®” enamel and
is equipped with a thermometer and a signal anode. The anode
with consumption indicator protects the internal cylinder from
corrosion.
SBB 401 WP SOL (GB) | SBB 501 WP SOL (GB)
These appliances are also equipped with a second indirect coil for
DHW heating with solar energy.
!

INSTALLATION
Cleaning, care and maintenance
4| SBB 301-302 WP (GB) | SBB 401-501 WP SOL (GB) www.stiebel-eltron.com
4. Cleaning, care and maintenance
f Have the function of the safety assembly and electrical safe-
ty of the fitted accessories regularly checked by a qualified
contractor.
f Never use abrasive or corrosive cleaning agents. A damp
cloth is sufficient for cleaning the appliance.
4.1 Signal anode consumption indicator
!
Material losses
If the consumption indicator changes colour from white
to red, have the signal anode checked by a heating con-
tractor and if necessary replaced.
26�03�20�0001
23 1
1 Signal anode consumption indicator
2 white = anode OK
3 Red = check by heating contractor required
4.2 Scaling
f Almost every type of water deposits limescale at high tem-
peratures. This settles inside the appliance and affects both
the performance and service life. If a flanged immersion
heater is installed, the heating elements must be descaled
from time to time. A heating contractor who knows the local
water quality will tell you when the next service is due.
f Check the taps/valves regularly. You can remove limescale
deposits at the tap outlets using commercially available des-
caling agents.
5. Troubleshooting
Telephone your contractor.
To facilitate and speed up your enquiry, please provide the serial
number from the type plate (000000-0000-000000):
No.: 000000-0000-000000
Made in Germany
D0000080572
INSTALLATION
6. Safety
Only a qualified contractor should carry out installation, commis-
sioning, maintenance and repair of the appliance.
6.1 General safety instructions
We guarantee trouble-free operation and operational reliability
only if the original accessories and spare parts intended for the
appliance are used.
6.2 Regulations, standards and instructions
Note
Observe all applicable national and regional regulations
and instructions.
6.3 Water installation
6.3.1 Cold water line
Steel or copper pipes or plastic pipework are approved materials.
A safety valve is required.
6.3.2 DHW line
Copper, stainless steel or plastic pipework are approved materials.
!
Material losses
If a flanged immersion heater is fitted and plastic pipe-
work systems are used at the same time, observe the
maximum permissible temperature/ the maximum per-
missible pressure in chapter “Specification/ Data table”.
Operate the appliance only with pressure-tested taps and valves.

INSTALLATION
Appliance description
www.stiebel-eltron.com SBB 301-302 WP (GB) | SBB 401-501 WP SOL (GB) | 5
7. Appliance description
7.1 Standard delivery
Delivered with the appliance:
- Cold water inlet pipe with flat gasket
- Adhesive rosettes for connecting lines
- Adjustable feet
- Fixing straps with closure element
- Thermometer (in its delivered condition located in the DHW
outlet)
- Safety assembly (with pressure reducing valve, non return
valve and safety relief valve)
- Expansion vessel 24 litre
- Bracket
- Tundish
SBB 401 WP SOL (GB) | SBB 501 WP SOL (GB):
- Connecting cable for high limit safety cut-out
7.2 Accessories
If it is not possible to fit an anode rod from above, install a seg-
mented signal anode.
Flanged immersion heaters and electric booster heaters are avail-
able as accessories.
Only the following accessories should be used:
- Flanged immersion heater: FCR 21/60 (part number 071330)
- Electric booster heater: BGC/45 (part number 075115)
- Corrugated connection pipe with union nut and threaded end
for optional linking of the lower and upper indirect coils:
WRV 32 (part number 232628)
SBB WP (GB) | SBB WP SOL (GB) must only be connected to speci-
fied heat pumps and solar pump assemblies. (see chapter “Spec-
ification/ Heat sources”.
8. Preparations
8.1 Installation site
Always install the appliance in a room free from the risk of frost
and near the draw-off point.
Ensure the floor offers sufficient stability (see chapter “Specifica-
tion/ Data table” for weight).
26�03�20�0008
f Use the adjustable feet to compensate for any unevenness in
the floor.
Minimum clearances
≥500 ≥300
≥300≥800
≥100
D0000061251
f Maintain the minimum clearances.

