STIEBEL ELTRON DJ 30 E User manual

1
DJ 30 E
English
Instantaneous shower water heater - Operation and installation instructions


This shower water heater must be installed (water and electrical installation), commissioned and
serviced by approved service technicians in accordance with these instructions.
!"!#

2
1. Installation instruction
for the user and the qualitied installer
D
Shower head must not be higher than the unit.
A
B
C
11
12
9
8
10
12
3
4
5
67

3
13
14
15
16
18
17
Type DJ 30 E

4
1.1 Description of the unit
The STIEBEL ELTRON DJ pressureless (open)
small instantaneous is device for heating
water for shower. The electrical power is
electronically controlled. The flow is
switched on and off by usingthe water
valve. The unit switches the power on
once the flow volume is sufficient.
The “Power” light indicates the unit is
switched on. The unit is fitted with an
overheatingprotection device.
The DJ is also equipped with an aerojet
system that blends water with air for that
fizzlingfeelingon your shower.
1.2 The essentials - in brief
AWater valve
BRotary control for temperature
adjustment
C“Power” light
DShower accessories
1.3 Important information
The unit must not be put under
pressure. The outlet of the unit
is also used as a vent. Aperiodical scale
removal is essential for the function of the
shower head.
1. Installation instructions
for the user and the qualitied installer
The unit is optionally equipped
with an ELSD (Type DJ..E only)
It is recommended to test the ELSD one
time per month.
How to test:
Switch on the electrical supply. Press the
Test button, the Trip light will go on. Press
the Reset button.
Warning!
If the Trip light activate after reset
or if the light activate duringshower, never
try to fix it. Contact your dealer for a check
and repair.
Warning!
If, duringa shower , the water
valve is closed, (such as applyingsoap to
the body), then valve opened again, high
water temperature may occur, to avoid risk
of scalding, stay any from the shower head
discharge zone momentarilly.
1.4 Care and Maintenance
All that is needed for the housingis a damp
cloth. Do not use any abrasive cleaning
agents or agents containingsolvents.
Maintenance work may only be
carried out by a qualified installer.
1.5 Hot water capacity
The hot water capacity depends on the
power of the unit, the cold water temperature,
and the flow volume.
Thermostat cut-off is a service
case only for qualified technician
- This appliance is not intended
for use by persons (including
children) with reduced physical, sensory or
mental capabilities, or lack of experience
and knowledge, unless they have been
given supervision or instruction concerning
use of the appliance by a person responsible
for their safety.
- Children should be supervised to
ensure that they do not play with
the appliance.
1.6 Technical data (the data on the unit ratingplate apply)
DJ
Type 30 E
Design Open outlet
Rated pressure 0MPa / 0bar
Cold water connection G 1/2”
Electrical connection 1/N/PE ~ 220.... 240 V
Dimension (W x H x D) (mm.) 200 x 360 x 104
Rated power (kW) - Rated current (A) kW - A
220V 3.0- 13.6
230 V 3.3- 14.3
240 V 3.6- 15.0
Recommended circuit breaker (A) 15
Recommended cable size (Sqmm.) 2.5

5
2. Installation instructions
for the user and the qualitied installer
2.3 Important note
All the information in these operating
and Installation Instructions must
be carefully followed. These instructions
provide important details regardingthe
safety, operation, installation, and maintenance
of the unit.
2.4 Installation location
The shower unit is to be installed
in a closed, frost-free room (disconnected
units are to be stored in a frost-free location,
since there will always be some water left in
the unit)
The DJ is to be installed vertically on
a wall (hot water connection downwards).
2.5 Installing the unit
1. Flush the cold water pipe thoroughly.
2. Fit a secure connection cable (11
ensure dimensions are correct).
3. Release cover securingscrew (12).
4. Remove cover.
5. Determine the position of the drill
holes and drill the holes. Insert the
wall plugs and screw in the screws
(ensure screw insertion depth is
correct, 13).
6. Feed the connection cable through
the cable seal (3) in the rear wall.
Guide the unit over the wall securing
screws.
7. Fit the cold water connection.
Connect the water valve (18) with
the filter (15) and the washer (16)
to the cold water inlet of the unit
(6). Tighten the union nut and
washer (17) to the water valve.
8. Straighten the unit and tighten the
screws.
9. Connect the electrical supply.
10. Fit the cover and secure with the
screw.
11. Turn the rotary control (B) to the
2.1 Technical data
1. Thermostat
2. Position for electrical connection
3. Cable duct for electrical connection
4. Power light
5. Rotary control for temperature
adjustment
6. Cold water connection
7. Hot water connection for shower
hose
8. Lower fixinghole
9. Uper fixinghole
10. ELSD (option)
11. Connection cable
12. Cover securingscrew
13. Depth for mountingscrew
14. Rear wall installation
15. Combination filter/seal
16. Washer
17. Union nut and washer, provide
by client
18. Water valve
2.2 Regulations and Provisions
- Regulations of the local power supply
anthority should be observed.
- Regulations of the water supply
anthority should observed
- Technical data.
- Install the unit flush with the wall.
- Electrical connection to be secure.
The device must be capable of
beingisolated from the mains, for
example by fuses, with an isolatingdistance
of at least 3,5mm, in all poles.
The unit must be earthed (see circuit
diagram). To protect against water
penetration, the cable seal (3) must be used.
left and right (internal settinglever
will engage).
12. Fit the shower accessories to the
unit.
The outlet must not be connected
to any tap or fittingother than those
specified. 2.6First operation (Only to be
carried out by a qualified installer)
Before switchingon, set the rotary
water valve to“Max”settinguntil
the pipework and the unit are free of air.
- Before switching“ON”, set the rotary
temperature control to “OFF”
- Check the operation of the water heater.
Handing over the unit
Explain to the user how the unit works and
familiarise him or her with its use.
- Advise the user about possible hazards
(high water temperature)
- Hand over these instructions, to be kept
in a safe place.
Do not switch on if there is a possibility
that the water in the heater is frozen.
(This warningis not required if the appliance
Incorporates a flow switch.
2.7 Service note
When carryingout any work,
isolate the unit from the mains
and shut off the water connection.
- Clean the filter
Disconnect water valve (18), remove
filter (15) and clean . Re-assemble
in reverse order.

6
3. Guarantee
For guarantees please refer to the respective
terms and conditions of supply for your
country.
The installation, electrical
connection and rst operation
of this appliance should be carried out by a
qualied installer.
The company does not accept liability
for failure of any good supplied which have
not been installed and operated in
accordance with the manufacturer’s
instructions.
4. Fault elimination for the user
Fault
No hot water despite ow volume
settingat
right-hand stop.
“Trip” - light on
The unit is not beingswitched on.
Electricity
supply and ow available.
Cause
The water ow volume required for the
unit to turn on has not been reached.
- The shower head is blocked with dirt or
limescale.
- Flow volume too low.
- ELSD activated
The water ow volume required for the
unit
to turn on has not been reached.
- Filter in the cold water connection pipe
blocked with dirt.
- Water pressure not enough
Rectication
- Clean shower head or remove limescale.
- Increase ow volume.
- Press “Reset” - button.
- Clean the lter after shuttingo the cold
water intake.
- Increase mains pressure