INSTALLATION
Preparing for installation
6| SBB 301-302 WP (GB) | SBB 401-501 WP SOL (GB) www.stiebel-eltron.com
8.2 Transport
!
Material losses
We recommend removing the cylinder casing for trans-
portation to the installation location to prevent it from
becoming dirty or damaged.
SBB 501 WP SOL (GB)
f Both side insulation sections can be removed for transporta-
tion in tight spaces. To do this, remove the cylinder casing.
26�03�20�0003
f Use the fixing straps to refit the thermal insulation sections
after transportation.
D0000095239
1
1
1 Side thermal insulation section
f Ensure that the closures are in the joint between a side
thermal insulation section and the thermal insulation of the
cylinder.
9. Preparing for installation
9.1 Removing / fitting the cylinder casing
Note
Open or remove the cylinder casing before fitting the
high limit safety cut-out and DHW circulation/indirect
coil lines.
Fit the cylinder casing before fitting a flanged immersion
heater.
The plinth trim should be fitted after the tightness check.
9.2 Checking the signal anode
!
Material losses
The appliance must not be operated without a consump-
tion indicator or with a damaged one, otherwise water
will leak out once the anode is depleted.
9.3 Heating installation
The connected heat source must not exceed a maximum flow
temperature of 60 °C or must, alternatively, be equipped with a
high limit safety cut-out. You may also install a motorised valve
that interrupts the cylinder heating by the heat source.
f Flush the indirect coils with water before connecting the
heating water pipes.
9.3.1 Water quality, solar circuit
A glycol/water mixture of up to 60% is permitted for the indirect
coil in the solar circuit if only dezincification-resistant metals,
glycol-resistant gaskets and diaphragm expansion vessels suitable
for glycol are used throughout the installation.
9.3.2 Oxygen diffusion
!
Material losses
Avoid open heating systems and plastic pipes in under-
floor heating systems which are permeable to oxygen.
In underfloor heating systems with plastic pipes that are per-
meable to oxygen and in open vented heating systems, oxygen
diffusion may lead to corrosion on the steel components of the
heating system (e.g. on the indirect coil of the DHW cylinder, on
buffer cylinders, steel heating elements or steel pipes).
!
Material losses
The products of corrosion (e.g. rusty sludge) can settle in
the heating system components and can result in a lower
output or fault shutdowns due to reduced cross-sections.
9.3.3 Solar installation
The circuit must include an air-vent, a check valve and an expan-
sion vessel. The check valve is not required if you are utilising a
Solar compact installation.
f Flush the solar indirect coil with water before connecting the
solar circuit.

INSTALLATION
Preparing for installation
www.stiebel-eltron.com SBB 301-302 WP (GB) | SBB 401-501 WP SOL (GB) | 7
9.3.4 SBB401WPSOL (GB) | SBB 501 WP SOL (GB)
without solar installation
f Connect both indirect coils to the “heat pump heating return”
and “solar flow” connections (see chapter “Specification /
Dimensions and connections”).
9.4 Fitting the water connection and the safety
assembly
Note
Carry out all water connection and installation work in
accordance with regulations.
f Flush the line thoroughly.
The max. permissible pressure must not be exceeded (see chapter
“Specification/ Data table”).
f Install a type-tested safety valve in the cold water supply
line. Please note that, depending on the static pressure, you
may also need a pressure reducing valve.
26�02�09�0035
1 2
1 Cold water connection
2 Cold water inlet pipe
f Connect the cold water supply directly to the cylinder or with
the connecting pipe routed between the cylinder feet.
f During fitting, counterhold the fitting with an open-ended
spanner (size 36).
f Check the rigidity of the connecting pipe and secure it further
if required.
See chapter “Specification/ Hydraulic diagram” for general ar-
rangement in schematic form. You can fit the safety assembly in
various positions to suit the space available but it must be placed
in the same order as shown. The safety assembly provided in the
pack is fitted to the cold water supply with the exception of the T&P
valve which is fitted at the top of the DHW cylinder. DHW cylinder
relief valve connections should not be used for other purpose.
No valve should be fitted between the expansion valve and the
DHW cylinder.
f To obtain a balanced water pressure in the cold water and
DHW lines, position the cold water outlet directly on the out-
let side of the pressure reducing valve.
f The expansion valve should not respond under normal oper-
ating conditions as the expansion vessel will accommodate
the water as it expands during the heating process.
f If a secondary return circuit is used then an additional ex-
pansion vessel may be required.
f Run the expansion valve outlet and that of the T&P valve to a
drain via a tundish. The purpose of the tundish is to let water
be seen should these valves respond. The outlet pipe should
not exceed 9 metres in length without forming an air break,
i.e. tundish. The pipe must fall continuously throughout its
length with no additional 90° bends. It must be heat resist-
ant and discharge to a safe visible position away from any
electrical devices. The pipe diameter must not be smaller
than the valve outlet. The two discharge pipes can be joined
together at the point of discharge into a single tundish if
required.
f Size the drain so that water can drain off unimpeded when
the safety valve is fully opened. The blow-off aperture of the
safety valve must remain open towards the atmosphere.
f Fit the blow-off line of the safety assembly with a constant
slope.
f Observe the information in the installation instructions of the
safety assembly.
f Install the expansion vessel.
f Adjust the pre-charge pressure. The pre-charge pressure
should be set to approximately 0.02 MPa below the pressure
reducing valve setting.
9.5 Fitting the thermometer and DHW sensor
26�03�20�0005
1
1 Thermometer
f Insert the thermometer as far as it will go and align it.
f Insert the DHW sensor into the upper “Sensor heat pump
DHW” sensor well (recommended position for energy sav-
ing). For higher levels of DHW convenience, you can alter-
natively insert the DHW sensor into the lower “Sensor heat
pump DHW optional” sensor well (higher energy demand).

INSTALLATION
Commissioning
8| SBB 301-302 WP (GB) | SBB 401-501 WP SOL (GB) www.stiebel-eltron.com
9.6 Connecting the high limit safety cut-out
WARNING Electrocution
Carry out all electrical connection and installation work
in accordance with relevant regulations.
Before any work on the appliance, disconnect all poles
from the power supply.
Note
Observe the operating and installation instructions of the
solar control unit
SBB 401 WP SOL (GB) | SBB 501 WP SOL (GB)
D0000072283
f Connect the high limit safety cut-out securely to the solar
controller (connecting cable included with standard delivery).
Observe the solar circuit pump connection.
f Connect the high limit safety cut-out between the solar
controller and the solar circuit pump (see chapter “Specifica-
tion/ Wiring diagram”).
D0000072284
f Route the high limit safety cut-out connecting cable as
shown.
D0000072285
f Refit the cylinder casing (see chapter “Removing / fitting the
cylinder casing”).
f Fit the cap of the high limit safety cut-out with the gap for
the connecting cable at the bottom.
10. Commissioning
Note
Some fluxes used to solder pipes and fittings need to
be flushed out with hot water. Where this is the case
the cylinder should be heated to its normal operating
temperature and all pipe work flushed with hot water to
ensure all flux and debris is removed from the system.
DHW system
f Open all taps.
f Open the shut-off valve in the cold water feed line. Allow
the system to fill and flush out all flux and debris from the
installation.
f Close all taps.
f Open a downstream draw-off point until the appliance has
filled up and the pipes are free of air.
f Check the function of the fitted accessories.
f Check the function of the safety assembly.
f Check that the DHW temperature on the heat pump control
unit is displayed correctly.
Heating system
For protection of drinking water, filling the heating system should
be undertaken via drain and fill valve in compliance with the UK
Water Supply (Water Fittings) Regulations 1999, Section8 G24.
f Observe the operating and installation instructions of the
heat pump.
f Vent the indirect coils after filling the heat pump system.
Solar system
f Observe the operating and installation instructions of the
solar pump assembly.
f Vent the indirect coils after filling the solar system.

INSTALLATION
Shutting down
www.stiebel-eltron.com SBB 301-302 WP (GB) | SBB 401-501 WP SOL (GB) | 9
10.1 Appliance handover
f Explain the appliance function to users and familiarise them
with its operation.
f Make users aware of potential dangers, especially the risk of
scalding.
f Hand over these instructions.
11. Shutting down
f Disconnect the appliance from the mains at the MCB/fuse in
the fuse box.
f Drain the appliance. See chapter “Maintenance / Draining the
appliance”.
12. Troubleshooting
Fault Cause Remedy
The expansion valve or
the T&P valve drips.
The valve seat is contam-
inated.
Clean the valve seat.
13. Maintenance
WARNING Electrocution
Carry out all electrical connection and installation work
in accordance with relevant regulations.
If you need to drain the appliance, observe chapter “Draining the
appliance”.
13.1 Checking the safety valve
f Regularly vent the expansion valve on the safety assembly
until a full water jet is discharged.
f Close the expansion valve when the check is complete.
f Check the T&P valve for tightness.
13.2 Draining the appliance
WARNING Burns
Hot water may escape during the draining process.
If the cylinder needs to be drained for maintenance or to protect
the whole installation when there is a risk of frost, proceed as
follows:
f Close the shut-off valve in the cold water line.
f Open the hot water taps on all draw-off points.
f Drain the appliance via the drain valve of the safety
assembly.
13.3 Replacing the signal anode
f Replace the signal anode if it becomes depleted. Ensure
there is a good connection between the anode and the cylin-
der (maximum permissible transition resistance 0.3Ω).
13.4 Cleaning and descaling the appliance
You can use the flange aperture as an inspection port to view the
cylinder interior.
26�03�01�0847
1
1
1 Threaded extraction holes
f Use the threaded lift-off holes to release the flange plate
from the flange connector.
For the torque of the flange screws, see chapter “Specification/
Dimensions and connections”.
Never use descaling pumps.
Never treat the cylinder surface or the signal anode with descaling
agents.
13.5 Resetting the high limit safety cut-out
D0000072286
f To reset the high limit safety cut-out, press its reset button.
!
Material losses
If the cylinder temperature exceeds 85°C, the high limit
safety cut-out responds and the solar circuit pump is shut
down. This results in a temperature rise in the solar col-
lector. If the collector limit temperature set at the solar
controller is exceeded, a collector emergency stop occurs
(see solar controller operating and installation instruc-
tions).
To ensure safe operation, our solar controllers are preset
at the factory with the following values:
- Set cylinder temperature = 45°C
- Maximum cylinder temperature = 60°C
f If you adjust the settings manually, never set the
maximum cylinder temperature to above 85°C.

INSTALLATION
Specication
10 | SBB 301-302 WP (GB) | SBB 401-501 WP SOL (GB) www.stiebel-eltron.com
14. Specification
14.1 Dimensions and connections
SBB 301 WP (GB)
i18
c13
c06
c01 c03
i01
i07
h43
h05
h06
c10
d08
d07
700
550
1695
1244
1095
368
80
50
494
45°
283
718
783
1008
1138
1710
1770
D0000017383
c06
c13
d08
c03
d07
c10
h05
h06
c01
i01
i07
h43
D0000034160
SBB 301 WP GB
c01 Cold water inlet Male thread G 1 A
c03 Cold water inlet pipe Male thread G 1 A
Torque nm 100
c06 DHW outlet Male thread G 1 A
c10 DHW circulation Male thread G 1/2 A
c13 T&P valve Diameter mm 22
d07 Heat pump heating flow Female thread G 1 1/2
d08 Heat pump heating return Female thread G 1 1/2
h05 Sensor heat pump DHW Diameter mm 9,5
h06 Sensor heat pump DHW optional Diameter mm 9,5
h43 Thermometer Diameter mm 9,5
i01 Flange Diameter mm 210
Pitch circle diameter mm 180
Screws M 12
Torque nm 55
i07 elec. emergency/booster heater Female thread G 1 1/2
i18 Protective anode Female thread G 1 1/4

INSTALLATION
Specication
www.stiebel-eltron.com SBB 301-302 WP (GB) | SBB 401-501 WP SOL (GB) | 11
SBB 302 WP (GB)
i18
c13
c06
d08
c01 c03
d07
i01
i07
h43
h05
h06
700
550
1695
1244
1095
368
80
50
494
45°
283
718
783
1138
1408
1710
1770
c10
D0000017385
c03
c10
h05
h06
c01
i01
i07
h43
c06
c13
d08
d07
D0000034163
SBB 302 WP GB
c01 Cold water inlet Male thread G 1 A
c03 Cold water inlet pipe Male thread G 1 A
Torque nm 100
c06 DHW outlet Male thread G 1 A
c10 DHW circulation Male thread G 1/2 A
c13 T&P valve Diameter mm 22
d07 Heat pump heating flow Female thread G 1 1/2
d08 Heat pump heating return Female thread G 1 1/2
h05 Sensor heat pump DHW Diameter mm 9,5
h06 Sensor heat pump DHW optional Diameter mm 9,5
h43 Thermometer Diameter mm 9,5
i01 Flange Diameter mm 210
Pitch circle diameter mm 180
Screws M 12
Torque nm 55
i07 elec. emergency/booster heater Female thread G 1 1/2
i18 Protective anode Female thread G 1 1/4

INSTALLATION
Specication
12 | SBB 301-302 WP (GB) | SBB 401-501 WP SOL (GB) www.stiebel-eltron.com
SBB 401 WP SOL (GB)
i18
750
600
c06
d08
d26
c03
d07
c10
d25
c01
i01
i07
h43
h05
h06
h28
1940
1880
1508
1348
993
913
708
658
413
288
50
80
373
1248
1448
1860
540
45°
15°
c13
D0000034165
d08
d26
c03
d07
c10
d25
h05
h06
h28
c01
i01
i07
h43
c06
c13
D0000034164
SBB 401 WP
SOL GB
c01 Cold water inlet Male thread G 1 A
c03 Cold water inlet pipe Male thread G 1 A
Torque nm 100
c06 DHW outlet Male thread G 1 A
c10 DHW circulation Male thread G 1/2 A
c13 T&P valve Diameter mm 22
d07 Heat pump heating flow Female thread G 1 1/2
d08 Heat pump heating return Female thread G 1 1/2
d25 Solar flow Female thread G 1 1/2
d26 Solar return Female thread G 1 1/2
h05 Sensor heat pump DHW Diameter mm 9,5
h06 Sensor heat pump DHW
optional
Diameter mm 9,5
h28 Sensor solar cylinder Diameter mm 9,5
h43 Thermometer Diameter mm 9,5
i01 Flange Diameter mm 210
Pitch circle diameter mm 180
Screws M 12
Torque nm 55
i07 elec. emergency/booster
heater
Female thread G 1 1/2
i18 Protective anode Female thread G 1 1/4

INSTALLATION
Specication
www.stiebel-eltron.com SBB 301-302 WP (GB) | SBB 401-501 WP SOL (GB) | 13
SBB 501 WP SOL (GB)
i18
810
650
1570
1372
1960
389
80
50
307
432
677
727
927
1012
1472
1632
1984
2044
690
560
45°
15°
c06
d26
c03
d25
c01
i01
i07
h43
h05
h06
h28
c10
d08
d07
c13
D0000034166
d08
d26
c03
d07
c10
d25
h05
h06
h28
c01
i01
i07
h43
c06
c13
D0000034164
SBB 501 WP
SOL GB
a23 Appliance Width excl. side insu-
lation sections
mm 690
c01 Cold water inlet Male thread G 1 A
c03 Cold water inlet pipe Male thread G 1 A
Torque nm 100
c06 DHW outlet Male thread G 1 A
c10 DHW circulation Male thread G 1/2 A
c13 T&P valve Diameter mm 22
d07 Heat pump heating flow Female thread G 1 1/2
d08 Heat pump heating return Female thread G 1 1/2
d25 Solar flow Female thread G 1 1/2
d26 Solar return Female thread G 1 1/2
h05 Sensor heat pump DHW Diameter mm 9,5
h06 Sensor heat pump DHW
optional
Diameter mm 9,5
h28 Sensor solar cylinder Diameter mm 9,5
h43 Thermometer Diameter mm 9,5
i01 Flange Diameter mm 210
Pitch circle diameter mm 180
Screws M 12
Torque nm 55
i07 elec. emergency/booster
heater
Female thread G 1 1/2
i18 Protective anode Female thread G 1 1/4

INSTALLATION
Specication
14 | SBB 301-302 WP (GB) | SBB 401-501 WP SOL (GB) www.stiebel-eltron.com
14.2 Heat sources
The DHW cylinders SBB WP (GB) | SBB WP SOL (GB) are approved according to the Building Regulations.
SBB WP (GB) | SBB WP SOL (GB) must only be connected to the following heat pumps and solar pump assemblies.
SBB 301 WP (GB)
Set
SBB 302 WP (GB)
Set
SBB 401 WP SOL (GB)
Set
SBB 501 WP SOL (GB)
Set
228944 228945 228946 228947
Heat pump
WPL 07 ACS classic • • • •
WPL 09 ACS classic • • • •
WPL 13 ACS classic • • • •
WPL 17 ACS classic • • • •
WPL 15 AS; WPL 15 ACS • • • •
WPL 25 AS; WPL 25 ACS • • • •
WPL 13 E/cool • • • •
WPL 18 E/cool - • • •
WPL 23 E/cool - - • •
WPL-A 05 HK 230 Premium • • • •
WPL-A 07 HK 230 Premium • • • •
WPE-I 04 H 230 Premium • • • •
WPE-I 06 H 230 Premium • • • •
WPE-I 08 H 230 Premium • • • •
WPE-I 12 H 230 Premium • • • •
WPE-I 15 H 230 Premium • • • •
WPF 05 S • • • •
WPF 07 S • • • •
WPF 10 S/M • • • •
WPF 13 S/M - • • •

INSTALLATION
Specication
www.stiebel-eltron.com SBB 301-302 WP (GB) | SBB 401-501 WP SOL (GB) | 15
14.3 Hydraulic diagram
< 600
> 300
1
2
345
6
18
8
9
10
11
12
13
14
15
16
17
11
7
D0000040507
1 Discharge below fixed grate
2 Cold water supply
3 Shut-off valve
4 Line strainer
5 Pressure reducing valve
6 Balanced pressure; cold water outlet
7 Check valve
8 Safety assembly
9 Tundish
10 Metal discharge pipe (D2) from tundish, with continuous fall
11 Equipotential bond
12 Drain valve
13 Cylinder
14 DHW outlet
15 T&P valve
16 Metal discharge pipe (D1) from T&P valve to tundish
17 Expansion vessel
18 Expansion valve
Minimum size of discharge pipe D1 mm 22
Minimum size of discharge pipe D2 from tundish mm 28 35 42
Maximum permissible pressure drop, expressed as
a length of straight pipe (i.e. no elbows or bends)
m 9 18 27
Pressure drop of each elbow or bend m 1.0 1.4 1.7
Connection dimensions
Safety assembly connection mm 22
Expansion valve end connection mm 15
Expansion vessel connection, male, BSP G ¾ A
Tundish inlet connection mm 22
Tundish outlet connection mm 28
14.4 Wiring diagram
SBB 401 WP SOL (GB) | SBB 501 WP SOL (GB)
L L‘ N
ϑ
11
12
M
1~
N L
AA20 AA21
XD40
XD01
MA40
BT70
D0000072140
AA20 SOM... solar controller
AA21 SOKI... solar compact installation
BT70 High limit safety cut-out
MA40 Solar circuit pump
XD01 Terminal
XD40 Solar circuit pump relay terminal

INSTALLATION
Specication
16 | SBB 301-302 WP (GB) | SBB 401-501 WP SOL (GB) www.stiebel-eltron.com
14.5 Details on energy consumption
Product datasheet: Hot water storage tanks to regulation (EU) no. 812/2013 / (S.I. 2019 No. 539 / Schedule 2)
SBB 301 WP (GB) Set SBB 302 WP (GB) Set SBB 401 WP SOL (GB) Set SBB 501 WP SOL (GB) Set
228944 228945 228946 228947
Manufacturer STIEBEL ELTRON STIEBEL ELTRON STIEBEL ELTRON STIEBEL ELTRON
Model identification of the supplier SBB 301 WP (GB) Set SBB 302 WP (GB) Set SBB 401 WP SOL (GB) Set SBB 501 WP SOL (GB) Set
Energy efficiency class C C C
standing loss S W 88 88 100 100
storage volume V l 321 319 424 533
14.6 Data table
Note
Observe the data table of the connected heat source.
SBB 301 WP (GB)
Set
SBB 302 WP (GB)
Set
SBB 401 WP SOL
(GB) Set
SBB 501 WP SOL
(GB) Set
228944 228945 228946 228947
Hydraulic data
Nominal capacity l301 290 391 493
Capacity, upper indirect coil l20.00 28.40 25.10 31.30
Capacity, lower indirect coil l 8.80 8.80
Surface area, upper indirect coil m² 3.20 4.80 4.00 5.00
Surface area, lower indirect coil m² 1.40 1.40
Pressure drop at 1.0 m³/h, upper indirect coil hPa 37 56 47 58
Pressure drop at 1.0 m³/h, lower indirect coil hPa 17 17
Heating water input power at flow rate, upper indirect coil kW - l/min 29.3 - 15.0 38.3 - 15.5 34.2 - 15.5 37.5 - 15.0
Heating water input power at flow rate, lower indirect coil kW - l/min 17.4 - 16.3 21.9 - 15.0
Reheating time, upper indirect coil min 32 17.5 22.4 29.0
Reheating time, lower indirect coil min 70.8 78.0
Amount of mixed water at 40 °C (15 °C/60 °C) l 529 514 681 857
DHW volume, upper indirect coil l261 232 257 329
DHW volume, lower indirect coil l 390 484
Max. operating temperature heating water °C 89 89 89 89
Application limits
Max. permissible pressure (Design Pressure) DHW cylinder MPa 0.70 0.70 0.70 0.70
Test pressure MPa 1.50 1.50 1.50 1.50
Max. permissible pressure (Design Pressure), upper indirect coil MPa 1.00 1.00 1.00 1.00
Max. permissible pressure (Design Pressure), lower indirect coil MPa 1.00 1.00
Max. permissible temperature °C 89 89 89 89
Max. flow rate l/min 38 38 45 50
High limit safety cut-out °C 85 85
Max. recommended collector aperture area m² 10 10
Electrical details
Max. breaking capacity 16A/250V~ 16A/250V~
Energy data
Standby energy consumption/24 h at 65 °C kWh 2.10 2.10 2.40 2.40
Energy efficiency class C C C
Output data
Tested to standard EN 12897:2016 EN 12897:2016 EN 12897:2016 EN 12897:2016
Values
Max. operating pressure DHW MPa 0.35 0.35 0.35 0.35
Max. operating pressure, upper indirect coil MPa 0.20 0.20 0.20 0.20
Max. operating pressure, lower indirect coil MPa 0.25 0.25
T&P valve, nominal set temperature °C 90 90 90 90
Safety assembly, max. supply pressure MPa 1.60 1.60 1.60 1.60
Pressure reducing valve, nominal pressure PN 16 PN 16 PN 16 PN 16
Pressure reducing valve, set value range MPa 0.30 0.30 0.30 0.30
Expansion valve, nominal set pressure MPa 0.60 0.60 0.60 0.60
Expansion vessel volume l25 25 25 25
T&P valve, nominal set pressure MPa 0.70 0.70 0.70 0.70

INSTALLATION
Specication
www.stiebel-eltron.com SBB 301-302 WP (GB) | SBB 401-501 WP SOL (GB) | 17
SBB 301 WP (GB)
Set
SBB 302 WP (GB)
Set
SBB 401 WP SOL
(GB) Set
SBB 501 WP SOL
(GB) Set
Dimensions
Height mm 1770 1770 1940 2044
Diameter mm 700 700 750 810
Height of unit when tilted mm 1750 1750 1930 2030
Weights
Weight, empty kg 156 184 219 260
Weight, full kg 457 477 610 753

18 | SBB 301-302 WP (GB) | SBB 401-501 WP SOL (GB) www.stiebel-eltron.com
GUARANTEE | ENVIRONMENT AND RECYCLING
Guarantee
The guarantee conditions of our German companies do not
apply to appliances acquired outside of Germany. In countries
where our subsidiaries sell our products a guarantee can only
be issued by those subsidiaries. Such guarantee is only grant-
ed if the subsidiary has issued its own terms of guarantee. No
other guarantee will be granted.
We shall not provide any guarantee for appliances acquired in
countries where we have no subsidiary to sell our products.
This will not aect warranties issued by any importers.
Environment and recycling
We would ask you to help protect the environment. After use,
dispose of the various materials in accordance with national
regulations.
GUARANTEEGUARANTEE
ENVIRONMENT AND RECYCLINGENVIRONMENT AND RECYCLING

www.stiebel-eltron.com SBB 301-302 WP (GB) | SBB 401-501 WP SOL (GB) | 19
NOTES

Deutschland
STIEBEL ELTRON GmbH & Co. KG
Dr.-Stiebel-Straße 33 | 37603 Holzminden
Tel. [phone] | Fax [phone]
[e-mail]
www.stiebel-eltron.de
Verkauf Tel. [phone] | Fax [phone] | [e-mail]
Kundendienst Tel. [phone] | Fax [phone] | [e-mail]
Ersatzteilverkauf www.stiebel-eltron.de/ersatzteile | [e-mail]
Irrtum und technische Änderungen vorbehalten! | Subject to errors and technical changes! | Sous réserve
d‘erreurs et de modifications techniques! | Onder voorbehoud van vergissingen en technische wijzigingen!|
Salvo error o modificación técnica! | Excepto erro ou alteração técnica | Zastrzeżone zmiany techniczne i
ewentualne błędy | Omyly a technické změny jsou vyhrazeny! | A muszaki változtatások és tévedések jogát
fenntartjuk! | Отсутствие ошибок не гарантируется. Возможны технические изменения. | Chyby a
technické zmeny sú vyhradené! Stand 9734
Australia
STIEBEL ELTRON Australia Pty. Ltd.
294 Salmon Street | Port Melbourne VIC 3207
Tel. [phone] | Fax [phone]
[e-mail]
www.stiebel-eltron.com.au
Austria
STIEBEL ELTRON Ges.m.b.H.
Gewerbegebiet Neubau-Nord
Margaritenstraße 4 A | 4063 Hörsching
Tel. [phone] | Fax [phone]
[e-mail]
www.stiebel-eltron.at
Belgium
STIEBEL ELTRON bvba/sprl
't Hofveld 6 - D1 | 1702 Groot-Bijgaarden
Tel. [phone] | Fax [phone]
[e-mail]
www.stiebel-eltron.be
China
STIEBEL ELTRON (Tianjin) Electric Appliance
Co., Ltd.
Plant C3, XEDA International Industry City
Xiqing Economic Development Area
300385 Tianjin
Tel. [phone] | Fax [phone]
[e-mail]
www.stiebeleltron.cn
Czech Republic
STIEBEL ELTRON spol. s r.o.
Dopraváků 749/3 | 184 00 Praha 8
Tel. [phone] | Fax [phone]
[e-mail]
www.stiebel-eltron.cz
Finland
STIEBEL ELTRON OY
Kapinakuja 1 | 04600 Mäntsälä
Tel. [phone]
[e-mail]
www.stiebel-eltron.fi
France
STIEBEL ELTRON SAS
7-9, rue des Selliers
B.P 85107 | 57073 Metz-Cédex 3
Tel. [phone] | Fax [phone]
[e-mail]
www.stiebel-eltron.fr
Hungary
STIEBEL ELTRON Kft.
Gyár u. 2 | 2040 Budaörs
Tel. [phone] | Fax [phone]
[e-mail]
www.stiebel-eltron.hu
Japan
NIHON STIEBEL Co. Ltd.
Kowa Kawasaki Nishiguchi Building 8F
66-2 Horikawa-Cho
Saiwai-Ku | 212-0013 Kawasaki
Tel. [phone] | Fax [phone]
[e-mail]
www.nihonstiebel.co.jp
Netherlands
STIEBEL ELTRON Nederland B.V.
Daviottenweg 36 | 5222 BH 's-Hertogenbosch
Tel. [phone] | Fax [phone]
[e-mail]
www.stiebel-eltron.nl
New Zealand
Stiebel Eltron NZ Limited
61 Barrys Point Road | Auckland 0622
Tel. [phone]
[e-mail]
www.stiebel-eltron.co.nz
Poland
STIEBEL ELTRON Polska Sp. z O.O.
ul. Działkowa 2 | 02-234 Warszawa
Tel. [phone] | Fax [phone]
[e-mail]
www.stiebel-eltron.pl
Russia
STIEBEL ELTRON LLC RUSSIA
Urzhumskaya street 4,
building 2 | 129343 Moscow
Tel. [phone]
[e-mail]
www.stiebel-eltron.ru
Slovakia
STIEBEL ELTRON Slovakia, s.r.o.
Hlavná 1 | 058 01 Poprad
Tel. [phone] | Fax [phone]
[e-mail]
www.stiebel-eltron.sk
South Africa
STIEBEL ELTRON Southern Africa (PTY) Ltd
30 Archimedes Road
Wendywood
Johannesburg, 2090
Tel. [phone]
[e-mail]
www.stiebel-eltron.co.za
Switzerland
STIEBEL ELTRON AG
Industrie West
Gass 8 | 5242 Lupfig
Tel. [phone] | Fax [phone]
[e-mail]
www.stiebel-eltron.ch
Thailand
STIEBEL ELTRON Asia Ltd.
469 Moo 2 Tambol Klong-Jik
Amphur Bangpa-In | 13160 Ayutthaya
Tel. [phone] | Fax [phone]
[e-mail]
www.stiebeleltronasia.com
United Kingdom and Ireland
STIEBEL ELTRON UK Ltd.
Unit 12 Stadium Court
Stadium Road | CH62 3RP Bromborough
Tel. [phone] | Fax [phone]
[e-mail]
www.stiebel-eltron.co.uk
United States of America
STIEBEL ELTRON, Inc.
17 West Street | 01088 West Hatfield MA
Tel. [phone] | Fax [phone]
[e-mail]
www.stiebel-eltron-usa.com
A 317211-44188-9734
4<AMHCMO=bhcbbg>
